ADF Web HD67D02-2-B2-868MHz User manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
Modbus Slave
/
LoRaWAN
Document code: MN67D02_ENG Revision 1.000 age 1 of 33
User Manual
Revision 1.000
English
Modbus Slave / LoRaWAN - Converter
(Order Code: HD67D02-2-B2-868MHz, HD67D02-5-B2-868MHz)
For Website information:
www.adfweb.com? roduct=HD67D02-B2
For rice information:
www.adfweb.com? rice=HD67D02-2-B2-868MHz
www.adfweb.com? rice=HD67D02-5-B2-868MHz
Benefits and Main Features:
Very easy to configure
ower Supply 18…35V DC and 8…24 V AC
Temperature range: -40°C/+85°C (-40°F/+185°F)
For others LoRaWAN products, see also the following links:
Converter LoRaWAN to
www.adfweb.com? roduct=HD67D01 (LoRaWAN)
www.adfweb.com? roduct=HD67D03 (Modbus TC Master)
www.adfweb.com? roduct=HD67D04 (Modbus TC Slave)
www.adfweb.com? roduct=HD67D05 (Serial)
www.adfweb.com? roduct=HD67D15 (M-Bus)
www.adfweb.com? roduct=HD67D16 (BACnet Master)
www.adfweb.com? roduct=HD67D17 (BACnet Slave)
www.adfweb.com? roduct=HD67D18 (Ethernet)
www.adfweb.com? roduct=HD67D19 (CAN)
www.adfweb.com? roduct=HD67D20 (CANopen)
www.adfweb.com? roduct=HD67D21 (DeviceNet Master)
www.adfweb.com? roduct=HD67D22 (DeviceNet Slave)
www.adfweb.com? roduct=HD67D23 (DMX)
www.adfweb.com? roduct=HD67D24 (EtherNet/I Master)
www.adfweb.com? roduct=HD67D25 (EtherNet/I Slave)
www.adfweb.com? roduct=HD67D26 (J1939)
www.adfweb.com? roduct=HD67D27 (KNX)
www.adfweb.com? roduct=HD67D28 (NMEA 0183)
www.adfweb.com? roduct=HD67D29 (NMEA 2000)
www.adfweb.com? roduct=HD67D30 ( ROFIBUS Master)
www.adfweb.com? roduct=HD67D31 ( ROFIBUS Slave)
www.adfweb.com? roduct=HD67D32 ( ROFINET Master)
www.adfweb.com? roduct=HD67D33 ( ROFINET Slave)
www.adfweb.com? roduct=HD67D34 (IEC61850 Client)
www.adfweb.com? roduct=HD67D35 (IEC61850 Server)
www.adfweb.com? roduct=HD67D36 (MQTT)
www.adfweb.com? roduct=HD67D37 (O C UA Client)
www.adfweb.com? roduct=HD67D38 (O C UA Server)
www.adfweb.com? roduct=HD67D39 (S7comm)
www.adfweb.com? roduct=HD67D40 (SNM Manager)
www.adfweb.com? roduct=HD67D41 (SNM Agent)
User Manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
Modbus Slave
/
LoRaWAN
Document code: MN67D02_ENG Revision 1.000 age 2 of 33
INDEX:
age
INDEX 2
U DATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAM LE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 7
CONFIGURATION 7
OWER SU LY 8
FUNCTION MODES 9
LEDS 10
LORAWAN 11
RS232 12
RS485 13
ETHERNET 14
USE OF COM OSITOR SW67D02 15
NEW CONFIGURATION / O EN CONFIGURATION 16
SOFTWARE O TIONS 17
SET COMMUNICATION 19
LORAWAN ACCESS 22
U DATE DEVICE 24
LORAWAN AYLOAD 26
MODBUS MA 27
MECHANICAL DIMENSIONS 29
ORDERING INFORMATIONS 31
ACCESSORIES 31
DISCLAIMER 32
OTHER REGULATIONS AND STANDARDS 32
WARRANTIES AND TECHNICAL SU ORT 33
RETURN OLICY 33
U DATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
REVISION LIST:
WARNING:
ADFweb.com reserves the right to change information in this manual about
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS:
All trademarks mentioned in this document belong to their respective
owners.
Revision Date Author Chapter Description
1.000 04/12/2020 Ff All First release version

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
Modbus Slave
/
LoRaWAN
Document code: MN67D02_ENG Revision 1.000 age 3 of 33
SECURITY ALERT:
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and
safety regulation are required for each individual application. The same applies also when using accessories.
I NTENDED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q UALIFIED ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job.
R ESIDUAL R ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage.
CE CONFORMITY
The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
Modbus Slave
/
LoRaWAN
Document code: MN67D02_ENG Revision 1.000 age 4 of 33
EXAM LE OF CONNECTION:

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
Modbus Slave
/
LoRaWAN
Document code: MN67D02_ENG Revision 1.000 age 5 of 33
CONNECTION SCHEME:
Figure 1a: Connection scheme for HD67D02 2 B2 xxxMHz

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
Modbus Slave
/
LoRaWAN
Document code: MN67D02_ENG Revision 1.000 age 6 of 33
Figure 1b: Connection scheme for HD67D02 5 B2 xxxMHz

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
Modbus Slave
/
LoRaWAN
Document code: MN67D02_ENG Revision 1.000 age 7 of 33
CHARACTERISTICS:
The HD67D02-B2 is a Modbus Slave / LoRaWAN Converter.
It allows the following characteristics:
Electrical isolation between LoRaWAN and ower Supply;
Mountable on 35mm Rail DIN;
Wide power supply input range: 12…35V DC and 8…24V AC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67D02 software on your C in order to perform the following:
Define the parameter of Modbus line;
Define the parameter of LoRaWAN line;
Define the list of LoRaWAN messages in uplink and downlink to the LoRaWAN gateway;
Update the device.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
Modbus Slave
/
LoRaWAN
Document code: MN67D02_ENG Revision 1.000 age 8 of 33
OWER SU LY:
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
8V 24V 12V 35V
Consumption at 24V DC:
Device Consumption [W/VA]
HD67D02-x-B2-xxxMHz 3.5
H
D67D02
-
x
-
B2
-
xxxMHz
Caution: Not reverse the polarity power

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
Modbus Slave
/
LoRaWAN
Document code: MN67D02_ENG Revision 1.000 age 9 of 33
FUNCTION MODES:
The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’:
The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.
The second, with ‘Dip1 of Dip-Switch A’ at “ON” position, is used for upload the roject and/or Firmware.
For the operations to follow for the updating, see ‘U DATE DEVICE’ section.
According to the functioning mode, the LEDs will have specifics functions, see ‘LEDS’ section.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
Modbus Slave
/
LoRaWAN
Document code: MN67D02_ENG Revision 1.000 age 10 of 33
LEDS:
The device has got four LEDs that are used to give information of the functioning status.
The various meanings of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
2: LoRaWAN communication
(yellow) Blinks when a LoRaWAN request is received Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: Modbus communication
(yellow) Blinks when Modbus data is received Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
4: Error state (yellow) ON: An error in the communication busses occurs
OFF: No errors are present
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
Modbus Slave
/
LoRaWAN
Document code: MN67D02_ENG Revision 1.000 age 11 of 33
LORAWAN:
The LoRaWAN® specification is a Low ower, Wide Area (L WA) networking protocol
designed to wirelessly connect battery operated ‘things’ to the internet in regional, national
or global networks, and targets key Internet of Things (IoT) requirements such as bi-
directional communication, end-to-end security, mobility and localization services.
LoRaWAN® network architecture is deployed in a star-of-stars topology in which gateways
relay messages between end-devices and a central network server.
The wireless communication takes advantage of the Long Range characteristics of the LoRa
physical layer, allowing a single-hop link between the end-device and one or many
gateways. All modes are capable of bi-directional communication, and there is support for
multicast addressing groups to make efficient use of spectrum during tasks such as
Firmware Over-The-Air (FOTA) upgrades or other mass distribution messages.
Converters from HD67D02 serie act as end-devices and they can communicate with one or
more LoRwaWAN Gateways.
The converters support all the standard datarates and they work both on public and private
networks.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
Modbus Slave
/
LoRaWAN
Document code: MN67D02_ENG Revision 1.000 age 12 of 33
RS232:
The connection from RS232 socket to a serial port (example one from a personal computer) must be made with a NULL MODEM cable (a
serial cable where the pins 2 and 3 are crossed).
It is recommended that the RS232 cable not exceed 15 meters.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
Modbus Slave
/
LoRaWAN
Document code: MN67D02_ENG Revision 1.000 age 13 of 33
RS485:
For terminating the RS485 line with a 120Ω resistor it is necessary to put ON dip 1, like in figure.
The maximum length of the cable should be 1200m (4000 feet).
Here some codes of cables:
Belden: p/n 8132 - 2x 28AWG stranded twisted pairs conductor + foil shield + braid shield;
Belden p/n 82842 - 2x 24AWG stranded twisted pairs conductor + foil shield + braid shield;
Tasker: p/n C521 - 1x 24AWG twisted pair conductor + foil shield + braid shield;
Tasker: p/n C522 - 2x 24AWG twisted pairs conductor + foil shield + braid shield.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
Modbus Slave
/
LoRaWAN
Document code: MN67D02_ENG Revision 1.000 age 14 of 33
ETHERNET:
The Ethernet port is used for programming the device.
The Ethernet connection must be made using Connector2 of HD67D02-B2 with at least a Category 5E cable. The maximum length of the
cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the
device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a C is recommended the use of a cross cable.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
Modbus Slave
/
LoRaWAN
Document code: MN67D02_ENG Revision 1.000 age 15 of 33
USE OF COM OSITOR SW67D02:
To configure the Converter, use the available software that runs with Windows called SW67D02. It is downloadable on the site
www.adfweb.com and its operation is described in this document. The software works with MS Windows (X , Vista, Seven, 8, 10; 32/64bit).
When launching the SW67D02, the window below appears (Fig. 2).
Note:
It is necessary to have installed .Net Framework 4.
F
igure 2: Main window for SW67D02

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
Modbus Slave
/
LoRaWAN
Document code: MN67D02_ENG Revision 1.000 age 16 of 33
NEW CONFIGURATION / O EN CONFIGURATION:
The “New Configuration” button creates the folder which contains the entire device’s configuration.
A device’s configuration can also be imported or exported:
To clone the configurations of a rogrammable “Modbus Slave / LoRaWAN - Converter” in
order to configure another device in the same manner, it is necessary to maintain the
folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the button
“Open Configuration”.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
Modbus Slave
/
LoRaWAN
Document code: MN67D02_ENG Revision 1.000 age 17 of 33
SOFTWARE O TIONS:
By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the
compositor.
In the section “Language” it is possible to change the language of the software.
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb.com website.
Checking the option “Check Software Update at Start of rogram”, the
SW67D02 check automatically if there are updatings when it is launched.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
Modbus Slave
/
LoRaWAN
Document code: MN67D02_ENG Revision 1.000 age 18 of 33
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in
the different sections of the software.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
Modbus Slave
/
LoRaWAN
Document code: MN67D02_ENG Revision 1.000 age 19 of 33
SET COMMUNICATION:
By ressing the “Set Communication” button from the main window for SW67D02
(Fig. 2) the window “Set Communication” appears (Fig. 3).
The window is divided in different sections in order to define the different parameters
of the converter:
LoRaWAN
Modbus Slave
Ethernet
Figure
3
a
:
“Set Communication” window

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
Modbus Slave
/
LoRaWAN
Document code: MN67D02_ENG Revision 1.000 age 20 of 33
L O R A WAN:
This section is used to define the general parameters of LoRaWAN. The means of the
fields are:
In the field “RF Band” the wireless band used for LoRaWAN communication is
defined;
In the field “Network Type” the type of LoRaWAN network is defined;
If the field “Adaptive Data Rate” is checked, the converter will enable the ADR
functionalities to select the best data rate to be used in relation to the
environmental conditions;
In the field “Data Rate” the data rate for LoRaWAN communication is
defined;
In the field “Transmission Type” the type of LoRaWAN communication is
defined;
In the field “Max ayload Size” the maximum dimension of the LoRaWAN
messages is defined (fixed in relation to the data rate selected);
In the field “Activation Method” the method used to join into a LoRaWAN
network is defined;
In the field “Device Address” the device identifier (DevEUI) is defined (only
for AB method);
In the field “Application Identifier” the application identifier (AppEUI) is
defined (only for AB method);
In the field “Network Session Key” the key used for the communication with the LoRaWAN gateway (NwkSKey) is defined (only for
AB method);
In the field “Application Session Key” the key for encryption and decryption of the payload (AppSKey) is defined (only for AB
method);
If OTAA method is selected, in the field “Application Key” the secret key for the dynamic activation of the converter in the LoRAWAN
network is defined.
Figure 3b: “Set Communication  LoRaWAN” window
