Adey MagnaClean Micro2 User manual

Installation and servicing

IMPORTANT - Always follow the electrical and safety standards when installing a MagnaClean filter
ensuring pipework is appropriately earth bonded either side of the filter.
For the most up to date version of the MagnaClean Micro2 Installation and Servicing
instructions visit adey.com. Warranty Terms & Conditions can be found at adey.com
Maximum working pressure: 6 bar
Maximum working temperature: 95°C
Flow rate: <50 l/min
Inlet: Bi-directional
MagnaClean filter contains a strong magnet. Keep away from all electrical devices, bank cards
and other magnetic devices.
MagnaClean filter contains a strong magnet. Caution should be taken at all times when handling
if you have a pacemaker fitted.
MagnaClean filter is a pressurized device. Always release pressure before servicing.
Unit may be hot in operation. Handle with care.
CAUTION:
Important
MagnaClean Micro2 is a compact filter delivering exceptional protection for domestic central heating
systems.
MagnaClean Micro2®
The following instructions are designed to support engineers in the safe and effective installation and
servicing of MagnaClean Micro2 and should be followed at all times. It is recommended that the filter
is installed by a qualified heating engineer. The lid seal should be checked for wear when servicing
MagnaClean®. It is Best Practice to replace the lid seal at each service. To arrange replacements please
visit adeyspares.co.uk or contact the ADEY Team on [phone].
Always re-dose the system with a suitable Protector such as ADEY MC1+®or MC1+ Rapide®
Central Heating System protector

Combi/sealed system
Open vented system
MagnaClean Micro2 can be installed anywhere before the boiler. To achieve the best
level of protection, it is recommended that the filter is fitted after the last radiator and before the boiler.
This also ensures a system flush can be carried out using a MagnaCleanse®on the return (position A
only).
Installation overview
Note: In both diagrams, position A is best practice, Position B is suitable if space is tight on the return.
New filter installation
4
2
1
2
4
3
4
1
- Always ensure the filling loop is fitted after the filter.
Cut and remove
section.
Valve A
Valve B
1
2
98mm
1
2

4
54
6
4 4
784
9
1
1
4
4
Ensure pin is in
locked position.
Tighten
compression
nuts.
CAUTION:
Do NOT
overtighten.
4
11
4
10 Tighten by a ¼ turn.
Important - Do NOT
overtighten.
Hand
tighten.
2
1
3
4
12
1 - Turn valves on.
2 - Vent.
3 - Wipe filter dry.

Servicing
1
2
4
11 - Turn valves off.
2 - Vent.
1
4
2
Remove
drain plug Vent.
4
3
4
4
Replace drain plug.
Important - Do NOT
overtighten.
4
5
Remove lid
assembly.
4
6
1
2
3
4
7
Remove sleeve.
Clean
1
1
2
3
4
8
Clean
Clean
4
9

4
10
O ring
The lid seal should be cleaned
and checked for wear when
servicing MagnaClean. It is
Best Practice to replace the
lid seal at each service.
1
Hand
tighten.
4
11 4 12 Tighten by a ¼ turn.
Important - Do NOT
overtighten.
1
2
3
4
13
1 - Turn valves on.
2 - Vent.
3 - Wipe filter dry.
Only use Silicon grease or
water to lubricate O ring.
Do not use flux or EP grease.

Replace locking pin
and turn 90°to lock.
4
5
4
4
Quick-release trigger
4
2
4
14 3
MagnaClean Micro2 incorporates a secure, quick-release, trigger which enables the filter to be
removed and reinstalled in seconds. The connections enable easy and swift filter removal during
servicing or to undertake a MagnaCleanse system flush. This also makes it ideal for systems where
there is little room to install a filter.
The following instructions are designed to support engineers in the safe and effective servicing of
MagnaClean Micro2 using the quick-release trigger.
Note: Follow servicing steps 1, 2, 3 and 4 before following Quick-release trigger steps below.
Disconnect.
Turn locking pin 90°
and remove. Remove.
Clean collets and lubricate
seals with water.
Fit quick release
trigger and canister
onto valves.
