ACME Zoopa 350 User manual

the game company


14+ JAHRE | YEARS | ANS
V1.05 – 2013
Manual
4

the game company
Read the entire user’s manual to become familiar with the characteristics of the product before using it. Incorrect use of the product
may lead to damage of the product, to personal property or cause serious injury. This is an advanced hobby product. It must be
operated with caution and requires some basic mechanical ability. Failure to operate this product in a safe and responsible manner can
result in injury or damage to property. This product is not intended to be used by children under 14 years. Teenagers should always be
accompanied by an adult when ying.
This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings
in the manual prior to assembly, setup or use, in order to be able to use the product correctly and avoid damage or serious injury.
_____________


the game company
INDEX
Content of the Box 
Exploded View 
Technical Data 
Tuning possibilities 
BC4024 2.4 GHz Controller 
Charging the helicopter 
Connecting the controller with the helicopter 
How to y 
Helicopter steering 
Trim/Adjust 
Flight maneuvers 
FAQ 
Safety Advice 
Warranty 
Service & Support 

16
zoopa 350


17
zoopa 350

CONTENT OF THE BOX
!

zoopa 350
Controller 2.4 GHz BC4024 Manual Phillips Screwdriver
LiPo 7,4V 850 mAh 2S LiPo Charger with Balancer 240 V Power Adapter
Spare Blades Tail Rotor Balance Bar
* Before you can start using the helicopter, you need to insert 8 x AA 1,5 V batteries into the controller.
These are not included in the set.

18
zoopa 350

BC4024 2.4 GHZ CONTROLLER
Beginner/Professional Mode
Gas Trim
Gas,Roll Stick
Roll Trim
On/Off Switch
Antenna
Power Indicator
Forward/Backward Trim (Nick)
Forward/Backward, Left/Right Control
Left/Right Trim (Sheer)
At the backside of the controller, there is the Reset Button located next to the battery compartment.
CHARGING THE HELICOPTER
»To charge the LiPo battery, connect the power adaptor with the charger.
»Connect the white balancer plug with the charger port.
»Charging takes, depending on the battery condition, up to one hour. The LED ashes green when the battery is fully charged.

BINDING THE CONTROLLER WITH THE HELICOPTER
Perform the binding process as followed:
»Insert 8 AA 1,5V batteries into the controller.
»The helicopter needs to be switched off! Connect the battery plugs.
»Place the helicopter on a plain surface and let the tail rotor point into your direction.
»Switch ON the helicopter.
»Pull the gas stick of the controller towards the lower left corner and hold it while you switch on the controller.
»A minimal servo reaction of the helicopter is being heard.
»Put the gas stick into neutral position.
»Switch OFF the controller.
»Leave the helicopter turned ON.
»Get 3 meters away from the model and switch ON the controller again.
»Done!

19
zoopa 350

HOW TO FLY
I.
II.

»
»
»

I. DRIFT
The zoopa 350 is an excellent Single-Blade helicopter that has been especially developed to enter into 4-Channel helicopter ight. Attention
should be paid to the fact, that 4-Channel helicopters tend to drift away into one direction. This drift can only be minimized by countersteering
with the controller at all time.
II. RANGE
The range of the controller is about 60 m. Avoid crashes against the ceiling or other obstacles – this causes damages to the helicopter.
Optimal ight can be reached at about 1 m height.
BEGINNER/ PROFESSIONAL MODE
Move down the dual-rate-switch for beginner mode: The servo movements are now reduced by 40 %. Move up the switch for professional
mode with 100 % amplitude and full agility.

20
zoopa 350

HELICOPTER STEERING
UP
to ascent, move up the left stick.
DOWN
to descent, move down the left stick slowly.
MOVE LEFT (ROLL)
pan to the left, move the right stick to the left.
MOVE RIGHT (ROLL)
pan to the right, move the right stick to the right.
FORWARD (NICK)
ying forward, move up the right stick.
BACKWARD (NICK)
ying backwards, move down the right stick.
LEFT ROTATION (SHEER LEFT)
turn around its own axis counterclockwise, move the left stick
to the left.
RIGHT ROTATION (SHEER RIGHT)
turn around its own axis clockwise, move the left stick to the
right.

21
zoopa 350

TRIM / ADJUST
If the helicopter turns or drifts to one side after start, you can adjust the movements with the trims.
Move the corresponding trims against the drift movements as shown below.
DRIFT ROTATION TO THE RIGHT (SHEER TRIM)
if the helicopter is turning right, press the digital sheer trim button to
the left until the result is satisfying.
DRIFT ROTATION TO THE LEFT (SHEER TRIM)
if the helicopter is turning left, press the digital sheer trim button to
the right until the result is ne.
DRIFT BACKWARDS
if the helicopter is moving backwards, press the digital nick trim
button to the top until the helicopter stops moving backwards.
DRIFT FORWARDS
if the helicopter is moving forward, press the digital nick trim button
downwards until the helicopter stops moving forward .
DRIFT RIGHT (ROLL)
if the helicopter pans right, press the digital roll trim button to the
left.
DRIFT LEFT (ROLL)
if the helicopter pans left, press the digital roll trim button to the
right.
!


22
zoopa 350

FLIGHT MANEUVERS
If you have gained some experience, you can try to realize the following maneuvers.
 
 
FAQ
  
The helicopter does not react on controls Batteries are not inserted in the controller
correctly
Check batteries
Batteries are empty Charge the batteries
Binding was not correct Check chapter “Binding”
Controller batteries are weak/empty Replace controller batteries
The helicopter does not gain height The Battery is weak Recharge the battery
The range is not sufcient Controller batteries are too weak Replace controller batteries
The Antenna inside the model is too close
to the PCB
Open the canopy and check the antenna

23
zoopa 350

EXPLODED VIEW
A
2
MV
O
O
K
N
R
B
E
I
K
Y
L
P
G
F
D
H
C
S
Q
W
F
E
H
O
J
U

  Article   Article   Article
  Canopy
  Main Blades
  Tail Rotor Blade
  Balance Bar
  Rotorcenter Assembly
  Carriage
  Swash Plate
  Linkage Set
  Rotorshaft
  Upper Frame
  Main Frame
  Battery Frame
  Landing Skids
  Tail Pipe
  Bearing Set
  Main Motor
  Tail Motor
  Rod Components
  Complete Tail
  Servos
  Steering Rod
  Main Gear
  Tail Gear Set
  Battery 7,4 V LiPo 850 mAh
  Mainboard
www.acme-online.net

24
zoopa 350

TECHNICAL DATA
Length: 390 mm
Height: 135 mm
Weight: 265 g
Motors: 370 category
Battery: LiPo 7,4 V 850 mAh 2S
Controller: BC4024 2,4 GHz 4 Channel
TUNING OPTIONS
MAXIMUM FLIGHT EXPERIENCE
Raise the ight time of the zoopa 350 with a bigger 1000mAh battery and witness a clearly extended
ight fun in a few quick steps.
– Art. No.: AA0350-X
PHOTOS AND VIDEOS FROM THE AIR
Record sensational videos from the air or shoot breathtaking landscapes and buildings. The FlyCamOne
eco V2 makes it possible. More detailed information at
www.camonetec.com
– Art. No.: FC2450
TRAINING KIT
Everyone starts small. In order to learn ying as gently as possible, we have invented the training
assistance for you.
– Art. No.: AA0353

25
zoopa 350

SAFETY ADVICE
The product contains LiPo batteries. Take used up batteries to a scheduled collecting point.

Mishandling may lead to explosion, re and smoke including damage of health or goods. Replace the battery by a recommended battery
of the same type. Dispose of used batteries in the appropriate manner. Never charge with reversed polarity – permanent damage, re and
smoke may occur! Do not short-circuit – risk of explosion and re! 

Always use AA alkaline batteries. If inappropriate batteries are used in the transmitter, they may become hot, leak and may rupture. Follow
these precautions:
»Do not mix different types of batteries, or old and new batteries.
»When changing batteries, replace ALL of the old batteries by new ones.
»Make sure the batteries are installed with the correct polarity as shown in the battery compartment.
»Do not disassemble your transmitter batteries. Do not let them become hot or even start burning. To avoid short-circuits, avoid them
getting wet.
»If liquid from inside the batteries encounters your skin or clothes, wash it off with water. If emergent battery uid gets into your eyes,
rinse them with cold water immediately and seek medical advice. Do not rub your eyes!
Dispose of empty batteries at a recycling centre.Herewith we declare that this item is in accordance with the essential
requirements and other relevant regulations of the directive 1999/5/EC. A copy of the original declaration of conformity can be
obtained at the following address.

This symbol is marked on a product or packaging, it means that the product including the batteries must not be disposed of with
your general household waste. Only discard electrical/electronic items in separate collection schemes, which cater for the
recovery and recycling of materials contained within. Your co-operation is vital to ensure the success of these schemes and for
the protection of the environment.

»Never y close to other people!
»Do not y in areas with obstacles that may complicate the ight!
»Do not y when it is too windy. Close windows and doors!
»Do not try to catch the helicopter in mid-air when ying. Danger of injury!
»Avoid to touch the helicopter with clothes, hair or ngers.
WARRANTY
!
!
SERVICE & SUPPORT
ACME the game company GmbH
Boikweg 24
33129 Delbrück
Germany
Phone: [phone]
E-Mail: [email protected]
www.acme-online.net
