SATA & SAS DATA SHEET
Adaptec SATA & SAS RAID Family
with Power Management
2045, 2405
Next-Generation Entry-level Unified Serial™Controllers Deliver
Hardware RAID 0, 1, 10 and JBOD for SATA and SAS Disk Drives
Product Highlights
Intelligent Power Management
800MHz Dual Core RAID on
Chip (ROC)
- High-performance RAID 0,
1, 10 and JBOD
- 128MB DDR2 cache
Low-profile MD2 form factor
Supports up to 128 SATA/SAS
devices using SAS expanders
Supports SATA and SAS
tape drives
3Gb/s throughput at each
drive port
x8 PCI Express host interface
Enclosure management support
via LED header and SES2/
SGPIO
>
These entry-level Adaptec Unified Serial
RAID controllers are designed to support
hardware hardware RAID 0, 1, 10 and JBOD
while offering direct I/O connectivity for
SATA/SAS tape devices and hard disk drives.
Equipped with an industry-leading dual
core RAID on Chip (ROC), this family
offers 128MB of DDR2 533MHz write cache
and supports up to 128 devices using SAS
expanders. They offer an x8 PCI Express
host interface bus connection in a low-
profile MD2 form factor. This family of
Adaptec Unified Serial controllers offers high
bandwidth for I/O applications and at the
same time basic hardware RAID functionality
that is fully independent of the host and
operating system and compatible with other
Adaptec RAID controller families.
Reduce power use by up to 70% with
Intelligent Power Management
The power required by disks is
a primary ongoing storage cost.
Full power is maintained to every
disk whether it is actively being
used or not, which also increases
cooling costs. Adaptec Intelligent Power
Management slashes power and cooling costs
by spinning down idle disks and providing a
lower power mode for active disks.
One-view storage management
This Adaptec Unified Serial RAID family
operates under Adaptec Storage Manager™, a
one-view tool that centralizes management
of all Adaptec RAID products. The software
enables remote configuration and monitoring
of RAID arrays through secure, encrypted
communications. The intuitive management
tool simplifies RAID array creation and power
management with pop-up tips and online help.
Broad operating system support
Extensive operating system support
includes all major software releases, such
as Windows, Linux, FreeBSD, and UNIX.
The latest operating system drivers are
available on the Adaptec support website,
www.adaptec.com/support. The Adaptec
unified driver model for Linux operating
systems allows the new Unified Serial
controllers to install with all Adaptec
Open Source Linux drivers included in the
standard Linux kernel since version 2.4.2.
Compatibility, reliability, and support
Adaptec has been delivering storage and I/O
solutions for more than 25 years. In fact,
Adaptec is the undisputed RAID leader; no
other vendor’s technology is more proven.
This Adaptec RAID Unified Serial family
has been extensively tested with third-
party components to deliver the utmost in
compatibility. The cards are backed by a
3-year warranty and legendary Adaptec
technical support.
™

SATA & SAS DATA SHEET
Adaptec SATA & SAS RAID with Power Management 2045, 2405
Adaptec, Inc.
691 South Milpitas Boulevard
Milpitas, California 95035
Tel: [phone]
Fax: [phone]
World Wide Web: www.adaptec.com
Pre-Sales Support: US and Canada: 1 [phone] or [phone]
Pre-Sales Support: Europe: Tel: [phone] or Fax: [phone]
Copyright 2008 Adaptec, Inc. All rights reserved. Adaptec, the Adaptec logo, Storage Manager, and Storage Manager Pro are trademarks of Adaptec, Inc., which may be registered in some jurisdictions.
Microsoft, Windows, Windows NT, and Windows 2000, are registered trademarks of Microsoft Corporation, used under license. All other trademarks used are owned by their respective owners.
Information supplied by Adaptec Inc., is believed to be accurate and reliable at the time of printing, but Adaptec Inc., assumes no responsibility for any errors that may appear in this document.
Adaptec, Inc., reserves the right, without notice, to make changes in product design or specifications. Information is subject to change without notice.
Part Number: 987058-011 Printed in U.S.A. 08/08 5022_2.3IN
Adaptec Unified Serial Controller Family
Why to buy? Delivers a new price/performance level and enhanced reliability for entry-level applications
Customer Needs The better reliability offered by hardware RAID, and a feature set designed for the latest applications, including Linux open source driv-
ers and external connectivity, without needing to step up to the cost of a more sophisticated controller for their entry-level applications.
Intelligent Power Management Automated customer-configurable feature that reduces disk drive energy use by up to 70% without compromising application
performance. Two configurable modes supported:
Standby mode – low-power mode; drive rotates at reduced RPM when not in use (requires that the drive support Advanced Power
Management specification). See Adaptec compatibility report for a list of supported disk drives.
Power-off mode – Spin down drives when not in use.
RAID Features — Supports up to 128 SATA or SAS devices using SAS expanders
— RAID levels 0, 1, 10 and JBOD
— Quick initialization
— Online Capacity Expansion
— Copyback Hot Spare
— Dynamic caching algorithm
— Native Command Queuing (NCQ)
— Background initialization
— Hot-plug drive support
— RAID Level Migration
— Hot spares – global, dedicated, and pooled
— Automatic/manual rebuild of hot spares
— SAF-TE enclosure management
— Configurable stripe size
— S.M.A.R.T. support
— Multiple arrays per disk drive
— Dynamic sector repair
— Staggered drive spin-up
— Bootable array support
— Optimized Disk Utilization
Management Utilities Adaptec Storage Manager™ (ASM)
— Java-based GUI Management Utility
— Remote configuration, monitoring and notification
— ASM OS Support: Windows, Linux, SCO, Solaris
— Microsoft VDS Support
— SNMP, SMTP
— Remote firmware updates
ARCCONF
— Command Line Interface
Adaptec BIOS Configuration Utility (ACU)
— BIOS level configuration utility
— Flashable BIOS support
Operating System Windows XP, Server 2003/2008, Vista, Red Hat Enterprise Linux (RHEL), SUSE Linux Enterprise Server (SLES), SCO OpenServer,
UnixWare, Sun Solaris 10 x86, FreeBSD
Physical Dimensions 2045/2405 — 2.5”H x 6.6”L (167mm x 64mm)
Operating Temperature 0°C to 35°C (without airflow)
0°C to 55°C (with 200 LFM airflow)
Operating Voltage 1 amp @ 3.3V
Regulatory Certification CE, FCC, UL, C-tick, VCCI
MTBF 873,402 hours at 40°C
Warranty 3 years
Accessories No battery option
Adaptec RAID 2405 2405 2045
Order Part Number 2260100-R (kit) 2260200-R (single) 2260300-R (single)
Form Factor MD2 - Low Profile MD2 - Low Profile MD2 - Low Profile
Ports 4 internal 4 internal 4 external
Connectors 1 SFF-8087 (int.) 1 SFF-8087 (int.) 1 SFF-8088 (ext.)
Bus Interface 8-Lane PCIe 8-Lane PCIe 8-Lane PCIe
Processor 800MHz 800MHz 800MHz
Cache 128MB 128MB 128MB
Fanout Cable Yes No No
™
