CONTROLLER 69
PRO

3
WELCOME
Thank you for choosing AC Infinity. We are committed to product quality and friendly customer service.
If you have any questions or suggestions, please don’t hesitate to contact us. Visit www.acinfinity.com
and click contact for our contact information.
EMAIL
[e-mail]
WEB
www.acinfinity.com
LOCATION
Los Angeles, CA

4
MANUAL CODE CTR69P2209X1
PRODUCT
CONTROLLER 69 PRO
MODEL
CTR69P
UPC-A
819137023659
FAN COMPATIBILITY
This controller is natively compatible with AC Infinity devices with UIS™ connectors. Older model inline
fans with EC motors may be used with this controller using a Molex adapter. An EC-motor fan will have
two cords coming out of its motor box for the power and the controller. Note that certain models that
previously used DC-motors now contain EC-motors in updated builds.
Please visit www.acinfinity.com to check for the latest models compatible with this controller.
EC Motor - Compatible AC or DC Motor - NOT Compatible

5
MANUAL INDEX
Compatibility ..................................................................................
Manual Index .................................................................................
Product Warning ............................................................................
Interference from MH and HPS Lights ...........................................
Key Features .................................................................................
Product Contents ...........................................................................
Powering and Setup ......................................................................
Controller Mounting .......................................................................
UISTM Platform ...............................................................................
UISTM Compatibility ........................................................................
Adding More Devices ....................................................................
Programming .................................................................................
Other Settings ...............................................................................
Download the App .........................................................................
Add a Device .................................................................................
FAQ................................................................................................
Other AC Infinity Products .............................................................
Warranty ........................................................................................
Page 4
Page 5
Page 6
Page 7
Page 8
Page 9
Page 10
Page 12
Page 15
Page 16
Page 17
Page 19
Page 43
Page 44
Page 45
Page 52
Page 55
Page 56

6
Ensure your power source conforms to the electrical requirements of this product.
Check your local code restrictions for additional safety measures that may be needed for a proper
code compliant installation.
Read all instructions before installing and using this product.
If you are unfamiliar or have doubts about performing this product’s installation, seek the services of a
qualified, trained, and licensed professional. Inappropriate installation will void this product’s warranty.
Do not attempt to hardwire this product. Performing any retrofitting actions may result in personal
injury and/or electrical damage, and will void this product's warranty.
This product must not be used in potentially hazardous locations such as flammable, explosive,
chemical-laden, or wet atmospheres.
Ducted products must always be vented to outdoor areas.
Do not cover power cords with rugs or other fabric materials.
This product pairs with those that has rotating parts. Safety precautions should be exercised during
the installation, operation, and maintenance of this product.
Do not insert or allow fingers or foreign objects to enter any ventilation or exhaust openings as it may
cause electric shock, fire, or damage to this product. Do not block or tamper with this product in any
manner while it is in operation.
Do not depend on the on/off programming as the sole means of shutting power from this product.
Unplug the power cord before installing, servicing, or moving this product.
Do not operate this product while its cord is damaged, or if it malfunctions, has been dropped, or is
damaged in any manner.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
PRODUCT WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS,
OBSERVE THE FOLLOWING:

7
Certain grow light models with HID* ballasts that do not use electromagnetic shielding will
create an area of radio frequency interference (RFI). This can distort nearby frequency-sensitive
components like internet lines and climate sensors. RFI can be emitted from the ballast’s cords or
the ballast itself.
Follow these steps to ensure proper functionality and to prevent radio frequency interference from
affecting your sensor probe:
TIP 1
Keep the probe cord far away
from your ballast's cords to ensure
the controller properly detects
climate conditions.
You may also wrap the probe
cord and create a cone around
the sensor head with aluminum
foil tape.
TIP 2
Do NOT plug your grow light and
inline fan into the same duplex
outlet. Plug your grow light and
inline fan into separate power
strips and electrical sockets.
*MH, HPS, CMH, or CHPS
INTERFERENCE from MH and HPS LIGHTS

8
41
23
KEY FEATURES
APP-CONTROLLED
Bluetooth/Wi-Fi enabled for
remote access to automations,
climate data, and history logs
through the AC Infinity app.
SMART CONTROLLER
Features automation controls
that activate your devices
based on climate conditions,
VPD, timers, and schedules.
ACTIVE MONITORING
LCD display shows key data
like temperature, humidity,
VPD, device levels, trends,
time, countdowns, and more.
UISTM CONNECTIVITY
Connect up to four devices to
simultaneously set programming
for all devices or independently
for each device.
ADVANCE SETTINGS
Additional setting options
include Fahrenheit/Celsius
toggling, clock, calibrations,
and custom transitions.
VERSATILE PLACEMENT
Mount the controller on a steel
surface using the rear magnet or
open the kickstand to sit it tilted
on your desktop.

9
PRODUCT CONTENTS
WIRE
TIE
(x1)
WOOD SCREWS
(WALL HANG)
(x2)
SMART
CONTROLLER
(x1)
SENSOR
PROBE
(x1)
UIS M - 4PIN F
ADAPTER
(x2)
CONTROLLER
PLATE BOLTS
(x2)
HEX
NUTS
(x3)

10
POWERING AND SETUP
STEP 1
Plug your device’s UIS connector into one of
the controller's ports.
STEP 2
Plug the sensor probe into the controller’s
3.5mm jack. Set the probe near your plants in
your grow tent for the most accurate reading.
Keep the probe cord away from your HID*
grow light ballast's power cord to ensure the
controller properly detects climate conditions.
*MH, HPS, CMH, or CHPS

11
POWERING AND SETUP
STEP 4
You may use the included tie mounts, wood
screws, and wire ties to cable manage the cords.
Secure the tie mounts onto a surface using the
wood screws. Loop the wire ties around the
cords into the tie mounts.
STEP 3
Plug your device’s power cord into an AC
power outlet to power it and the controller.

12
CONTROLLER MOUNTING
STEP 1 — WALL MOUNTING
Locate a spot free of obstruction and secure the
anchors into your wall. Twist the wood screws
into the anchors.
STEP 2 — WALL MOUNTING
Hang the controller by the screws using the
holes on the backside.

13
PLATE MOUNTING*
Screw the bolts into the slot or mounting holes
at the upper half of the plate.
Hang the controller by the bolts using the holes
on the backside.
MAGNET MOUNTING
You may also mount the controller onto a steel
surface using the magnet located behind the label.
CONTROLLER MOUNTING
*Controller plate not included

14
KICKSTANDING
Open the stand behind the controller to set it
tilted on your desktop.
CORD ARRANGEMENT
Cords may be routed into or outside of the
kickstand grooves, and through a cut hole
behind the controller.
CONTROLLER MOUNTING

15
The UISTM platform enables you to connect a single central controller with several grow devices
simultaneously. By creating this fully integrated system, you can power and program all your
devices together or separately for optimized grow tent management.
Your grow system can be regulated using your controller hub or remotely on the AC Infinity app
(paired with compatible controllers), where you will have access to automation programming and
climate data.
You can also connect your favorite grow light and outlet device to integrate them into the UIS
platform using our RJ11/12 adapter and control plug module.
Grow devices will be sold separately and may still be in development
at the time of your purchase of this product.
UISTM PLATFORM

16
UISTM COMPATIBILITY
EXTENSION CABLE*
Use male-to-male UIS extension cords to connect devices with female UIS ports at an extended
range from your controller. Included with UIS-compatible devices.
EXPANSION DONGLE*
The expansion dongle will allow you to connect 2 or 4 devices with a single port and can support
additional dongles to create more expansion ports (up to 64 units supported with the use of 20
dongles). Intended for exclusive use with AC Infinity controllers with UIS ports and sold separately.
UIS M - F
4 PORT DONGLE
UIS M - F
2 PORT DONGLE
MOLEX ADAPTER
Use the included Molex adapter to plug inline fans with 4-pin Molex connectors into this controller.
Plug your fan's Molex connector into the adapter. Then plug the adapter into the controller.
UIS M - 4PIN F
ADAPTER
UIS M - M
CORD
UIS M - M
CLIP FAN CORD
*Not included
1 2
1 2 3 4

17
ADDING MORE DEVICES
The CONTROLLER 69 PRO is built with four ports that enable you to power and control multiple
devices at the same time. See image below for a sample configuration.

18
ADDING MORE DEVICES
USING THE DONGLE
Each controller port can support mix-and-
matched devices regardless of their size.
When using a 2-port or 4-port dongle, plug
your first device into Port 1 for the controller to
recognize as the primary device.
All other devices plugged into the dongle will
follow programming intended for the device
plugged into Port 1.
Dongles are not included and sold separately.
EXTENDING THE CHAIN
When plugging additional dongles into Port
1, all devices plugged into this chain must be
of the same type (ex. grow lights of any size)
regardless of the length of the dongle chain.
1 2 3 4
1 2
1 2
1 2 3 4 1 2

19
PROGRAMMING
1. PORT BUTTON
Cycles through up to four
connected devices. Each device
is programmed independently, or
together when navigating to ALL.
5. PORTS
Displays all connected devices
as well as their current level.
Digits are displayed by the UIS
symbol when a device is plugged
into its corresponding port.
6. PROBE TEMPERATURE
Displays the current temperature
that the probe is detecting. Shows
“--” if no probe is plugged in.
Includes a trend indicator that
signals a rise, stability, or fall in
temperature within the last hour.
4. UP/DOWN BUTTONS
Adjusts the value of your current
mode. The up button increases
and down button decreases the
setting. Hold both to reset values
to OFF/Default.
10. CURRENT TIME
Displays the current time. The
internal battery sustains the clock
so it does not default to 00:00 if
power is cut off.
9. CONTROLLER MODE
Displays the controller's current mode.
Pressing the mode button cycles through
the available modes.
14. ALERT ICONS
Displays alerts and statuses
of the controller, including the
controller lock, CLIMATE alert,
and TIMER alert.
13. USER SETTING
Displays the value of your current
mode. Use the up or down
buttons to adjust the value.
12. COUNTDOWN
Displays the countdown of the TIMER
TO ON, TIMER TO OFF, CYCLE,
or SCHEDULE mode activates or
deactivates the devices. TO ON shows
the amount of time left before the devices
turn on. TO OFF shows the amount of
time left before the device turn off.
7. PROBE HUMIDITY
Displays the current humidity that
the probe is measuring. Shows
"--" if no probe is plugged in.
Includes a trend indicator that
signals a rise, stability, or fall in
humidity within the last hour.
3. SETTING BUTTON
Cycles through the controller’s
settings: DISPLAY, CLOCK,
°F / °C, CALIB. T° / H% / kPa,
TRANS. T° / H% / kPa, BUFF. T° /
H% / kPa, and LEAF OFFSET.
2. MODE BUTTON
Cycles through the controller’s modes:
OFF, ON, AUTO (4 triggers), VPD
(2 triggers), TIMER TO ON, TIMER
TO OFF, CYCLE (ON and OFF), and
SCHEDULE (ON and OFF).
11. CURRENT LEVEL
Displays the connected
devices' current setting. Includes
a trend indicator that signals if the
setting is currently rising, falling,
or holding steady.
8. PROBE VPD
Displays the current VPD that
the probe is detecting (in kPa).
Shows “--” if no probe is plugged
in. Includes a trend indicator that
signals a rise, stability, or fall in
VPD within the last hour.
1
2
3
4
6
8
9
10
11
12
13
14
5
7

20
PROGRAMMING
ALL PORTS
Navigate to the ALL port to set simultaneous
programming for all connected devices.
Programming set in this port mode applies to all
connected devices, but will not be active if you
navigate to other ports. Re-entering the ALL
port will resume its programming.
INDIVIDUAL PORT
Navigate to a numbered port with a connected
device to set individual programming.
Programming will run in the background even
while you navigate to other numbered ports.
PORTS
Pressing the port button will cycle through the controller’s available ports: ALL, 1, 2, 3, and 4. Dot
indicates the current device. No digit is displayed if a device is not plugged into the corresponding port.
