ACME hi-skyper User manual

Manual
Information, updates and the latest manual for download under
www.Hi-Skyper.com
Content
Model is made of a multipart EPP-
Body
Brushless motor with holder
Propeller
Motor controller
3 Servos
Cockpit cover
Controller
with internal mixer
Antenna with flag
Parts to add:
Rear wing
left and right truss
Ruder
6 screws to fix the rear wing
3 servo arms with screw
2 short linkage for the elevator
1 medium linkage for the ruder
2 long linkage to connect lower and
upper elevator
4-Channel receiver with antenna wire
1000mAh 7,2V LiPo battery pack
Accessoires
LiPo charger with balancer
10V /220V adaptor
BlueGlue EPP glue
water protection tape
screwdriver
Spare propeller
manual
Registration card
V.1.04

SECURITY ADVICES
•The Hi-Skyper is not suitable for children under the age of 14 years. Adolescents just can run the model under attention of a parent.
•The operation with this Hi-Skyper model requieres a high level of technical knowledge, carefulness and an special safety-conscious
acting.
•The usage under the influence of alcohol or drugs is prohibited.
•Never use in public traffic, nearby parcs, schoolyards and playgrounds.
•Keep sufficient distance to traffic, rail traffic, airports, buildings and high voltage wires.
•ATTENTION! The Hi-Skyper has a real fast rotating and powerful engine! Never reach for the rotating actuation. Fingers could be
disembodied. Never stand in the area where the model is flying or in front of it. Bring to mind that damaged parts can come off. Those
parts can cause considerable injuries. Please attend the danger zone and advert spectators of the dangers that are connected with using
the Hi-Skyper. A safety clearance of 5 meters has to be observed. Always keep the necessary distance to persons and obstacles – never
cross those with a low height. Approach to the model just from the back.
The picture shows the models danger zone – the darker, the
higher is the risk of getting injured in the mentioned zone. The
radius of the danger zone is 5 meters.
•The Hi-Skyper has no brakes! Consider the breaking distance depending on the subfont.
•Without motor speed the model is not controlable.
•Check the model on damages before every start. NEVER start the model with a damaged accumulator, damaged engine or defective
steering. The functionality of the remote control has to be checked before every start.
•Don´t run the model in brine or saline beaches.
•The use during temperatures between –5°C and 35°C is not recommendable.
•Don´t use the model during strong current, high waves and strong wind.
•The usage in areas of nature reserve, landscape reserve and water pollution control is prohibited.
•In Case of a damage just use original Hi-Skyper spare parts.
•The model must be run with full loaded transmitter accumulators respectively with new batteries.
•Pay attention that you don´t disturb other models with the same channel or that they disturb you. Don´t start the Hi-Skyper if you´re not
sure that the choosen channel is free.
Warnings Lithium Polymer Battery Pack!
Charge the Lipo battery pack only under supervision. Store the Battery on a non-flammable and heat resistant surface during charging. Keep away
from flammable goods and liquids. Never charge inside a vehicle!
•Mishandling may occur explosion, fire and smoke including damage of health or goods. It will also reduce battery performance.
•Stop using our model when battery power rapidly goes down. Discharging lower than 2,5V will cause permanent damage!
•Capacity of the LiPo battery pack will be reduced with every discharging circle. After 50 circles the capacity is reduced to 60-80%.
•Use a LiPo-Charger with balancer for charging only!
•Charge and store the LiPo battery pack at a temperature of 0°C to 40°C – avoid a temperature higher than 65° C when discharging.
•Never charge a damaged LiPo battery pack. Stop charging if the LiPo battery pack is getting deformed (blown up).
•Never charge with reversed polarity – permanent damage, fire and smoke may occur!
•Do not shortcut – Risk of explosion and fire!
•Never carry a Lipo in pockets of your trousers or jacket – in case of fire, taking them out will not be in time!
•Avoid contact to any kind of liquids.
•The LiPo battery pack is not a toy! Keep away from children!
•If electrolyte contacts your skin or eyes, immediately wash it off using plenty of clean water. Consult a doctor!
•Remove the LiPo battery pack of the model after using and store according to the charging instructions. Note that deep-discharged
batteries will be damaged permanent. Charge in time!
•Dispose used batteries in the appropriate manner.
Note:
ACME the game company is unable to ensure correct use according to these instructions. For this reason ACME the game company is
obliged to refute any claim under guarantee.

The remote control
The model will be controlled by the left and right throttle (1 & 2) – Factory Settings: left sided elevator and ruder/ right
sided acceleration and Querruder. The trimmer (3-6), each close to the throttle will be used to adjust ruder an elevator.
Under the cover (7) the crystal is located which firms the channel oft he controller – onboard the receiver inside the
model the opposite one is build in.. Spare crystals to change the channel are available at your nearest model retailer.
Beneath the crystal the LED (8) green indicates power, the LED (9) red the activated mixer. Settings of the
microswitches (10) will be shown later on. The switch (0) at the left will reduce the elevator by 50% (dual rate).
Fig.1
Fig.2
0
1 2
3 4 Fig.3
5 6
Fig.4
7 8 9 10
Figures 1-7 shows ruder and elevator action
(Mikroswitches 1 OFF , 2-4 ON):
Throttle position will be given in clock: 0= center position Fig.5
Fig. Left throttle Right throttle Describtion
1 0 6 Nutreal
2 3 6 Right
3 9 6 Left
4 6 6 Rise
Fig.6
5 12 6 Decrease
6 0 4 Role to the right
7 0 8 Role to the left
Settings of microswitches (10) from the left to the right
Schalter Describtion
1 Invert ruder
Fig.7
2 Invert mixer
3 Invert elevator
4 Mixer on/off

Assembling of the model
Step 1 Assembling of the rear wing
Add the parts as shown in Figure 1. Assure that the outer carriers
are not mixed up (Stickers at the outer side)
Fix the carriers and ruder to the wing using the smaller screws.
Step 2 Installation of the receiver
Below the cockpit you will find the plugs for the servos and
the motor controller marked as follows:
1 Motor controller/Power
2 Servo left - elevator
3 Servo center - ruder
4 Servo right - elevator
Connect the plugs as shown in
Fig. 2. Pay attention to the right
polarity!
(Ground/black is outside).
Fig.2
Step 3 Adjustment of the servos and connection of the linkage
Prepare the pre-adjustments of the elevator. Turn the controller on und move
the trimmers to center position. Pull the right throttle to 6 o’clock. Connect the
charged Lipo battery now. Attention! The motor confirms readiness.
Servos are in center position now. Disconnect the Battery before continuing.
Mount the servo arms as shown in Figure 3. Arms for the elevator point upright
Above, the one for the ruder points to the right. Fix the arms with the screws.
. Fig. 3
Both PCB’s have to be wrapped by the included teflon
sealing tape to prevent destruction by wetness. .
Step 4 Sticking the rear wing
Put the rear wing for testing into the mounting slot of the body
marked with A;B and C (Figure 4).Assure that everything fits
together and take off the wing again. Put some BlueGlue into
the slots now.
IMPORTANT! Work very exactly!
Install the wing swiftly now and move it into exact position
without leaving any gaps between carriers and body. Let it
dry for 5 minutes.
Step 5 Installing the linkage
Hook the linkage to the servo arms.
Connect the short ones with left and right elevator, the medium
one with the ruder. Turn the trim parts to adjust elevators and
ruder. Last but not least connect the lower and upper elevators
with the remaining longer linkages.
Make sure that finally all elevators will have the same position Fig.4
Guide the antenna off the cockpit to the ruder. Unscrew both
center screws a bit and put antenna between carrier and wing.
DO NOT shorten the antenna!

ATTENTION! ATTEND SECURITY ADVICES
Test drive, not test flight
Weather conditions: less / no wind
For testing the Hi-Skyper , a free and flat surface is required – a sheet of ice, a snow-capped or asphalted area with the
dimensions of 100 x 100 m would be ideal.
Always attend the following way of proceeding:
The operating time of the remote control covers the time of the model – that means: switch on the remote control first
and then the model. If you switch it off, first the model then the remote control.
Switch on the remote control. Pull the throttle (right) to 6 o’clock. Connect
the LiPo battery pack with the Hi-Skyper and shut the cockpit. Absent
yourself from the model. Now, move the right stick to the left or right –
the rudder reject to the left or right. If you move the control stick (left) to
the front the elevators go down if you move it to the back they go up. The
control stick has to be steered very precise because an unobservant
moving can cause the takeoff and lead to a damage by landing. To avert
the accidental takeoff, in case you´re not acquainted with steering a 4-
channel model aircraft, please remove the linkage from servo to elevator
to try the first slides without the elevators. Now move the control stick to
the front – the propeller starts to turn- depending on the surface the model starts to move slowly forward. Do some
turns before moving the stick further and correct the on-center feel with help of the trim notch.
Please attend:
The Hi-Skyper has no breaks and will continue gliding while the motor is powered off.
Controlling the model is reduced when the propeller is stopped!
The speed can be reduced by moving the elevators down. The nose will be pressed to the ground and the model gets
slower.
Get used to the sliding at the ground before you try to fly. Do the next step only when you are able to control the model
at the ground – complete linkage installed.
Hoovering
Weather conditions: No wind
As long as the skids of your Hi-Skyper touch the ground you are a good Hi-
Skyper pilot. To the next step: hoovering with 2 to 7 centimeters to the
ground.
Preparations to start are known – make sure that elevators and ruder are
in exact positions. Start against wind direction and increase the speed one
by one. Reduce the speed if the model lifts off with one skid only. Adjust
the model by moving the trims and try again. Redo the start again and
again – and begin than with light ruder movement

Flying
Weather conditions: No wind
Within the last days your Hi-Skyper got cuts and perhaps was also broken – time to train the flying. This chapter is
especially short because within the last days you got known of your model and you know how it reacts. Probably you
already had experience in short flights. Two things to say: flying the model requires full batteries and less ruder. In the
air the model will be controlled by the elevators only. If this is new for you return to hovering! Seperate available V-
wings can help to stabilize the model.
The Elements
Water
Before entering the water you have to prevent the PCB’s against water. Wrap both PCB’s with teflon tape until they are
water resistant. Water
Check if the EPP-Body of your Hi-Skyper is undamaged. Maybe materialabrasives let water in; your model will become
a heavy weight and take off from the water will be impossible. Just operate your Hi-Skyper on smooth water surfaces –
Waves but also heavy curves can overturn the model - navigate against with the elevator. Should the model land
headlong in the water tow directly the throttle to the back. More gas can destroy the motor controller, if water gets
inside the Hi-Skyper. Check directly the body and the battery pack if water is intruded in the inside. If the battery pack
is wet, disconnect the circuit and let the components dry. Keep the battery pack according to the safety instructions and
let it dry.
Frozen water
If you test your Hi-Skyper on an iced areal, just enter it if everything safety. Don´t get in Danger. On an iced area the
Hi-Skyper can achieve the top speed – optimal to fight races.
Sliding on a snowcovered surfaces is ideal for first hoover- or flightsteps. The snowcover safes the model for damages.
Fire
Flying through a ring of fire you must abandoning other. Hopefully you´ve read in the safety instructions that the Hi-
Skyper is in deal with fire.
Earth
Is very suitable, assumed if it is snowy or just asphaltic. But the asphaltic can damage your Hi-Skyper more than
smoothie snow.
Air
The Air and also the Ground are home of the Hi-Skyper – but the requirements to the pilot are more ambitiously! Don´t
damage your Hi-Skyper, because you overvalue yourself.
Repairs
Your Hi-Skyper is made of EPP (..) a material which can absorb mechanic interferences through extreme resiliency.
Anyhow the model can damage. Possible breaks and broken plastic parts you can glue with the EPP-glue (Blue Glue)
inside the set. To glue the carabon shaft to the motorbody in the plastic holder use superglue with activiator (model
shop) or synthetic resin. Change damage propellers .
An unbalance can bunk out the Motor supporter.
Servicing & Care
Clean the model after every insert and remove dust and dirt, so you can stay long with the Hi-Skyper. Water inside
must remove. Change damage accessories!
You get all spare parts at your modelmakingshop or in the internet under www.Hi-Skyper.com . At the end of this
instruction you will see a list of spare parts. If you need help, call: Fon [phone] or mail at support@Hi-
Skyper.com.

Debugging
Error Reason Resolution
Model doesn´t react. Accumulator is not charged Load accumulator.
Remote control is not switched on Switch on remote control.
Accumulator plug is not connected the right. Open the shutter of models accumulator and
check the connection.
Empty batteries inside remote control. Change batteries – charge accumulators.
Check the connection of the charging lead.
The model can´t be controled resp. just hardly
controlled.
Batteries / accumulator to weak. Load accumulators – if necessary change
batteries
Remote control with a wrong frequency. Just use supplied remote control!
The Electronics or engine of the model is damaged. Installation of new electronics – on
www.Hi-Skyper.com you will find suppliers.
Contact breaks down after 5 – 15 meters. Models antenna abrupt – (let it) solder
Contact breaks down after 30 – 50 meters Receiver or transmitter board damaged –
service
Servo reacts slowly resp. delays control commands. Servo damaged Change defective servo
Model doesn´t keep the track. (ice, asphalt) On a hard, slick ground the model just changes the
direction by the propellers boost.
For the usage on iced surfaces the Hi-Skyper
can be modified by little lightweight steel
edges.
Model can be controled hardly. Foreign objects disrupt the free run of the propellers. Clean the model
Fuselag seriously damaged. Repair damages like crannies or breakings by
Blue Glue or change damaged parts.
The wind speed is to high, it´s squally. Wait for better wheather.
The model tilts to the left or right during flying,
without touching the controlstick.
The Hi-Skyper is pretty wobbly caused by its
construction type.
Constant steering into the opposite direction
is necessary.
The model doesn´t start from the water. Accumulator not charged completely. Charge accumulator.
Accumulator exhausted. Insert new accumulator
The fuselag is damaged and the the EPP soaks up
water – the model becomes to heavy.
Let the model dry off and caulk the damaged
parts by Blue Glue. If necessary replace
fuselag or vats.
The model doesn´t slide straight. The plastic sliders are damaged. Stick new plastic sliders on the model.
Trimming is not alright. Trim rudders
The surface falls off to one side. Choose another surface for starting
Sidewind affects the sliding. Always start against the wind.
Schematic
4
1 3
2
Further hints are available on the Hi-Skyper homepage: www.Hi-Skyper.com

Ersatzteile & Zubehör / Spare Parts & Accessories
Pièces de Rechange & Accessoires
Artikel-Nr.
Catalogue-No. EAN
Artikel
Article
Beschreibung
Description
HS1101 Propeller
Propeller
HS1103 LiPo Battery Pack 7,4V 2x LiPo Zelle 1000mAh
2x LiPo cell 1000mAh
HS1106 Kompletter Rumpf
Complete fuselag
HS1107 Motorhalterung
engine mounting
Kunststoffanker mit Karbonstab und Alu-Motoraufnahme
plasticbrace with carboniferous bar and aluminium engine
attachment
HS1108 Kunststoffanker
Plasticbrace
für Motorhalterung
for engine mounting
HS1109 Abdeckhaube
covering hood
Kabine mit Verschluss
Cabin with closure
HS1110 Kufe L
skid l
HS1111 Kufe R
skid r
HS1102 Motor
Engine
Brushless
HS1105 Servo
servo
AA1112 Gestänge
linkage
5x Steuergestänge
5x linkage for steering
HS1104 Empfänger
receiver
Ohne Quarz
without Quartz
HS1107 Motor Controller
engine controller
HS1113 Abdichtset
Caulking-set
HS1114 Gleiterfolienset
set with foils for sliding
AA1124 BlueGlue EPP-Klebstoff
EPP-glue
HS1115 Antenne
antenna
für die Fernbedienung
fort he antenna
HS1132 LiPo Ladegerät
LiPo charger
AA1130 FlyCamOne USB 8Mb 24g 320x240px Li-Ion SD CardSlot
ACME the game company – Industriestr. 10A – 33397 Rietberg – Germany
Hotline: [phone] - Fax [phone]
[email protected]
www.ACME-Online.de

CE - Declaration Wichtige Hinweise zum Akku Pack und den Batterien
Herewith we declare that this item is in
accordance with the essential requirements
and other relevant regulations of the directive
1999/5/EC. A copy of the original Declaration
of Conformity can be obtained at the
following address.
Hiermit erklären wir das dieses Modell den
grundlegenden Anforderungen und den anderen
relevanten Vorschriften der Richtlinie 199/5/EG
entspricht. Eine Kopie der Konformitätserklärung
kann unter der nachfolgenden Adresse
angefordert werden.
Par ceci nous déclarons que cette model est en
règle avec le requises essentielles et autres
régulations relevantes de la directive 1999/5/EC.
Une copie de la Déclaration d’origine de
Conformité peut être obtenu à l’adresse
suivante.
Noi dichiara che questo veicolo è conforme ai
requisti essenziali e agli altri specifici regulamenti
della derittiva 199/5/EC. Copia della
Dichiarazione di Conformità originale può essere
richiesta al seguente indirizzo.
Por la presente nosotros declara que este coche
cumple con los requesitos essenciales y con el
resto de la normativa relevante según la directiva
n° 1999/5/EC. Una copia de la Declaration de
Conformidad original puede ser obtenida en la
siguiente dirección.
Hierbij verklaren wij dat deze auto voldoet aan
de noodzakelijke eisen en andere relevante
regelgevingen van de richtlijn 1999/5/EC. Kopien
van de originele verklaring van conformiteit kan
verkregen worden bij:
Härmed deklarerar vi, att denna bil
överensstämmer med de väsentliga krav och
relevannta foreskrifter av direktiv 1999/5/EC. En
kopia av originalet av Declaration of Conformity
kan rekvireras fran följande adress:
Täma tuote on direktiiven 1999/5/EC
vaatimusten mukainen. Alkuperäset
vaatimustenmukaisuus-asiakirjat ovat saatavilla:
Hermed erklaerer vi, at denne bil
overensstemmelse med de pakraevet
regelementer og i henhold til andre relevante
regulativer ifolge direktiv 1999/5/EC. En kopi af
den originale erklaering med de angivne regler
kan rekvireres pa folgende adresse:
CME the game company
Industriestr. 10A
33397 Rietberg – Germany
T: [phone]
F: [phone]
E:[email protected]
www.ACME-Online.de
Hinweise zum Akku Pack im Modell
In die Modelle ist ein wiederaufladbarer Akku eingebaut.
Ein unsachgemäßer Gebrauch kann zur Beschädigung oder Entzündung
des Akkus führen. Bitte beachten Sie folgende Vorsichtsmaßnahmen:
•Beim ersten Laden des Akkus oder wenn das Fahrzeug längere Zeit
nicht benutzt wurde, kann es sein, dass das Akku nicht vollständig
aufgeladen wird. Das ist kein Mängel des Akkus. Während der ersten
vier bis fünf Mal Auf- und Entladen (Fliegen) verlängert sich die
Flugdauer kontinuierlich.
•Laden Sie Ihr Modell nur, wenn der Akku völlig entleert ist. Bereits
aufgeladene Akkus sollten nicht weiter geladen werden, um eine
Überladung zu vermeiden.
•Verwenden Sie zum Laden ausschließlich die speziell dafür in der
Fernsteuerung integrierte Ladevorrichtung.
•Sollte das Akku-Pack sich erwärmen, so lassen Sie es vor weiterem
Gebrauch vollständig abkühlen.
In dem Modell ist ein LiPo-Akku enthalten. Bringen Sie verbrauchte Akkus zu
einer dafür vorgesehenen Sammelstelle.
Hinweise zu den Batterien in der Fernbedienung
Benutzen alkaline Batterien (1,5 V Mignon AA) oder Akkuzellen (1,2V AA).
Ungeeignete Batterien können sich erhitzen, auslaufen oder
kaputt gehen. Beachten Sie bitte folgende Hinweise:
•Nehmen Sie keine unterschiedlichen Batterietypen oder mischen neue
und alte Batterien. Tauschen Sie immer ALLE alten Batterien gegen
neue aus.
•Achten Sie beim Einsetzen der Batterien in die Fernsteuerung auf die
richtige Polarität (+/-) wie im Batteriefach abgebildet.
•Versuchen Sie niemals die Batterien aus der Fernsteuerung zu öffnen.
Lassen Sie die Batterien niemals heiß werden oder mit Feuer in
Berührung kommen. Schützen Sie die Batterien vor Nässe oder
Feuchtigkeit, um einen Kurzschluss zu vermeiden.
•Kommt auslaufende Batterieflüssigkeit mit Augen in Kontakt, so muss
sofort mit viel kaltem Wasser ausgespült und ein Arzt konsultiert
werden. Waschen Sie Batterieflüssigkeit, die mit Haut oder Kleidung in
Berührung kommt, mit klarem Wasser ab.
Alte Batterien gehören nicht in den Restmüll, sondern sollten zu den
entsprechenden Sammelstellen gebracht werden.
Important Battery Information
Model Battery Care
A rechargeable battery has been built into to main body of the model.
Using the battery incorrectly will cause it to, rupture or ignite.
Follow these precautions:
•Charge the battery only when the car is NOT running. To prevent
overcharging, never recharge a battery which has already been fully
charged. This will not increase flying speed.
•Recharge the battery only with the transmitters built-in charger.
•If the chassis becomes warm, let it cool before running again.
This product uses a NiMh battery. NiMh batteries are recyclable, and a
valuable resource. To dispose of the battery, remove it and take it to a
recycling centre.
Transmitter Battery Care
Always use AA alkaline batteries. If improper batteries are used in the
transmitter, they may become hot, leak and may rupture.
Follow these precautions:
•Do not mix different types of batteries, or old and new batteries.
•When changing batteries, replace ALL of the old batteries with new
ones.
•Make sure the batteries are installed with the correct polarity as shown
in the battery compartment.
•Do not disassemble your transmitter batteries. Never allow them to
become hot or to burn. To avoid short-circuits, avoid getting them wet.
•If liquid from inside the batteries contact your skin or clothes, wash them
with water. If leaked battery fluid gets into your eyes, flush them
immediately with cool water and seek medical attention. Do not rub
eyes.
Dispose empty Batteries at a recycling centre.
Entretien de la batterie du modèle
Le boîtier principal de la avion contient une batterie rechargeable. Si elle est
utilisée de manière incorrecte, celle-ci peut fuir, se briser ou prendre feu.
Suivez les instructions de sécurité suivantes :
•Si la model n'a pas été utilisée pendant longtemps ou si vous
chargez la batterie pour la première fois, il est possible que
celle-ci ne se charge pas à pleine capacité. Ceci ne veut pas
dire qu'elle ne fonctionne pas correctement. L'autonomie du
modèle augmente pendant les 4 ou 5 premiers chargements.
•Ne rechargez la batterie que lorsque le modèle cesse de
fonctionner.
•Pour éviter tout risque de surcharge, ne rechargez pas une
batterie qui vient d'être chargée à pleine capacité.
•Utilisez exclusivement le chargeur embarqué de la
radiocommande pour recharger la batterie.
•Si le châssis devient chaud, laissez-le refroidir avant de
l'utiliser à nouveau.
Ce produit utilise une pile NiMh. Les piles NiMh sont recyclables et
constituent une ressource précieuse. Lorsque la pile ne fonctionne plus,
enlevez-la et emmenez-la dans un centre de recyclage.
Entretien des batteries de l’émetteur
Utilisez toujours des piles AA. Si les piles de la radiocommande ne sont pas les
piles adéquates, elles risquent de surchauffer, de fuir et de casser. Respectez
les précautions suivantes :
•Ne mélangez pas différents types de piles, ou des piles neuves
et usagées.
•Lorsque vous changez les piles, remplacez toujours TOUTES les
piles usagées.
•Assurez-vous que les piles respectent bien les polarités
indiquées dans le compartiment des piles.
•Ne chargez pas ou ne démontez pas les piles de votre
radiocommande. Empêchez qu'elles ne surchauffent ou ne
prennent feu.
•Pour empêcher les courts-circuits, évitez tout contact avec de
l'eau.
•·En cas de contact de liquide provenant des piles avec votre
peau ou vos vêtements, lavez-les à l'eau. En cas de contact de
fluide provenant d'une pile avec vos yeux, rincez-les
abondamment à l'eau et consultez votre médecin.
© copyright 2006 ACME the game company
