Acnodes Pc 5171 User manual

’

PC 5171

Socket478(P4/P4-M)

17-inch PanelPCSystem

PC 5171 Panel PC System

With LCD / Touch screen (optional)

OPERATION MANUAL

This operation manual is meant to assist users in installing and setting up the

system. The information contained in this document is subject to change

without prior any notice.

This manual is copyrighted August, 2004. You may not reproduce or

transmit in any form or by any means, electronic, or mechanical, including

photocopying and recording.

ACKNOWLEDGEMENTS

All trademarks and registered trademarks mentioned herein are the property

of their respective owners.

CE NOTICE

This is a class A product. In a domestic environment this product may cause

radio interference in which case the user may be required to take adequate

measures.

FCC NOTICE

This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference when

the equipment is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a

residential area is likely to cause harmful interference in which case the user

will be required to correct the interference at his own expense.

You are cautioned that any change or modifications to the equipment not

expressly approve by the party responsible for compliance could void your

authority to operate such equipment.

CAUTION!

Danger of explosion if battery is incorrectly replaced. Replace only with the

same or equivalent type recommended by the

manufacturer.

Dispose of used batteries

according to the manufacturer’s instructions.

WARNING!

Some internal parts of the system may have high electrical voltage. And

therefore

strongly

recommend

that qualified engineers can open and disassemble the

system.

The LCD and touch screen are fragile, please handle them with extra care.

* All information contained in this document is subject to change without prior notice.

Contents

TABLE OF CONTENTS

CHAPTER 1 INTRODUCTION

1-1 About This Manual ....................................................... 1-2

1-2 Case Illustration ............................................................. 1-3

1-3 System Specification ..................................................... 1-4

1-4 Safety Precautions ......................................................... 1-9

CHAPTER 2 SYSTEM

CONFIGURATION

2-1 Jumper & Connector Quick Reference Table ............... 2-2

2-2 Component Locations ................................................... 2-3

2-3 How to Set the Jumpers ................................................ 2-4

2-4 COM Port Connector ………………………………… 2-6

2-5 COM Port RI & Voltage Selection ……………….….. 2-8

2-6 RS232/422/485 (COM2) Selection …………..….…… 2-12

2-7 VGA Connector ……………………………………….. 2-13

2-8 LVDS Connector ……………………………………… 2-14

2-9 Brightness Voltage Selection …………………………. 2-15

2-10 LCD Panel Voltage Selection ………………………… 2-16

2-11 Power Connector ………………………………………. 2-17

2-12 Floppy Disk Drive Connector ………………………… 2-18

2-13 Hard Disk Drive Connector ………..…………………. 2-19

2-14 Printer Connector ……………………………………… 2-21

2-15 LAN Connector ………………….……………………. 2-22

2-16 LAN LED Connector …...…………………………….. 2-22

2-17 Keyboard Connector ………………………………….. 2-23

2-18 PS/2 Mouse Connector ………………………………… 2-23

2-19 Sound Connector ………………………………………. 2-24

2-20 Reset Connector ……………………………………….. 2-25

2-21 HDD LED Connector ………………………………….. 2-25

2-22 Power Button ………………….…................................. 2-26

2-23 External SMI Connector ………………………………. 2-26

2-24 External Speaker Connector …………………………… 2-26

2-25 Keylock Connector ……………………………………. 2-27

2-26 Clear CMOS Selection ………………………………… 2-27

2-27 USB Connector ……………………………………….. 2-28

2-28 Inverter Connector …………………………………….. 2-29

2-29 Reset/NMI/Clear Watchdog Selection ………………… 2-30

2-30 CPU FAN Connector ………………………………….. 2-31

Contents

2-31 System FAN Connector ……………………………….. 2-31

2-32 North Chip FAN Connector …………………………… 2-31

2-33 Power LED Connector ………………………………… 2-32

2-34 Memory Installation ............……….............................. 2-32

2-35 P4/ P4-M CPU Selection ……………………………… 2-33

2-36 Digital Input/Output Connector ……………………….. 2-34

2-37 ATX +12V Power Connector …………………………. 2-34

2-38 LVDS Panel Resolution Selection …………………….. 2-35

CHAPTER 3 SOFTWARE

UTILITIES

3-1 Introduction ................................................................... 3-2

3-2 VGA Driver Utility ....................................................... 3-3

3-3 Flash BIOS Update ....................................................... 3-4

3-4 LAN Driver Utility ........................................................ 3-6

3-5 Sound Driver Utility .............................…...................... 3-7

3-6 Intel® Chipset Software Installation Utility ………… 3-8

3-7 USB2.0 Chipset Software Installation Utility …………. 3-9

3-8 Touch Screen Driver Utility (Optional) ………..…….. 3-9

3-9 USB CF Card Driver Utility (Optional) ……………… 3-9

3-10 Watchdog Timer Configuration .................................... 3-10

CHAPTER 4 AWARD

BIOS

SETUP

4-1 Introduction ................................................................... 4-2

4-2 Entering Setup ............................................................... 4-3

4-3 The Standard CMOS Features ….................................. 4-4

4-4 The Advance BIOS Features ….................................... 4-8

4-5 The Advanced Chipset Features ................................... 4-11

4-6 Integrated Peripherals ……........................................... 4-14

4-7 Power Management Setup ……………………………. 4-18

4-8 PNP/PCI Configuration ................................................ 4-20

4-9 PC Health Status …………………………………….. 4-22

4-10 Frequency / Voltage Control ………………………… 4-24

4-11 Load Fail-Safe Defaults ................................................ 4-25

4-12 Load Optimized Defaults .............................................. 4-25

4-13 Password Setting .................................................…...... 4-26

4-14 Save & Exit Setup ......................................................... 4-27

4-15 Exit Without Saving ...................................................... 4-28

APPENDIX A SYSTEM

ASSEMBLY

Contents

Exploded Diagram for Removing Arm Holder ……………… A-2

Exploded Diagram for Removing Hook Holder ……………… A-3

Exploded Diagram for Removing EXT-Case ………………… A-4

Exploded Diagram for Removing Back Cover ……………….. A-5

Exploded Diagram for Removing LCD Assembly …………. A-6

Exploded Diagram for Front Panel …………………………… A-8

Exploded Diagram for Removing CD-ROM Assembly ……… A-10

Exploded Diagram for Removing HDD Assembly …………… A-11

Exploded Diagram for Removing Motherboard & Power …… A-12

Exploded Diagram for Removing Output Panel ……………… A-13

Exploded Diagram for Removing FDD & CD-ROM ………… A-14

Exploded Diagram for Removing Mask ………………………. A-16

Exploded Diagram for Wall Mounting ……………………….. A-17

APPENDIX B TECHNICAL

SUMMARY

Block Diagram ......................................................................... B-2

Interrupt Map ............................................................................ B-3

RTC & CMOS RAM Map ....................................................... B-4

Timer & DMA Channels Map .................................................. B-5

I/O & Memory Map ................................................................. B-6

INTRODUCTION

CHAPTER

This chapter gives you the inform lso

outlines the System specifications.

Section includes:

About This Manual

Case Illustration

System Specifications

Safety precautions

for a Quick Start.

ge 2-1

Page:1-1

Chapter 1 Introduction

1-1. ABOUT THIS MANUAL

Thank you for purchasing our Panel PC. It is an updated system designed to be

comparable with the highest performance of IBM AT personal computers. It

provides faster processing speed, greater expandability, and can handle more

tasks. This manual is designed to assist you on how to make the proper

installation to set up the system. It contains five chapters. The user can use

this manual for configuration according to the following chapters :

Chapter 1 Introduction

This chapter introduces you to the background of this manual, illustration of

the case, and the specifications for this system. The final page of this chapter

indicates some safety reminders on how to take care of your system.

Chapter 2 System Configuration

This chapter outlines the Prox-7400 components' locations and their functions.

In the end of this chapter, you will learn how to set jumper and how to

configure the system for your own needs.

Chapter 3 Software Utilities

This chapter contains helpful information for proper installations of the VGA

utility, LAN utility, Sound utility and Flash BIOS update. It also describes

the function of the Watchdog Timer.

Chapter 4 Award BIOS Setup

This chapter indicates on how to set up the BIOS configurations.

Appendix A System Assembly

This section gives you the exploded diagram for the whole system unit.

Appendix B Technical Summary

This section gives you the information about the Technical maps.

Page: 1-2 PC 5171 USER MANUAL

Chapter 1 Introduction

1-2. CASE ILLUSTRATION

PC 5171 USER

MANUAL Page: 1-3

Chapter 1 Introduction

1-3. SYSTEM SPECIFICATIONS

MAINBOARD

CPU TYPE:

Intel® Pentium® 4/Pentium® 4-M/Intel® Celeron/ Mobile processors

CPU Frequency 2.0~2.8GHz

Auto detect voltage regulator.

CHIPSET:

Intel® 845GV

MEMORY :

Up to 1GB DDR SDRAM

One 184-pin DIMM sockets on board.

CACHE :

Built-in CPU(128/256KB Cache).

REAL-TIME CLOCK :

CR2023 battery backed CMOS RAM

Hardware implementation to indicate century rollover.

BIOS :

Phoenix-Award Flash BIOS for plug & play function.

Memory size with 4MB and with VGA BIOS.

Support S I/O Setup.

KEYBOARD CONNECTOR :

Mini DIN connector.

Supports PC/AT Keyboard.

MOUSE CONNECTOR :

Mini DIN connector.

Supports PS/2 Mouse.

Page: 1-4 PC 5171 USER

S MANUAL

Chapter 1 Introduction

SSD SOCKET (OPTIONAL) :

One 32-pin socket on board.

Supports Disk-on-chip up to 576MB.

BUS SUPPORT :

External PCI Bus (Riser card support 1P1I/3P3I).

VGA :

Integrated in 845GV, supports CRT & TFT-LCD panel. LCD panel

connector on board for LVDS panel (7305), 15-Pin VGA D-sub connector

on rear panel. Supports LCD backlight turn off function. Chrontel CH7305

supports 18/24-bit 2 channel LVDS panel or CH7304 (Pin-to-pin compatible

to CH7305) supports 18/24-bit 1 channel LVDS panel. ( 20-pin pin header X

2 on-board.)

WATCHDOG :

I / O port 443H to Enable watchdog. I

/ O port 441H to Disable watchdog.

Selectable for NMI or Reset function.

Time-out timing select 0 / 8 / 16 / 24 / 32 / 40 / 48 / 56 / 64 / 72 / 80 / 88 /

96 / 104 / 112 / 120 sec +/- 25%.

IDE INTERFACE :

Two IDE port, support for Ultra ATA-33/66/100/133.

Support up to four IDE devices.

FLOPPY DISK DRIVE INTERFACE :

One 26-pin connector.

Support for slim Floppy Disk Drive.

SERIAL PORT :

Four high speed 16550 Compatible UARTs with Send / Receive 16 Byte

FIFOs.

COM1 (D-Sub Connector) for RS-232;

COM2 (D-Sub Connector) for RS-232/422/485;

COM3 (D-Sub Connector) for RS-232

COM4 (D-Sub Connector) for RS-232.

PC 5171 USER

S MANUAL Page: 1-5

Chapter 1 Introduction

COM1/2/3/4 contain 5V or 12V power capability with 9-pin D-sub

connector on rear panel. COM4 with 9-pin box-header available for

touch panel installed.

PARALLEL PORT :

One 25-pin D-Sub connector on rear panel.

Support for SPP, ECP, EPP Function.

Bi-directional parallel port.

LAN ADAPTER :

Intel® 82541 chip.

RJ-45 jack onboard, Support for 10/100/1000 mbps Ethernet.

Support Wake-On-LAN function.

USB CONNECTOR :

Two USB ports on rear panel.

One internal USB port for touch panel.

Complies with USB Spec Rev 2.0.

SOUND :

RealTek ALC202A , AC’ 97 Codec. The signal of MIC-in, Line-in, Line-

out connectors on rear panel and CD audio-in designed in as a standard

connector.

HARDWARE MONITORING FUNCTION :

Monitor CPU Voltage, CPU Temperature and Cooling Fan.

LED INDICATOR :

System power.

HDD Read/write.

DMA CONTROLLER :

82C37 x 2

DMA CHANNELS :

INTERRUPT CONTROLLERS :

82C59 x 2

Page: 1-6 PC 5171 USER

S MANUAL

Chapter 1 Introduction

INTERRUPT LEVELS :

LCD PANEL

TFT color LCD is manufactured by using very high brightness technology.

Some sequential pixels may not light or may light always, but this is not a

failure.

LCD TYPE :

LCD Panel 17” : Priority source - AU (2 LVDS) or similar model.

PIXEL PITCH :
