ActionTec R1524SU User manual

The Actiontec Wireless-Ready DSL Gateway offers
Local Exchange Carriers and Internet Service
Providers a comprehensive and expandable DSL
Gateway solution. It features a full-rate ADSL modem
integrated with a 4-port 10/100 Mbps Ethernet switch
to provide the end user with a simple and nearly instant
broadband home network.
The Gateway is capable of speeds up to 8 Mbps downstream
and 1 Mbps upstream. It has been tested with all major
DSLAMs,each with multiple line cards and is compliant with
all major ADSL standards, including T1.413i2 and G.dmt.
The ActiontecWireless-Ready DSL Gateway has been carefully
designed to maximize performance and compatibility at all
loop lengths.**
The integrated 4-port Ethernet switch allows users to share
files and resources at speeds up to 100 Mbps. The advanced
built-in router supports a variety of networking protocols
and provides easy configuration, maximum security and full
network compatibility. The Gateway also features a firewall,
Internet service blocking, Web site blocking and full logging
support.
TheActiontecWireless-ReadyDSLGatewayisupgradeablevia
two open PC card slots. One slot accepts an 802.11b wireless
card that provides full access point services to computers on
the wireless network. The second slot will support a variety
of PC Cards to extend the networking functionality of the
Gateway.*
DSL and network configuration are handled through a
browser-based wizard that walks the end user through the
simple process step-by-step. This Gateway also features the
Actiontec Installation BuddyTM software designed to easily
guidethe enduserthroughinstallation andsetupof theirnet-
work.Thishelpstoeliminatemanytechnicalsupportcallsand
problems in the field. The Actiontec Wireless-Ready DSL
Gateway is compatible with any computer built with a RJ-45
Ethernet or USB (PC only) port and Web browser. Setup is
further simplified through color-coded Ethernet and USB
cables and connectors.
·Full-rate ADSL Modem
Supports speeds up to 8 Mbps downstream,1Mbps upstream**
·T1.413i2 and G.dmt Compliant
Supports full range of ADSL standards at up to 18,000 feet ***
·Exceeds DSL Forum Performance Specifications
·Compatible With All Major DSLAMs
·LAN: Available as a 4-Port 10/100 Mbps Auto Sensing
Ethernet Switch
·
USB LAN Port
·
2 PC Card Slots for Expansion (i.e.,802.11b wireless (64/128 bit WEP)
·Advanced Security
Firewall, using Stateful Packet Inspection,Website & Web Service
Blocking,Internet traffic logging, wireless MAC Address Authentication
·Advanced Network Services
PPPoE (client),DNS (client), TFTP (client/server),DHCP
(client/server), and NAT
·Other Features include:
·WAN IP Address Selection
·Unnumbered Mode & VIP Mode Support
·LAN IP Address Selection (Configurable LAN Subnet Mask)
·DHCP Server Option
·NAT Services Blocking
·VPN Pass Through***
·Remote Management
·Port Fowarding
·DMZ Hosting
·Mac Address Cloning
·Static & Dynamic (RIP V1, V2) Routing
Features
Wireless-Ready
DSL Gatewa
y
Model Number:
R1524SU
WR DSL Gateway 2.7.03.qxd 2/7/03 10:25 AM Page 1

• PC or Macintosh with Ethernet network adapter or
USB (PC only)
•Microsoft Windows:98SE / ME / NT / 2000 / XP,
MacOS 8.01 or higher
(USB: Windows 98SE,ME, 2000, XP)
• TCP/IP installed
• Internet Explorer 4.0+ or Netscape 4.0+
• Wireless-Ready DSL Gateway
• Power Supply
• Installation BuddyTM CD-ROM
• User’s Manual on CD-ROM
• Quick Start Guide
• Ethernet Network Cable (RJ-45)
• USB Cable
• RJ-11 Phone Cable
• Phone Filters are Optional
PackageContents
Minimum System Requirements
BroadbandTechnology Made Easy
Specifications
Interface Ports
ADSL Features
ATM and AAL Support
Standards Compliance
VPN Support
Setup and Management
Optional Router Features
Protocols Supported
Visual Indicators
Maximum Computer Users Supported
Compliance Certification
LimitedWarranty
Internet (WAN): (1)ADSL RJ-11, (1) Phone Port with filter
Network (LAN): 4-Port 10/100 Mbps Auto-sensing
Ethernetswitch, USB
PC Card: Two PCMCIA expansion slots
Top slot for wireless 802.11b PC Card*
Bottom slot for PC Expansion cards
exclusively from Actiontec*
Embedded full-rate ADSL Modem
Compliant with T1.413, G.dmt and G.lite
G.dmt full-rate connectivity at up to 8 Mbps
downstream,1 Mbps upstream
Up to 18,000 feet loop reach (over standard
loops)**
AAL5
ATM Transmission Convergence (TC) layer
Support for full range of PVC settings
Hardware SAR
ADSL G.dmt (ITU G.992.1,ANSI TI.413)
ADSL G.lite (ITU G.992.2)
Bridge/Routed RFC 1483 (2684), RFC 2364,RFC 2516
IEEE 802.3 10 Base-T Ethernet
IEEE 802.3u 100 Base-Tx Fast Ethernet
PPTP, L2TP,IPSec (all pass-through)***
Web-based
RFC 2516 (PPPoE), 2364 (PPPoA) clients
TCP
IP, UDP
NAT, PAT
DHCP (client, server)
DNS (client)
TFTP (client, server)
SMTP, POP3
WAN Link, LAN Link/Traffic,PC Card,Power
253
FCC Part 15,FCC Part 68, UL
One year
* PC Cards must be from Actiontec or Actiontec certified for use with the Actiontec Wireless-
Ready DSL Gateway.
** Actual speeds achieved are a factor of line conditions, distance between the gateway and
Central Office, and the configuration of the DSL Network, among other things .
© 2003 Actiontec Electronics, Inc.Actiontec,and the Actiontec logo are trademarks of Actiontec
Electronics,Inc.All other names are properties of their respective owners.
Product photo may differ from actual product,however functionality remains as stated above.
WRDG/1202
Wireless-Ready DSL Gateway
