ActionTec MegaPlug HPE400T User manual

85 Mbps
MegaPlug
Ethernet Adapter
Model #: HPE400T
User Manual
Ver 1.0
Solutions for the Digital Life™

i
Table of Contents
1 Introduction 1
Package Contents 1
Features 2
System Requirements 2
Getting to Know the 4-Port Hub 3
Technical Support 4
2 Connecting the MegaPlug Hub 5
Connecting the Hub 5
Installing the Configuration Utility 6
3 Using the Configuration Utility 9
Quick Setup 9
Advanced 10
About 12
4 Troubleshooting 13
Troubleshooting 13
Frequently Asked Questions 14
5 Setting Up Static IP Address 17
Windows 98 SE 17
Windows Me 20
Windows 2000 23
Windows XP 27
6 Setting Up File and Printer Sharing 31
File Sharing 31
Printer Sharing 39
A Specifications 41
General 41
LED Indicators 42
Environmental 42
B Glossary 43
Notices 47
Regulatory Compliance Notices 47
Modifications 47
Miscellaneous Legal Notices 48
Limited Warranty 49

ii
Actiontec HomePlug 4-Port Hub User Manual
ii
This page left intentionally blank.

1
Introduction
Thank you for purchasing the Actiontec MegaPlug 4-Port Hub. The MegaPlug 4-
Port Hub is one of the easiest ways to enjoy home or small business networking. It
operates on the MegaPlug Powerline Specification Turbo standard, providing data
transfer speeds up to 85 Mbps over home AC wiring. Since home power lines are
the most pervasive medium in households, with multiple outlets in every room,
the MegaPlug 4-Port Hub allows multiple desktop and laptop computers to be
networked easily, enabling them to share an Internet connection, printers, files, and
games, without any additional wiring. If you want to take your computer network-
ing to the next level, the Actiontec MegaPlug 4-Port Hub is sure to be one of the
keys to your success.
Package Contents
Make sure the following items came in this package:
s Actiontec 85 Mbps MegaPlug 4-Port Hub
s Ethernet Cable
s Power Cord
s Installation CD (includes this manual)
s Quick Start Guide
1

2
Actiontec MegaPlug 4-Port Hub User Manual
3
Chapter 1 Introduction
Features
s HomePlug Turbo compliant
s 85 Mbps data rate (maximum)
s 56-bit DES encryption
s Two-pronged US power plug (fits ungrounded power outlets)
s Power and Link indicators
System Requirements
s At least 1 available power outlet
s Standard home power wiring
s Computer with the following:
· CD-ROM drive
· IBM compatible running at 200 MHz or better
· Windows 98SE, Me, 2000, or XP installed
· 64 MB of RAM
· Ethernet network Hub
· TCP/IP installed

2
Actiontec MegaPlug 4-Port Hub User Manual
3
Chapter 1 Introduction
Getting to Know the 4-Port Hub
This section contains a quick description of the Hub’s external features.
Front Panel
The Hub’s front panel features six lights (LEDs):
Power Light
The Power light glows green the Hub is powered up (“On”). If the Power light is
off, the Hub is powered down (“Off”).
HP Light
The HP light illuminates when the Hub is connected to a MegaPlug network.
Ethernet Lights (1, 2, 3, 4)
The Ethernet lights glow green when a device is connected to the Hub via the
respectively number Ethernet port.
Rear Panel
The Hub’s bottom panel contains an AC port and four Ethernet port:
Ethernet Ports
The Ethernet ports (1, 2, 3, and 4) are used to connect the Hub to a computer or
gateway/router via Ethernet cable.

4
Actiontec MegaPlug 4-Port Hub User Manual
AC IN Port
The AC IN port is used to connect Hub with an electrical wall socket via the
included Power cable
Information Sticker
The information sticker (located on the bottom of the Hub) displays the MAC
(Media Access Control) address, device ID, and other information about the Hub.
Technical Support
Actiontec Electronics prides itself on making durable, high-quality, high-perfor-
mance products. If you need assistance, the Actiontec Technical Support Department
is available all day every day to provide professional support.
Actiontec Electronics, Inc.
760 N. Mary Avenue
Sunnyvale, CA 94085
Technical Support
Phone: (USA) 1-888-436-0657
E-mail: http://support.actiontec.com/email_support/support_form.php
Internet: www.actiontec.com/support

5
Connecting the
MegaPlug Hub
To connect the Hub, it must be connected to a computer, plugged into a standard
wall outlet, and the Configuration Utility loaded on the computer.
Connecting the Hub
To use the Hub properly, if should be plugged into electrical outlets, and devices
(computers, printers, etc.) connected to them.
Connecting a Hub to a Computer
1. Get a Hub and one Ethernet cable.
2. Insert one end of the Ethernet cable into the Ethernet port of the Hub.
3. Plug the Hub into a wall outlet.
☞
Note: Do not plug the Hub into a UPS or power strip with surge
protection. The Hub’s network signal may not pass through
these devices.
4. Insert the other end of the Ethernet cable into an Ethernet port on the back of
a computer.
Connecting a Hub to a Router/Gateway
1. Get a Hub and one Ethernet cable.
2. Insert one end of the Ethernet cable into the Ethernet port of the Hub.
3. Plug the Hub into a wall outlet.
☞
Note: Do not plug the Hub into a UPS or power strip with surge
protection. The Hub’s network signal may not pass through
these devices.
4. Insert the other end of the Ethernet cable into an Ethernet port on a router/
gateway connected to a computer.
2

6
Actiontec MegaPlug 4-Port Hub User Manual
7
Chapter 2 Connecting the MegaPlug Hubs
5. Insert the other end of the Ethernet cable into an Ethernet port on a router/
gateway connected to a computer.
Follow the instructions in the next section, “Installing the Configuration Utility.”
Installing the Configuration Utility
After connecting the Hub, install the Configuration Utility:
1. Insert the Installation CD in the CD-ROM drive of the computer connected
to a Hub.
2. When the “Welcome” screen appears, click Next.
3. When the “Choose Destination Screen” appears, click Next.

6
Actiontec MegaPlug 4-Port Hub User Manual
7
Chapter 2 Connecting the MegaPlug Hubs
4. When this window appears, click Finish.
5. Repeat for other computers connected to a Hub.
The MegaPlug Hub is now connected and ready to use, and the Configuration
Utility is loaded on the computers. Go to chapter 3, “Using the Configuration
Utility” for information about changing the default configuration settings of the
Hub.

8
Actiontec MegaPlug 4-Port Hub User Manual
This page left intentionally blank.

9
Using the
Configuration Utility
Once the Hub has been properly connected and installed, the user can further con-
figure the Hub using the Actiontec MegaPlug Configuration Utility. The Utility also
provides information about the network. To access the Utility:
1. Click Start on the desktop, then Programs.
2. From the Programs menu, find “Actiontec MegaPlug,” then select MegaPlug
Configuration Utility.
The Utility appears on the desktop. See the following sections for more informa-
tion about the Utility’s capabilities.
Quick Setup
Selecting Quick Setup from the row of tabs near the top of the Utility’s window
generates the “Quick Setup” tab.
Use this tab to quickly set up security on all MegaPlug devices on the network.
3

10
Actiontec MegaPlug 4-Port Hub User Manual
11
Chapter 3 Using the Configuration Utility
Local Device(s) on Your Computer
The list displays all MegaPlug Hubs connected to the computer.
☞
Note: If no Hub appears in the Device List, make sure the Hub
is connected properly (with the appropriate Ethernet cable) to
the computer. Then, unplug the Hub, and plug it back in again.
If, after performing these actions, no Hub appears in the Device
List, the Hub may be defective. Contact technical support.
MegaPlug Encryption Key
Enter an encryption key in this text box to provide security for your MegaPlug
network. A key is similar to a password, and can be made up of any combination
of letters or numbers, from 4 to 24 characters long. Once activated, this key must
be entered into a device’s network configuration to join the MegaPlug network.
P
Important: All Hubs on the same network must have the
same encryption key. If not, they will not be able to connect.
Set Local Device Only
Click this button to encrypt the device selected in the “Local Device(s) on your
computer” list box.
Advanced
Selecting Advanced from the row of tabs near the top of the Utility’s window gen-
erates the “Advanced” tab.

10
Actiontec MegaPlug 4-Port Hub User Manual
11
Chapter 3 Using the Configuration Utility
Local Device(s) on Your Computer
The list displays all MegaPlug Hubs connected to the computer.
☞
Note: If no Hub appears in the Device List, make sure the Hub
is connected properly (with the appropriate Ethernet cable) to
the computer. Then, unplug the Hub, and plug it back in again.
If, after performing these actions, no Hub appears in the Device
List, the Hub may be defective. Contact technical support.
Network List
The Network List (the list box at the center of the Network tab) lists all other Hubs
connected to this MegaPlug network. Only Hubs with the same password as the
Hub connected to this computer are shown on this list. The available Hubs are
listed by their MAC addresses, and include their device name, device ID, and the
quality of the connection.
Add
Clicking this button allows the user to add a MegaPlug Hub to the network. In the
window that appears, enter the device name and password in the appropriate text
boxes, then click OK.
Rename
Clicking this button allows the user to rename a MegaPlug Hub listed in the Network
List. Select the device from the Network list, click Rename, then enter the new name.
Enter Device ID
Clicking this button allows the user to enter a MegaPlug Hub device ID. The device
ID is found on the sticker attached to the Hub (see page 3).
MegaPlug Encryption Key
Enter an encryption key in this text box to provide security for your MegaPlug net-
work. A key is similar to a password, and can be made up of any combination of
letters or numbers, from 4 to 24 characters long. Once activated, this key must be
entered into a devices network configuration to join the MegaPlug network.

12
Actiontec MegaPlug 4-Port Hub User Manual
Set All Devices
Click this button to encrypt all devices on the MegaPlug network.
About
Selecting About from the row of tabs near the top of the Utility’s window gener-
ates the “About” tab.
The About tab displays the MegaPlug Configuration Utility version.

13
Troubleshooting
This chapter contains a list of problems that may be encountered while using the
MegaPlug 4-Port Hub, and techniques to solve them. Note that these techniques may
not be successful in all cases. Also included is a list of frequently asked questions.
Troubleshooting
If the Hub is showing signs of trouble, before attempting any other troubleshoot-
ing procedures, plug the Hub into a working electrical wall socket.
The Power light doesn’t light up after I plug the Hub into a wall outlet.
First, make sure the Hub is installed and connected correctly. Then, ensure the
wall outlet is working by plugging other electric devices into it. If it is working,
plug in the Hub again, and if the Power light still doesn’t illuminate, try plugging
it into other wall outlets. If the Hub is still experiencing this problem, contact
technical support.
The Link light doesn’t light up on the Hub.
If one of the Hub’s Ethernet lights is not illuminating, a LAN connection is not
being detected.
s Make sure the Hub is installed and connected correctly.
s Check the Hub on the computer and make sure it is enabled and working
properly. Also, make sure the right type of Ethernet cable is being used.
I can’t connect to the Internet or any of the other computers on the network.
s Make sure the IP address and TCP/IP protocol are set up properly for all the
computers on the network, then try to ping the gateway.
s Use the Hub’s Configuration Utility to detect all other Hubs on the network.
Then, plug the Hubs into adjacent sockets. If the Ethernet lights still don’t
illuminate, contact technical support.
4

14
Actiontec MegaPlug 4-Port Hub User Manual
15
Chapter 4 Troubleshooting
The Power and Link lights are on, but I can’t access the router/gateway from
the computer
s Try plugging the Hub in different power outlets.
s Make sure all Hubs on the network are using the same security parameters.
Frequently Asked Questions
What’s the transfer speed over the Hub’s network?
The Hub’s network transfer speed is 85 Mbps (maximum) over a standard home
power line network.
What’s the estimated range of the Hub’s network?
Approximately 300 meters (~985 ft.) in wall power lines (one household).
Will the Hub work in any home?
The Hub will work in any home with built-in copper wiring. It may not operate
in some older homes (pre-1950) with alternate wiring.
Will the Hub’s network signal pass through circuit breakers?
Yes, the Hub’s network signal will pass through circuit breakers. It will not, how-
ever, pass through power transformers.
Does the Hub work with a 100 – 240V AC input ?
Yes.
Does using the Hub cause any interference with other home networking
devices?
No. The Hub operates at a different frequency than other power line control
devices and can co-exist with technologies such as X-10, CEBus, and LONworks.

14
Actiontec MegaPlug 4-Port Hub User Manual
15
Chapter 4 Troubleshooting
Can my neighbor receive the Hub’s network signal?
It is possible for a neighbor to receive the network signal. To prevent this, change the
default 56-bit DES security encryption password on the Hub (see chapter 3).
How do I find out what the current speed and signal strength of the Hub’s
network is?
Run the Hub’s Configuration Utility to show current speed and signal strength.
How many Hubs do I need to set up a network?
One.
To set up the Hub’s network correctly, do I have to install the Configuration
Utility on each computer on the network?
No, the Configuration Utility is a diagnostic and security tool. Since the Hub is
fully plug-and-play compatible, it needs no software drivers to operate.
How many Hubs can be installed on the same LAN (local area network)?
Actiontec recommends using no more than 16 Hubs on one network.

16
Actiontec MegaPlug 4-Port Hub User Manual
This page left intentionally blank.

17
Setting Up Static
IP Address
To communicate with a MegaPlug 4-Port Hub from a computer on the network,
the user may have to switch the IP address settings from DHCP-enabled to static IP,
so that the computer and the Hub are on the same subnet.
To set up static IP on a computer, select the operating system and follow the
instructions.
☞ Note: The following procedures are based on the Hub’s factory
default IP address. If the Hub’s IP address has been changed,
enter the new IP address when instructed to enter an IP address.
Windows 98 SE
1. From the desktop, click on the Start button in the lower left corner.
2. From the menu that appears, select Settings.
5
