Adam Equipment CQT1752GR User manual

© Adam Equipment Company 2012
Adam Equipment
Grain Scale
Model: CQT1752GR
Part No. 3086611514, Rev A1, April 2012
Software Ver 3.3

© Adam Equipment Company 2012

© Adam Equipment Company 2012 1
1.0 CONTENTS
1.0 CONTENTS ............................................................................................................1
2.0 INTRODUCTION.....................................................................................................2
3.0 SET UP...................................................................................................................2
3.1 UNPACKING AND SETTING UP YOUR SCALE................................................2
3.2 OVERVIEW - DISPLAY / KEY BOARD...............................................................3
3.3 INSTALLING BATTERIES...................................................................................4
3.4 LOCATING AND PROTECTING YOUR SCALE.................................................5
4.0 BASIC OPERATION...............................................................................................6
4.1 TURNING ON THE SCALE.................................................................................6
4.2 ZEROING / TARE................................................................................................6
4.3 WEIGHING..........................................................................................................6
4.4 WEIGHING UNITS..............................................................................................6
4.5 GRAIN DETERMINING.......................................................................................7
5.0 USER SETTINGS.................................................................................................11
5.1 USER SETTING ENTRY...................................................................................11
5.2 YIELD................................................................................................................11
5.3 CONTAINER SIZE ............................................................................................12
5.4 DOCKAGE.........................................................................................................12
6.0 PARAMETERS.....................................................................................................13
6.1 PARAMETER SETTING....................................................................................13
6.2 FILTER..............................................................................................................13
6.3 ZERO TRACKING.............................................................................................13
6.4 STABILITY.........................................................................................................14
6.5 AUTO POWER OFF..........................................................................................14
6.6 SETTING THE BACKLIGHT..............................................................................14
7.0 CALIBRATION .....................................................................................................15
8.0 TROUBLE SHOOTING.........................................................................................16
8.1 ERROR MESSAGES ........................................................................................16
9.0 PARTS LIST.........................................................................................................17
10.0 SPECIFICATIONS................................................................................................18
11.0 WARRANTY INFORMATION...............................................................................19

© Adam Equipment Company 2012 2
2.0 INTRODUCTION
Thank you for purchasing your new grain scale which is based upon the Core series
of Balances. The CQT1752GR model has been specifically designed to assist in the
grading of grain quality following screenings in relation to an initial sample weight of
grain, and to give an indication of yield in Kilograms per hectoliter (k.hl), and Pounds
per bushel (L.bu) Winchester.
There are 4 container sizes available --- 0.5liter, 1 liter, 1 pint and 1 quart as well as
positive and negative % dockage readings following up to 5 x screenings, plus a
memory facility for up to 5 x stored sample weights.
3.0 SET UP
3.1 UNPACKING AND SETTING UP YOUR SCALE
1) Remove the shipping protection screw and round cover as shown below using the
hex allen key supplied in the box. (It is advisable to keep the shipping protection
screw and the round cover for shipping to another location in the future).
Shipping protection screw
Round cover protecting the load
cell.
2) Place the pan (which comes separately packed) in the receptacle on the top cover.
Use the screw that is packed
separately in a bag with the
allen key to screw the plastic
pan into place. Be careful
when inserting the screw that
you do not use excessive
force as it can damage the
loadcell. Use light force to
secure the screw.
3) Place the stainless steel pan on top of the plastic pan.
4) Place the balance on a firm and flat surface for accurate weighing.

© Adam Equipment Company 2012 3
3.2 OVERVIEW - DISPLAY / KEY BOARD
AC adapter socket
Lock down slot
Stainless Steel pan
LCD display
[On/Off] key
Turns the balance on/off
[Con/Unit] key
Selects the container size
and (Unit) switches
between weighing modes
and results
[Tare] key
Tares the balance
[Store]key
Stores the initial sample
and subsequent weights
following screening
[Recall/CE] key
Recalls stored weighing
results and (CE) clears
previously stored results
from the memory

© Adam Equipment Company 2012 4
3.3INSTALLING BATTERIES
Remove the battery compartment cover and insert six batteries (R6P/LR6 /AA size) into
the battery compartment.
Battery compartment
screws
Battery compartment
cover
Batteries are not
included
ZERO indicator
Indicates when the scale
is at zero.
STABLE indicator
Indicates when the
reading is stable.

© Adam Equipment Company 2012 5
3.4 LOCATING AND PROTECTING YOUR SCALE
In order to keep your scale functioning at its best we suggest that you do the following:
Avoid extremes of temperature. Do not place in direct sunlight or
near air conditioning
vents.
Make sure the scale is located on a strong table and free from
vibration.
Avoid unstable power sources. Do not operate near large users of
electricity such as welding equipment or larg
e motors. Do not leave
the
batteries inside the scale if you are not using it for a long time.
Keep free from vibration. Do not place near heavy or vibrating
machinery.
Avoid high humidity that might cause condensation, and keep away
from direct contact with water.
Do not place near open windows, air
-conditioning vents or fans that
may cause a draught and unstable readings.
Keep the scale
clean, and do not stack material on the scale when it
is not in use.

© Adam Equipment Company 2012 6
4.0 BASIC OPERATION
4.1 TURNING ON THE SCALE
Plug in the unit using the AC adapter or insert batteries and press the [on/off] key.
1) The scale will show grn- X.X, “X.X” meaning software revision number, “grn”
meaning it has grain scale software, and then show the voltage X.X Vol. “X.X” is
the voltage of the batteries if being used on battery power, or the regulated voltage
from the AC adapter. Following this the scale will then count from 0 to 9, and then
display "0.00g" with the Stable symbol, Zero symbol and the last chosen container
size indicator being shown.
2) The scale is now ready to be used.
3) To turn the scale off after use press the [on/off] key again. There is an auto
power-off function that will automatically turn the unit off, this can be set in the
parameters section.
4.2 ZEROING / TARE
You can press the [Tare] key to set a new zero point. Zero will be set if the reading on
the scale is less than 70g. This may be necessary if the weight is not reading zero with
no weight on the pan. The zero indicator will show in the top left corner of the LCD.
If you are using a container to weigh then you can place this on the platform and press
the [Tare] key, the display will show zero and NET on the display.
You can then weigh any material added to the container. Taring weight subtracts from the
scale’s total capacity.
Note: When the container is removed a negative value will be shown. If the [Tare] key is
pressed when the container has been removed it will again zero the scale.
4.3 WEIGHING
To determine the weight of a sample, tare an empty container, then place the sample in
the container. The display will show the weight and the unit of weight currently in use.
The stable indicator will light up when the reading is stable.
4.4 WEIGHING UNITS
Three weighing units are available: grams (g), Kilograms per Hectoliter (k.hl), and
Pounds per bushel (L.bu) based on the Winchester bushel.

© Adam Equipment Company 2012 7
4.5 GRAIN DETERMINING
1) Turn on the scale and wait for the scale to display zero. Press [CON/UNIT] to
select the container size you will use, an Indicator will show next to the container
size to confirm which one you have selected (for example below 0.5lt).
2) Place the empty container on the pan and press [TARE]
qt
pt
Smp 0.5lt lt
stored
3) Load the 500ml container with the grain. The screen shows the net weight (the
first net weight) of the grain (in this example the total weight is 400g).
qt
pt
Smp 0.5lt lt
stored
At this point you can press the [CON/UNIT] key to view the yield values calculated
in k.hl and L.bu based on the net weight in the container.
4) To store this weight as the initial sample value, press the [STORE]key, the
display will show “Store smp” and then return to the last weighing mode, an
indicator above Smp/stored will show to confirm the sample weight has been
stored in the memory.
qt
pt
Smp 0.5lt lt
> 0<
Net
0.00 g
Net
400.00 g
Net
400.00
g

© Adam Equipment Company 2012 8
stored
The container can now be removed from the scale and a screening performed.
5) Replace the same 500ml container on to the scale with the grain that is left
following the screening. The display will show the net weight of the grain that is
left, for example 300g left meaning 100g removed.
Again at this point you can press the [CON/UNIT] key to view the yield values
calculated in k.hl and L.bu based on the new net weight in the container.
qt
pt
Smp 0.5lt lt
stored
6) In order for the scale to calculate a negative or positive dockage following the first
screening press the [STORE] key, Store 1st will be displayed. The new net weight
will be entered into the memory and calculate the % grain remaining and removed
against the initial sample weight value stored at point 4.
Note that in order to perform a new STORE the scale has to go back to ZERO or a
negative value, removing the container to perform a screening allows the display
to go to a negative value which then permits the new STORE to be performed
when the container is placed back onto the top pan.
The first dockage result will then be displayed, and by pressing the [CON/UNIT]
key further results can be viewed including dockage, the net weight in grams
which was used in the calculation, and also the new yield values.
Pressing the [RECALL/CE] key unlocks the display for further weighings. Pressing
the [RECALL/CE] key again continuously will show you the same results with
reference to a particular screening, this can be done at any time and will progress
from the 1st screening through to the last screening stored showing all results.
Once all of the stored results have been displayed the next press of the
[RECALL/CE] key will exit you from these results.
7) A further screening can now take place following the same procedure as above
with the next net value being stored. Following the storing of the new net weight
the same information is available by pressing the appropriate keys. Screenings
can be repeated for up to 5 times with each result able to be stored and %
dockage, grams, yield and net weight values to be recalled. Each time a net
weight is stored the display will show Store x (x being the number of the screening
performed).
Net
300.00
g

© Adam Equipment Company 2012 9
Examples of displayed information following [RECALL/CE] is as below, once a
complete test result is shown the next stored results will be displayed showing the
number of that test until the last set of test results are displayed.
Negative dockage (showing the % of grain removed after screening), and
indicating the 1st recorded set of test results.
qt
pt
Smp 0.5lt lt
stored
Positive dockage (showing the % of grain remaining after screening) and
indicating the 1st recorded set of test results.
qt
pt
Smp 0.5lt lt
stored
Yield in Kilograms per hectolitre of the remaining grain following the first screening
qt
pt
Smp 0.5lt lt
stored
%
Net
-25.0 1st
%
Net
75.0 1st
Net
60.00k.hl

© Adam Equipment Company 2012 10
Yield in Pounds per bushel of the remaining grain following the first screening
qt
pt
Smp 0.5lt lt
stored
Net weight used for all calculations following first screening
qt
pt
Smp 0.5lt lt
stored
The memorised values can be deleted at any time by pressing and holding the
[RECALL/CE] key for 3 seconds. A message of CLEAR will be displayed to
confirm deletion of the stored values and the indicator above Smp stored will go
out.
New tests can now be performed.
If the balance is turned off during the weighing process, it will retain the stored
information in the memory so that you could then complete the tests without
having to start again due to a loss of power.
Once a sample weight has been stored the scale will not allow you to change the
container size.
Net
46.56L.bu
Net
300.00
g

© Adam Equipment Company 2012 11
5.0 USER SETTINGS
The grain scale can be set up by the USER to enable or disable container sizes,
units of yield and dockage results in order to make operation and recalling of
results faster.
The scale has 3 settings available.
FUNCTION
SECTION
DESCRIPTION
Yield
See section 5.2
Selects which units of yield are to be displayed
Container size
See section 5.3
Selects the container sizes available to be used
Dockage
See section 5.4
Selects the type of dockage to be displayed in the
test results
5.1 USER SETTING ENTRY
•Press the [ON/OFF] key to turn the balance off.
•Press and Hold the [CON/UNIT]key and press the [ON/OFF]key to switch
the scale on, the scale will show “grn-3.3 GRN” and then enter the USER
setting mode. The display will show "X k.hl" which is the first parameter.
5.2 YIELD
Yield can be shown in Kilograms per hectolitre (k.hl) and/or Pounds per bushel (L.bu).
1)The display will show ‘‘X k.hl’’ (X being the current setting)
2) Press [TARE] to set ON or OFF for k.hl
3) Press [STORE] to select L.bu
4) Press [TARE] to set ON or OFF for L.bu
5) Press [RECALL/CE] to confirm settings

© Adam Equipment Company 2012 12
5.3 CONTAINER SIZE
The container size can be set so that any amount of the 4 can be selected.
1)The display will show ‘‘X qt’’ (X being the current setting)
2) Press [TARE] to set ON or OFF for qt
3) Press [STORE] to select pt
4) Press [TARE] to set ON or OFF for pt
5) Press [STORE] to select 1lt
6) Press [TARE] to set ON or OFF for 1lt
7) Press [STORE] to select 0.5lt
8) Press [TARE] to set ON or OFF for 0.5lt
9) Press [RECALL/CE] to confirm settings
5.4 DOCKAGE
The dockage results can be set to display negative % and/or positive % dockage
1) The display will show X -% (X being the current setting)
2) Press [TARE] to set ON or OFF for -%
3) Press [STORE] to select % (positive)
4) Press [TARE] to set ON or OFF for % (positive)
5) Press [RECALL/CE] to confirm settings
Pow er OFF the scale and then ON after pressing [RECALL/CE] to return to normal
weighing with the required settings.

© Adam Equipment Company 2012 13
6.0 PARAMETERS
The scale has 5 parameters that can be set by the user.
FUNCTION
SECTION
DESCRIPTION
Filter
See section 6.2
Sets the display update rate
Zero Tracking
See section 6.3
Sets the zero tracking for return to zero
Stability
See section 6.4
Sets the stability symbol sensitivity
Auto Off
See section 6.5
Sets the auto power off function
Backlight
See section 6.6
Sets the backlight control
6.1 PARAMETER SETTING
•Press [ON/OFF]to turn the balance off.
•Press and Hold the [TARE]key and press the [ON/OFF]key to switch the
scale on, the scale will show “grn-3.3 GRN” and then enter the parameter
setting. The display will show "X FIL" which is the first parameter.
6.2 FILTER
The filter function allows the USER to adjust the speed of display update, a setting
of 1 will mean a faster response on the display from when the weight is placed on
the pan, default is 2.
1) The display will show ‘‘X FIL’’ (X being the current setting)
2) Press the [TARE] key to increment through the various settings 1-6
3) Press the [RECALL/CE] key to confirm the setting chosen
6.3 ZERO TRACKING
The zero tracking function influences the scale to return to zero, a setting of 1 will
automatically return the display to zero when it is within 1 division of the zero point.
A setting of 7 will automatically return the display to zero when it is within 7
divisions of the zero point, if the environment is not good it may mean a higher
setting is required, default is 2.
1) The display will show ‘‘X ZEO’’ (X being the current setting)
2) Press the [TARE] key to increment through the various settings 1-7
3) Press the [RECALL/CE] key to confirm the setting chosen

© Adam Equipment Company 2012 14
6.4 STABILITY
The stability setting function adjusts when the STABILITY symbol shows, this can
be useful when printing in a number of different environments to ensure a stable and
correct reading is printed, default is 2.
1) The display will show ‘‘X STA’’ (X being the current setting)
2) Press the [TARE] key to increment through the various settings 1-6
3) Press the [RECALL/CE] key to confirm the setting chosen
6.5 AUTO POWER OFF
The auto power off function helps conserve power when using the batteries or AC
adapter. The Auto power-off time period may be set by the user and is the amount of time
in seconds of inactivity, i.e. no weight movement or key presses, default is OFF.
1) The display will show “OFF PWR”
2) Press the [TARE]key to increment through the various settings as below.
OFF PWR
Auto power off
10 PWR
10 seconds before the power will switch off
20 PWR
20 seconds before the power will switch off
30 PWR
30 seconds before the power will switch off
40 PWR
40 seconds before the power will switch off
50 PWR
50 seconds before the power will switch off
60 PWR
60 seconds before the power will switch off
70 PWR
70 seconds before the power will switch off
80 PWR
80 seconds before the power will switch off
90 PWR
90 seconds before the power will switch off
3) Press the [RECALL/CE] key to confirm the setting, the display will show “AUTO
BL”
6.6 SETTING THE BACKLIGHT
The backlight control can be set by the USER. If the backlight is disabled, the battery life
will be longer, default is AUTO.
1) The display will show “AUTO BL”.
2) Press the [TARE]key to increment through the various settings as below.
AUTO
Sets the backlight to operate automatically
ON
Sets the backlight to be ON at all times.
OFF
Sets the backlight to be OFF at all times.
3) Press the [RECALL/CE]key to confirm the setting
Pow er OFF the scale and then ON after pressing [RECALL/CE] to return to normal
weighing with the required settings.

© Adam Equipment Company 2012 15
7.0 CALIBRATION
Calibration may be required when the scale is initially installed or moved to a new
location.
Over time and use, mechanical deviations may occur so it is recommended that you
calibrate your scale regularly.
Before calibrating you should make sure you have a suitable weight. The weights should
be known to an accuracy that is appropriate for the balance being calibrated, for
example, OIML Class F1 type or ASTM E617 Class 2. If you do not have proper weights
do not attempt calibration.
1) To enter into the calibration parameter turn the power off, switch the scale on and
during the counting up sequence press the [TARE] and [STORE] keys together,
then release these keys.
2) The display will show UnLOAD, remove any weight from the pan.
3) Press the [TARE]key, the weight value used for the last calibration will be
displayed.
4) To select a different calibration weight value press the [STORE] key. This will
cycle you through the weight values that can be selected for your calibration,
values available are 500g, 1000g and 1500g.
5) Once you have selected the weight to use press the [TARE] key.
6) LOAD will be displayed, place the calibration weight on the pan.
7) Once the stable sign is shown press the [TARE] key.
8) If the weight is within 5% of the last calibration the display will show PASS, exit the
calibration routine and return to normal weighing mode. If the calibration is not
successful the display will show FAIL and exit the routine, if the calibration fails try
again.

© Adam Equipment Company 2012 16
8.0 TROUBLE SHOOTING
8.1 ERROR MESSAGES
ERROR
CODE
DESCRIPTION
POSSIBLE CAUSES
Solutions
NO dkg
No dockage results
Recall button pressed before
any screenings have taken
place
Store an initial sample,
perform a screening and
store the new weight to
give you dockage results
NO smp
No sample weight
stored
Store button pressed without a
weight on the top pan
Place a container with
grain on the top pan and
press STORE to register
your initial sample weight
Error
Incorrect weight
attempting to be
stored
A weight reading higher than
the previous one is attempting
to be stored
, or the scale did
not return to zero before the
next STOR
E was attempted
Check that the last
screening process was
performed correctly, each
screening should result in a
lower net weight than the
previous one
ADO
A/D Value too high.
Weight on the pan when
turning on.
Improper calibration of the
scale.
Damaged
load cell.
Damaged Electronics.
Remove any weight from
the stainless steel pan.
Recalibrate.
ADL
A/D Value too low.
Pan is not installed when
turning on.
Calibration not correct.
Damaged load cell.
Install pan and power on.
Recalibrate.
Low battery indicator.
Batteries may be flat.
Change the batteries.
FAIL
Calibration failure.
Incorrect mass used to
calibrate. The user calibration
is not within 5% of factory
calibration.
Possible damaged to load cell.
Try to recalibrate, check
that the weight used to
calibrate matches that of
the value
displayed on the
scale.
Unstable – machine
cannot
display a
stable reading.
Possible damage to the
mechanics /
Load cell.
Possible poor
and drafty
location caused by
air
condition
er or next to open
windows or doors.
Replace load cell
Make sure the balance is
on a flat
surface and away
from vibration and air
movement.
No Power when
turning on.
Battery may be flat. AC
adapter may not be working.
Change the batteries. Or
use the AC adapter

© Adam Equipment Company 2012 17
9.0 PARTS LIST
CQT 1752-GR
Part
number
Description
3.08.2.3.2030
IN USE COVER
3.08.1.2.2011 TOP PAN 145mm
3.08.2.3.2010
SUB PAN 145mm
3.08.2.3.2038 LOAD CELL BRACKET FOR SUB PAN
3.08.1.0.2040
LOAD CELL -2000g cell
3.08.5.6.11519 KEYPAD
3.08.4.8.2031
MAIN PCB inc DISPLAY PCB
3.08.2.3.2003 UPPER HOUSING
3.08.2.3.2004
LOWER HOUSING
7.00.4.0.0023 POWER SUPPLY STANDARD MODEL 12Vac 150ma- UK
7.00.4.0.0024
POWER SUPPLY STANDARD MODEL 12Vac 150ma- USA
7.00.4.0.0025 POWER SUPPLY STANDARD MODEL 12Vac 150ma- OZ
7.00.4.0.0026
POWER SUPPLY STANDARD MODEL 12Vac 150ma- EURO
7.00.4.0.0027 POWER SUPPLY STANDARD MODEL 12Vac 150ma- SA
3.08.1.0.2043
CARRY CASE
3.08.2.3.2032 BATTERY COVER
3.08.3.0.0001
COMPLETE PACKING
3.08.4.0.2029
POWER JACK

© Adam Equipment Company 2012 18
10.0 SPECIFICATIONS
Model #
CQT1752GR
Maximum
Capacity
1750g
Readability
0.05g
Repeatability
(Std Dev)
0.05g
Linearity ±
0.1g
Units of
Measure
grams, Kilograms per hectoliter, and
Pounds per bushel(Winchester)
Stabilisation
Time
2-3 seconds
Operating
Temperature
0ºC to 40ºC
32ºF to 104ºF
Power Supply
12VAC @ 150mA adapter or 6x AA
batteries
Calibration
Push button calibration using external mass
Calibration Mass
500g, 1000g or 1500g
user selectable
Display
6 digit LCD, 18mm digits, with backlight
Balance
Housing
ABS Plastic
Pan Size
145mm ø (5.7” ø)
Overall
Dimensions
(w x d x h)
173 x 255 x 86mm (6.8” x 10” x 3.3”)
Net Weight
760g (1.7lb)
