ADF Web HD67B11-IP-B2 User manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
BACnet Slave
Document code: MN67B11_ENG Revision 1.00 Page 1 of 33
User Manual
Revision 1.00
English
OPC UA Client / BACnet Slave - Converter
(Order Code: HD67B11-IP-B , HD67B11-MSTP-B )
for Website information:
http://www.adfweb.com/?Product=HD67B11
for Price information:
http://www.adfweb.com/?Price=HD67B11-IP-B
http://www.adfweb.com/?Price=HD67B11-MSTP-B
Benefits and Main Features:
Triple electrical isolation
Power Supply 18…35V DC and 8… 4 V AC
Temperature range: -40°C/+85°C (-40°F/+185°F)
For others OPC UA Client devices, see also the following links:
OPC UA Client from/to …
www.adfweb.com?Product=HD67B08 (Serial)
www.adfweb.com?Product=HD67B09 (Modbus Slave)
www.adfweb.com?Product=HD67B10 (Modbus TCP Slave)
www.adfweb.com?Product=HD67B1 (CAN)
www.adfweb.com?Product=HD67B13 (CANo en)
www.adfweb.com?Product=HD67B14 (DeviceNet Slave)
www.adfweb.com?Product=HD67B15 (DMX)
www.adfweb.com?Product=HD67B16 (EtherNet/IP Slave)
www.adfweb.com?Product=HD67B17 (J1939)
www.adfweb.com?Product=HD67B18 (KNX)
www.adfweb.com?Product=HD67B19 (MQTT)
www.adfweb.com?Product=HD67B 0 (NMEA0183)
www.adfweb.com?Product=HD67B 1 (NMEA2000)
www.adfweb.com?Product=HD67B (PROFINET)
www.adfweb.com?Product=HD67B 3 (SNMP Agent)
Do you have an your customer protocol?
See the following links:
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
Ask it to the following link:
www.adfweb.com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
BACnet Slave
Document code: MN67B11_ENG Revision 1.00 Page of 33
INDEX:
Page
INDEX
UPDATED DOCUMENTATION
REVISION LIST
WARNING
TRADEMARKS
SECURITY ALERT 3
EXAMPLE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 7
CONFIGURATION 7
POWER SUPPLY 8
FUNCTION MODES 9
LEDS 10
RS485 (FOR BACNET MS/TP) 11
ETHERNET 1
USE OF COMPOSITOR SW67B11 13
NEW PROJECT / OPEN PROJECT 14
SOFTWARE OPTIONS 15
SET COMMUNICATION 17
OPC UA ACCESS 0
SET BACNET ACCESS 6
UPDATE DEVICE 8
MECHANICAL DIMENSIONS 30
ORDERING INFORMATIONS 31
ACCESSORIES 31
DISCLAIMER 3
OTHER REGULATIONS AND STANDARDS 3
WARRANTIES AND TECHNICAL SUPPORT 33
RETURN POLICY 33
Pagina 2 di 33
UPDATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
REVISION LIST:
Revision Date Author Cha ter Descri tion
1.000 13/03/ 019 Nv All First release version
1.001 11/10/ 019 Ff All Revision
1.00 17/04/ 0 0 Ff All Revision
WARNING:
ADFweb.com reserves the right to change information in this manual about
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS:
All trademarks mentioned in this document belong to their respective
owners.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
BACnet Slave
Document code: MN67B11_ENG Revision 1.00 Page 3 of 33
SECURITY ALERT:
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and
safety regulation are required for each individual application. The same applies also when using accessories.
I NTENDED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q UALIFIED P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job.
R ESIDUAL R ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage.
CE CONFORMITY
The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
BACnet Slave
Document code: MN67B11_ENG Revision 1.00 Page 4 of 33
EXAMPLE OF CONNECTION:

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
BACnet Slave
Document code: MN67B11_ENG Revision 1.00 Page 5 of 33
CONNECTION SCHEME:
Figure
1
a
: Connection
scheme
fo
r HD67
B11
-
I
-
B2

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
BACnet Slave
Document code: MN67B11_ENG Revision 1.00 Page 6 of 33
Figure
1
b
: Connection
scheme
for HD67
B11
-
MST
-
B2

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
BACnet Slave
Document code: MN67B11_ENG Revision 1.00 Page 7 of 33
CHARACTERISTICS:
The HD67B11-xxx-B is a OPC UA Client / BACnet Slave converter.
It allows the following characteristics:
Up to 1500 bytes in reading and 1500 bytes in writing;
Two-directional information between BACnet and OPC UA;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8… 4V AC or 1 …35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67B11 software on your PC in order to perform the following:
Define the parameter of OPC UA;
Define the parameter of BACnet line;
Define the list of OPC UA servers connected to the converter;
Define the list of BACnet objects accessible on BACnet side;
Update the device.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
BACnet Slave
Document code: MN67B11_ENG Revision 1.00 Page 8 of 33
POWER SUPPLY:
The devices can be powered between a wide range of tensions. For more details see the two tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
HD67B11-xxx-B2 8V 24V 12V 35V
Consumption at 4V DC:
Device W/VA
HD67B11-xxx-B 4
Caution: Not reverse the olarity ower
HD67B11-xxx-B

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
BACnet Slave
Document code: MN67B11_ENG Revision 1.00 Page 9 of 33
FUNCTION MODES:
The device has got two functions mode depending of the position of the Dip1 of ‘Dip-Switch A’:
The first, with Dip1 in Off position (factory setting), is used for the normal working of the device.
The second, with Dip1 in On position, is used for upload the Project/Firmware.
For the operations to follow for the updating (see ‘UPDATE DEVICE’ section).
According to the functioning mode, the LEDs will have specifics functions (see ‘LEDS’ section).

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
BACnet Slave
Document code: MN67B11_ENG Revision 1.00 Page 10 of 33
LEDS:
The device has got five LEDs that are used to give information of the functioning status.
The various meanings of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
: OPC UA comm. (yellow) Flashing: OPC UA response
OFF: No OPC UA response
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: BACnet comm. (yellow) Flashing: BACnet request
OFF: No BACnet request
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
4: Error state (yellow) ON: At least one OPC UA Server is disconnected
OFF: all OPC UA Servers are connected
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
5: Link Ethernet (green) ON: Ethernet cable connected
OFF: Ethernet cable disconnected
ON: Ethernet cable connected
OFF: Ethernet cable disconnected

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
BACnet Slave
Document code: MN67B11_ENG Revision 1.00 Page 11 of 33
RS485 (for BACnet MS/TP):
For terminating the RS485 line with a 1 0Ω resistor it is necessary to put ON dip 1, like in figure.
The maximum length of the cable should be 1 00m (4000 feet).
Here some codes of cables:
Belden: p/n 813 - x 8AWG stranded twisted pairs conductor + foil shield + braid shield;
Belden p/n 8 84 - x 4AWG stranded twisted pairs conductor + foil shield + braid shield;
Tasker: p/n C5 1 - 1x 4AWG twisted pair conductor + foil shield + braid shield;
Tasker: p/n C5 - x 4AWG twisted pairs conductor + foil shield + braid shield.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
BACnet Slave
Document code: MN67B11_ENG Revision 1.00 Page 1 of 33
ETHERNET:
The Ethernet connection must be made using Connector3 of HD67B11-xxx-B with at least a Category 5E cable. The maximum length of the
cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the
device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended the use of a
cross cable.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
BACnet Slave
Document code: MN67B11_ENG Revision 1.00 Page 13 of 33
USE OF COMPOSITOR SW67B11:
To configure the Converter, use the available software that runs with Windows called SW67B11. It is downloadable on the site
www.adfweb.com and its operation is described in this document. (This manual is referenced to the last version of the software present on
our web site). The software works with MSWindows (XP, Vista, Seven, 8, 10; 3 /64bit).
When launching the SW67B11, the window below appears (Fig. ).
Note:
It is necessary to have installed .Net Framework 4.
Figure 2: Main window for SW67B11

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
BACnet Slave
Document code: MN67B11_ENG Revision 1.00 Page 14 of 33
NEW CONFIGURATION / OPEN CONFIGURATION:
The “New Configuration” button creates the folder which contains the entire device’s configuration.
A device’s configuration can also be imported or exported:
To clone the configurations of a programmable “OPC UA Client / BACnet Slave -
Converter” in order to configure another device in the same manner, it is necessary to
maintain the folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the button
“O en Configuration”.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
BACnet Slave
Document code: MN67B11_ENG Revision 1.00 Page 15 of 33
SOFTWARE OPTIONS:
By pressing the “Settings” ( ) button there is the possibility to change the
language of the software and check the updatings for the compositor.
In the section “Language” it is possible to change the language of the software.
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb.com website.
Checking the option “Check Software U date at Start of Program”, the
SW67B11 check automatically if there are updatings when it is launched.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
BACnet Slave
Document code: MN67B11_ENG Revision 1.00 Page 16 of 33
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in the
different sections of the software.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
BACnet Slave
Document code: MN67B11_ENG Revision 1.00 Page 17 of 33
SET COMMUNICATION:
This section define the fundamental communication parameters of two buses, OPC UA
Client and Modbus TCP.
By Pressing the “Set Communication” button from the main window for SW67B11
(Fig. ) the window “Set Communication” appears (Fig. 3a).
The window is divided in three sections in order to define the different parameters of
the converter:
OPC UA Client
BACnet Slave
NTP (Network Time Protocol)
Figure 3a: “Set Communication” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
BACnet Slave
Document code: MN67B11_ENG Revision 1.00 Page 18 of 33
Figure 3c: “Set Communication  BACnet Slave”
window
OPC UA C LIENT :
The means of the fields for “OPC UA Client” are:
In the fields “IP Address” the IP address for OPC UA side of the converter is
defined;
In the fields “SubNet Mask” the SubNet Mask for OPC UA side of the
converter is defined;
In the fields “Gateway” the default gateway of the net is defined. This
feature can be enabled or disabled pressing the Check Box field. This feature
is used for going out of the net;
In the field “DNS” the IP Address of the DNS server is defined. This feature
can be enabled or disabled pressing the Check Box field.
BAC NET S LAVE ( FOR BAC NET /IP):
This section is used to define the main parameters of BACnet/IP line. The means of
the fields are:
the fields “IP ADDRESS” the IP address of BACnet/IP side of the converter
is defined;
In the fields “SUBNET Mask” the SubNet Mask of BACnet/IP side of the
converter is defined;
In the fields “GATEWAY” the default gateway of the network is defined. This
feature can be enabled or disabled pressing the Check Box field. This feature
is used for going out of the net;
In the field “Port” the port used for BACnet communication is defined. The
default port used for BACnet communication is 47808, but is possible to
insert any value;
In the field "BACnet Device Name" the name of BACnet/IP side of the
converter is defined;
In the field “Device Identifier” the ID of BACnet/IP side of the converter is
defined;
If the field “BACnet descri tion u to 32 chars” is checked, the description of the BACnet objects can be up to 3 chars.
Figure 3b: “Set Communication  O C UA Client”
window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
BACnet Slave
Document code: MN67B11_ENG Revision 1.00 Page 19 of 33
Figure 3d: “Set Communication  BACnet Slave”
window
Figure 3e: “Set Communication  NT (Network
Time rotocol” window
BAC NET S LAVE ( FOR BAC NET MS/TP):
This section is used to define the main parameters of BACnet MS/TP line. The
means of the fields are:
In the field “Baudrate” the data rate of the BACnet line is defined;
In the field “Parity” the parity of the line is defined;
In the field “BACnet Device Name” the name to give to the BACnet node is
defined;
In the field “MAC Address” the MAC of BACnet node (from 0 to 54) is
defined;
The field “Max Master” specifies the highest allowable address for master
nodes. The value shall be less than or equal to 1 7;
The field “Max Info Frames” specifies the maximum number of information
frames the node may send before it must pass the token;
In the field “Device Instance” the of the BACnet MS/TP side of the
converter is defined;
In the field “Network” the BACnet MS/TP network number is defined;
If the field “BACnet descri tion u to 32 chars” is checked, the
description of the BACnet objects can be up to 3 chars.
NTP (N ETWORK T IME P ROTOCOL )
This section is used to define the parameters of NTP protocol. The means of the
fields are:
In the field “Server URL” the URL or the IP Address of the NTP Server is
defined;
In the field “Poll Time (seconds)” the polling time for the time
synchronization is defined.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
BACnet Slave
Document code: MN67B11_ENG Revision 1.00 Page 0 of 33
Figure 4: “
O C UA Client Access
” window
OPC UA ACCESS:
By Pressing the “OPC UA Client Access” button from the main window for SW67B11 (Fig. ) the window “OPC UA Client Access” appears
(Fig. 4).
This section is used to define the list of the OPC UA Servers to read/write with the OPC UA Client.
