ACV 281230-30-1 User manual

9. Attach mounting brackets
and facia plate to 1-DIN
head unit
10. Remove switches and
control unit from OEM panel
11. Mount switches and control
unit to facia plate
All installation work must be performed by a qualied professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
1-DIN Kit
Installation Manual
Opel Meriva ->
part-no.: 281230-30-1
colour: black
Comptible with1-DIN head units
Kit Content
(1) Facia Plate
(2) Mounting bracket right
(3) Mounting bracket left
(4) at headed screw
(5) self-tapping screw with collar
1
2
4
3
4
5
5

1. Opel Meriva OEM dash board
2. Unclip und remove side panels at
the left and right side
4. Unclip and remove
panel under the gear box
(see arrows)
3. Remove 4 screws of
OEM front panel
(see arrows)
5. Pull gear box panel
slightliny into your direction
(See arrows)
6. Pull front panel carefully
into your direction in order
to unplug all connectors and
cables.
Remove front panel
7. Remove two screws of
OEM head unit
8 . Unplug all cables and
connectors carefully
Remove OEM head unit
by pulling it towards your
direction
