RK1016T
1U Keyboard Drawer with 16-port KVM Switch
Installation Guide
RK1016T: 1U 88-key Keyboard Drawer with16-port KVM
switch

© Copyright 2009 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
661 Brea Canyon Rd., Suite 3
Walnut, CA 91789
tel: [phone], fax: [phone], www.acnodes.com
RK1016T
1U Keyboard Drawer with 16-port KVM Switch
2.4 Installation
BeforeInstallation,pleasemakesureallofperipheralsandcomputershavebeenturnedoff.
1.Connectthe3-in-1cablewith2mini-din6-pinconnectorsandaHDDB15-pinconnectorthethecomputer
ports.
2.ConnectanotherendofthecabletoKVMswitch.
3.Connecttoamonitortotheconsoleport oftheswitch.
4.Plugthepoweradapterincludedtotheswitch.
5.Afterpoweringoncomputers andfinishingtheboot-upprocess,youcanstartkeyboarddrawerwithPS/2
KVMswitch
