ADB Safegate RELIANCE Series User manual

RELIANCE Inset Light
8” and 12” High-intensity Runway Guard Light, Runway Guard
Light L-852G(L), and Stop Bar L-852S(L), (SL-RGL-SB-I)
User Manual
UM-0197, Rev. 1.0, 2019/11/19

A.0 Disclaimer / Standard Warranty
CE certification
The equipment listed as CE certified means that the product complies with the essential requirements concerning safety and
hygiene. The directives that have been taken into consideration in the design are available on written request to ADB
SAFEGATE.
ETL certification
The equipment listed as ETL certified means that the product complies with the essential requirements concerning safety and
FAA Airfield regulations. The directives that have been taken into consideration in the design are available on written request
to ADB SAFEGATE.
LED Product Guarantee
Where applicable, per FAA EB67 (applicable edition), ADB SAFEGATE L858(L) Airfield Guidance Signs are warranted against
electrical defects in design or manufacture of the LED or LED specific circuitry for a period of 4 years. ADB SAFEGATE LED light
fixtures (with the exception of obstruction lighting) are warranted against mechanical and physical defects in design or
manufacture for a period of 12 months from date of installation; and are warranted against electrical defects in design or
manufacture of the LED or LED specific circuitry for a period of 4 years per FAA EB67 (applicable edition).
Note
See your sales order contract for a complete warranty description. In some specific cases, deviations are (to be)
accepted in the contract, which will supersede the standard warranty.
Standard Product Guarantee
Products of ADB SAFEGATE manufacture are guaranteed against mechanical, electrical, and physical defects (excluding lamps)
which may occur during proper and normal use for a period of one year from the date of installation or 2 years from date of
shipment and are guaranteed to be merchantable and fit for the ordinary purposes for which such products are made. ADB
SAFEGATE L858 Airfield Guidance Signs are warranted against mechanical and physical defects in design or manufacture for a
period of 2 years from date of installation per FAA AC 150/5345-44 (applicable edition).
Note
See your sales order contract for a complete warranty description.
All Products Guarantee
LED Products of ADB SAFEGATE, manufactured and sold by ADB SAFEGATE or its licensed representatives, meets the
corresponding requirements of FAA, ICAO and IEC.
ADB SAFEGATE will correct by repair or replacement per the applicable guarantee above, at its option, equipment or parts
which fail because of mechanical, electrical or physical defects, provided that the goods have been properly handled and
stored prior to installation, properly installed and properly operated after installation, and provided further that Buyer gives
ADB SAFEGATE written notice of such defects after delivery of the goods to Buyer. Refer to the Safety section for more
information on Material Handling Precautions and Storage precautions that must be followed.
ADB SAFEGATE reserves the right to examine goods upon which a claim is made. Said goods must be presented in the same
condition as when the defect therein was discovered. ADB SAFEGATE furthers reserves the right to require the return of such
goods to establish any claim.
ADB SAFEGATE’s obligation under this guarantee is limited to making repair or replacement within a reasonable time after
receipt of such written notice and does not include any other costs such as the cost of removal of defective part, installation
of repaired product, labor or consequential damages of any kind, the exclusive remedy being to require such new parts to be
furnished.
UM-0197, Rev. 1.0, 2019/11/19 iii
Copyright © ADB Safegate, All Rights Reserved

ADB SAFEGATE’s liability under no circumstances will exceed the contract price of goods claimed to be defective. Any returns
under this guarantee are to be on a transportation charges prepaid basis. For products not manufactured by, but sold by ADB
SAFEGATE, warranty is limited to that extended by the original manufacturer.
This is ADB SAFEGATE’s sole guarantee and warranty with respect to the goods; there are no express warranties or warranties
of fitness for any particular purpose or any implied warranties of fitness for any particular purpose or any implied warranties
other than those made expressly herein. All such warranties being expressly disclaimed.
Liability
WARNING
Use of the equipment in ways other than described in the catalog leaflet and the manual may result in personal injury,
death, or property and equipment damage. Use this equipment only as described in the manual.
ADB SAFEGATE cannot be held responsible for injuries or damages resulting from non-standard, unintended uses of its
equipment. The equipment is designed and intended only for the purpose described in the manual. Uses not described in the
manual are considered unintended uses and may result in serious personal injury, death or property damage.
Unintended uses includes the following actions:
•Making changes to equipment that have not been recommended or described in this manual or using parts that are not
genuine ADB SAFEGATE replacement parts or accessories.
•Failing to make sure that auxiliary equipment complies with approval agency requirements, local codes, and all applicable
safety standards if not in contradiction with the general rules.
•Using materials or auxiliary equipment that are inappropriate or incompatible with your ADB SAFEGATE equipment.
•Allowing unskilled personnel to perform any task on or with the equipment.
© ADB SAFEGATE BVBA
This manual or parts thereof may not be reproduced, stored in a retrieval system, or transmitted, in any form or by any means,
electronic, mechanical, photocopying, recording, nor otherwise, without ADB SAFEGATE BVBA’s prior written consent.
This manual could contain technical inaccuracies or typographical errors. ADB SAFEGATE BVBA reserves the right to revise this
manual from time to time in the contents thereof without obligation of ADB SAFEGATE BVBA to notify any person of such
revision or change. Details and values given in this manual are average values and have been compiled with care. They are not
binding, however, and ADB SAFEGATE BVBA disclaims any liability for damages or detriments suffered as a result of reliance
on the information given herein or the use of products, processes or equipment to which this manual refers. No warranty is
made that the use of the information or of the products, processes or equipment to which this manual refers will not infringe
any third party’s patents or rights. The information given does not release the buyer from making their own experiments and
tests.
RELIANCE Inset Light
iv
Copyright © ADB Safegate, All Rights Reserved

TABLE OF CONTENTS
1.0 Safety.........................................................................................................................................................................................1
1.1 Safety Messages.......................................................................................................................................................................................................... 1
1.1.1 Introduction to Safety...................................................................................................................................................................................2
1.1.2 Intended Use.................................................................................................................................................................................................... 2
1.1.3 Material Handling Precautions: Storage................................................................................................................................................ 3
1.1.4 Material Handling Precautions: Fasteners.............................................................................................................................................3
1.1.5 Operation Safety.............................................................................................................................................................................................4
1.1.6 Maintenance Safety....................................................................................................................................................................................... 4
1.1.7 Material Handling Precautions, ESD........................................................................................................................................................5
1.1.8 Arc Flash and Electric Shock Hazard........................................................................................................................................................5
2.0 About this Manual................................................................................................................................................................... 7
3.0 Introduction..............................................................................................................................................................................9
3.1 Safety Instructions.......................................................................................................................................................................................................9
3.2 Description of the Runway Guard light fixture................................................................................................................................................ 9
3.3 Description of the Stop Bar light fixture.............................................................................................................................................................9
3.4 Dimensions of the 8" light fixture.......................................................................................................................................................................10
3.5 Dimensions of the 12" light fixture.................................................................................................................................................................... 11
3.6 Selection of Isolation transformer......................................................................................................................................................................11
3.6.1 2.8-6.6A system.............................................................................................................................................................................................11
3.6.2 Light fixture load...........................................................................................................................................................................................12
3.6.3 Cable losses (secondary cable)...............................................................................................................................................................12
3.6.4 IQ function load (Option)..........................................................................................................................................................................12
3.6.5 2A system........................................................................................................................................................................................................12
3.6.6 Transformer Calculation Examples.........................................................................................................................................................13
4.0 Installation..............................................................................................................................................................................15
4.1 Tools required.............................................................................................................................................................................................................15
4.2 Unpack the unit......................................................................................................................................................................................................... 15
4.3 Installation and removal of the 8" light fixture..............................................................................................................................................15
4.4 Installation and removal of the 12" light fixture...........................................................................................................................................17
5.0 Operation................................................................................................................................................................................19
5.1 RELIANCE Intelligent Lighting..............................................................................................................................................................................19
5.2 RELIANCE IQ and the 2A concept...................................................................................................................................................................... 19
5.3 Sensor Interface Unit (SIU)....................................................................................................................................................................................19
5.4 Network Concentrator Unit (NCU).....................................................................................................................................................................19
5.5 Series Circuit Modem (SCM).................................................................................................................................................................................19
5.6 Series Circuit Filter (SCF).........................................................................................................................................................................................19
5.7 Control System Interface........................................................................................................................................................................................19
5.8 Programming RELIANCE IQ.................................................................................................................................................................................. 20
5.8.1 Hardware equipment set-up....................................................................................................................................................................20
5.8.2 Software programming..............................................................................................................................................................................22
5.9 Connection in a Series Circuit..............................................................................................................................................................................26
5.9.1 Operational characteristics.......................................................................................................................................................................26
5.9.2 Power On or Default State........................................................................................................................................................................26
5.9.3 Safe State.........................................................................................................................................................................................................26
5.9.4 Command memory..................................................................................................................................................................................... 26
5.9.5 Soft ON/OFF...................................................................................................................................................................................................26
5.9.6 Sequenced flashing.....................................................................................................................................................................................27
5.10 Runway Guard Light system description.......................................................................................................................................................27
5.11 Stop Bar system description...............................................................................................................................................................................27
6.0 Maintenance........................................................................................................................................................................... 29
6.1 Workshop Maintenance......................................................................................................................................................................................... 29
6.2 Basic maintenance program.................................................................................................................................................................................30
UM-0197, Rev. 1.0, 2019/11/19 v
Copyright © ADB Safegate, All Rights Reserved

6.2.1 Workshop Maintenance 8" fixture.........................................................................................................................................................30
6.2.2 Workshop Maintenance 12" fixture...................................................................................................................................................... 34
6.2.3 Check the light fixture for water-tightness.........................................................................................................................................38
6.2.4 Reset the Fail Open converter 2.3..........................................................................................................................................................39
6.2.5 Reset the Fail Open converter 48010921 and 48011111..............................................................................................................40
7.0 SUPPORT.................................................................................................................................................................................41
7.1 ADB SAFEGATE website..........................................................................................................................................................................................41
7.2 Recycling.......................................................................................................................................................................................................................41
7.2.1 Local authority recycling............................................................................................................................................................................41
7.2.2 ADB SAFEGATE recycling...........................................................................................................................................................................41
8.0 Spare parts..............................................................................................................................................................................43
RELIANCE Inset Light
TABLE OF CONTENTS
vi
Copyright © ADB Safegate, All Rights Reserved

1.0 Safety
Introduction to Safety
This section contains general safety instructions for installing and using ADB SAFEGATE equipment. Some safety instructions
may not apply to the equipment in this manual. Task- and equipment-specific warnings are included in other sections of this
manual where appropriate.
1.1 Safety Messages
HAZARD Icons used in the manual
For all HAZARD symbols in use, see the Safety section. All symbols must comply with ISO and ANSI standards.
Carefully read and observe all safety instructions in this manual, which alert you to safety hazards and conditions that may
result in personal injury, death or property and equipment damage and are accompanied by the symbol shown below.
WARNING
Failure to observe a warning may result in personal injury, death or equipment damage.
DANGER - Risk of electrical shock or ARC FLASH
Disconnect equipment from line voltage. Failure to observe this warning may result in personal injury, death, or
equipment damage. ARC Flash may cause blindness, severe burns or death.
WARNING - Wear personal protective equipment
Failure to observe may result in serious injury.
WARNING - Do not touch
Failure to observe this warning may result in personal injury, death, or equipment damage.
CAUTION
Failure to observe a caution may result in equipment damage.
Qualified Personnel
Important Information
The term qualified personnel is defined here as individuals who thoroughly understand the equipment and its safe
operation, maintenance and repair. Qualified personnel are physically capable of performing the required tasks, familiar
with all relevant safety rules and regulations and have been trained to safely install, operate, maintain and repair the
equipment. It is the responsibility of the company operating this equipment to ensure that its personnel meet these
requirements.
Always use required personal protective equipment (PPE) and follow safe electrical work practice.
UM-0197, Rev. 1.0, 2019/11/19 1
Copyright © ADB Safegate, All Rights Reserved

1.1.1 Introduction to Safety
CAUTION
Unsafe Equipment Use
This equipment may contain electrostatic devices, hazardous voltages and sharp edges on components
• Read installation instructions in their entirety before starting installation.
• Become familiar with the general safety instructions in this section of the manual before installing,
operating, maintaining or repairing this equipment.
• Read and carefully follow the instructions throughout this manual for performing specific tasks and
working with specific equipment.
• Make this manual available to personnel installing, operating, maintaining or repairing this
equipment.
• Follow all applicable safety procedures required by your company, industry standards and
government or other regulatory agencies.
• Install all electrical connections to local code.
• Use only electrical wire of sufficient gauge and insulation to handle the rated current demand. All
wiring must meet local codes.
• Route electrical wiring along a protected path. Make sure they will not be damaged by moving
equipment.
• Protect components from damage, wear, and harsh environment conditions.
• Allow ample room for maintenance, panel accessibility, and cover removal.
• Protect equipment with safety devices as specified by applicable safety regulations
• If safety devices must be removed for installation, install them immediately after the work is
completed and check them for proper functioning prior to returning power to the circuit.
Failure to follow this instruction can result in serious injury or equipment damage
Additional Reference Materials
Important Information
•IEC - International Standards and Conformity Assessment for all electrical, electronic and related technologies.
•IEC 60364 - Electrical Installations in Buildings.
•FAA Advisory: AC 150/5340-26 (current edition), Maintenance of Airport Visual Aid Facilities.
•Maintenance personnel must refer to the maintenance procedure described in the ICAO Airport Services Manual,
Part 9.
•ANSI/NFPA 79, Electrical Standards for Metalworking Machine Tools.
•National and local electrical codes and standards.
1.1.2 Intended Use
CAUTION
Use this equipment as intended by the manufacturer
This equipment is designed to perform a specific function, do not use this equipment for other purposes
• Using this equipment in ways other than described in this manual may result in personal injury, death
or property and equipment damage. Use this equipment only as described in this manual.
Failure to follow this instruction can result in serious injury or equipment damage
RELIANCE Inset Light
Safety
2
Copyright © ADB Safegate, All Rights Reserved

1.1.3 Material Handling Precautions: Storage
CAUTION
Improper Storage
Store this equipment properly
• If equipment is to be stored prior to installation, it must be protected from the weather and kept free
of condensation and dust.
Failure to follow this instruction can result in equipment damage
1.1.4 Material Handling Precautions: Fasteners
DANGER
Foreign Object Damage - FOD
This equipment may contain fasteners that may come loose - torque properly.
• Only use fasteners of the same type as the one originally supplied with the equipment.
• Use of incorrect combination of gaskets, bolts and nuts can create severe damages to the product
installation and create safety risk .
• You need to know what base the light fixture will be installed in, in order to chose the correct gasket,
bolts and nuts.
• Bolt type, length, and torque value are determined by type of base, height of spacers used, and clamp
force required in FAA Engineering Brief No 83 (latest revision).
• Due to the risk of bolts vibrating loose, do not use any type of washer with the fixing bolts (such as
split lock washers) other than an anti-vibration washer. Anti-vibration washers as defined in FAA EB
83 (latest edition) must be used. For installations other than FAA, use the base can manufacturer's
recommendations.
• Always tighten the fasteners to the recommended torque. Use a calibrated torque wrench and apply
the recommended adhesive type.
• Obey the instructions of the adhesives necessary for the fasteners.
Failure to follow these warnings may cause the fasteners to loosen, damage the equipment,
potentially to loosen the equipment. This can lead to a highly dangerous situation of FOD, with
potential lethal consequences.
Note
To minimize the risk of errors, the ADB SAFEGATE Sales Representative will have information on which gasket goes
with which base. This information is also provided in the product Data sheets, the User Manuals and the Spare Part
Lists.
CAUTION
Use of incorrect combination of gaskets, bolts and nuts can create severe damages to the product installation and
create multiple safety risks.
To obtain a safe and watertight installation the O-ring and retaining bolt stated in the document must be used.
You need to know what base the light fixture will be installed in, in order to choose the correct gasket, bolts and nuts.
Failure to follow these cautions can result in equipment damage or aircraft FOD.
UM-0197, Rev. 1.0, 2019/11/19 3
Copyright © ADB Safegate, All Rights Reserved

1.1.5 Operation Safety
CAUTION
Improper Operation
Do Not Operate this equipment other than as specified by the manufacturer
• Only qualified personnel, physically capable of operating the equipment and with no impairments in
their judgment or reaction times, should operate this equipment.
• Read all system component manuals before operating this equipment. A thorough understanding of
system components and their operation will help you operate the system safely and efficiently.
• Before starting this equipment, check all safety interlocks, fire-detection systems, and protective
devices such as panels and covers. Make sure all devices are fully functional. Do not operate the
system if these devices are not working properly. Do not deactivate or bypass automatic safety
interlocks or locked-out electrical disconnects or pneumatic valves.
• Protect equipment with safety devices as specified by applicable safety regulations.
• If safety devices must be removed for installation, install them immediately after the work is
completed and check them for proper functioning.
• Route electrical wiring along a protected path. Make sure they will not be damaged by moving
equipment.
• Never operate equipment with a known malfunction.
• Do not attempt to operate or service electrical equipment if standing water is present.
• Use this equipment only in the environments for which it is rated. Do not operate this equipment in
humid, flammable, or explosive environments unless it has been rated for safe operation in these
environments.
• Never touch exposed electrical connections on equipment while the power is ON.
Failure to follow these instructions can result in equipment damage
1.1.6 Maintenance Safety
DANGER
Electric Shock Hazard
This equipment may contain electrostatic devices
• Do not operate a system that contains malfunctioning components. If a component malfunctions,
turn the system OFF immediately.
• Disconnect and lock out electrical power.
• Allow only qualified personnel to make repairs. Repair or replace the malfunctioning component
according to instructions provided in its manual.
Failure to follow these instructions can result in death or equipment damage
RELIANCE Inset Light
Safety
4
Copyright © ADB Safegate, All Rights Reserved

1.1.7 Material Handling Precautions, ESD
CAUTION
Electrostatic Sensitive Devices
This equipment may contain electrostatic devices
• Protect from electrostatic discharge.
• Electronic modules and components should be touched only when this is unavoidable e.g. soldering,
replacement.
• Before touching any component of the cabinet you shall bring your body to the same potential as the
cabinet by touching a conductive earthed part of the cabinet.
• Electronic modules or components must not be brought in contact with highly insulating materials
such as plastic sheets, synthetic fiber clothing. They must be laid down on conductive surfaces.
• The tip of the soldering iron must be grounded.
• Electronic modules and components must be stored and transported in conductive packing.
Failure to follow this instruction can result in equipment damage
1.1.8 Arc Flash and Electric Shock Hazard
DANGER
Series Circuits have Hazardous Voltages
This equipment produces high voltages to maintain the specified current - Do NOT Disconnect while
energized.
• Allow only qualified personnel to perform maintenance, troubleshooting, and repair tasks.
• Only persons who are properly trained and familiar with ADB SAFEGATE equipment are permitted to
service this equipment.
• An open airfield current circuit is capable of generating >5000 Vac and may appear OFF to a meter.
• Never unplug a device from a constant current circuit while it is operating; Arc flash may result.
• Disconnect and lock out electrical power.
• Always use safety devices when working on this equipment.
• Follow the recommended maintenance procedures in the product manuals.
• Do not service or adjust any equipment unless another person trained in first aid and CPR is present.
• Connect all disconnected equipment ground cables and wires after servicing equipment. Ground all
conductive equipment.
• Use only approved ADB SAFEGATE replacement parts. Using unapproved parts or making
unapproved modifications to equipment may void agency approvals and create safety hazards.
• Check the interlock systems periodically to ensure their effectiveness.
• Do not attempt to service electrical equipment if standing water is present. Use caution when
servicing electrical equipment in a high-humidity environment.
• Use tools with insulated handles when working with airfield electrical equipment.
Failure to follow these instructions can result in death or equipment damage
UM-0197, Rev. 1.0, 2019/11/19 5
Copyright © ADB Safegate, All Rights Reserved

RELIANCE Inset Light
Safety
6
Copyright © ADB Safegate, All Rights Reserved

2.0 About this Manual
This document includes RELIANCE™ inset light fixture information with a focus on safety, installation and maintenance
procedures.
For more information, see www.adbsafegate.com.
Note
It is very important to read this document before any work is started.
This manual covers the following 8" and 12" RELIANCE fixtures:
•High intensity Runway Guard Lights, Runway Guard Lights L-852G(L)
•Stop Bar Lights L-852S(L)
UM-0197, Rev. 1.0, 2019/11/19 7
Copyright © ADB Safegate, All Rights Reserved

RELIANCE Inset Light
About this Manual
8
Copyright © ADB Safegate, All Rights Reserved

3.0 Introduction
RELIANCE - the all in one revolution
The RELIANCE inset light is a bi- or unidirectional low-protrusion light-emitting diode (LED) fixture and available in three
versions:
•RELIANCE – a LED light fixture with integrated fail open technology with CCR monitoring
compatibility.
•RELIANCE IQ – a RELIANCE with additional and integrated intelligence (IQ) in a built in converter for
individual monitoring and control, based on RELIANCE Intelligent Lighting, ADB SAFEGATE's Individual
Light Control and Monitor System (ILCMS).
•RELIANCE IQ0 – RELIANCE IQ light fixture with disabled IQ (ILCMS) functionality. Non-MON light
fixture with possibility to activate IQ at a later stage.
Note
RELIANCE IQ light fixtures are not fail-open light fixtures. When IQ is activated the monitoring as well as the control
functionality is handled by the ILCMS system.
The inset light fixture is a 8'' or 12'' unidirectional low-protrusion LED light fixture.
The fixture can be installed in standard 8'' or 12'' bases, in existing or new airfield lighting systems. The light fixtures are ready
for installation, each unit supplied completely assembled, tested and sealed. The electrical connection is with one or two
secondary cable to a transformer(s), equipped with an FAA L-823 plug (style 6). Each unit is individually packed in a durable,
cushioned and corrugated cardboard box, labeled with its reference name and code.
This document describes the installation, operation and maintenance of the inset light fixture.
3.1 Safety Instructions
Warning
PRIOR TO THE COMMENCEMENT OF WORK ALL ELECTRICAL SERVICES MUST BE ISOLATED FROM THE SUPPLY AND
CONNECTED TO EARTH. FULL DETAILS OF THE WORK INVOLVED MUST BE GIVEN TO THE AUTHORIZED PERSON
RESPONSIBLE FOR THE ELECTRICAL ENGINEERING SERVICES AT THE AIRPORT WITH REGARD TO THE DURATION OF
THE WORK AND SO ON... IT IS RECOMMENDED THAT PRIOR TO STARTING ANY CUTTING WORK THE NATURE AND
LOCATION OF SERVICES SUCH AS CABLE DUCTS AND SO ON. SHOULD BE IDENTIFIED ANY INSTALLATION OR
MAINTENANCE WORK SHOULD ONLY BE CARRIED OUT BY TRAINED AND EXPERIENCED PERSONNEL.
HIGH LIGHT INTENSITY! DO NOT STARE DIRECTLY INTO THE LIGHT BEAM AT A CLOSE DISTANCE.
3.2 Description of the Runway Guard light fixture
The runway guard lights warns the pilots, and drivers of vehicles when they are operating on taxiways, that they are about to
enter a runway. The inset runway guard lights are alternately yellow flashing lights that are installed across the taxiway.
3.3 Description of the Stop Bar light fixture
The stop-bar lights consist of a row of unidirectional inset red light fixtures. The stop-bar is provided at the runway holding
position and is an important tool to reduce the risk for runway incursions of aircraft and vehicles.
UM-0197, Rev. 1.0, 2019/11/19 9
Copyright © ADB Safegate, All Rights Reserved

3.4 Dimensions of the 8" light fixture
19
6.35
74
165
60o
120o
O11
164
200
8-inch
RELIANCE Inset Light
Introduction
10
Copyright © ADB Safegate, All Rights Reserved

3.5 Dimensions of the 12" light fixture
12-inch
304
252
304
78 6.35
19
11
286
3.6 Selection of Isolation transformer
3.6.1 2.8-6.6A system
An Isolation transformer in a series system has a specified current ratio (normally 6.6/6.6 A) that is considered to be fixed as
long as the load does not exceed the nominal wattage of the transformer.
Most manufacturers specify a certain spare capacity (20-30%).
When the load exceeds the nominal wattage, the transformer begins to saturate, the current ratio drops as a function of the
overload. To avoid this current drop (intensity drop) the nominal wattage should not be exceeded. It is even more important
in a system with RELIANCE IQ where the IQ function adds a secondary load for its power consumption.
Note
The RELIANCE fail open is not to be connected to transformers larger than 100W. A correct calibration of the CCR is
important to achieve an accurate fail open response.
UM-0197, Rev. 1.0, 2019/11/19 11
Copyright © ADB Safegate, All Rights Reserved

The secondary load of an Isolation Transformer in a RELIANCE/RELIANCE IQ system includes:
•Lamp load
•Cable losses (secondary cables)
•IQ function load (Option)
3.6.2 Light fixture load
This load must be considered when calculating the total CCR load.
L-852G(L) - Runway Guard Light (RGL-I) 25 W
L-852S(L) – Stopbar Light (SB-I) 16 W
3.6.3 Cable losses (secondary cable)
The cable between the Isolation Transformer and the lamp adds losses that cannot be ignored, for example:
2.8-6.6A Operation
2.5 mm2 Cu-wire: 0.6 W/m
4 mm2 Cu-wire: 0.4 W/m
2A Operation
2.5 mm2 Cu-wire: 0.06 W/m
4 mm2 Cu-wire: 0.04 W/m
Note
Cable lengths should not exceed 100 m.
3.6.4 IQ function load (Option)
With IQ enabled, an additional load of 12 W need to be added to the transformer calculations
Note
RELIANCE IQ is not to be connected to transformers smaller than 65W.
3.6.5 2A system
When dimensioning the isolation transformer size for a 2A-system (a series circuit with RELIANCE IQ 2A which is only
supposed to run at 2A), it is important to know that the regular method by adding up the total wattage on the isolation
transformer secondary side, cannot be used. This is because a standard isolation transformer 6.6A/6.6A is marked with a
maximum wattage running at 6.6A. According to the Lenz Law of Induction, the dimensioning property of a transformer is the
total voltage, and not the wattage, of the secondary side of the transformer in a 50/60Hz series circuit system.
The consequence in a 2A-system is the wattage marked on a 6.6A/6.6A isolation transformer must generally be multiplied by
the factor 0.3 to find the total wattage which can be supplied from the transformer without saturating.
Note
The same dimensioning method must be used for a CCR, as the transformer kVA-size marked on a CCR is normally
calculated at 6.6A, not at 2A. There are also more constraints to consider such as spare capacity. For more information,
contact Safegate for a complete CCR dimensioning procedure.
RELIANCE Inset Light
Introduction
12
Copyright © ADB Safegate, All Rights Reserved

3.6.6 Transformer Calculation Examples
L-852G(L) Runway Guard Light Cable area
2.5 mm2
Cable area
4 mm2
Total load
(W)
Transformer
(W)
RELIANCE IQ
<50m 55 65
50-100m 85 100
<50m 45 65
50-100m 65 100
RELIANCE IQ (2A)
<50m 28 150
50-100m 31 150
<50m 27 150
50-100m 29 150
L-852S(L) Stop Bar Cable area
2.5 mm2
Cable area
4 mm2
Total load
(W)
Transformer
(W)
RELIANCE
<50m 46 45
50-100m 76 100
<50m 36 45
50-100m 56 65
RELIANCE IQ
<50m 46 65
50-100m 76 100
<50m 36 65
50-100m 56 100
RELIANCE IQ (2A)
<50m 19 100
50-100m 22 150
<50m 18 100
50-100m 20 150
UM-0197, Rev. 1.0, 2019/11/19 13
Copyright © ADB Safegate, All Rights Reserved

RELIANCE Inset Light
Introduction
14
Copyright © ADB Safegate, All Rights Reserved
