ADF Web HD67908-5-A1 User manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus Slave
/ HART Master
Document code: MN67908_ENG Revision 1 001 Page 1 of 32
User Manual
Revision 1 001
English
Modbus Slave / HART Master - Converter
(Order Code: HD67908-5-A1)
For Website information:
www adfweb com?Product=HD67908
For Price information:
www adfweb com?Price=HD67908-5-A1
Benefits and Main Features:
Very easy to configure
Triple Electrical isolation
Temperature range: -40°C/+85°C (-40°F/+185°F)
For other HART products see also the following link:
Converter HART Master to
www adfweb com?Product=HD67900 (Serial)
www adfweb com?Product=HD67901 (BACnet Slave)
www adfweb com?Product=HD67902 (CAN)
www adfweb com?Product=HD67903 (CANopen)
www adfweb com?Product=HD67904 ( eviceNet Slave)
www adfweb com?Product=HD67905 (Ethernet)
www adfweb com?Product=HD67906 (EtherNet/IP Slave)
www adfweb com?Product=HD67907 (J1939)
www adfweb com?Product=HD67909 (Modbus TCP Slave)
www adfweb com?Product=HD67910 (MQTT)
www adfweb com?Product=HD67911 (PROFIBUS Slave)
www adfweb com?Product=HD67912 (PROFINET Slave)
www adfweb com?Product=HD67913 (SNMP Agent)
Do you have your customer protocol? Then go to:
www adfweb com?Product=HD67003
Do you need to choose a device? Do you want help?
www adfweb com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus Slave
/ HART Master
Document code: MN67908_ENG Revision 1 001 Page 2 of 32
IN EX:
Page
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAMPLE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 6
CONFIGURATION 6
POWER SUPPLY 7
FUNCTION MODES 8
LEDS 9
HART 10
RS485 11
ETHERNET 12
USE OF COMPOSITOR SW67908 13
NEW CONFIGURATION / OPEN CONFIGURATION 14
SOFTWARE OPTIONS 15
SET COMMUNICATION 17
HART VARIABLES 19
UPDATE DEVICE 21
SCAN FUNCTION 23
WEBSERVER INTERFACE 25
MECHANICAL DIMENSIONS 29
ORDERING INFORMATIONS 30
ACCESSORIES 30
DISCLAIMER 31
OTHER REGULATIONS AND STANDARDS 31
WARRANTIES AND TECHNICAL SUPPORT 32
RETURN POLICY 32
UP ATE OCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document
With this “Document Code” go to web page www adfweb com/download/
and search for the corresponding code on the page Click on the proper
“Document Code” and download the updates
REVISION LIST:
WARNING:
ADFweb com reserves the right to change information in this manual about
our product without warning
ADFweb com is not responsible for any error this manual may contain
TRA EMARKS:
All trademarks mentioned in this document belong to their respective
owners
Revision ate Author Chapter escription
1 000 18/06/2019 Tf All First Release
1 001 27/04/2020 Ff All Added web pages for HART conf

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus Slave
/ HART Master
Document code: MN67908_ENG Revision 1 001 Page 3 of 32
SECURITY ALERT:
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual When using the device, legal and
safety regulation are required for each individual application The same applies also when using accessories
I NTEN E U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i e
independent limit switches, mechanical interlocks, etc )
Q UALIFIE P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job
R ESI UAL R ISKS
The device is state-of-the-art and is safe The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage
CE CONFORMITY
The declaration is made by our company You can send an email to support@adfweb com or give us a call if you need it

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus Slave
/ HART Master
Document code: MN67908_ENG Revision 1 001 Page 4 of 32
EXAMPLES OF CONNECTION:

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus Slave
/ HART Master
Document code: MN67908_ENG Revision 1 001 Page 5 of 32
CONNECTION SCHEME:
Figure 1a: Connection scheme for HD6790 -5-A1

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus Slave
/ HART Master
Document code: MN67908_ENG Revision 1 001 Page 6 of 32
CHARACTERISTICS:
The HD67908-x-A1 are Modbus Slave / HART Master - Converters
It allows for the following characteristics:
Triple isolation between Serial - Power Supply, Serial - HART, HART - Power Supply;
Two-directional information between Serial bus and HART bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F]
CONFIGURATION:
You need Compositor SW67908 software on your PC in order to perform the following:
Define the parameters of Modbus line;
Define the parameters of HART line;
Define HART variables in read/write;
Update the device

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus Slave
/ HART Master
Document code: MN67908_ENG Revision 1 001 Page 7 of 32
POWER SUPPLY:
The devices can be powered at 8…24V AC and 12…35V DC For more details see the two tables below
VAC
V C
Vmin Vmax Vmin Vmax
8V 24V 12V 35V
Consumption at 24V DC:
evice Consumption [W/VA]
HD67908-X-A1 3 5
HD67908-X-A1
Caution:
o n
ot reverse the polarity power

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus Slave
/ HART Master
Document code: MN67908_ENG Revision 1 001 Page 8 of 32
FUNCTION MO ES:
The device has got two function modes depending on the position of the ‘Dip2 of Dip-Switch A’:
The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device
The second, with ‘Dip2 of Dip-Switch A’ at “ON” position, is used for uploading the Project and/or Firmware
For the operations to follow for the updating, see ‘UPDATE DEVICE’ section
According to the functioning mode, the LEDs will have specific functions, see ‘LEDS’ section
Warning:
Dip1 of ‘Dip-Switch A’ must be at ON position to work even if the Ethernet cable is not inserted

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus Slave
/ HART Master
Document code: MN67908_ENG Revision 1 001 Page 9 of 32
LE S:
The device has got six LEDs that are used to give information about the functioning status
The various meanings of the LEDs are described in the table below
LE Normal Mode Boot Mode
1: HART communication
(green) It blinks when HART communication is running Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
2: Ethernet link (green) ON: Ethernet cable connected
OFF: Ethernet cable disconnected
ON: Ethernet cable connected
OFF: Ethernet cable disconnected
3: Modbus communication
(green) It blinks when a Modbus request is received Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
4: Device State
(green) Blinks slowly (~1Hz) Blinks quickly: Boot state Blinks very slowly (~0.5Hz): update in progress

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus Slave
/ HART Master
Document code: MN67908_ENG Revision 1 001 Page 10 of 32
HART:
“HART” is an acronym for Highway Addressable Remote Transducer The HART Protocol makes uses Frequency Shift Keying (FSK) standard
to superimpose digital communication signals at a low level on top of the 4-20mA This enables two-way field communication to take place
and makes it possible for additional information beyond just the normal process variable to be communicated to/from a smart field
instrument
It is possible to provide the current loop for HART communication and an additional low power supply @ 24 V DC for feeding HART devices
by setting Dip-Switch D at ON position
Current loop for HART is required when there is not an external device in the bus that provides it

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus Slave
/ HART Master
Document code: MN67908_ENG Revision 1 001 Page 11 of 32
RS485:
For terminate the RS485 line with a 120Ω resistor it is necessary to put ON dip 1, like in figure
The maximum length of the cable should be 1200m (4000 feet)
Here some codes of cables:
Belden: p/n 8132 - 2x 28AWG stranded twisted pairs conductor + foil shield + braid shield;
Belden p/n 82842 - 2x 24AWG stranded twisted pairs conductor + foil shield + braid shield;
Tasker: p/n C521 - 1x 24AWG twisted pair conductor + foil shield + braid shield;
Tasker: p/n C522 - 2x 24AWG twisted pairs conductor + foil shield + braid shield

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus Slave
/ HART Master
Document code: MN67908_ENG Revision 1 001 Page 12 of 32
ETHERNET:
The updating of the converters must be made using Connector4 of the HD67908-X-A1 with at least a Category 5E cable The maximum
length of the cable should not exceed 100m The cable has to conform to the T568 norms relative to connections in cat 5 up to 100 Mbps To
connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended
the use of a cross cable

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus Slave
/ HART Master
Document code: MN67908_ENG Revision 1 001 Page 13 of 32
USE OF COMPOSITOR SW67908:
To configure the Converter, use the available software that runs with Windows called SW67908 It is downloadable on the site
www adfweb com and its operation is described in this document (This manual is referenced to the last version of the software present on
our web site) The software works with MSWindows (XP, Vista, Seven, 8, 10; 32/64bit)
When launching the SW67908, the window below appears (Fig 2)
Note:
It is necessary to have installed Net Framework 4
Figure 2: Main window for SW67
90

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus Slave
/ HART Master
Document code: MN67908_ENG Revision 1 001 Page 14 of 32
NEW CONFIGURATION / OPEN CONFIGURATION:
The “New Configuration” button creates the folder which contains the entire device’s configuration
A device’s configuration can also be imported or exported:
To clone the configurations of a programmable “Modbus Slave / HART Master” in order
to configure another device in the same manner, it is necessary to maintain the folder
and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “Open Configuration”

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus Slave
/ HART Master
Document code: MN67908_ENG Revision 1 001 Page 15 of 32
SOFTWARE OPTIONS:
By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the
compositor
In the section “Language” it is possible to change the language of the
software
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb com website
Checking the option “Check Software Update at Start of Program”, the
SW67908 checks automatically if there are updatings when it is launched

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus Slave
/ HART Master
Document code: MN67908_ENG Revision 1 001 Page 16 of 32
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in
the different sections of the software

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus Slave
/ HART Master
Document code: MN67908_ENG Revision 1 001 Page 17 of 32
SET COMMUNICATION:
This section define the fundamental communication parameters of HART and Modbus
buses
By Pressing the “Set Communication” button from the main window for SW67908 (Fig
2) the window “Set Communication” appears (Fig 3)
The means of the fields for the “HART Master” section are:
In the field “Address” the type of Master is defined;
In the field “Retry Limit” the maximum number of retries in case of missing
response from HART device is defined;
The means of the fields for the “Modbus Slave” section are:
In the field “Baudrate” the baudrate for the serial line is defined;
In the field “Parity” the parity of the serial line is defined;
In the field “Stop Bits” the number of Stop Bits of the serial line is defined;
In the field “I evice” the ID of Modbus side of the converter is defined (only if
“Asynchronous” mode is set);
If the field “Read with Input Register / Status Function” is checked, it is
possible to read the data from HART side with Input Registers (Function 04) and
write the data to publish on HART side with Holding Registers (Function 06/16) The
Output data are readable with Function 03 Otherwise, only Holding Registers will
be used and the Output data of HART side cannot be read back
Figure 3: “Set Communication” window

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus Slave
/ HART Master
Document code: MN67908_ENG Revision 1 001 Page 18 of 32
The means of the fields for the “Ethernet” section are:
In the field “IP Address” the IP address of the converter is defined;
In the field “SubNet Mask” the Subnet Mask of the converter is defined;
In the field “Gateway” the default gateway of the net is defined This feature can be enabled or disabled pressing the Check Box
field This feature is used for going out of the net
The means of the fields for the “Web Pages” section are:
In the field “User” the user name for webserver’s authentication is defined;
In the field “Password” the password for webserver’s authentication is defined

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus Slave
/ HART Master
Document code: MN67908_ENG Revision 1 001 Page 19 of 32
Figure 4: “HART Variables” window
HART VARIABLES:
By Pressing the “HART Variables” button from the main window for SW67908 (Fig 2) the window “Definition of HART Variables List”
appears (Fig 4)
This section is used to define the HART variables to read/write with the Modbus Master
The means of the fields are:
If the field “Enable” is checked, the HART variable is enabled;
In the field “ evice Address” the address of HART device is defined;
In the field “Preamble Count” the number of bytes for the synchronization is defined;
If the field “Type” the type of HART parameter is defined;
In the field “Var/Cmd Number” the identification of variable/command to read/write is defined From HART standard, the most used
numbers are:
o246: Primary Variable;
o247: Secondary Variable;
o248: Tertiary Variable;
o249: Quaternary Variable

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus Slave
/ HART Master
Document code: MN67908_ENG Revision 1 001 Page 20 of 32
In the field “Params” the parameters for the commands are defined;
In the field “Position” the starting byte of the internal array where mapping the HART data is defined;
In the field “Swap” the bytes’ order is reversed;
In the field “Conv Int” the data from HART device is converted in Integer format;
In the field “Operations” a post-operation on the data read is defined;
In the field “Mnemonic” a description of the variable is defined
Note:
In order to configure the HART devices and their variables, it is possible to scan the HART network and get the data automatically It
is enough to click on “Scan” button See page 22 for more info
