Acer AR585 F1 User manual

1
Acer AR585 F1 specifications
Product overview
The Acer AR585 F1 is a four-socket 2U server for space-conscious users who demand the highest
performance and utmost expansion capa ility. Delivering the latest technology, this server was designed
for cost-effective growth and includes a comprehensive list of management features.
Internal view
1 2 x 1400 W 80 PLUS
®
gold-level efficient easy-swap power supplies (1+1 redundant, hot-
plugga le)
2 4 x AMD Opteron
™
6200 / 6100 series processors
3 32 x DDR3 ECC registered / un uffered DIMMs
4 N+1 redundant cooling fans
5 4 x PCIe expansion slots
6 1 x slimline ODD drive
7 6 x 3.5” hot-swappa le hard drive ays
1
2
3
4
5
6
7

2
Acer AR585 F1 specifications
Front View
Rear View
Front I/O
1 2 x USB 2.0 ports
2 Serial port
3 Network, hard drive, power, and system status indicators
Rear I/O
1 PS2 mouse and key oard ports
2 2 x USB ports
3 Serial port
4 Video port
5 2 x Giga it LAN port (RJ-45)
6 System ID LED
7 Management port (RJ-45)
What's New
• Next-gen AMD Opteron 6200 processor support
NOTE: 6200 support egins in Q4 2011
• Hot-plugga le/redundant power supply with 80 PLUS
®
gold-level efficiency
• Smart Server Manager v1.1 with improved management functionality
Product Specifications
Processors and Chipset
• Up to four AMD Opteron 6200 / 6100 series processors
• Chipset: AMD SR5690 and SR5670/SP5100
1
2
3
1
2
5
3
4
6
7

3
Acer AR585 F1 specifications
emory
• Memory capacity:
 Registered DIMM: 2, 4, 8, 16 GB
 Un uffered DIMM: 2, 4 GB
• Up to 512 GB registered DIMMs when fully populated with 2 DIMMs per channel in 32 slots
• Up to 128 GB un uffered DIMMs when fully populated with 2 DIMMs per channel in 32 slots
Network Controllers
• Integrated Intel® 82576EB Giga it Ethernet Controller with dual ports
Storage
• Hard disk form factor: 3.5”
• Type: SAS/ SATA with hot-plug capa ility
• 3.5” Maximum capacity:
 Up to 12 TB SATA (2 TB 3.5" x 6 HDDs)
 Up to 3.6 TB SAS (600 GB 3.5” x 6 HDDs)
Storage Controllers
• Integrated AMD
®
SP5100 Chipset Serial ATA host controller with RAID 0, 1, 10 support
• Optional PCIe 4-/8-port SAS RAID card
Expansion slots
• Two low profile PCI-E 2.0 x16 slots
• One low profile PCI-E 2.0 x8 slot
• One Acer Flex I/O x8 or PCI-E 2.0 x8 slot
anagement
• Acer Smart Server Manager
• System ID LED uttons, System Health LED
• Acer Smart Console for server management and KVM over IP remote management
Deployment/Serviceability
• Acer Smart Setup
• BIOS Update Tool
• IPMI Firmware Update Tool
Operating Systems
• Windows Server
®
2012 (availa le in Q4 2012)
• Windows Server
®
2008
• Windows Server
®
2008 R2
• Windows Server
®
2003
• Red Hat
®
Enterprise Linux 5.4 (availa le with AMD Opteron 6100 series)
• Red Hat
®
Enterprise Linux 6.1 (new for AMD Opteron 6200 series)
• SUSE
®
Linux Enterprise Server 11 SP1 (availa le with AMD Opteron 6100 series)
• SUSE
®
Linux Enterprise Server 11 SP2 (new for AMD Opteron 6200 series)
• VMware ESXi
™
4 update 1 (availa le with AMD Opteron 6100 series)
• VMware ESX
™
4 update 1 (availa le with AMD Opteron 6100 series)
• VMware vSphere
™
5 with ESXi
™
5 (new for AMD Opteron 6200 series)

4
Acer AR585 F1 specifications
•
Citrix
®
XenServer 5.6
• Oracle
®
Solaris 10
Input/output interface
Front
• 2 x USB 2.0 ports
• Serial port
• Network, hard drive and power, and system status indicators
Rear
• PS2 mouse and key oard ports
• 2 x USB ports
• 2 x Giga it LAN port (RJ-45)
• Video port
• Serial port
• System ID LED
• Management port (RJ-45)
Chassis/Form Factor
• 2U rack optimized
Power Supply
• 2 x 1400 W 80 PLUS® gold-level efficient, easy-swap power supply (1+1 redundant, hot-plugga le)
Regulatory Compliant Standards
EMC
• FCC (Class A)
• CE (Class A)
• BSMI (Class A)
Safety
• UL/cUL
• CB
Nemko/GS
Environmental Specifications
Dimensions 437 (W) x 709 (D) x 89 (H) mm (17.2 × 27.9 × 3.5 inches)
Weight Maximum 25.9 kg (57 l s)
Minimum (includes a single HDD, CPU and
RAM, and PSU)
18.6 kg (41 l s)
System inlet
temperature
Operating 10° - 35° C (50° - 95° F)
Non-operating -40° - 70° C (-40° - 158° F)
Relative
humidity
Operating 8 - 90 %
Non-operating 5 - 95 %
Acoustics Idle
LWAd 6.7 BA
LpAm 54.1 dBA

5
Acer AR585 F1 specifications
Operating
LWAd 7.7 BA
LpAm 67.7 dBA
Power Rated Steady –state power 1400 W
Maximum Peak Power 1400 W
BTU rating 4095 BTU/hr at 100 - 140V AC
4778 BTU/hr at 180-240V AC

6
Acer AR585 F1 specifications
Technical specifications
PCIe
®
specifications
The primary I/O us for the main oard is PCIe Gen2. The following ta le lists the characteristics of the PCI-
E us segments. Details a out each us segment follow the ta le.
NOTE: The signaling it rate of PCI Express is 2.5G it/s one direction per lane for Gen 1 and 5.0G it/s one
direction per lane for Gen 2.
Expansion
slot
Num er Type Bus
width
1
Voltage Connector Location Length
PCIe x16 2 PCIe
Gen2
x16 3.3V x16 On oard Low-profile
PCIe x8
1
Up to 2 PCIe
Gen2
x8 3.3V x8 On oard Low-profile
Flex I/O
1
1 PCIe
Gen2
x8 3.3V x8 On oard Low-profile
NOTE:
1. If the Flex I/O slot is used, the second PCIe x8 cannot e used.
2. Indicates the num er of physical electrical lanes running to a PCIe
®
connector.
2. Default us assignment (in decimal). Inserting cards with PCI™ ridges may alter the actual us
assignment num er.
3. Slots are enumerated differently ased on the operating system. Microsoft® operating systems enumerate
Device ID y us starting from the lowest us to the highest.
Onboard storage specifications
Item Description
Controller AMD
®
SP5100 SATA controller
Simultaneous drive transfer channels 6 on oard SATA ports
Max throughput per channel 3 G /s
Data transfer method • Non-RAID mode
• RAID mode (Adaptec RAID driver)
Drive type supported Serial ATA
RAID levels support • RAID 0, 1, 10 (Adaptec software RAID)
RAID function support
 Supports multiple logical volumes
 Setup through ROM ased Array Configuration Utility
Installation scripting support
NOTE: This controller does not support LED functions
RAID OS support • Windows Server 2012
• Windows Server 2008
• Windows Server 2008 R2
• Windows Server 2003

7
Acer AR585 F1 specifications
•
Red Hat Enterprise Linux 5.4
• SuSE Linux Enterprise Server 11
Additional features • NCQ (Native Command Queuing)
•
AHCI (Advanced Host Controller Interface)
Onboard LAN specifications
Item Description
Controller 1 x Intel
®
82576EB Giga it Ethernet Controller
(2 ports total)
Network interface 10Base-T / 100Base-TX / 1000Base-T
Compati ility standards • IEEE 802.3 Ethernet interface for 10BASE-T
• IEEE 802.3a Ethernet interface for 1000BASE-T,
• IEEE 802.3u Ethernet interface for 100BASE-TX
Managea ility • NC-SI, SMBus
• PXE, iSCSI oot
Virtualization acceleration
 Intel
®
I/O Acceleration Technology
 Virtual Machine Device Queues (VMDq)
 PCI-SIG SR-IOV implementation
Connector RJ-45
Supported ca le type CAT 5e wire
emory specifications and population
Item Description
Supported memory types • Registered DDR3 1066 / 1333 MHz
• Un uffered DDR3 1066 / 1333 MHz
NOTE: Acer does not qualify mixed memory configurations of
memory type, capacity or make.
Population Acer’s validated memory populations are listed elow.
NOTE: Support for 8 / 16 GB DIMMs may vary y regional
availa ility.
Dual processor configuration guide
DIMM# CPU 1 CPU 2
4B 4A 3B 3A 2B 2A 1B 1A 4B 4A 3B 3A 2B 2A 1B 1A
4 x x x x
8 x x x x x x x x
16 x x x x x x x x x x x x x x x x

8
Acer AR585 F1 specifications
Quad processor configuration guide
CPU1 CPU2 CPU3 CPU4
# 4
B
4
A
3
B
3
A
2
B
2
A
1
B
1
A
4
B
4
A
3
B
3
A
2
B
2
A
1
B
1
A
4
B
4
A
3
B
3
A
2
B
2
A
1
B
1
A
4
B
4
A
3
B
3
A
2
B
2
A
1
B
1
A
8 x
x
x
x
x
x
x
x
16
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
32
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
On-Line Spare
On-line spare is a RAS mechanism that allows the system to reserve one rank of one logical DIMM to e
used as a spare rank. The spare rank must e greater than or equal to the size of all other ranks in the
system. The system can switch to the spare rank when system software determines that one of the ranks in
the system is no longer functioning properly and needs to e replaced.
emory Identification
Generally, there are some memory information printed on the la el of DIMM, ut different vendor may have
different format. For example:
4GB 2Rx4 PC3-10600R xx xx xxx
1. Density
 1GB, 2GB, 4GB, 8GB, 16GB
2. Rank
 1R = Single Rank
 2R = Dual Rank
 4R = Quad Rank
 Note: if any quad rank DIMM is used, maximum only 2 DIMM per channel can e supported
3. Bit Organization
 This platform supports x4 and x8
 Note: It’s not recommend to mix DIMM with different it organization in one system
4. Speed
 PC3 – 6400 => DDR3- 800
 PC3 – 8500 => DDR3- 1066
 PC3 – 10600 => DDR3- 1333

9
Acer AR585 F1 specifications
Power specifications
1400W Power Supply
Operational Input
Voltage Range
(Vrms)
1200W: 100-140 VAC
1400W: 180 – 240 VAC
Frequency
Range (Nominal)
(Hz)
60/50
Nominal Input
Voltage (Vrms)
100 120 208 200 220 230 240
Max. Rated
Output Wattage 1237.3
1237.4 1403.4 1403.4 1403.2 1403.0 1403.7
Nominal Input
Current (A rms) 14.21 11.95 7.92 7.62 7.13 6.83 6.55
Max. Rated Input
Wattage Rating
(Watts)
1416.74
1428.26
1577.66
1578.62
1560.76
1559.90
1561.00
Max. Rated VA
(Volt-Amp) 1421.0
1434.0 1584.0 1585.0 1568.6 1570.9 1572.0
Efficiency (%) at
Max. Rated
Output Wattage
87.33%
86.64% 88.95% 88.90% 89.91% 89.94% 89.92%
Power Factor 0.997 0.996 0.996 0.996 0.995 0.993 0.993
Leakage Current
(mA) 1.1 1.2 1.1 1.1 1.2 1.2 1.2
Max. Inrush
Current (A peak)
16.74 15.98 16.05 16.11 15.70 15.89 16.20
Max. Inrush
Current Duration
(mS)
4.61 4.60 4.63 4.63 4.65 4.72 4.75
Max. British
Thermal Unit
Rating (BTU/hr)
4222.90
4223.24
4789.80 4789.80 4789.12 4788.439 4790.82

10
Acer AR585 F1 specifications
Acer server software utilities
Smart Setup 2.X Easy deployment via the latest version of Acer’s Smart Setup. Smart Setup is
availa le oth in ox as a driver packed installation DVD or a downloada le file to e
put into a USB 2.0 device, and eases the deployment of Acer servers for any certified
OS. Through its unique interface, users may select to have all the correct drivers e
pre-deployed for the OS of their choosing, as well as setup hardware RAID devices,
BMC settings (where availa le), and even clone the pre-settings to a oota le USB
device to ease mass server deployments.
Smart Console We - ased management utility to simplify system management with em edded
iBMC, system monitoring and alerting, event handling, remote power control and
KVM-over-IP. Smart Console is OS independent and offers virtual media through
floppy, ODD, and remova le disk.
Smart Server
Manager v1.1
Offering 24-7 monitoring for system health and performance.
 Delivers proactive event management features including system event logging,
event handling from e-mail and SNMP Trap (PET) alerting.
 Monitors on oard hardware, operating systems and virtual machines
 Allows remote control from KVM and Power control
 Satisfies management in we - ased UI, role- ased administration, and automated
management scripts.

11
Acer AR585 F1 specifications
Available options
Processors (up to 4)
AMD Opteron
™
6200 series processor (16-core)
6278 (16 MB L3 cache, 2.4 GHz, DDR3-1600, 115W (ACP 80W); Up to 3.3 GHz with tur o core ena led)
6276 (16 MB L3 cache, 2.3 GHz, DDR3-1600, 115W (ACP 80W); Up to 3.2 GHz with tur o core ena led)
6274 (16 MB L3 cache, 2.2 GHz, DDR3-1600, 115W (ACP 80W); Up to 3.1 GHz with tur o core ena led)
6272 (16 MB L3 cache, 2.1 GHz, DDR3-1600, 115W (ACP 80W); Up to 3.0 GHz with tur o core ena led)
6262 HE (16 MB L3 cache, 2.1 GHz, DDR3-1600, 115W (ACP 80W); Up to 2.9 GHz with tur o core
ena led)
AMD Opteron
™
6200 series processors (12-core)
6238 (16 MB L3 cache, 2.6 GHz, DDR3-1600, 115W (ACP 80W); Up to 3.2 GHz with tur o core ena led)
6234 (16 MB L3 cache, 2.4 GHz, DDR3-1600, 115W (ACP 80W); Up to 3.0 GHz with tur o core ena led)
AMD Opteron
™
6200 series processors (8-core)
6220 (16 MB L3 cache, 3.0 GHz, DDR3-1600, 115W (ACP 80W); Up to 3.6 GHz with tur o core ena led)
6212 (16 MB L3 cache, 2.6 GHz, DDR3-1600, 115W (ACP 80W); Up to 3.2 GHz with tur o core ena led)
AMD Opteron
™
6100 series processor (12-core)
6176 (12 MB L3 cache, 2.3 GHz, DDR3-1333 MHz, 115W (ACP 80W))
6174 (12 MB L3 cache, 2.2 GHz, DDR3-1333 MHz, 115W (ACP 80W))
6172 (12 MB L3 cache, 2.1 GHz, DDR3-1333 MHz, 115W (ACP 80W))
6168 (12 MB L3 cache, 1.9 GHz, DDR3-1333 MHz, 115W (ACP 80W))
6166HE (12 MB L3 cache, 1.8 GHz, DDR3-1333 MHz, 75W (ACP 65W))
6164HE (12 MB L3 cache, 1.7 GHz, DDR3-1333 MHz, 75W (ACP 65W))
AMD Opteron
™
6100 series (8-core)
6140 (12 MB L3 cache, 2.6 GHz, DDR3-1333 MHz, 115W (ACP 80W))
6136 (12 MB L3 cache, 2.4 GHz, DDR3-1333 MHz, 115W (ACP 80W))
6134 (12 MB L3 cache, 2.3 GHz, DDR3-1333 MHz, 115W (ACP 80W))
6128 (12 MB L3 cache, 2.0 GHz, DDR3-1333 MHz, 115W (ACP 80W))
6132HE (12 MB L3 cache, 2.2 GHz, DDR3-1333 MHz, 75W (ACP 65W))
6128HE (12 MB L3 cache, 2.0 GHz, DDR3-1333 MHz, 75W (ACP 65W))
6124HE (12 MB L3 cache, 1.8 GHz, DDR3-1333 MHz, 75W (ACP 65W))
emory

12
Acer AR585 F1 specifications
Memory type Registered / Un uffered DDR3 ECC memory
Capacities 1 / 2 / 4 / 8 / 16 GB DIMMs
DIMM num er 32
Max memory 512 GB (128 GB un uffered)
Hard drives
Type Interface, andwidth Capacities (RPM)
Enterprise SATA, 3.5” 3 G /s 250 GB (7.2K)
500 GB (7.2K)
1 TB (7.2K)
2 TB (7.2K)
6 G /s 500 GB (7.2K)
1 TB (7.2K)
2 TB (7.2K)
3 TB (7.2K)
Enterprise SAS, 3.5”
NOTE: SAS drives require an
add-on RAID card
6 G /s 300 GB (15K)
450 GB (15K)
600 GB (15K)
RAID cards
Model Port num er RAID support
LSI
®
MegaRAID SAS 9261-8i**
(512 MB DDR2 cache)
8 internal ports 0, 1, 5, 6, 10, 50, 60
Flex I/O, LSI
®
SAS 2108* 8 internal ports 0, 1, 5, 6, 10, 50, 60
**Battery Backup Unit BBU08 availa le
RAID HBA for Tape Drive
Note: LTO tape drives require an add on card for external or internal connectivity
Model Port num er RAID support
LSI
®
SAS3442E-R 4 internal / 4 external ports 0, 1, 10
Ethernet network cards
Model Port num er Bandwidth
Intel
®
Giga it CT2 desktop
adapter
1 10/100/1000 M ps
Supermicro AOC-SG-i2 server 4 10/100/1000 M ps

13
Acer AR585 F1 specifications
adapter
Supermicro AOC-SG-i4 server
adapter
4 10/100/1000 M ps
Supermicro AOC-STGN-i2S
server adapter (DA2)*
2 10 G ps
Intel
®
X520-SR1 server adapter* 1 10 G ps
Intel
®
X520-SR2 server adapter* 2 10 G ps
Intel
®
X520-LR1 server adapter* 1 10 G ps
*Note: Intel’s 10G E cards vary in terms or their connecter type. The X520-DA2 is a copper connector for
lengths up to 7M, while the X520-SR1/2 is an optical connection for ca les up to 550M. The X520-LR1 is
for even longer ca le lengths up to 10kM.
Fibre Channel HBAs
Model Port num er Bandwidth
Qlogic
®
QLE2460 1 4 G /s
Qlogic
®
QLE2462 2 4 G /s
Qlogic
®
QLE2560 1 8 G /s
Qlogic
®
QLE2562 2 8 G /s
Tape Backup Unit (TBU)
Model Tape capacity Form factor
LTO Ultrium-3, 3G /s SAS 400/800 GB External 1U rack
LTO-4, 3G /s SAS 400/800 GB External 1U rack
TP module
TPM module with STMicro chip

14
Acer AR585 F1 specifications
Service and support
Acer Servers offer a comprehensive service suite to take care of daily IT needs. Users can select the 3-
year standard warranty or choose extended warranties and services.
In a continuing effort to improve the quality of our products, information in this document is su ject to
change without notice. Images shown are only representations of some of the configurations availa le for
this model. Availa ility may vary depending on region.
© 2012. All rights reserved.
Microsoft and Windows are registered trademarks of Microsoft Corporation. AMD, AMD logo, Opteron are
trademarks or registered trademarks of AMD Inc.
NOTE: Extension warranty services may vary y country. Please contact Acer authorized resellers for more
information.
