ActronAir SCA260C User manual

Commercial
Split Ducted Unit
Installation and Commissioning Guide - Outdoor
Model Numbers
CRA300T SCA260C
SCA290C
SCA300C
SCA330C
SCA340C
SCA400C
IMPORTANT NOTE:
Please read this manual carefully before installing or operating your air conditioning unit.
That’s better. That’s Actron.

Installation and Commissioning Guide - Standard Commercial Split Ducted Commercial Outdoor Unit
Doc. No.0525-056 Ver. 7 220308
Installation and Commissioning Guide Split Ducted Outdoor Units
2
Table of Contents
. Introduction .............................................................................................................................. 
. Information About This Guide 
. Product Inspections 
. Codes, Regulations And Standards 
. Important Safety Symbols And Labels 
. General Information ..................................................................................................................
. Safety Instructions ....................................................................................................................
. Installation Information ............................................................................................................
. Operation Manual Access ..........................................................................................................
. Components Overview ..............................................................................................................
. Unit Dimensions, Clearances and Weights .................................................................................
. Unit Dimensions 
. Minimum Service Access Area, Airflow Clearances and Weights 
. Banking of Units ......................................................................................................................
. Unit Lifting Procedure .............................................................................................................
. Outdoor Unit Preparation ........................................................................................................ 
. Field Pipe Connection .............................................................................................................. 
. Piping and Brazing 
. Pressure Testing 
. Evacuation Procedure (Triple Evacuation) 
. Electrical Installation ............................................................................................................... 
. Split Unit Electrical Connection ...............................................................................................
. Control Cable Length and Specification ...................................................................................
. Refrigerant Charging ...............................................................................................................
. Maintenance ...........................................................................................................................
. Maintenance Frequency Checklist ........................................................................................... 
. Key Parts List ...........................................................................................................................
. Start Up and Commissioning Report ........................................................................................

Installation and Commissioning Guide Split Ducted Outdoor Units
Installation and Commissioning Guide - Standard Commercial Split Ducted Commercial Outdoor Unit
Doc. No.0525-056 Ver. 7 220308
3
. Introduction
CONGRATULATIONS on your purchase of an ActronAir air conditioning system! This unit has been designed and
engineered to provide optimum air conditioning and to achieve maximum energy efficiency.
Your air conditioning system has been manufactured from the highest quality materials. Numerous “in house” and
“external” inspection and test procedures were conducted to your air conditioning to ensure satisfactory operation.
01.01. Information About This Guide
This guide provides installation instructions, specific to your split ducted unit. Read this manual thoroughly and take
into consideration all specifications and instructions to ensure correct installation and safe operation of your air
conditioning system.
IMPORTANT
Keep this document for future reference. Ensure all technicians that work on the unit can refer to this manual at any time.
01.02. Product Inspections
Check your air conditioning unit and all items against the invoice upon receiving your shipment. Inspect the unit,
components and accessories for any sign of damage. If there is any damage to the unit, contact ActronAir Customer
Care Department immediately on: 1300 522 722 to obtain a Goods Return Number.
Check the unit nameplate to verify the model, serial number, electrical rated specifications are correct.
01.03. Codes, Regulations And Standards
The installer and/or contractor assumes responsibility to ensure that unit installation complies with the relevant
council, state / federal codes, regulations and building code standards. All electrical wiring must be in accordance with
current electrical authority regulations and all wiring connections to be as per electrical diagram provided with the unit.
01.04. Important Safety Symbols And Labels
Safety Symbols and labels appear at appropriate sections throughout this manual to indicate immediate or potential
hazards. Pay full attention and comply to the safety information and instructions. Failure to follow safety instructions
increases the risks of personal injury, death and/or property damage. Damages to the product as a result of such failure
may void warranty.
ActronAir has endeavored to provide sufficient safety warnings and recommendations, however current and prevailing
WH&S regulations must be observed and will take precedent whenever performing the installation instructions
discussed in this manual.
. General Information
The ActronAir Series Ducted air conditioning units are designed for applications where superior performance, high
efficiency, reliability, supply air quality and quiet operation are the prime priorities. The units are built with the latest
technology, fixed speed scroll compressor, EC indoor fans (on specific models), low-noise outdoor fans and an intelligent
electronic control.
For optimum efficiency, your air conditioning unit will deliver just the right amount of cooling or heating capacity you
demand. Even in extreme conditions, the unit will still supply the required demand at peak performance.
WARNING
EC Motors are fitted with high power capacitors and can have dangerous residual voltages at motor terminals after power has
been isolated. Wait at least 5 minutes after power isolation and test for any residual voltage before beginning service work.

Installation and Commissioning Guide - Standard Commercial Split Ducted Commercial Outdoor Unit
Doc. No.0525-056 Ver. 7 220308
Installation and Commissioning Guide Split Ducted Outdoor Units
4
Energy Efficient Refrigeration Circuits
The ActronAir refrigeration system was designed with the application of highly effifficient capacity circuit that deliver the
required amount of cooling or heating to maintain your desired space comfort at optimum effifficiency.
Each refrigeration circuit consists of:
•High effifficiency scroll compressor.
•Hydrophilic Blue Fin coil protected condenser designed for optimum performance and efficiency with corrugated fins
and riffled tubing.
•Hydrophilic Blue Fin coil protected evaporator coil designed for optimum performance and efficiency with lanced fins
and riffled tubing.
Evaporator Section
The commercial series evaporator section has EC fans (on most models) which deliver the nominated airflow. The fans
provide superior performance for your comfort at optimum efficiency:
•Highly efficient variable EC motor that uses less energy than the traditional AC motor.
•Low noise operation.
•Adjustable indoor airflow.
Condenser Section
Uses multiple speed outdoor fans and a state of the art scroll compressor, with the following features:
•Highly efficient axial fans with direct drive AC motor
•Low noise operation
•Multi speed outdoor fan
•Low ambients coolng operation to +5oC
Electrical Section
The electrical section is composed of a separate panel for controls, protecting the components from the elements.The electrical section is composed of a separate panel for controls, protecting the components from the elements.
Durable Design and ConstructionDurable Design and Construction
ActronAir is an Australian manufacturer with proven high quality air conditioning products. Known for their durability andActronAir is an Australian manufacturer with proven high quality air conditioning products. Known for their durability and
reliable performance, these products are designed and built to withstand the extreme weather conditions.reliable performance, these products are designed and built to withstand the extreme weather conditions.
The galvanized steel cabinet, with powder coatedThe galvanized steel cabinet, with powder coated epoxy enamel finish, resists the toughest conditions. The louveredfinish, resists the toughest conditions. The louvered
outdoor coil guard protects the condenser coil from any potential damage brought by hail, stones and other solid objectsoutdoor coil guard protects the condenser coil from any potential damage brought by hail, stones and other solid objects
that may be projected to the unit.that may be projected to the unit.
Hydrophilic Blue Coil Protection heat exchangers ensures an enhanced heat transfer with increased performance
efficiency.
System Flexibility
The ActronAir air conditioning units are the first choice for residential, office, schools and other air conditioning facilities
applications, both for new construction or retrofitting projects.
Refrigerant Handling and Accountability
ActronAir strongly urges that all service technicians make every effort to eliminate and/or vigorously reduce the emission
of refrigerants to the atmosphere. Everyone must act in a responsible manner to conserve refrigerants.
Sustainability and Environmentally Friendly
The air conditioning system is supplied with zero ozone depleting R-410A refrigerant, which has no phase out or
replacement concern.
With cooling and heating performance capacity that are among the best in the market, the ActronAir air conditioning
units provide the solution for the reduction of energy consumption, COemission, high fuel dependency and high
network grid demand.

Installation and Commissioning Guide Split Ducted Outdoor Units
Installation and Commissioning Guide - Standard Commercial Split Ducted Commercial Outdoor Unit
Doc. No.0525-056 Ver. 7 220308
5
. Safety Instructions
•Only licensed HVAC technicians* should install and service this air conditioning equipment. Improper service or
alteration by an unqualified technician could result in significant and major damage to the product or property which
may render your warranty null and void. Such unqualified service could also lead to severe physical injury or death.
Follow all safety instructions in this literature and all warning labels that are attached to the equipment.
•Prevailing WH&S regulations must be observed and will take precedence to the safety instructions contained on this
manual. Safe work practices and environment must be the paramount importance in the performance of all the service
procedures.
•Ensure that unit installation complies with relevant council regulations and building code standards.
•All electrical wiring must be in accordance with current electrical authority regulations and all wiring connections to be
as per electrical diagram provided.
•Secure the fans against accidental contact. Beware of pinch point and sharp edges which can cause cutting injury.
•Always wear appropriate PPE, remove any dangling jewellery and protect long hair by wearing a cap.
•Make sure that safety guards and panel covers are always firmly secured and not damaged.
•This appliance is not intended for use by young children or infirm persons unless they have been adequately supervised
by a responsible person to ensure that they can use the appliance safely. Young children should be supervised to ensure
that they do not play with the appliance.
•Installer must incorporate a means of electrical disconnection (isolator) in the sub mains fixed wiring in accordance
with the latest edition of the AS/NZS 3000 (also known as Australian Wiring Rules).
•Secure the power cords and control cables that goes in/out the unit. Use the cable ties provided in the control box.
•This unit is designed for use with R-410A refrigerant only.
*Qualifications required will be appropriate Electrical, Refrigeration and Refrigerant Handling License and Training
dependent on local State/Territory regulations.
DANGER
Hazardous Voltage - Risk of Electrocution.
Turn Off the power from main isolator before proceeding with any service work of the unit. Observe proper
LOCK-OUT/TAG-OUT (LOTO) procedures for electrical appliances in order to prevent accidental switching-on of the power
supply. Extreme care and caution must be observed should there be a need to work on live circuit.
CAUTION
Beware of Rotating Fans!
Ensure that indoor and outdoor fans are isolated and have come to a complete stand still before servicing the equipment.
Beware of pinch point and sharp edges which can cause cutting injury. Secure the fans against accidental contact.
Always wear appropriate PPE and remove any dangling jewellery and protect long hair by wearing a cap. Ensure that no loose
clothing can be caught / entangled in moving parts.
VISUAL INSPECTION AND WORK ASSESSMENT
Work areas and conditions must first be assessed and evaluated for any potential hazardous conditions. It is also important to be
familiar with the unit parts and components before proceeding with any service task.

Installation and Commissioning Guide - Standard Commercial Split Ducted Commercial Outdoor Unit
Doc. No.0525-056 Ver. 7 220308
Installation and Commissioning Guide Split Ducted Outdoor Units
6
. Installation Information
All service technicians handling refrigerant must be licensed to handle refrigerant gases.
Recover and Recycle Refrigerants
Never release refrigerant to the atmosphere! It is an offence in Australia to do so. Always recover, recycle and reuse
refrigerants. When removing from the system, properly contain and identify refrigerants in its dedicated container for
proper disposal and/or storage. Always consider the recycle or reclaim requirements of the refrigerant before beginning
the recovery procedures. Obtain a chemical analysis of the refrigerant if necessary. For the recovered refrigerant and
acceptable refrigerant quality refer to the existing standards and regulations.
Refrigerant Handling and Safety
Consult the refrigerant manufacturer’s Material Safety Data Sheet (MSDS) for information on proper handling and to
fully understand health, safety, storage and disposal requirements. Use the approved containment vessels and refer to
appropriate safety standards. Comply with all applicable transportation standards when shipping refrigerant containers.
Service Equipment and Recovery Procedures
Always use refrigerant reclaiming equipment in order to minimise refrigerant emissions. Use equipment and methods
which will pull the lowest possible system vacuum while recovering and condensing refrigerant. Equipment capable of
pulling a vacuum of less than 500 microns is required.
Do not open the system to the atmosphere for service work until refrigerant is fully removed and/or recovered. Perform
refrigeration system evacuation, prior to charging, in accordance with AIRAH / IRHACE Refrigerant handling code of
practice.
Let the unit stand for 1 hour and with the vacuum not rising above 500 microns. A rise above 500 microns indicates a leak
from the system and a leak test is required to locate and repair any leak.
CAUTION
A leak test is always required on any repaired section of the refrigeration system.
Charge refrigerant into the system only after the equipment does not leak or contain moisture. Ensure that R-410A is
only charged in liquid form. Take into consideration the correct amount of refrigerant charge specified for the system
to ensure efficient unit operations. When charging is complete, reclaim refrigerant from charging lines into an approved
refrigerant container. Seal all used refrigerant containers with approved closure devices to prevent unused refrigerant
from escaping to the atmosphere. Take extra care to maintain all service equipment directly supporting refrigerant service
work such as gauges, hoses, vacuum pumps and recycling equipment.

Installation and Commissioning Guide Split Ducted Outdoor Units
Installation and Commissioning Guide - Standard Commercial Split Ducted Commercial Outdoor Unit
Doc. No.0525-056 Ver. 7 220308
7
INSTALLATION PREPARATION (Pre-Installation considerations)
The following items must be considered before beginning the unit installation:
•Verify the unit capacities and ratings with the unit nameplate.
•Make certain the floor or foundation is level, solid and has sufficient structural strength to support the unit and
accessories weight.
•Allow minimum recommended clearances for periodic maintenance and service access.
•Allow sufficient space above the unit for the outdoor air discharge. Condenser air inlet, located on the coil side of the
unit, requires sufficient airflow clearance for the optimum unit performance.
•Note the conditioned supply air and return air location. Ensure sufficient spaces are allocated for these purposes.
•For the connection and location of condensate drain in the unit, refer to the drawings and dimensions section of this
manual.
•Wiring connections must be in accordance with the wiring diagram provided with the unit.
•Make sure all wirings are in accordance with local electricity authority regulations and standards.
•Do not install the unit close to an area where there is a danger of fire due to volatile, explosive, flammable and/ or
hazardous materials.
•Ensure that spaces around the unit are free from any obstructions for optimum unit performance.
•Installer to ensure correct size/type that main circuit breaker and cable is installed in unit sub-mains to protect the sub
mains and unit wiring.
•Installer to ensure correctly rated Residual Current Device (RCD) is installed as per the latest edition of the AS/NZS
3000 (also known as Australian Wiring Rules).
•Secure the power cords and control cables that goes in/out the unit. Use the cable ties provided in the control box.
NOTE
This outdoor unit is designed to match only with an ActronAir Series indoor unit as specified in the Technical Selection
Catalogue.
This unit is designed for use with R-410A refrigerant only.
The unit is supplied with factory charged R-410A refrigerant. Be aware of all the relevant regulations concerning the handling of
refrigerant.
All images in this document are for illustration purposes only.
. Operation Manual Access
Download from website
C7-4
Operation manuals can be downloaded through our website shown below.
https://www.actronair.com.au/brochures-manuals/#operating-manuals

Installation and Commissioning Guide - Standard Commercial Split Ducted Commercial Outdoor Unit
Doc. No.0525-056 Ver. 7 220308
Installation and Commissioning Guide Split Ducted Outdoor Units
8
. Components Overview
LP CONTROL
THIRD ANGLE
PROJECTION
3
7.
BY
0525-0XX Install Guide Commercial Split V1 - Page 5
D
E
F
C
B
A
321 5
C
D
4 6 7 8
A
B
0525-0XX Install Guide Commercial Split V1 - Page 5
A3
SHEET 1 OF 1
N.T.S
DRAWING NO.
MATERIAL:
DESCRIPTION:
DATE
DRAWN BY: APPROVED BY: SCALE:DRAWN DATE:
DESCRIPTION
FINISH:
REV PCR
intellectual property of Actron
PH. [phone]
0.1/~0
E
FLAT PATTERN
ANGLES & SQUARENESS
written consent is prohibited
REV.
A.B.N. 34 002 767 240
This drawing always remains theActronAir Pty Ltd
Engineering Pty Ltd. Copying,
1
2.
F
5 Irvine Place
4.
HOLE DIAMETER
5.
Modifying or Distributing without
0.5 / m
0.5 / m3.
FOLD
1.
Norwest Business Park
Bella Vista NSW 2153
GENERAL TOLERANCES
(UNLESS OTHERWISE SPECIFIED)
ALL TUBES
UNLESS OTHERWISE SPECIFIED
3rd ANGLE PROJECTION.1.
DIMENSIONS IN MILLIMETRES.2.
DO NOT SCALE.3.
TUBE ENDS MUST BE ROUND AND OF FULL4.
DIAMETER.
TUBE MUST BE CLEAN AND FREE FROM5.
BURRS INSIDE AND OUTSIDE AND SUITABLE
OF FOR SOLDERING.
ALL BENDS 90 .6.
ALL SHEETMETAL'S DIMENSIONS OUTISDE.
ASSEMBLY
HP CONTROL
COMPRESSOR*
ELECTRICAL PANEL
COIL
ASSEMBLY
FANS
LIQUID LINE
FILTERDRYER
REVERSING
VALVE
ACCUMULATOR
*For illustration purpose only. Actual unit may vary.
Unit shown above represent 1-Stage model.

Installation and Commissioning Guide Split Ducted Outdoor Units
Installation and Commissioning Guide - Standard Commercial Split Ducted Commercial Outdoor Unit
Doc. No.0525-056 Ver. 7 220308
9
. Unit Dimensions, Clearances and Weights
07.01. Unit Dimensions
Note: SCA 290C model shown for illustration purposes only.
** DRAWING IS SUBJECT TO CHANGE WITHOUT NOTICE**
CONDENSATION POINTS ARE DESIGNED TO ENSURE ALL
CONDENSATION IS REMOVED EFFICIENTLY TO AVOID
WATER POOLING WITHIN THE CONDENSER. IF A SINGLE
CONDENSATION DRAIN POINT IS REQUIRED, ACTRONAIR
RECOMMENDS THE INSTALLATION OF A CONDENSER
TRAY. THESE ARE AVAILABLE AS AN ADDITIONAL
ACCESSORY.
H
BA C
OUTDOOR COIL
COMP
SIDE
OUTDOOR AIR INLET
AIR
INLET
AIR INLET
AIR OUTLET
W
ELECT. ACCESS
2 x Ø 25.4 mm (1")
GAS PIPE
LIQUID PIPE
SCA260-400C Gen Dim.TCW
SCA260-400C Gen Dim
D
TOP VIEW
SIDE VIEW FRONT VIEW
Unit
Model
Overall Nominal
Dimensions (OA)
Mounting Distance
(Centre to Centre) Gas
Pipe
Liquid
Pipe
No. of
Comp.
H W D A B C
CRA300T 1330 1875 875 835 7 3 7. 5 7 3 7. 5 2 x Ø 19.1mm
(3/4") Swaged
2 x Ø 9.5mm
(3/8") Swaged 2
SCA260C 1105 1685 685 616 673.5 673.5 Ø 28.6 mm
(1-1/8") Swaged
Ø 15.9 mm
(5/8") Swaged 1
SCA290C
1330
1875 875 835 7 3 7. 5 7 3 7.5
Ø 28.6mm
(1-1/8") Swaged
Ø 15.9mm
(5/8") Swaged 1
SCA300C 2 x Ø 19.1mm
(3/4") Swaged
2 x Ø 9.5mm
(3/8") Swaged 2
SCA330C Ø 28.6mm
(1-1/8") Swaged
Ø 15.9mm
(5/8") Swaged 1
SCA340C 2 x Ø 19.1mm
(3/4") Swaged
2 x Ø 9.5mm
(3/8") Swaged 2
SCA400C 1315 2 x Ø 22.2mm
(7/8") Swaged
2 x Ø 12.7mm
(1/2") Swaged 2

Installation and Commissioning Guide - Standard Commercial Split Ducted Commercial Outdoor Unit
Doc. No.0525-056 Ver. 7 220308
Installation and Commissioning Guide Split Ducted Outdoor Units
10
07.02. Minimum Service Access Area, Airflow Clearances and Weights
Note: SCA 290C model shown for illustration purposes only.
NOTES:
1. Do not scale drawing. All
dimensions are in mm
unless specified. Refer to
corresponding unit dimensional drawing for
mounting hole details.
2. Ensure that Service Access Areas and Spaces
for Airflow Clearances are met. This is based on
the condition that the spaces around the units
are free from any obstructions and a walkway
passage of 1000mm between the units or
between the unit and the outside perimeter is
available.
3. Minimum service access areas and spaces for
airflow clearances are responsibilities of the
installer, ActronAir will not be held liable for any
extra charges incurred due to lack of access and
space for airflow.
4. Under all circumstances, condenser air must not
recirculate back onto condenser coil. Keep all
clearance free of any obstructions.
5. MTG C-C DIST = Mounting Centre to Centre
Distance.
6. Use M12 bolt for feet mounting.
THIRD ANGLE
PROJECTION
OUTDOOR COIL
COMP
SIDE
SCA260-400C Gen Dim.TCW
SCA260-400C Clearances
X
SERVICE /
AIRFLOW
AND
CLEARANCE
TOP VIEW
Y
SERVICE
CLERANCE
(COMPRESSOR
AND
ELECTRICALS)
Z
SERVICE / AIRFLOW CLERANCE
F
D
C
B
E
ANIL - TO - MINIMUM SERVICE CLEARANCE
Unit Model
Number
Unit
Weight
(kg)
Corner Weights (kg) Service Clearance and
Airflow Allowance Height
Clearance
A B C D E F X Y Z
CRA300T 300 23.7 29.6 90.1 33.2 17.8 105.6
300 800
750
1500
SCA260C 245 16.0 24.6 81.3 22.5 24.6 76.0 600
SCA290C 290 33.8 28.0 84.1 23.2 30.9 90.0
750
SCA300C 300 23.7 29.6 90.1 33.2 17.8 105.6
SCA330C 305 25.4 24.3 100.5 37.0 17. 3 100.5
SCA340C 335 43.0 23.7 103.1 33.7 23.7 107.8
SCA400C 332 43.9 23.5 101.2 32.8 23.5 107.1

Installation and Commissioning Guide Split Ducted Outdoor Units
Installation and Commissioning Guide - Standard Commercial Split Ducted Commercial Outdoor Unit
Doc. No.0525-056 Ver. 7 220308
11
. Banking of Units
NOTES
• All dimensions are in mm. Do not scale drawing.
• Ensure that Service Access Areas and Spaces for Airflow Clearances are met. This is based on the condition that the
spaces around the units are free from any obstructions and a walkway passage of 1000mm between the units or
between the unit and the outside perimeter is available.
• Minimum service access areas and spaces for airflow clearances are responsibilities of the installer, ActronAir will not be
held liable for any extra charges incurred due to lack of access and space for airflow.
• The distance between two units must be the wider clearance required.
HEIGHT CLEARANCE
FOR ALL UNITS = 1500mm
CONFIGURATION 1
*600/750 mm
AIRFLOW ALLOWANCE and SERVICE CLEARANCE - OUTDOOR COIL
NIL - TO - MINIMUM SERVICE CLEARANCE
300mm
SERVICE CLEARANCE
800mm
SERVICE
CLEARANCE
(COMPRESSOR
AND
ELECTRICALS)
800mm
SERVICE
CLEARANCE
(COMPRESSOR
AND
ELECTRICALS)
UNIT 1 UNIT 2
*Clearances will vary depending on model. Higher capacity models clearance requirement must be allocated.
CONFIGURATION 2
UNIT 1 UNIT 2
300mm
SERVICE
CLEARANCE
300mm
SERVICE
CLEARANCE
NIL - TO - MINIMUM SERVICE CLEARANCE
NIL - TO - MINIMUM SERVICE CLEARANCE
800mm
SERVICE
CLEARANCE
(COMPRESSOR
AND
ELECTRICALS)
*600/750 mm AIRFLOW ALLOWANCE
AND
SERVICE CLEARANCE OUTDOOR COIL *
*600/750 mm AIRFLOW ALLOWANCE
AND
SERVICE CLEARANCE OUTDOOR COIL *
HEIGHT CLEARANCE
FOR ALL UNITS = 1500mm

Installation and Commissioning Guide - Standard Commercial Split Ducted Commercial Outdoor Unit
Doc. No.0525-056 Ver. 7 220308
Installation and Commissioning Guide Split Ducted Outdoor Units
12
CONFIGURATION 3
UNIT 2
UNIT 3
NIL - TO - MINIMUM SERVICE CLEARANCE
NIL - TO - MINIMUM SERVICE CLEARANCE
300mm
SERVICE
CLEARANCE
800mm
SERVICE CLEARANCE
(COMPRESSOR AND ELECTRICALS)
300mm
SERVICE CLEARANCE 800mm
SERVICE
CLEARANCE
(COMPRESSOR AND
ELECTRICALS)
* 600/750 mm AIRFLOW
ALLOWANCE
and SERVICE CLEARANCE -
OUTDOOR COIL *
* 600/750 mm AIRFLOW
ALLOWANCE
and SERVICE CLEARANCE -
OUTDOOR COIL *
* 600/750 mm AIRFLOW
ALLOWANCE
and SERVICE CLEARANCE -
OUTDOOR COIL *
UNIT 1
HEIGHT CLEARANCE
FOR ALL UNITS = 1500mm
*Clearances will vary depending on model. Higher capacity models clearance requirement must be allocated.

Installation and Commissioning Guide Split Ducted Outdoor Units
Installation and Commissioning Guide - Standard Commercial Split Ducted Commercial Outdoor Unit
Doc. No.0525-056 Ver. 7 220308
13
. Unit Lifting Procedure
WARNING
WH&S regulations must be observed and will take precedence during lifting process.
Crane Lifting Method
Crane lifting method is recommended for high rise lifting.
Connect the loop endsConnect the loop ends
of slings into shackleof slings into shackle
A
Fig. 1
SPREADER
BAR
Provide rubber pads
under spreader bar
to prevent damage
to the unit
DETAIL A
OUTDOOR
UNIT
Slip nylon slings
through the pallet
Connect the loop ends
of slings into shackle
NOTE
Undo the 6-screws (4-screws only for SCA260C) holding down the unit unto the pallet before removing the pallet
Equipment Required For Crane Lifting:
• 1 Shackle
• 2 x Nylon Slings
• Spreader bars
Refer to catalogue for unit weight before selecting shackles and slings.
NOTE
Refer to Unit Dimensions and Clearances section for unit weight before selecting shackle and slings.
Procedure:
1. Slip nylon slings through the pallet as shown in Fig. 1.
2. Use a Bow or Dee shackle to connect the slings.
3. Ensure slings are protected by rubber pads or similar if slings are draped across unit edges, corners, or air grilles .
This will prevent the unit from being damaged during lifting.
4. SPREADER BARS must be used when lifting the unit.
5. Test lift the unit to determine exact unit balance and stability before hoisting it to the installation location.

Installation and Commissioning Guide - Standard Commercial Split Ducted Commercial Outdoor Unit
Doc. No.0525-056 Ver. 7 220308
Installation and Commissioning Guide Split Ducted Outdoor Units
14
Fork Lift Method
DANGER
Make sure rigging equipment, accessories and plant are sufficiently and safely capable to lift the unit in order to prevent
potential damage to property, severe personal injury or death. Please check unit weight and weight distribution points as
shown in the unit drawing dimensions section.
Procedure:
1. To move the unit around with a forklift, insert the fork tines through the pallet, as shown in Fig. 2.
2. Only fork the unit through compressor end or side of the unit. (See illustration for location of compressor end)
FIG. 2
INSERT FORKLIFT
TINES HERE
COMPRESSOR
END
CAUTION
DO NOT LIFT UNIT
at this end.
X
CAUTION
Length of fork lift tines must pass the unit middle section, in order to safely carry the unit.

Installation and Commissioning Guide Split Ducted Outdoor Units
Installation and Commissioning Guide - Standard Commercial Split Ducted Commercial Outdoor Unit
Doc. No.0525-056 Ver. 7 220308
15
. Outdoor Unit Preparation
ACCESS
PANEL
MOUNTING
SCREWS
Step 1: Remove mounting screws, as shown:
Step 2: Remove Access Panel.
A
Removal Order:
Pull-Out 20mm
Pull-Down to remove
Access Panel-Electrical
A
B
B
THIRD ANGLE
PROJECTION
7.
BY
0525-0XX Install Guide Commercial Split V1 - Page 21 - 3
D
E
F
C
B
A
321 5
C
D
4 6 7 8
A
B
0525-0XX Install Guide Commercial Split V1 - Page 21 - 3
A3
SHEET 1 OF 1
N.T.S
DRAWING NO.
MATERIAL:
DESCRIPTION:
DATE
DRAWN BY: APPROVED BY: SCALE:DRAWN DATE:
DESCRIPTION
FINISH:
REV PCR
F
3
intellectual property of Actron
PH. [phone]
A.B.N. 34 002 767 240
REV.
2.
1ActronAir Pty Ltd This drawing always rem ains the
1.
HOLE DIAMETER 0.1/~0
E
0.5 / m
written consent is prohibited
ANGLES & SQUARENESS
FLAT PATTERN
Norwest Business Park
5.
4.
0.5 / m3.
FOLD
5 Irvine Place
Bella Vista NSW 2153 Modify ing or Distributing without
Engineering Pty Ltd. Copying,
GENERAL TOLERANCES
(UNLESS OTHERWISE SPECIFIED)
ALL TUBES
UNLESS OTHERWISE SPECIFIED
3rd ANGLE PROJEC TION.1.
DIMENSIONS IN MILLIMETRES.2.
DO NOT SCALE.3.
TUBE ENDS MUST BE ROUND A ND OF FULL4.
DIAMETER.
TUBE MUST BE CLEAN AND FREE FRO M5.
BURRS INSIDE AND OUT SIDE AND SUITABLE
OF FOR SOLDERING.
ALL BENDS 90 .6.
ALL SHEETMETAL'S DIMENSIONS OUTISDE.
ASSEMBLY
REMOVE
ACCESS
PANEL

Installation and Commissioning Guide - Standard Commercial Split Ducted Commercial Outdoor Unit
Doc. No.0525-056 Ver. 7 220308
Installation and Commissioning Guide Split Ducted Outdoor Units
16
THIRD ANGLE
PROJECTION
0525-0XX Install Guide Commercial Split V1 - Page 21 - 4
D
E
F
C
B
A
321 5
C
D
4 6 7 8
A
B
0525-0XX Install Guide Commercial Split V1 - Page 21 - 4
A3
SHEET 1 OF 1
N.T.S
DRAWING NO.
MATERIAL:
DESCRIPTION:
DATE
DRAWN BY: APPROVED BY: SCALE:DRAWN DATE:
DESCRIPTION
FINISH:
REV PCR
F
E
REV.
BY
7.
31.
HOLE DIAMETER
A.B.N. 34 002 767 240
PH. [phone]
Bella Vista NSW 2153
Norwest Business Park
5 Irvine Place
written consent is prohibited
Modifying or Distributing without
Engineering Pty Ltd. Copying,
4.
intellectual property of Actron
This drawing always remains theActronAir Pty Ltd
ANGLES & SQUARENESS
0.1/~02.
FLAT PATTERN
1
0.5 / m3.
FOLD
5.
0.5 / m
GENERAL TOLERANCES
(UNLESS OTHERWISE SPECIFIED)
ALL TUBES
UNLESS OTHERWISE SPECIFIED
3rd ANGLE PROJEC TION.1.
DIMENSIONS IN MILLIMETRES.2.
DO NOT SCALE.3.
TUBE ENDS MUST BE ROUND A ND OF FULL4.
DIAMETER.
TUBE MUST BE CLEAN AND FREE FRO M5.
BURRS INSIDE AND OUT SIDE AND SUITABLE
OF FOR SOLDERING.
ALL BENDS 90 .6.
ALL SHEETMETAL'S DIMENSIONS OUTISDE.
ASSEMBLY
Step 3: Install Interconnecting Field Pipes
Braze refrigeration piping. Refer to Section 11 for details of field pipe sizes and piping installation procedure.
WARNING
Live electrical within enclosure. Isolate electrical supply before
removing panels. Authorised technicians access only.
. Field Pipe Connection
11.01. Piping and Brazing
CAUTION
The units described in this guide use R-410A refrigerant
R-410A operates at a pressure approximately 1.6 times higher than similar systems using R-22. When installing equipment
using R-410A refrigerant, there are number of standards that must be met:
• The compressor of this unit operates with Polyolester (POE) oil that rapidly absorbs moisture. The maximum time any
system can opened to atmosphere is 15 minutes, if the system is left open for extended period cap it off to prevent the oil
from absorbing moisture.
• It is important to work with absolute cleanliness.
• Brazing must be done with the use of Nitrogen to avoid carbon deposits into the pipes.
• The system must be evacuated thoroughly to 500 microns (see evacuation procedure).
• The system must always be charged with R-410A refrigerant in liquid state.
• Never allow R-410A refrigerant to vent into the atmosphere. It is an offence to release refrigerant in Australia.
• Always reclaim refrigerant using equipment and container dedicated for R-410A system use only.
• Only qualified technicians are allowed to perform any work described in this guide.
• All work must be carried out in accordance with Australia and New Zealand refrigerant handling code of practice.
Maximum allowable total equivalent field pipe length is 60 metres, see diagram below. This includes all the equivalent pipe
fitting loses and vertical height difference. Vertical height difference must not exceed 20 metres. Table 1 below shows the
equivalent straight pipe length of elbow fittings.

Installation and Commissioning Guide Split Ducted Outdoor Units
Installation and Commissioning Guide - Standard Commercial Split Ducted Commercial Outdoor Unit
Doc. No.0525-056 Ver. 7 220308
17
TABLE 1: EQUIVALENT STRAIGHT PIPE LENGTH OF ELBOW FITTINGS METRES
Pipe size Nominal
Diameter
90oLong Radius
Elbow
90oShort Radius
Elbow
45oLong Radius
Elbow
45oShort Radius
Elbow
9.52 (3/8”) 0.24 0.36 0.09 0.14
15.88 (5/8”) 0.30 0.45 0.15 0.23
19.05 (3/4”) 0.40 0.60 0.18 0.27
22.22 (7/8”) 0.46 0.69 0.21 0.32
25.4 (1”) 0.52 0.78 0.24 0.36
28.58 (1-1/8”) 0.55 0.83 0.27 0.41
Selected field pipe sizes must match the recommended sizes in Table 2. If the installation requires different field pipe
diameter due to different application condition other than recommended, contact ActronAir for advice.
Most of unit pipe connections are factory swaged to easily fit to the recommended field pipe diameter.
When it is required to install other refrigeration devices, such as refrigerant drier, solenoid valve and the like, include the
equivalent straight pipe length of the device in the calculation of total equivalent field pipe length.
Both pipes are required to be insulated.
A = EQUIVALENT PIPE LENGTH,
60 meters (max)
B = VERTICAL HEIGHT,
20 meters (max)
B
OUTDOOR UNIT
INDOOR UNIT
A
FIELD PIPE
(Installer to Supply)

Installation and Commissioning Guide - Standard Commercial Split Ducted Commercial Outdoor Unit
Doc. No.0525-056 Ver. 7 220308
Installation and Commissioning Guide Split Ducted Outdoor Units
18
Example of Total Equivalent Field Pipe Length Calculations
CAUTION
Illustration shown as calculation examples only. It is
the responsibility of the Installer to design an efficient
refrigeration piping lay out for optimum unit performance.
E1
OUTDOOR
UNIT E2
V1
H1
H2
INDOOR
UNIT
E3
V2
H3
E4
Equivalent Pipe Length = Total Horizontal Length + Total Vertical Length
+ Total Losses from Elbows
Where:
H = Horizontal Length
V = Vertical Length
E = Elbow Losses
Equivalent Pipe Length = (H1+ H2+ H3) + (V1+ V2) + (E1+ E2+ E3+ E4)
TABLE 2: REFRIGERATION PIPING
Reverse Cycle
(Outdoor / Indoor)
CRA300T/
EVA300S
SCA260C/
SCG260E
SCA290C/
SCG290E
SCA300C/
SCA300E
SCA330C/
SCA330E
SCA330C/
SCG330E
SCA340C/
SCA340E
SCA340C/
SCG340E
SCA400C/
SCG400E
Max. Equivalent Pipe
Length Range (metres) 0 - 60 0 - 60 0 - 60 0 - 60 0 - 60 0 - 60 0 - 60 0 - 60 0 -60
Max. Vertical Height
Differential (1) (metres) 20 20 20 20 20 20 20 20 20
Field Pipe Size
Liquid Line - inch (mm) 9.52 (3/8) 15.9 (5/8) 15.9 (5/8) 9.52 (3/8) 15.9 (5/8) 15.9 (5/8) 9.52 (3/8) 9.52 (3/8) 12.7 (1/2)
Gas Line - inch (mm) 19.05 (3/4) 1 (25.4) 28.6 (1-1/8) 19.05 (3/4) 28.6 (1-1/8) 28.6 (1-1/8) 19.05 (3/4) 19.05 (3/4) 22.2 (7/8)
Outdoor Pipe Size
Liquid Line - inch (mm) 9.52 (3/8)
swaged
15.9 (5/8)
swaged
15.9 (5/8)
swaged
9.52 (3/8)
swaged
15.9 (5/8)
swaged
15.9 (5/8)
swaged
9.52 (3/8)
swaged
9.52 (3/8)
swaged
12.7 (1/2)
swaged
Gas Line - inch (mm) 19.05 (3/4)
swaged
28.6 (1-1/8)
ID to fit
field pipe
28.6 (1-1/8)
swaged
19.05 (3/4)
swaged
28.6 (1-1/8)
swaged
28.6 (1-1/8)
swaged
19.05 (3/4)
swaged
19.05 (3/4)
swaged
22.2 (7/8)
swaged
Indoor Pipe Size
Liquid Line - inch (mm) 9.52 (3/8)
swaged
15.9 (5/8)
swaged
15.9 (5/8)
swaged
9.52 (3/8)
swaged
15.9 (5/8)
swaged
15.9 (5/8)
swaged
9.52 (3/8)
swaged
9.52 (3/8)
swaged
12.7 (1/2)
swaged
Gas Line - inch (mm)
22.2 (7/8)
cut-off
swaged
1 (25.4)
swaged
28.6 (1-1/8)
swaged
22.2 (7/8)
cut-off
swaged
28.6 (1-1/8)
swaged
28.6 (1-1/8)
swaged
22.2 (7/8)
cut-off
swaged
22.2 (7/8)
cut-off
swaged
22.2 (7/8)
swaged
Field Pipe Qty. (Liquid / Gas) 2 / 2 1 / 1 1 / 1 2 / 2 1 / 1 1 / 1 2 / 2 2 / 2 2 / 2
(1) Included in maximum field pipe length.

Installation and Commissioning Guide Split Ducted Outdoor Units
Installation and Commissioning Guide - Standard Commercial Split Ducted Commercial Outdoor Unit
Doc. No.0525-056 Ver. 7 220308
19
CAUTION
Brazed joints should only be made while purging Nitrogen through the system.
Failure to do so will cause carbon deposit to be left on the internal pipe surface, that in turn can cause system failure and void
warranty.
Detail A
OPEN PIPE
Rubber bung
into pipe opening
to create seal
Nitro
Regulator
Set to 2 L/s
N
I
T
R
O
G
E
NLIQUID
PIPE
A
GAS PIPE
BRAZE JOINTS
Installing interconnecting pipe work to indoor, nitrogen bleed procedure (First fit or rough in stage only)
1. Run interconnecting pipe work from condenser location to evaporator.
2. Release pressure in evaporator and remove caps.
3. Fit copper tube into tail, set nitro bottle and regulator up at condenser end of pipe work.
4. Fit nitrogen line into liquid line with rubber bung to seal the connection. The seal will prevent air being sucked into pipe
work.
5. Leave suction line open, set nitro regulator for nitrogen to flow through pipe work at 2 l/s flow rate @20kPa.
6. Braze required joints as quick as possible. See Diagram Above.
Installing interconnecting pipe work to outdoor, nitrogen bleed procedure (First fit or rough in stage only)
1. Starting with circuit 1 system, remove piping caps from the condenser and fit pipe work into tails.
2. Fit nitro hose onto suction ball valve and fit open hose onto liquid line post valve.
3. Set nitrogen regulator to 2 l/s flow rate through pipe work and evaporator.
4. Braze remaining joints as quick as possible.
5. Allow the brazed joints to cool and conduct leak test in the connections.

Installation and Commissioning Guide - Standard Commercial Split Ducted Commercial Outdoor Unit
Doc. No.0525-056 Ver. 7 220308
Installation and Commissioning Guide Split Ducted Outdoor Units
20
11.02. Pressure Testing
Pressurize the system to 2500kPa in stages. A recommended pressure test is to be performed for no less than 1 hour at
2500kPa.
NOTES
Importance of Evacuation:
• Any non-condensable product left in the system can cause the pressure in the high side of the system to increase and in
turn, the compression temperature to rise.
• Moisture will result in adverse reaction in the refrigerant circuit.
• The POE oil used in the R-410A compressor is hygroscopic, which means that it absorbs moisture from the air. To prevent
chemical reactions in the system, any moisture must be removed at all costs.
• Oxygen (air) reacts with the compressor oil and can lead to faults such as compressor failure.
Detail B
Open
Hose
Nitrogen
Hose
N
I
T
R
O
G
E
N
Braze
Joints
To
Indoor Unit
A
See Diagram Below:See Diagram Below:
