Acorn C-9403 User manual

30309218 Issue 1.13
Providing 2 tones.
Standard: EN 54-3.
Description
C-9403 Conventional Sounder Strobe is an audible
and visible alarm device used to warn people in field
when fire occurs. It can give audible and visible alarm
signal when applied to external 24VDC power (D1
connected with positive and D2 with negative).
A 25.5mm high shallow base and a 40mm high deep
base are available. Unless otherwise stated, all
descriptions in this manual take the shallow base as
example.
Connection & Cabling
Terminals on the base are shown in Fig. 2.
?110
110.4mm
95.9mm
Shallow Base
Deep Base
Tamper-proof
knockout Drain Hole
Fig.1
1
D
2
K
1
2
Z
K
Z
1
S
2
D
mm
G
Arrow Upward
Fig. 2
G(10), D1(9), D2(7): Connecting with 24VDC power,
polarity-sensitive. G connects with positive output, D1
with positive input and D2 with negative.
Recommended Wiring
1.5mm2or above fire cable for 24VDC power line,
subject to local codes.
Installation
When surface mounted, the sounder strobe should
be placed 0.2m from the ceiling for normal space
height. When the conduit is embedded, the base
can be mounted on the back box. When the
conduit is surface mounted, the deep base should
be adopted. Knock the knockout hole, and connect
the conduit with it. The mounting hole spacing and
mounting direction are shown in Fig. 2. Mounting
method is shown in Fig. 3a and Fig. 4. The conduit
must be embedded when the shallow base is used,
as shown in Fig. 3b.
The base and the sounder strobe are twisted
together. When mounting, remove the sounder
strobe, thread cables through the cable entry in the
base and connect with corresponding terminals,
then twist the sounder strobe onto the base.
Fig. 3a
Conduit
Back Box
Sounder Strobe
Fig. 3b
Sounder Strobe
Conduit
Fig. 4
If the sounder strobe is required to be tamper-proof,
knock down the arch knockout as shown in Fig. 1
and fix it with ST2.9×6.5 self- tapping screws (in
this case, it can only be removed by a cross
screwdriver).
Application
Tone can set through pins inserted on the main circuit
board.
C-9403
Conventional Sounder Strobe
548e/01
2831-CPR-F0128
GST-0003-01
13
www.acornfiresecurity.com
www.acornfiresecurity.com

Tone Type
Tone
Description
01
2800Hz 0.34s off/0.4s on
02
2400Hz -2900Hz @3Hz
Tone 1: Jumper should be inserted in two
pins on the edge of board as shown in Fig. 5.
VPP
+3.3V
SCL
GND
SDA
Fig. 5
Tone 2: Jumper should be inserted in two
pins on the other side shown in Fig. 6.
VPP
+3.3V
SCL
GND
SDA
Fig. 6
Limited Warranty
GST warrants that the product will be free of charge
for repairing or replacing from defects in design,
materials and workmanship during the warranty period.
This warranty shall not apply to any product that is
found to have been improperly installed or used in any
way not in accordance with the instructions supplied
with the product. Anybody, including the agents,
distributors or employees, is not in the position to
amend the contents of this warranty. Please contact
your local distributor for products not covered by this
warranty.
This product is not approved to EN54-23 (Beacon
Functionality) and must not be used as a visual alarm
device or to provide a primary warning notification of
fire.
WEEE Information
2012/19/EU (WEEE directive): Products
marked with this symbol cannot be
disposed of as unsorted municipal waste
in the European Union. For proper
recycling, return this product to your
local supplier upon the purchase of
equivalent new equipment, or dispose of it at
designated collection points.
Specification
Operating Voltage
Power: 24VDC (20V~28V)
Operating Current
Start current ≤35mA
Flash Frequency
2.0×(1±20%)Hz
Sound Level
Tone 1: not lower than 95dB (at
1m distance)
Tone 2: not lower than 95dB
(at 1m distance)
Ingress Protection
Rating
IP33C
Operating
Temperature
-10℃~ +50℃
Relative Humidity
≤95%, non condensing
Material
of Enclosure
ABS
Dimension
(D×H)
ф110mm×110.4mm (deep base)
ф110mm×95.9mm(shallow base)
Mounting
Hole Spacing
55mm ~ 80mm
Weight
About 355g (deep base) About
327.2g (shallow base)
Sound Level Data (EN54-3 approved)
Tone 2800Hz 0.34s off/0.4s on. Max Volume
Angle
Horizontal
Vertical
Volatge
20V
28V
20V
28V
15°
77.8
79.2
79.9
79.5
45°
86.5
79.4
86.7
88.6
75°
88.0
90.3
88.4
90.3
105°
88.6
90.4
88.5
90.0
135°
87.2
79.1
86.7
79.3
165°
76.7
80.1
76.6
81.7
Tone 2400Hz-2900Hz @ 3Hz. Max volume
Accessories and Tools
Angle
Horizontal
Vertical
Volatge
20v
28v
20v
28v
15°
83.6
86.5
88.5
87.2
45°
91.9
93.7
90.5
94.5
75°
91.8
94.7
91.3
94.7
105°
91.8
94.9
91.6
94.1
135°
91.3
94.4
91.9
93.3
165°
84.9
88.1
85.7
87.9
Model
Name
Remarks
C-94DB
Deep Base
Order separately
