ADEMCO Vista-20 User manual

VISTA-20
2-PARTITIONED
SECURITY SYSTEM
INSTALLATION
INSTRUCTIONS
(2NDEMCOI
N7526V211/95
Previous Menu
Addition of new 5800 series
transmitters with this control
panel is prohibited, other than for
repair of existing installations.
Non-permitted use voids U.S.
warranty.

RECOMMENDATIONS FOR PROPER PR-OTECTION
Thefollowing recommendations for the location of fire and burglary detection
devices help provide proper coverage for the protected premises.– -
ecommendations For Smoke And Heat DetectorsR
With regard to the number and placement of smoke/heat detectors, we subscribe to
recommendations contained in the National Fire Protection Association’s (NFPA) Standard
notedbelow.
the
#72
Early warning fire detectionis best achievedby the installation of fire detectionequipment in
all rooms and areas of the household as follows: For minimum protection asmoke detector
should be installed outside of each separate sleeping area, and on each additional floor of a
multi-floor family living unit, including basements. The installation of smoke detectors in
kitchens,attics (finished or unfinished), or in garagesis not normally recommended.
For additional protection the NFPA recommendsthat you install Wor smoke detectorsin
the living room, dining room, bedroom(s),kitchen, hallway(s), attic, furnace room, utility and
storagerooms, basementsand attachedgarages.
In addition, we recommendthe following
Install asmokedetectorinside every bedroomwhere asmoker sleeps.
Install asmoke detectorinside every bedroomwhere someonesleepswith the door partly or
completelyclosed.Smokecouldbe blockedby the closeddoor.Also, an alarm in the hallway
outsidemay not wake up the sleeperif the dooris closed.
Install asmoke detector inside bedrooms where electrical appliances (such as portable
heaters, air conditionersor humidifiers) are used.
Install asmoke detectorat both ends of ahallway if the hallway is more than 40 feet (12
meters)long.
Install smoke detectorsin any room where an alarm controlis located.or in anv room where
.
alarm control connectionsto an AC sourceor phone lines are made. If detectorsare not so
located, afire within the room could prevent the control from reporting afire or an
intrusion.
,%wke Detectors for Minimum Protecticm
QSmoke Detectofs fer AdcMimal Protection
AHeet-ktiited Detecbs
LVNGRM
Remmmendations For Proper IntrIAon Protection
For proper intrusion coverage,sensorsshould be locatedat every possiblepoint of entry to ahomeor
commercialpremises. This would include any skylightsthat may be present,and the upper windows
in amulti-level building.
In addition, we recommend that radio backup be used in asecurity systemsothat alarm signals can
still be sent to the alarm monitoring station in the event that the telephone lines are out of order
(alarm signalsare normally sent over the phone lines, if connectedto an alarm monitoring station).
-2-

Section 1.
Section 2.
Section 3.
Section 4.
Section 5.
Section 6.
Section 7.
GENERAL DESCRIPTION ...............................................+.............................................9
INSTALLING THE CONTROL ..................................................................................... 12
Mounting the Cabinet........................................................................................................ 12
Installing the Lock (if used) ............................................................................................. 12
Mounting the Control’s Circuit Board Alone in the Cabinet........................................... 13
Mounting Control and RF ReceiverCircuit Boards Togetherin the Cabinet................ 14
Standard Phone Line Comedians .................................................................................... 15
Wiring the AC Transformer .............................................................................................. 15
Installing the Back-Up BatieW ......................................................................................... 16
Earth Ground Connections............................................................................................... 16
INSTALLING REMOTE ~W~S ............................................................................. 17
Keypads That May Be Used.............................................................................................. 17
Wiring The Keypads.......................................................................................................... 17
Mounting The Ke~ads ...................................................................................................... 18
Using ASupplementary PowerSupply To PowerAdditional Keypads.......................... 18
Preliminary Check-Out Procdure .................................................................................... 19
MECHANICS OF PROGRAMMING ............................................................................ 20
General Programming Information .................................................................................. 20
Entering Program Mode .................................................................................................... 20
Programming aData Field ................................................................................................ 20
Reviewing aData Field/Erasing an Entry in aData Field ............................................. 21
Interactive Mode Programming (*56, *80, *82, and *83) .............................................. 21
Loading Factory Defaults ..................................................................................................2l
Programming System SetupFields .................................................................................. 21
Exiting the fio~.ming Mode........................................................................................ 21
BASIC HARD-WIRED ZONES l+ ............................................................................... 22
Installing the Hard-Wired Zones...................................................................................... 22
Common CharacteristicsFor Zones l . ........................................................................ 22
Wiring Burglary and PanicDevicesto Zanes 1-8 ......................................................... 22
Wiring 2-Wire Smoke Detectorsto Zone 1..................................................................... 22
“’Veri&”Operation of 2-Wire Smoke Detectorsin Zone 1............................................. 22
Turning Off Fire Alarm %mting ................................................................................. 23
Wiring 4-Wire Smoke/CombustionDetectorson Zones2-7 ......................................... 23
Wiring 2-Wire Latching Type Glass Break Detectorson Zone 8................................. 24
Programming Hard-Wired Zones...................................................................................... 25
Check-Out Procedurefor Hard-Wired Zones ................................................................... 27
WIRED ZONE EXPANSION (4219, 4229) ................................................................... 28
Installing Zone Expansion Units ...................................................................................... 28
Connectionsand Set.Up................................................................................................. 28
Programming Wired Expansion Zones............................................................................. 29
Check-Out Procedurefor Wired Expansion Zones........................................................... 31
WIRELESS ZONE EXPANSION (5800 SYSTEM) ..................................................... 32
General Infomation .......................................................................................................... 32
ReceiverSupervision ......................................................................................................32
House Identification .......................................................................................................32
Installing the 5881/5882RF Wceiver............................................................................... 33
RF SystemInstallation Advisories................................................................................33
Installation and Set-Up ofthe 5881J5882Receiver...................................................... 33
Installing the 5800TM Module.......................................................................................... 34
Mounting the 5800TM Module ...................................................................................... 34
5800TM Wiring Connections.........................................................................................34
5800 SeriesTransmitters ..................................................................................................34
General............................................................................................................................
Transmitter Supervision................................................................................................ ::
-3-

Transmitter Input Types .........................~......................................V..............................35
Transmitter Battery Life ...............................................................................................35
programming the Receiverand Transmitters..................................................................36
Using the ‘lknsmitter Sniffer Mode ................................................................................39
To Either Temporarily or Permanently RemoveaZoneFrom the System.................... 39
Deleting aTransmitter Serial Number From aZonein *56 Mode ................................. 39
5800 SeriesTransmitters Table........................................................................................ 40
Installing 5800 Series ~msmitiers .................................................................................4l
Go/No Go Test Mode .......................................................................................................4l
SettingDIP Switcheson the 5827 Transmitter(s) .......................................................41
Section 8RELAY OUTPUTS &POWERLINE CARRIER DEVICES ...................................... 42
Relay/PowerlineCarrier DeviceBasics............................................................................42
Nos. 4204And4229 Output Relay Modules ....................................................................42
4204/4229 Setup ..........................................................................................................42
PowerlineCarrier Detices.................................................................................................43
Wifig Couections .....................................................................................................44
Programming Options Defined .........................................................................................45
Programming Output Relays and Powerline Carrier Devices........................................47
Section 9. 4285 VOICE MODULE ...................................................................................................5O
Installing the VoiceModule ..............................................................................................5O
General ~ormation .......................................................................................................5O
Mounting The VoiceModule ..........................................................................................5o
VoiceModule Wiring ......................................................................................................5l
Caller ID Units ...............................................................................................................5l
Programming The Control For Phone Access..................................................................53
Checkingthe Operation of the 4285 VoiceModule ..........................................................54
Section 10. EXTERNAL SO~E~ ...............................................................................................55
CompatibleSounders.........................................................................................................55
Somder Comectio~ .........................................................................................................56
Programming For External Souders ............................................................................... 56
Testingthe Sounder ...........................................................................................................57
Section 11. LONG RANGE RADIO ...................................................................................................58
General Information .......................................................................................................... 58
Connection
..........................................................................................................................58
Programming .....................................................................................................................58
Section 12. REMOTE KEYSWITCH ..................................................................................................59
Installing the KeysWitch...................................................................................................59
RemoteKeysw-itchConnections.....................................................................................59
programming for the RemoteKeyswitch......................................................................... 61
KeysWitchOperation .........................................................................................................62
Section 13. AUDIO AIAR.M VERIFICATION (AAV) UNIT .........................................................63
General Infomation .......................................................................................................... 63
Wfig Comections ............................................................................................................63
Programming ....................................................................................................................63
Section 14. FINAL POWER UP .........................................................................................................65
Earth Ground Connections ...............................................................................................65
Connectingthe Back-Up Batie~ ......................................................................................65
Calculating the Battery Size Needed ............................................................................65
Making the Battery Connections
................................................................................... 66
Auxiliary Device Current Draw Worksheet ..................................................................... 66
Section 15. ALPHA DESCRIPTION PROGRAMMING ................................................................ 67
&si@g~ne Descnptirs ...............................................................................................67
Entering Zone Descriptors(in program Menu Mode *82) ............................................... 67
Programming the Descriptors........................................................................................67
Alternate Method for Programming ZoneDescriptors.................................................69
Adding Custom Words .......................................................................................................70
4-

Alpha Vocabulary List (For Entering ZoneDestiptors) ...................~............................ 71
Character (ASCII) Chart ...................................................................................................71
Section 16. USING *83 MODE TO ADD, DELETE, OR CHANGE SE- NUMBERS
OF WIRELESS TRANSMITTERS ............................................................................... 72
Adding aSerial Nm&r .................................................................................................... 72
Deleting aSerial Number ..................................................................................................73
Changing aSerial Number ............................................................................................... 7-4
Section 17. SYSTEM COMMUNICATION ...................................................................................... 75
Report Code Formats ......................................................................................................... 75
Table of ContactID Codes.......................................................................................... 77
Communication Programming .......................................................................................... 78
Section 18. ZONE RESPONSE TYPE DEFINITIONS ................................................................... 83
Section 19. DATA FIELD DESCRIPTIONS ....................................................................................85
Description of SystemData Fields....................................................................................85
Section 20. REMOTE PROG RAMMING AND CONTROL (DOWNLOADING) ........................ 96
General Information .......................................................................................................... 96
Equipment Required ......................................................................................................... 96
Inititial Dotioad .............................................................................................................. 96
Remote Programming Information ................................................................................... 96
Remote Programming Advisory Notes .............................................................................97
Section 21. TESTING THE SYSTEM ................................................................................................ 98
Test Procedure................................................................................................................... 98
To the Installer .................................................................................................................. 99
Section 22. SYSTEM OPEW~ON .................................................................................................100
Security Codes..................................................................................................................100
Installer Code ............................................................................................................... 100
Master Code..................................................................................................................100
SecondaryUser Codes.................................................................................................. 100
Keypad Functions ............................................................................................................ 101
General Itiormation ..................................................................................................... 101
krning Functions .........................................................................................................lol
Panic Keys..................................................................................................................... 102
Relay/Powerline Carrier Devices(if used) ..................................................................102
4285 VoiceModule ........................................................................................................ 102
Exit Alarm Displays .....................................................................................................102
Trouble Conditions ..........................................................................................................103
General Itiomation ..................................................................................................103
“Check and “Battery”Displays................................................................................ 103
Telephone Line Failure .............................................................................................103
Power Failure ............................................................................................................ 103
Other Displays (Fixed Word Keypads).....................................................................103
Section 23. TROUBLESHOOTING GUIDE ...................................................................................104
Contacting TechnicalSupport In The Event Of Problems ............................................ 106
REGULATORY AGENCY STATEMENTS .................................................................... 107
Section 24. SPECIFICATIONS &ACCESSORIES ...................................................................... 108
Specifications...................................................................................................................108
Accessories(CompatibleDevices)...................................................................................110
APPENDIX A5800 RF SystemWireless Transmitters, Input Loop IdentificationDiagrams..... 111
Limitations Of This Alarm System ..................................................................................................113
Index ......................................................................................................................................................ll4
Limited Warranty ................................................................................................................................119
programming Form ........................................................................................................................Inseti
-5-

LIST OF FIGURES -
Figure 1.
Figure 2.
Figure 3.
Figure 4.
Figure 5.
Figure 6.
Figure 7.
Figure 8.
Figure 9.
Installing the Cabinet Lock ................................................................ 12
Mounting The PC Board ..................................................................... 13
Mounting the PC Board&RF ReceiverTogetherin the Cabinet..... 14
Telephone Line Connections............................................................... 15
Connectionof 4300 Transformer to the Control Board ..................... 16
Keypad Comections to the Control Board ......................................... 18
Using aSupplementary Power Supply............................................... 19
2-Wire Smoke DetectorConnectedto Zone 1..................................... 23
4-Wire Smoke DetectorConnections(Zones2-7) .............................. 23
Figure 10. Glass Break DetectorConnectionsto Zone 8................................... 24
Figure 11. Wiring Connection,4219 &4229 (4229 shown)...............................28
Figure 12. 5881/5882 RF Receiver(coverremoved)........................................... 33
Figure 13. 4229 ConnectionsTo Control ............................................................ 43
Figure 14. 4204 ConnectionsTo Control ............................................................ 43
Figure 15. 4300 Transformer Wiring Connections............................................44
Figure 16. 4285 Voice Module Wiring Connections........................................... 52
Figure 17. Typical Sounder Wiring ....................................................................56
Figure 18. Long Range Radio Comections......................................................... 58
Figure 19.
(A) Keystitih Wiring (4300Interfacetransformer Not Used) ............60
(B) KeyswitchWiring (4300 InterfacetransformerAlso Used)............ 60
Figure 20. Connectionof AAV Unit When Not Using a 4285VoiceModule ....64
Figure 21. Comection of AAV Unit When Also Using a 4285VoiceModule ...64
Figure 22. VISTA-20 Summary of Connections......................Inside Back Cover
-6-

HOW TO USE THIS MAIUWiL
This manual is written to accommodate both the new and the experienced installer
of Ademco products. Ageneral description of the entire system is located at the
beginning of the manual. The wiring and physical setup of the hardware follows.
The sections at the core of the manual include both hardware setup and
programming requirements of each device to make that specific device operational in
the system. Acheckout procedure is included at the end of each section. We
recommend this method to ensure that each device is working properly before
proceeding to the next section. It must also be used if you are making aparticular
addition to the system of one of these devices.
Each of the sections covering the installation of peripheral devices includes the
programming for that device. Without an understanding of the programming of the
system, you will not be able to successfully perform the required programming in
each of these sections. We therefore urge you to read Section 2. Mechanics of
Programming before any programming is petiormed.
If you are an experienced user of Ademco products, you may choose to wire and then
program the entire system at once. If so, refer to Section 4: Mechanics of
Programming and Section 19. Data Field Descriptions after the hardware setup is
complete. Ablank pull-out programming form is included with this manual.
This manual uses various icons to denote critical notes and technical tips to assist
you with the installation of this system. These are easily seen in the left-hand
column of the relevant information.
-7-

CONVENTIONS USED IN THIS MANUAL
Before you begin using this manual, it is important that you understand
the meaning of the following symbols (icons).
Enter Zn Num.
(00 =Quit) 01
*OO
Many system options are programmed in an
interactive mode by responding to Alpha keypad
display prompts. These prompts are shown in a
double-line box.
When programming the system, data fields are
indica~ by a“star; (*) fo~owed by the data field
number.
PRODUCT MODEL NUMBERS Unless noted otherwise, references to
specificmodel numbers representAdemcoproducts.

The VISTA-20 is a2-partition controlthat supportsup to 32 zones,using
basichard-wired, wired expansion,and/or wireless,plus 3keypadzones.
Baeic~zones
Rovides 8basichardwired zoneshaving the followingcharacteristics:
●
●
●
●
●
●
EOLR supervisionsupporting N.O. or N.C. sensors
Rogrammable responsetime (10, 350,or 700milliseconds)
Individually assignableto either partition
Up to sixteen$!-tie smokedetectorson zone1
4wire smokeor heat detectorson zones2through 7(asmany as canbe
poweredfrom AUX power on the contil)
Up to ~2-wire latching@pe glassbreakdetectorson zone8with auto
reset
@tiOd ~OEl &nes (Up to 24 td.a& wired end wirdeee)
Wired Expanswn:
Supports up to 8additional wired zonesusing a 4219 expansionmodule or
4229 expansionhelay module. These zones have the following
characteristics:
“ EOLR supervisionsupporting N.O. or N.C. sensors
●300-500 msecnormal responsewith an optionfor fast (10-15 msec)re-
sponseon loopA(fist expansionzone)
Wireless J%panswn:
Supportsup to 24 wirelesszones(lessifusing wired expansionzones).
●
●
Two Par@ons
●
●
●
●
Requires the use of a5881(5882 in Canada) type RF Receiver, as
indicatedbelow
Recenwr Model
.No- of= %
n
58811J5882L Upto8
588UW5882M up to 16
5881H/5882H up to 24
Requiresthe use of 5800 serieswirelesstransnu
utters
Rovides the ability to control two separateareas independently, each
area functioning asif it had its own separatecontrol
Zones(including wireless)assignableto eitherpartition 1or 2
Relay and Powerline Carrier device outputs assignable to either
partition 1or 2, or to both partitiona
Certain wozrammed smtem options, such as Entry/Exit delay and
SubsCrib&r Account n&nber, ~rogr&nmed independently for each
partition
Remote Keypads
Up to 4of any of the followingkeypadsmay beusedin eachpartition
Fixed-Word Rkypads: 4127*, 4137AD, 6127*,6137,and 6128.
*Thesekeypadscannotbeusedif the4285VoiceModuleisbeingused.
AZpho Keypads: 5137AD, 6139 (2-linealphanumericdisplays)
6138 (l-line alphanumericdisplay).

—
One installer codefor entire system(user 1)
One Master codefor eachpartition (user 2)
12 secondaryuser codesfor eachpartition (users 3-14)
One baby-sittercodefor eachpartition (user 15)
One duresscodefor eachpartition (user 16)
Keypad panic Keys
“Up to 3programmablepanickey functions are provided.
●DesignatedasZones95,96,99
●Activatedby wired &wirelesskeypads
“Reported separately by partition, distinguished by subscriber ID
number
Zone Monitor Feature
●The control will sense ahigh resistance in the loops on hard-wired
zones 2-8 if it is present, and will display airouble message (rather
than an alarm) for the afYectedzonewhen the systemis in the disarmed
mode. This feature also prevents the system from being armed while
this high resistanceconditionezists.
Exit Error False AlaIWBPrevention Feature
●Enables the system to determine the difference between aregular
alarm and an alarm causedby leaving an Entry/Exit or Interior zone
open after the exit delay expires. If not disarmed in time, an alarm will
sound and an “Exit Error” report sent to the central station.
●An Exit Alarm conditionwill alsooccurif an Entry/Exit or Interior zone
re-openswithin 2minutes afterthe end of an exit delay.
Optional output Relays and Powerline Carrier Dewicee (X-1O type)
●Up to 4relays using one 4204Relay Module
“ Up to 2relays using one 4229Zone/Relay Module
●Up to 8Powerline Carrier devices(you must subtract the number of
relay outputsactuallyusedby the 4204 or 4229 modules, if used)
optioriel Keyewitch
●Supports the Ademco4146 keyswitch on basic hardwire zone 7. May
be assignedto either partition.
Optional Voice Module
“Supports the Ademco4265 Voice Module on Partition 1only.
-10-

optional Long Bange Badio
“Allows allmessages that have been programmed togototheprimzuy
telephonenumber to be reported additionally to a 7720 PLUS or 7820
radio. Ck.eckavailability of tkese models.
Built-in Telmhme be ModtorinQ Chstion
●
Event Logging
●
Alarm output
●
●
●
The telephoneIin;vofiage can be monitoredto supervisethe phone line
connection. The panel must be connected to aproper earth
ground for this feature to function.
The lossof the line can optionally causealocaldisplay, or adisplay and
trouble sound.
Event Logging feature keeps arecord of selectedeventsin ahistory log
(UP to 48 events). AU control and readout fkom the log is done via
AdemcoV-Link softwareonly.
Provides a12VDC, 2AMP output that” can drive the compatible
sounderslisted in the EXTERNAL SOUNDERS section(assumesafully
chargedbatteqyisconnected).
Steady output for Burglary/Panic, or pulsing output for Fire
Usescun%ntlimiting circuitry for protection
Anxmary Power (hltput
●
●
●
●
Provides 12VDC, 600 mA maximum. Uses current limiting circuitry for
protection.
This output interrupts for smoke detector reset if 4-wire smoke
detectorsare used.
Programmed options are stored in electrically erasable, non-volatile
EEROM memory (information can be reprogrammed at any time and
will not be lostin the event of apowerloss).
The system can be uploaded, downloaded, or controlled via an IBM
compatiblecomputer,‘V-Link softwareand a HAYES modem specii3ed
by Ademco.
Keypad programming consists ofi
●Data field programming
●Interactive(menu) mode programming
bmmtmication Fonnate supported
●
●
●
●
Zone Descriptor v.
AdemcoLow Speed(Standard or Expanded)
Sescoa/Ttadionics(Standard or Expanded)
AdemcoExpress
AdemcoContactID
~MI can assismAlpha descriptors to all zones (useful only when using
Alpha keypa~ andor the 4285 VoiceModule).
AC power fkpp~ Uses 132UTFZ 11OVACplug-in transformer with 16.5VAC 25VA output,,
unless Powerline Carzier devices(ex.X-10 type) are used, in which casea
4200 transformer module must be used.
Back-up Battery
●Rechargeable(Gel @pe) 12VDC, 4AH minimum.
-11-

This section provides instructions for mounting the control cabinet, and
installing the cabinet lock (if used). Also included in this section are
instructions for the following
●Installing the main PC board.
“Mounting the 5881 (5882 in Canada) RF Receiverboard in the cabiuet(if
used)
●Standard phoneline connections.
cInstalhg the back-up battery in the”cabinet.
●Connecting the AC tmnsformer.
●Making earth ground connections.
Mounting the Cabinet
Mount the control cabinet to asturdy wall using fasteners or anchors (not
supplied), in aclean, dry area which is not readily accessibleto the general
public. Four mounting holesare provided at the backofthe cabinet.
If an RF Receiveris being used and you intend to mount its PC board within
the cabinet,notethe following
“Do not mount the cabineton or nesr metal objects.This will decreaseRF
range andlor blockRF hnsmissions fkomwirelesstransmitters.
sDo not locatethe cabinetin an area of high RF interference(revealedby
frequent or prolonged lighting of the LED in the receiver after it is
operational (random flicker is OK).
instalhg the Lock (ii need)
Use an Ademco No. N6277 Cam
(Retainer Clip).
Note: The cabinet can be closed
screwsin the cover’sedge.
Lock and No. N6277-1 Push-On Clip
and secured without alock by using 2
k
Figure 1. InetaUbg The Cebiiet Lock
1,
2.
3.
Removethe cabinet door.It is
easily removable for servicing
and is easily re-installed.
Remove the lock knockout
fkomthe control cabinet door.
Insert the key into the lock.
Position the lock in the hole
making certain that the latch
will make contact with the
latchbracketwhen the door is
closed.
Hold the lock steady, and in-
sert the retainer clip into the
retainer slots. Position the
clip as illustrated in order to
permit easyremoval.
-12-

Mounting The Control’s Ckuit Board Alone in The Cabiiet @lg. 2)
1. Hang two short Black mounting clips (provided) on the raised cabinet
tabs (seeDetail Bin Fig. 2).
2. Insert the top of the circuitboard into the slotsat the top of the cabinet.
Make sure that the boardrestson the correctrow (seeDetail A).
3. Swingthe baseof the board into the mounting clips and securethe board
to the cabinetwith the accompanyingscrews(seeDetail Bin Fig. 2).
Figure 2. Mountiog The PC Board
-13-

Mounting Control and RF Receiver Ckuit Boarda Togetbr, bthe Cebmet
1.
2.
3.
4.
5.
6.
7.
8.
Hang two short (black) mounting clips (provided with receiver) on the
raised cabinettabs,as shownin Detail Bin Figure 3.
Insert the top of the receiver board (removed from its own case as de-
scribed in its instructions) into the slots at the top of the cabinet, as
shownin Detail Ain Figure 3. Make sure that the board rests on the cor-
rectrow of tabs,as shown.
Swing the baseof the board into the mounting clips and secureit to the
cabinetwith the accompanyingscrews(seeDetail Bin Fig. 3).
Insert the top of the control’sboard into the slot in the clipsand position
two long (red) clipsat the lower edgeof the board (seeDetail C).
Swing this boardinto placeand secureit with two additional screws.
Insert groundinglugs (supplied with the receiver)through the top of the
cabinetinto theleft-hand terminals of the antenna blocks(at the upper
edgeof the receiverboard) and securethem to the cabinettop with the
screwsprovided,as shownin Detail D.
Insert the receiver’santennasthrough the top of the cabinet,into the
blocks’right-hand terminals, and tightenthe screws.
Refer to the WIRELESS ZONE EXPANSION sectionfor setup and wiring
of the receiver.
i4vLEs mm AN7HNWS
AND GROIJNLWJC LUGS
SOAm SUPPOSTING SLo’rs
RESEIESEII Uncul-f
MAW SoARo
DC-rut A
sJcnEmEw OF
BoARo wPPORllNG SLOB
SHORT(sIA@ MOUNTINGCLIPS >
COwROl.
w-y
LONG(FEO)MOUNTINGCLIPS
@@
ILu TOc?m m
S40E WEWOF
-MOUNTING CLIPS
~SCREW OrrAIL c
~ANTENNA SIDEVIEWof
eLONGMOusnw CLIPS
V/
GROUNOING LUG “
h— :’::
‘f=
Figure 3. Mounting 7be PC Board And RF Receiver Together In lb Cabinet
-14-

Stenderd Fimne Line ComMctione
Incoming phone line and handset wiring is connectedto the main terminal
block(via aRJ31Xjack) asfollows(alsoseeFigure 4>
Term. 21: LocalHandset (TIP -Brown*)
Term. 22: LocalHandset (RING -Grafl)
Term. 23: IncomingPhone Line (TIP –Green*)
Term. 24 IncomingPhone Line (RING –Red*)
*Colorsofwiresin DirectConnectCord.
––i E@E@iEl
Incoming
Handset TelcaLine
21 22 23 24 2S
TERMINALS
ON CONTROL >y“-I,NciMiNGiE,co,,N,
r
C5
z
z
131x:;G PREMISES
ml ~~+ I“IJACK PHONES
1I“u
r
PLUG
I
Figure 4. Telephme Line Connections
We Ilse AC T~
132U’I’F2 Wire the 132UTF2 transfomner to terminals 1 and 2 on the control board.
Seewking table belowfor wire gaugeto use.
Caution must be taken when wiring the transformer to the control panel to
guard against blowing the fuse inside the transformer (the fuse is non-
replaceable).
4300 If you are going to use a 4300 transformer interface (required if Powerline
Carrier devices are going to be used), connect the 4300 transformer’s
terminals as follows:
a. Terminals 1, 3(AC), and 2 (Ground) to ccmtiolboard terminals 1, 2, and
25, respectively(seeFigure 5). Seetable belowfor wire gauge to use.
WIRING TABLE
Distanceof Transformer WireGauge
Fromthe ControlPanel To Use
up to50feet #20
50-100feet #18
100-250feet #16
-15-

b. Wire the other three terminals (Sync,- Data, Corn) on the 4300
transformer. Wires from these terminals must be connectedto a9-pin
connectoron the controlboard (using a4142TR cablesupplied with the
4300 transformer), as shownin Figure 5. Theseparticular wires canbe
24 gauge or larger, snd can be run along with the AC and ground wires
to the controlpanel.
The complete wiringfor the 4300 transformer is also coveredin Section 8.
RELAY OUTPUTS &POWERLIAW CARRIER DEVICES.
00 TRANSFORMERANTERFACE
mlo
Earth
AC GroundAC i
w
123
Vtt
1252
TERMINALSON
CONTROL
BOARD
n
)
.
~‘“””””
000000000 ONm’mo,m)lr?,
1
IIIIiIiII
111t I I I 1I
c4142TRCASLE
1I
“%-J H“’” m-r Y
IINOT “--
USED \
USSD THESEWIRES(7,8,& 9)NOTUSED
UNLESS4145KEW3VITCHANDIOR
Figure 5. Connections of 4300 Transformer To The Control Board
.
IneMhng The Back-Up Battery
If necessary, refer to Section 14. FINAL POWER UP for information
regarding battery sizeto use, etc.
LPlace the 12-voltback-up battery in the controlcabinet.
2. Attach Red and Black wires on the batteqyconnectorcableas follows:
a. Red to the positive(+) battery terminal on the control board (see
Summaqy of ConnectionsDiagram for location,ifnecessary)o
b. Black to the negative (-) battery temnind on the control board.
EarthGroundCkmections
The designated earth ground terminal (25), must be terminated in a good
earth ground for the lightning transient protectivedevicesin this product to
be effective. The following are examples of good earth grounds available at
most installations:
Metal Cold Water Pipe: Use anon-comosive metal strap (copper is
recommended) fmly secured to the pipe to which the ground lead is
electricallyconnectedand secured.
AC Power Outlet Ground Available born 3-prong, 120VAC, power outlets
only. To test the integri~ of the ground terminal, use a.three-wire circuit
tester with neon lamp indicators, such as the UL-Listed Ideal Model 61-035,
or equivalent, availableat most electricalsupply stores.
-16-

This section lists the wired keypads that may be used and provides
instructions for wiring and mounting thekeypads.
Apreliminary check-out procedure is also provided to ensure that the
connectedkeypadsare fimctioning properly in the system.
~tiM~*U=d GFixed-Word Display. 4137AD, 4127,6127, 6128, 6137
●Alpha Display 5137AD, 6138, 6139
●Up to 4keypadsin eachpartition (totalof 8in the system),independent of
auxiliary power considerations(you may need to use an auxiliary power
SUPPlYif the 600mA aux. output is exceeded)
W~To The Keypade
1. Determine wire gauge by referring to the wiring lengtldgauge chart
below. Wire lengthdgauge for Partition 2keypads should be determined
separatelyfkomthosekeypadaconnectedto Partition 1.
For devices(Keypads,RF Receivers,Zone Expander, etc.)connectedto a
single 4-wire run, determine the current drawn by all units connectedto
the single wire run, then refer to the Wiring Run chart to determine the
maximum wire length that can be safelyused for eachwire size. Current
draw for all devices can be found in the SPECIFICATIONS AND
ACCESSORIES section.
Note Refer to “Auxiliary Device Current Draw Worksheet” in Section
14.F~AL POWER UP for current draw for all keypads.
W~g Run Chart For Devices* Drawing AusPower From
The Control (12V+ &12V-)
TOTALCURRENTDBAWNBYALLDEVICESCONNECTEDTOASINGIX WIRE RUN
wire size 50mAorless 100IA 300nA 500 IA 6oonA
#22 500ft(152m) 250ft(76m) 80ft (24m) 50ft (15m) 42ft (13m)
#20 I750ft(228.6m) I380a (l16m) I130R(39.6m) I80ft (24m) I67ft (20.4m)
#18 1300ft (396m) 650t%(198m) 220fi (67m) 130ft (39.6m) 115ft (35m)
#16 1500ft (457m) 1000R(305m) 330ft (100.5m) 200ft (70m) 170ft (52m)
*IncludesKeypads,RF Receivers,ZoneExpander/RelayUnits,or4285VoiceModule.
2. Run field wiring fkom the control to the keypads (using standard 4-
conducturtwistedwire cableusing the wire gauge determinedin step 1).
-17-

3. Connectremote Keypadsfor Partition 1to brminals 4,5,6, and 7 on the
controlboard, as shownin Figure 6.
4. Connect remote Keypads for Partition 2@the 4-pin connector on the
control board (see the SurnmarY of Connections diagram for location of
the 4pin connectorfor partition-2).
CON?-ROL 1!
TERMINALS
KEYPADCONNECTORCABLE(SUPPLIEDWITH VISTA-20)
N4632-E I
n
l\ PARTITION 2KEYPADS
I
I
CONNECTOF?PINS FOR
PARTITION2ON CONTROL BOARD
Fii6. Kaypad Commctm
“naTo The Control Board
Mountimg the Kaypads
1. Make sure addressable type keypads (4137AD, 5137AD, 6128,6137,
6138, and 6139) are set to non-addressablemode (address 31), which is
the factory default setting. Refer to the instructions provided with the
keypad for addresssettingprocedure.
2. Mount the keypads at aheight that is convenientfor the user. Refer to
the instructionsprovidedwith the keypadfor mounting procedure.
You can either surface mount or flush mount keypads (using an
appropriate Trim Ring Kit: 5137TRK or 6139TRIQ. Refer to the
mounting instructions and template included with the keypad and/or
trim ring kit for spetic information.
Wing aSupplementary Power supply to Powar Add&mid Kaypada
The conixolprovides 600mA for powering keypads (up to amaximum of 4per
partition) end other devicesfkom the auxiliary power output. The backup
batterywill supply powerto thesekeypadsin the event that AC power is lost.
When the control’sauxilky powerload for all devicesexceeds600 @you
can power additional keypads fkom aregulate~ 12VDC power supply (e.g.,
487-12 supplies 12V, 2504, 488-12 supplies 12V, 5001nA). Use aUL
Listed,battery-backedsupply for UL installations.
The 487-12/488-12 power supplieshave a backup battery which can power
thesekeypads in the event ofAC powerloss.
-18-

‘1 I
SUPPLEMENTARY CONTROL
POWERSUPPLY TERMINALSTRIP
F&ma 7. Using ASu=)piammtarp Power Supply For Keypads
check-out Procedura
If you want to checkthat the systemis working beforeconnectingfield wiring
from zonesand devices,do the foll-
1.
2.
3.
4.
Temporarily connecta 2000 ohm end-of-line resistor across each of the
basic hard-wire zones 1-8, as shown in the Summary of Connections
diagram.
Without actual zone wiring or EOL resistors connected,the keypads in
eachpartition ofthe systemwill not display the ‘l?eadfl message.
Power up the system temporarily by plugging the AC transformer
(previouslywired to the control)into a120VAC outlet.
Busy -Standby (Alpha keypads) or dl (Fixed-word keypads) will be
displayed.
-r approximately 1minute*, the green ‘TtEADY” LED (or TOWER”
LED on some@es of keypads)should light, and the word READY (Fixed-
word keypads),or DISARMED...READY TO ARM (Alpha keypads) should be
displayed.
*To bypassthe l-minute delay,press#plus O.
If the %eady” display doesnot appesron any of the keypadsin the system
(in either of the partitions), or a‘lNotReady messageis displayed, check
the keypad wiring connections,and make sure each of the 8basic hard-
wired zoneshas a 2000 ohm resistorconnectedacrossits terminals.
When you getthe proper “Ready”displays on the keypad(s),the systemis
functioning properly at this point.
Do not removethe EOL resistorauntil you are ready to make connections
to the hard-wired zones,to allowfor testinglater in the manual.
-19-

This sectionprovides information on how programming is performed in this
system. It will enable you to understand how to enter and exit the
programming mode,and how to program the data fields and the user-friendly
interactivemodes (*56, *80, *81, *82, *83). We therefore urge you to read
and understand the followingbeforeproceedingwith the installation.
.
Rqmmmmg Infcmnation
Characteristicsfor eachinstallation are storedin non-removable, electrically
erasable,non-volatile EEROM memory. These must be programmed for the
particularinstallation to establishits specificalarm and reporting features.
It is possible to program the system at any time, even at the installer’s
premisesprior to the actual installation. Simply appIy power temporarily to
the contioland then program the unit as desired.
Important Note: You cannot enter the programming mode unless
~ptilioIM are disarmed.
There are two programming
gmodes: data field pro- amming and interactive
(menu) mode programming. Data field programming is used for setting
various system options and interactive programming is used for
programming zone information, progmmming relay outputs, and for learning
transmitter serial numbers.
Rogramming canalsobe performedremotely horn the installer’s office/home,
using an IBM personal computer, amodem, and V-Link downloading
software. See the REMOTE PROGRAMMING AND CONTROL
(DOWNLOADING) SeCtiOIl,
Entering Program Mode
You may use one of the followingmethods:
a) Press both the [*] and [#] keys at the same time within 50 seconds
after power is applied to the Control, or
b) Mter powerup, enter the Installer code(4 1 1 2)+ SO0.
This method is disabledif you exit the program mode using *98 instead of
*99. See“Ex~ fiogram Mode” paragraph later in this section.
If adifTerentInstsler codeis subsequentlyprogrammed, use it instead of
4112to gain accessto the I?rogrammin
gmode.
Following entry into program mode, data field *2O will be displayed (this is
the first field in the system).The systemwill now acceptentries for field =0.
-~s aD* ~~d
1. Press [*] plus Field No. (for example,*21), then make the required entry.
2. When you have completely programmed adata field, the keypad will
“beep”three times and then automatically display the next data field in
sequence.Togo to adifferent field, press [*] PIUSthe desiredfield No.
-20-
