ActionTec GT701-WG User manual

54 Mbps
Wireless
DSL Gateway
Model #: GT701-WG
Firmware Version: 3.0.1.0.6.0-GT701-WG
User Manual
Ver 2.0
Solutions for the Digital Life™

i
Table of Contents
1 Introduction 1
Package Contents 1
Minimum System Requirements 2
Features 2
Getting to Know the Gateway 4
2 Setting Up the Gateway 7
Connecting a Computer to the Gateway 7
Installing Phone Filters 20
Setting Up the DSL Connection 25
3 Performing a Basic Setup 31
Basic Setup 31
Changing the User Name and Password 33
4 Using Advanced Setup 35
Accessing Advanced Setup 35
WAN IP Address 36
LAN IP Address 40
DHCP Server 40
Services Blocking 42
Website Blocking 43
Remote Management 44
Application Layer Gateway and Port Forwarding 45
DMZ Hosting 46
Firewall 47
Dynamic Routing 49
NAT (Network Address Translation) 50
Static Routing 50
UPnP (Universal Plug and Play) 51
Time Zone 51
Remote Syslog Capture 52
Wireless Settings 52
Wireless MAC Authentication 56
Wireless Advanced Settings 57
5 Viewing the Gateway’s Status 59
General Status 59
Routing Table 61
ARP Table 61
WAN Status 62
LAN Status 63
Active User List 63

ii
Actiontec 54 Mbps Wireless DSL Gateway User Manual
ii
6 Using Utilities 65
Web Activity Log 65
System Log 66
DSL Settings 67
Restore Default Settings 68
Upgrade Firmware 68
7 Setting Up a Network 69
Ethernet 69
USB 74
Wireless 78
8 Troubleshooting 79
Troubleshooting 79
Frequently Asked Questions 80
a Reference 85
Locating Computer Information 85
Locating Windows Operating System Files 86
b Setting Up Static IP on the Computer 89
Windows 98 SE 89
Windows Me 92
Windows 2000 95
Windows XP 99
c Computer Security 103
Comparing DSL Service with a Dial-Up Modem 103
Gateway Security 104
Computer Security 104
Electronic Security 105
d Specifications 107
General 107
Wireless Operating Range 108
LED Indicators 108
Environmental 108
e Glossary 109
f Non-Windows System Setup 113
Classic 113
OS X 115
Notices 117
Regulatory Compliance Notices 117
Modifications 117
Miscellaneous Legal Notices 118
Limited Warranty 119

1
Introduction
Thank you for purchasing the Actiontec 54 Mbps Wireless DSL Gateway. The
Gateway is the simplest way to connect computers to a high-speed broadband
connection. This easy-to-use product is perfect for the home office or small busi-
ness. If you want to take your computing to the next level, the Actiontec 54 Mbps
Wireless DSL Gateway is sure to be one of the keys to your success.
Package Contents
s Actiontec 54 Mbps Wireless DSL Gateway
s Black Bag
s Phone filters
s Yellow (Ethernet) cable
s Purple (USB) cable
s Installation CD
s Quick start guide
s Start here guide
s Wireless start here guide
s Technical support card
1

2
Actiontec 54 Mbps Wireless DSL Gateway User Manual
3
Chapter 1 Introduction
Minimum System Requirements
s Active DSL service
s Computer with a 10/100 Mbps Ethernet connection, or USB connection
s Microsoft Windows 98 Second Edition (SE), Windows Millennium Edition
(Me), Windows NT 4.0, Windows 2000, Windows XP, Mac OS 7.1 and above
☞ Note: USB LAN port is not supported with Microsoft Windows
NT 4.0 or any Mac OS.
s Internet Explorer 4.0 or higher (5.x recommended) or Netscape Navigator
4.0 or higher (4.7 recommended)
s TCP/IP network protocol installed on each computer
Features
s Plug-and-Play installation support for systems with Windows operating
systems (98, 98SE, Me, 2000, and XP)
s ADSL WAN port (RJ-11)
s Compliant with full-rate ANSI T1.413 Issue 2, ITU G.992.1 (G.dmt) and
G.992.2 (G.lite) standard
s Auto-handshake for different ADSL flavors
s USB 1.1 device specification compliance
s 12 Mbps USB data rate (full speed)
s Multiprotocol Encapsulation over ATM, PPP over ATM, PPP over Ethernet
s Precise ATM traffic shaping
s IP packet routing and transparent bridging
s Routing protocol supports RIP-1, RIP-2, static routing
s Built-in NAT, DHCP server

2
Actiontec 54 Mbps Wireless DSL Gateway User Manual
3
Chapter 1 Introduction
s DNS relay support
s PAP/CHAP authentication, administrative passwords through Telnet and
HTTP
s 64-, 128-, and 256-bit WEP/WPA wireless LAN security
s Compliant with IEEE 802.3 Ethernet standard
s 10/100 Base-T Ethernet port
s Flow control support for Fast Ethernet
s Web-based configuration setup
s Default configuration backup restore
s Firmware upgradeable
s Web download support
s 802.11b/g support

4
Actiontec 54 Mbps Wireless DSL Gateway User Manual
5
Chapter 1 Introduction
Getting to Know the Gateway
This section contains a quick description of the Gateway’s lights, ports, etc.
The Gateway contains several indicator lights (LEDs) on its front panel and a series
of ports on its rear panel.
Front Panel
The front panel of the Gateway features six lights: Power, DSL, Internet,
Ethernet, USB, and Wireless.
Power
DSL
Internet
Ethernet
USB
Power
DSL
Internet
Ethernet
USB Wireless
Wireless
Power Light
The Power light displays the Gateway’s current status. If the Power light glows
steadily green, the Gateway is receiving power and fully operational. When the
Power light flashes rapidly, the Gateway is initializing. If the Power light is not
illuminated when the Power cord is plugged in and the Power switch is turned
on, the Gateway has suffered a critical error and technical support should be
contacted.
DSL Light
The DSL light illuminates when the Gateway is connected to a DSL (Digital
Subscriber Line) line. When it flashes, the Gateway’s built-in DSL modem is
training for DSL service.

4
Actiontec 54 Mbps Wireless DSL Gateway User Manual
5
Chapter 1 Introduction
Internet Light
When the Internet light glows steadily, the Gateway is connected to the DSL pro-
vider.
Ethernet Light
The Ethernet light illuminates when the Gateway is connected via its Ethernet
port.
USB Light
The USB light illuminates when the Gateway is connected via its USB port.
Wireless Light
The Wireless light illuminates when the Gateway is activated for wireless use.
Rear Panel
The rear panel of the Gateway contains seven ports (Line, Phone, USB, Ethernet,
and Power), as well as a Reset switch.
Power
USB
Ethernet
Line
Reset
Phone
Line Port
The Line port is used to connect the Gateway to a DSL connection.

6
Actiontec 54 Mbps Wireless DSL Gateway User Manual
Phone Port
The Phone port is used to connect the Gateway to a telephone.
USB Port
The USB port is used to connect a computer to the Gateway via USB cable.
Ethernet Port
The Ethernet port is used to connect a computer to the Gateway via a straight-
through Ethernet cable. A crossover Ethernet cable cannot be used when con-
necting to this port.
Power Port
The Power port is used to connect the Power cord to the Gateway.
N Warning: Do not unplug the Power cord from the Gateway
during the reset process. Doing so may result in permanent
damage to the Gateway.
Reset Switch
Depressing the Reset switch for one or two seconds will power cycle the Gateway
(similar to unplugging and then plugging in the Gateway’s Power cord). To
restore the Gateway’s factory default settings, depress and hold the Reset switch
for approximately 10 seconds. The reset process will start about 10 seconds after
releasing the switch.

7
Setting Up
the Gateway
The instructions that follow parallel the steps contained in the Actiontec Installation
Buddy™, which provides a visual guide to setting up the Gateway. It is recommended
the user run the Installation Buddy first, before attempting any other procedures.
To set up the Gateway, it must be connected to a computer, and then configured.
After connecting this first computer, other computers can be added to the network
via USB, Ethernet, or wirelessly (see “Setting Up a Network” on page 69).
Connecting a Computer to the Gateway
Connecting a computer to the Gateway for setup involves three basic steps: initial
setup, plugging in the Gateway’s power cord, and connecting the Gateway to the
computer.
Connecting Via Ethernet
1. Insert the Installation CD in the CD-ROM drive of the computer. The
Installation Buddy starts automatically. Wait until the following screen
appears, read the on-screen instructions, then click Next.
2

8
Actiontec 54 Mbps Wireless DSL Gateway User Manual
9
Chapter 2 Setting Up the Gateway
2. Read the instructions, select Initial Setup by clicking on the appropriate check
box, then click Next.
3. Click in the check box next to Ethernet (Recommended), then click Next.

8
Actiontec 54 Mbps Wireless DSL Gateway User Manual
9
Chapter 2 Setting Up the Gateway
4. Make sure the items needed to connect the Gateway to the first computer are
included in the kit, then click Next.
5. Get the Gateway from the kit, then click Next.

10
Actiontec 54 Mbps Wireless DSL Gateway User Manual
11
Chapter 2 Setting Up the Gateway
6. Get the Power cord and plug the smaller end into the black Power port on
the rear panel of the Gateway, then click Next.
7. Plug the larger end of the Power cord into a power outlet, then click Next.

10
Actiontec 54 Mbps Wireless DSL Gateway User Manual
11
Chapter 2 Setting Up the Gateway
8. Confirm the Power light on the front of the Gateway glows solid green, then
click Next.
9. Get the yellow Ethernet cable from the kit and plug one end into the yellow
Ethernet port on the back of the Gateway, then click Next.

12
Actiontec 54 Mbps Wireless DSL Gateway User Manual
13
Chapter 2 Setting Up the Gateway
10. Plug the other end of the yellow Ethernet cable into an Ethernet port on
the back of the computer. Click Next.
☞ Note: An Ethernet port looks similar to a phone jack, but is
slightly larger.
11. Make sure the Ethernet light on the front of the Gateway glows solid green.
Click Next.

12
Actiontec 54 Mbps Wireless DSL Gateway User Manual
13
Chapter 2 Setting Up the Gateway
12. Get the green DSL cable from the kit and plug one end into the gray Line
port on the rear panel of the Gateway. Click Next.
13. Plug the other end of the green DSL cable into the phone jack closest to the
computer. Click Next.
The Gateway is connected to a computer via Ethernet. Next, install the filters as
described in “Installing Filters” on page 20.

14
Actiontec 54 Mbps Wireless DSL Gateway User Manual
15
Chapter 2 Setting Up the Gateway
Connecting Via USB
1. Insert the Installation CD in the CD-ROM drive of the computer. The
Installation Buddy starts automatically. Wait until the following screen
appears, read the on-screen instructions, then click Next.
2. Read the instructions, select Initial Setup by clicking on the appropriate check
box, then click Next.

14
Actiontec 54 Mbps Wireless DSL Gateway User Manual
15
Chapter 2 Setting Up the Gateway
3. Click the check box next to USB, then click Next.
4. Make sure the items needed to connect the Gateway to the first computer are
included in the kit, then click Next.

16
Actiontec 54 Mbps Wireless DSL Gateway User Manual
17
Chapter 2 Setting Up the Gateway
5. Get the Gateway from the kit, then click Next.
6. Get the Power cord and plug the smaller end into the black Power port on
the rear panel of the Gateway, then click Next.

16
Actiontec 54 Mbps Wireless DSL Gateway User Manual
17
Chapter 2 Setting Up the Gateway
7. Plug the larger end of the Power cord into a power outlet, then click Next.
8. Confirm the Power light on the front of the Gateway glows solid green, then
click Next.
