Adey MagnaClean Micro 2 User guide

2
Telephone: [phone] Email: [e-mail]
www.adey.com
Produced from recycled material
A carbon neutral company
Installation and servicing
instructions
M06525 LF2-01-01366
MagnaClean®Micro2 incorporates a secure, quick-release, trigger which
enables the filter to be removed and re-installed in seconds.
The industry leading connections are an integral part of the new MagnaClean
Micro2 design. They enable easy and speedy filter removal during annual
servicing or to undertake a MagnaCleanse system flush. This also makes it ideal for
systems where there is little room to install a filter.
The following instructions are designed to support engineers in the safe and
effective servicing of MagnaClean Micro2 using the quick-release trigger.
Quick-release trigger
FOR BEST RESULTS
Install and service with MC1+, the advanced system inhibitor from
the UK’s No 1 manufacturer of magnetic filters.
Micro
Micro
MagnaClean®Micro2 is a proven, high efficiency, full-flow, compact magnetic and
non-magnetic filter. It is designed to protect domestic heating systems and remove
virtually 100% of suspended black iron oxide.
It delivers exceptional domestic central heating system protection against the
damaging effects of black iron oxide sludge and non-magnetic debris in applications
where space is extremely limited.
The compact in-line and rapid fit filter not only helps reduce heating energy bills
and extend the operational life of the system, it also helps reduce maintenance
costs and carbon emissions.
IMPORTANT Always follow the Standard Electrical Best Practice guidelines when
installing a MagnaClean filter. A copy of these guidelines can be found at
www.hse.gov.uk/electricity
The inlet and outlet on MagnaClean Micro2 are reversible and there is no flow
restriction. Following installation, don’t forget to complete the warranty card.
Alternatively, complete the registration online at www.adey.com
This product is backed by a two year limited guarantee.
MagnaClean Micro2
1
54
N.B. Periodically remove collets
and lubricate seals with water
Replace the collets,
quick-release trigger
and canister.
3
Turn locking pin 90˚
and remove
Replace locking pin
and turn 90˚to lock

MagnaClean®Micro2has been developed by the company that pioneered
magnetic filtration. ADEY’s filters protect more than a million central heating systems in
UK homes removing virtually 100% of the damaging suspended black iron oxide sludge
that builds up in all heating systems.
The dual-action filter can be installed anywhere on the main circuit. However, to achieve
the best level of protection for the boiler, it is recommended that MagnaClean Micro2 is
fitted after the last radiator and before the boiler.
Installation
The following instructions are designed to
support engineers in the safe and effective
installation and servicing of MagnaClean
Micro2 and should be followed at
all times.
Any queries should be directed to your
supervisor or ADEY direct on 01242 546717. Open vented system Combi/Sealed system
In both diagrams, position Ais best
practice, while Bis suitable.
N.B. We firmly recommend MagnaClean
Micro2 is installed and serviced by a
qualified heating engineer.
Your system is protected by
Annual service required
www.adey.com
Lubricate
with jointing
compound
2
Servicing
3
2
1
2
Open drain
Close
drain
Open vent
Take care not to
over tighten
4
No need to
over tighten
7
67
CUT AND REMOVE SECTION
1
1
2
3
Tighten compression nuts
4589
6
2
1
Open
vent
Turn
valves
ON
10
1
2
Open vent
Turn
valves
OFF
13
1
2
3
4
Clean
Clean
5
Clean
Remove sleeve
1
2
Open
vent
Turn
valves
ON
8
Ensure pin is in
locked position
Micro
Micro
98mm
