SERIES 6 DATA SHEET
Unied Serial® (SATA/SAS) 6Gb/s RAID Controllers Deliver Superior Bandwidth
and Reliability, Energy Efciency and Operating Costs Savings
Adaptec 6Gb/s SATA & SAS RAID Family
with Intelligent Power Management & Zero-Maintenance
Cache Protection (6405, 6445, 6805)
Adaptec Series 6 RAID controllers feature PMC-
Sierra’s market-leading, multi-core SRC 8x6G
RAID-on-Chip (ROC), 512MB DDR2 667MHz
cache, and an x8 PCI Express Gen2 host bus
connection. ey support up to 256 SATA/SAS
devices and feature Adaptec Intelligent Power
Management for improved energy-eciency, plus
Zero-Maintenance Cache Protection (ZMCP —
pronounced “zemcap”) to help data centers save
thousands of dollars in operating costs.
Highest Performance
Series 6 controllers deliver up to 60% higher
sustained sequential throughput than previous
generation Adaptec controllers and up to 2GB/s
sustained data transfer rate to the host. At peak
performance, Series 6 oers 4.8GB/s through the
SAS 2.0 interface and 4.0GB/s through the PCI
Gen 2 host interface.
Advanced Data Protection
Adaptec RAID Code (ARC) delivers maximum
reliability with RAID levels 0, 1, 1E, 5, 5EE, 6, 10,
50, 60 and JBOD. ARC also oers RAID Level
Migration (the ability to easily migrate RAID
levels), Online Capacity Expansion (expand
capacity without powering down the server),
and Copyback Hot Spare (when a failed drive has
been replaced, data is automatically copied from
the hot spare back to the restored drive).
Hybrid RAID
With Hybrid RAID 1 & 10 the Series 6 controllers
oer maximum performance and reliability
by combining Solid State Drives (SSDs) and
Hard Disk Drives (HDDs) in a single array. By
performing read operations from the faster SSD
and write operations on both the SSDs and HDDs
the result is tremendous performance gains over
standard HDD RAID arrays. Hybrid RAID oers
the benets of both technologies and allows a
better cost per GB ratio than comparable SSD-
only RAID arrays.
The Case for Cache
e fastest way for a RAID controller to fulll
a read or write request is to serve data out of
its cache. Savvy network administrators know
that enabling the RAID controller cache oers
signicant performance benets, such as reduced
latency in I/O requests, bandwidth and queue
depths that surpass soware application limits, and
on-the-y parity calculations on sequential writes.
Zero-Maintenance Cache Protection
RAID controllers typically employ battery backup
units (BBUs) to protect cached data during power
loss, but BBUs require constant monitoring and
preserve data for a maximum of 72 hours during
power loss. Series 6 controllers introduce Zero-
Maintenance Cache Protection, a revolutionary
advancement that solves BBU deciencies by
providing full protection to cached data with no
installation, monitoring, maintenance, disposal,
or replacement costs.
Featuring 4GB of SLC based NAND ash memory
with super capacitor technology (available as a
separate Kit), Series 6 controllers instantly save
cache contents in the event of system power loss.
On a power failure, the data is copied from the
high performance DRAM cache of the controller
to the NAND ash memory while the super
capacitor provides enough energy to support this
process and power the controller for approximately
60 seconds. Unlike a BBU, the data is protected for
years when copied to the ash memory.
Intelligent Power Management
Intelligent Power Management (IPM) slashes
power and cooling costs by up to 70% using
intelligent I/O caching combined with disk drive
power savings via standby and power-o modes.
One-view Storage Management
e Series 6 family operates under Adaptec
Storage Manager™, a one-view tool that centralizes
management of all Adaptec RAID products.
Broad Operating System Support
e Series 6 family supports all major operating
systems, including Windows, Linux, VMware and
FreeBSD.
Compatibility, Reliability, and Support
e Series 6 family has been extensively tested
with third-party components to deliver the utmost
in compatibility. e cards are backed by a 3-year
warranty and the company’s legendary technical
support.
™
Product Highlights
6Gb/s throughput at each port
PMC-Sierra PM8013 Dual Core
RAID on Chip (ROC)
SAS 2.0 interfaces and PCIe
Gen 2 Host Connection
4- and 8-port low-profile MD2
Supports up to 256 SATA or
SAS devices
Enclosure management support
via LED header and SES2/
SGPIO
Intelligent Power Management
– Reduces power and cooling
costs by as much as 70%
Adaptec Flash Module 600
(AFM-600) for Zero-Maintenance
Cache Protection with 4GB
NAND flash (optional kit):
– No data loss from power
failures: Replaces lithium ion
batteries
– Low Operating Costs:
No installation, monitoring, main-
tenance, disposal or replacement
costs due to batteries
– Maintenance-free cached data
protection
– Instant RAID cache protection
– Environmentally conscious
– No toxic battery disposal
– Simplified IATA compliance
Hybrid RAID 1 & 10: SSD +
HDD for Maximum Performance
and Reliability
>

SERIES 6 DATA SHEET
Adaptec SATA & SAS RAID Family (6405, 6445, 6805)
PMC-Sierra, Inc.
1380 Bordeaux Dr.
Sunnyvale, CA 94089 USA
Tel: [phone]
© Copyright PMC-Sierra, Inc. 2011. All rights reserved. PMC, PMC-SIERRA and Adaptec are registered trademarks of PMC-Sierra, Inc. “Adaptec by PMC” is a trademark of PMC-Sierra, Inc.
Other product and company names mentioned herein may be trademarks of their respective owners. For a complete list of PMC-Sierra trademarks, see www.pmc-sierra.com/legal.
DS_Series6_021711_US Information subject to change without notice.
World Wide Web: www.adaptec.com
Pre-Sales Support: US and Canada: 1 [phone] or [phone] or [email protected]
UK: [phone] or [email protected]
Australia: [phone]
Singapore: [phone]
Adaptec Unified Serial Controller Family
Why to buy? 6Gb/s performance Unified Serial RAID controllers support both SATA and SAS devices and offer unique features including Zero Mainte-
nance Cache Protection and Intelligent Power Management. Ideal for bandwidth intensive storage applications; NAS, online transaction
processing servers (OLTP), web servers, digital surveillance and streaming applications.
Customer Needs High I/O transaction and high bandwidth processing; solutions that reduce energy consumption and maintenance costs
Zero Maintenance Cache
Protection
— Maximizes performance and extends power savings by protecting data in controller cache without incurring monitoring, replacement or
disposal costs.
— Support for full installation lifecycle – up to ten years – ensuring data availability and reducing total cost of ownership.
Intelligent Power
Management
Automated customer-configurable feature that reduces disk drive energy use by up to 70% without compromising application
performance. Two configurable modes supported:
Standby mode – low-power mode; spins disks at lower RPMs (must be supported by disk drive).
Power-off mode – Spin down drives when not in use.
RAID Features — Supports up to 256 SATA or SAS devices using SAS expanders
— RAID levels 0, 1, 1E, 5, 5EE, 6, 10, 50, 60 and JBOD
— Hybrid RAID 1 & 10
— Quick initialization
— Online Capacity Expansion
— Copyback Hot Spare
— Dynamic caching algorithm
— Native Command Queuing (NCQ)
— Background initialization
— Hot-plug drive support
— RAID Level Migration
— Hot spares - global, dedicated, and pooled
— Automatic/manual rebuild of hot spares
— SES and SAF-TE enclosure management
— Configurable stripe size
— S.M.A.R.T. support
— Multiple arrays per disk drive
— Dynamic sector repair
— Staggered drive spin-up
— Bootable array support
— Optimized Disk Utilization
Management Utilities Adaptec Storage Manager™ (ASM)
— Java-based GUI Management Utility
— Remote configuration, monitoring and notification
— ASM OS Support: Windows, Linux, SCO, Solaris, FreeBSD
— Microsoft VDS Support
— SNMP, SMTP
— Remote firmware updates
ARCCONF
— Command Line Interface
Adaptec BIOS Configuration Utility (ACU)
— BIOS level configuration utility
— Flashable BIOS support
Operating System Windows 7, Windows Server 2008/2008 R2, Windows Server 2003/2003 R2, Windows Vista, VMware ESX Classic 4.x (vSphere),
Red Hat Enterprise Linux (RHEL), SUSE Linux Enterprise Server (SLES), Sun Solaris 10 x86, FreeBSD, Debian Linux, Ubuntu Linux.
The latest drivers are available at www.adaptec.com/support.
Physical Dimensions 2.536”H x 6.6”L (64mm x 168mm)
Operating Temperature 0°C to 55°C (with 200 LFM airflow)
Operating Voltage 0.17A @ 3.3V; 1.25A @ 12V measured on PCIe Gen2 systems with 6G drives.
Regulatory Certification CE, FCC, UL, C-tick, VCCI, KCC
Environmental Compliance RoHS, REACH, WEEE
MTBF 6405 is 889,115 hours / 6445 is 862,728 hours / 6805 is 860,953 hours all at 40°C
Warranty 3 years
Accessories Adaptec Flash Module 600 (2269700-R)
™
Adaptec RAID 6405 6445 6805
Order Part Number 2271100-R (kit)
2270000-R (single)
2270200-R (single) 2271200-R (kit)
2270100-R (single)
Form Factor MD2 - Low Profile MD2 - Low Profile MD2 - Low Profile
Ports 4 internal 8 (4 int / 4 ext) 8 internal
Connectors 1 SFF-8087 (int.) 1 SFF-8087 (int.) / 1 SFF-8088 (ext.) 2 SFF-8087
Bus Interface 8-Lane PCIe Gen2 8-Lane PCIe Gen2 8-Lane PCIe Gen2
Processor PM8013 PM8013 PM8013
Cache 512MB 512MB 512MB
Fanout Cable (Kit only) mSASx4 to 4xSATA
w/sideband (0.7M) x1
None mSASx4 to 4xSATA
w/sideband (0.7M) x 2
