ADF Web HD67E52-2-A1 User manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Master / Modbus Slave
Document code: MN67E52_ENG Revision 1. Page 1 of 3
User Manual
Revision 1.
English
EtherCAT Master / Modbus Slave - Converter
(Order Code: HD67E52-2-A1, HD67E52-5-A1)
For Website information:
www.adfweb.com?Product=HD67E52
For Price information:
www.adfweb.com?Price=HD67E52-A1
Benefits and Main Features:
Very easy to configure
Triple Electrical isolation
Temperature range: -4 °C/+85°C (-4 °F/+185°F)
For other EtherCAT Master products see also the following link:
Converter EtherCAT Slave to
www.adfweb.com?Product=HD67E5 (Serial)
www.adfweb.com?Product=HD67E51 (Modbus Master)
www.adfweb.com?Product=HD67E53 (Modbus TCP Master)
www.adfweb.com?Product=HD67E54 (Modbus TCP Slave)
www.adfweb.com?Product=HD67E55 (BACnet Master)
www.adfweb.com?Product=HD67E56 (BACnet Slave)
www.adfweb.com?Product=HD67E57 (CAN)
www.adfweb.com?Product=HD67E58 (CANo en)
www.adfweb.com?Product=HD67E59 (DeviceNet Master)
www.adfweb.com?Product=HD67E6 (DeviceNet Slave)
www.adfweb.com?Product=HD67E61 (DMX)
www.adfweb.com?Product=HD67E62 (Ethernet)
www.adfweb.com?Product=HD67E64 (IEC61850 Client)
www.adfweb.com?Product=HD67E65 (IEC61850 Server)
www.adfweb.com?Product=HD67E66 (J1939)
www.adfweb.com?Product=HD67E67 (MQTT)
www.adfweb.com?Product=HD67E68 (NMEA0183)
www.adfweb.com?Product=HD67E69 (NMEA2000)
www.adfweb.com?Product=HD67E7 (OPC UA Client)
www.adfweb.com?Product=HD67E71 (OPC UA Server)
www.adfweb.com?Product=HD67E72 (PROFINET Master)
www.adfweb.com?Product=HD67E73 (PROFINET Slave)
www.adfweb.com?Product=HD67E74 (SNMP Manager)
www.adfweb.com?Product=HD67E75 (SNMP Agent)
www.adfweb.com?Product=HD67E76 (EtherNet/IP Master)
www.adfweb.com?Product=HD67E77 (EtherNet/IP Slave)
www.adfweb.com?Product=HD67E78 (S7comm Client)
User Manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Master / Modbus Slave
Document code: MN67E52_ENG Revision 1. Page 2 of 3
INDEX:
Page
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAMPLE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 7
CONFIGURATION 7
POWER SUPPLY 8
FUNCTION MODES 9
LEDS 1
ETHERCAT 11
RS232 12
RS485 13
ETHERNET 14
USE OF COMPOSITOR SW67E52 15
NEW CONFIGURATION / OPEN CONFIGURATION 16
SOFTWARE OPTIONS 17
SET COMMUNICATION 19
ETHERCAT SET ACCESS 21
UPDATE DEVICE 24
MECHANICAL DIMENSIONS 26
ORDERING INFORMATIONS 28
ACCESSORIES 28
DISCLAIMER 29
OTHER REGULATIONS AND STANDARDS 29
WARRANTIES AND TECHNICAL SUPPORT 3
RETURN POLICY 3
UPDATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
REVISION LIST:
WARNING:
ADFweb.com reserves the right to change information in this manual about
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS:
All trademarks mentioned in this document belong to their respective
owners.
Revision Date Author Cha ter Descri tion
1. 5/12/2 22 Ln All First Release

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Master / Modbus Slave
Document code: MN67E52_ENG Revision 1. Page 3 of 3
SECURITY ALERT:
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and
safety regulation are required for each individual application. The same applies also when using accessories.
I NTENDED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q UALIFIED P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job.
R ESIDUAL R ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage.
CE CONFORMITY
The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Master / Modbus Slave
Document code: MN67E52_ENG Revision 1. Page 4 of 3
EXAMPLE OF CONNECTION:

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Master / Modbus Slave
Document code: MN67E52_ENG Revision 1. Page 5 of 3
CONNECTION SCHEME:
Figure 1a: Connection scheme for HD67E5 - -A1

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Master / Modbus Slave
Document code: MN67E52_ENG Revision 1. Page 6 of 3
Figure 1b: Connection scheme for HD67E5 -5-A1

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Master / Modbus Slave
Document code: MN67E52_ENG Revision 1. Page 7 of 3
CHARACTERISTICS:
The HD67E52-A1 are EtherCAT Master / Modbus Slave - Converters.
It allows for the following characteristics:
Isolation between EtherCAT – Modbus – Power Supply;
Two-directional information between EtherCAT bus and Modbus bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -4 °C / 85°C [-4 °F / +185°F].
CONFIGURATION:
You need Compositor SW67E52 software on your PC in order to perform the following:
Define the parameters of EtherCAT line;
Define the parameters of Modbus line;
Define EtherCAT slaves from which reading/writing the data;
Export the ESI file for configuration of EtherCAT Master;
Update the device.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Master / Modbus Slave
Document code: MN67E52_ENG Revision 1. Page 8 of 3
POWER SUPPLY:
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
8V 24V 12V 35V
Consumption at 24V DC:
Device Consum tion [W/VA]
HD67E52-A1 3.5
HD67E52-A1
Caution:
Do n
ot reverse the olarity ower

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Master / Modbus Slave
Document code: MN67E52_ENG Revision 1. Page 9 of 3
FUNCTION MODES:
The device has got two function modes depending on the position of the ‘Dip1 of Dip-Switch A’:
The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.
The second, with ‘Dip1 of Dip-Switch A’ at “ON” position, is used for uploading the Project and/or Firmware.
For the operations to follow for the updating, see ‘UPDATE DEVICE’ section.
According to the functioning mode, the LEDs will have specific functions, see ‘LEDS’ section.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Master / Modbus Slave
Document code: MN67E52_ENG Revision 1. Page 1 of 3
LEDS:
The device has got seven LEDs that are used to give information about the functioning status.
The various meanings of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: ON [supply voltage ]
(green)
ON: Device powered
OFF: Device not powered
ON: Device powered
OFF: Device not powered
2: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: EtherCAT comm. (green) It blinks when EtherCAT communication is running Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
4: Modbus comm. (green) It blinks when Modbus communication is running Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
5: EtherCAT link (green) ON: EtherCAT cable connected
OFF: EtherCAT cable disconnected
ON: EtherCAT cable connected
OFF: EtherCAT cable disconnected
6: Ethernet link (green) ON: Ethernet cable connected
OFF: Ethernet cable disconnected
ON: Ethernet cable connected
OFF: Ethernet cable disconnected

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Master / Modbus Slave
Document code: MN67E52_ENG Revision 1. Page 11 of 3
ETHERCAT
EtherCAT (Ethernet for Control Automation Technology) is an Ethernet-based fieldbus system, invented by Beckhoff Automation.
The protocol is standardized in IEC 61158 and is suitable for both hard and soft real-time computing requirements in automation technology.
With EtherCAT, the standard Ethernet packet or frame (according to IEEE 8 2.3) is no longer received, interpreted, and copied as process
data at every node. The EtherCAT slave devices read the data addressed to them while the telegram passes through the device, processing
data "on the fly". In other words, real-time data and messages are prioritized over more general, less time-sensitive or heavy load data.
EtherCAT connection must be made using Connector5 of the HD67E52-A1.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Master / Modbus Slave
Document code: MN67E52_ENG Revision 1. Page 12 of 3
RS232:
The connection from RS232 socket to a serial port (example one from a personal computer) must be made with a NULL MODEM cable (a
serial cable where the pins 2 and 3 are crossed).
It is recommended that the RS232 cable not exceed 15 meters.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Master / Modbus Slave
Document code: MN67E52_ENG Revision 1. Page 13 of 3
RS485:
For terminate the RS485 line with a 12 Ω resistor it is necessary to put ON dip 1, like in figure.
The maximum length of the cable should be 12 m (4 feet).
Here some codes of cables:
Belden: p/n 8132 - 2x 28AWG stranded twisted pairs conductor + foil shield + braid shield;
Belden p/n 82842 - 2x 24AWG stranded twisted pairs conductor + foil shield + braid shield;
Tasker: p/n C521 - 1x 24AWG twisted pair conductor + foil shield + braid shield;
Tasker: p/n C522 - 2x 24AWG twisted pairs conductor + foil shield + braid shield.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Master / Modbus Slave
Document code: MN67E52_ENG Revision 1. Page 14 of 3
ETHERNET:
The updating of the converter must be made using Connector6 of the HD67E52-A1 with at least a Category 5E cable. The maximum length
of the cable should not exceed 1 m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 1 Mbps. To
connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended
the use of a cross cable.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Master / Modbus Slave
Document code: MN67E52_ENG Revision 1. Page 15 of 3
USE OF COMPOSITOR SW67E52:
To configure the Converter, use the available software that runs with Windows called SW67E52. It is downloadable on the site
www.adfweb.com and its operation is described in this document. (This manual is referenced to the last version of the software present on
our web site). The software works with MSWindows (XP, Vista, Seven, 8, 1 , 11; 32/64bit).
When launching the SW67E52, the window below appears (Fig. 2).
Note:
It is necessary to have installed .Net Framework 4.
Figure : Main window for SW67E5

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Master / Modbus Slave
Document code: MN67E52_ENG Revision 1. Page 16 of 3
NEW CONFIGURATION / OPEN CONFIGURATION:
The “New Configuration” button creates the folder which contains the entire device’s configuration.
A device’s configuration can also be imported or exported:
To clone the configurations of a programmable “EtherCAT Master / Modbus Slave -
Converter” in order to configure another device in the same manner, it is necessary
to maintain the folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient
to duplicate the project folder with another name and open the new folder with the
button “O en Configuration”.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Master / Modbus Slave
Document code: MN67E52_ENG Revision 1. Page 17 of 3
SOFTWARE OPTIONS:
By pressing the “Settings” ( ) button there is the possibility to change the
language of the software and check the updatings for the compositor.
In the section “Language” it is possible to change the language of the software.
In the section “Connection Options”, it is possible to check if there are some updatings
of the software compositor in ADFweb.com website.
Checking the option “Check Software U date at Start of Program”, the SW67E52
checks automatically if there are updatings when it is launched.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Master / Modbus Slave
Document code: MN67E52_ENG Revision 1. Page 18 of 3
In the section “Software Settings”, it is possible to enable/disable some keyboard’s
commands for an easier navigation inside the tables contained in the different
sections of the software.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Master / Modbus Slave
Document code: MN67E52_ENG Revision 1. Page 19 of 3
SET COMMUNICATION:
This section define the fundamental communication parameters of two buses, EtherCAT and
Modbus.
By Pressing the “Set Communication” button from the main window for SW67E52 (Fig. 2) the
window “Set Communication” appears (Fig. 3).
The means of the fields for “Ethernet Connection” are:
In the field “Device Name (Hostname)” the Hostname to assign to the converter is
defined;
If the field “Obtain an IP Address Automatically (DHCP for Cable Connection)” is
checked, DHCP for LAN connection is enabled;
If the field “Enable DNS” is checked, DNS protocol is enabled;
In the field “Primary DNS” the IP Address of the primary DNS server is defined;
In the field “Secondary DNS” the IP Address of the secondary DNS server is defined.
The means for the fields for the “Modbus Slave” are:
In the field “Serial” the serial port to use is defined (RS232 or RS485);
In the field “Baudrate” the baudrate for the serial line is defined;
In the field “Parity” the parity of the serial line is defined;
In the field “Sto Bits” the number of Stop Bits of the serial line is defined;
In the field “ID Device” the ID of Modbus side of the converter is defined;
If the field “Read with In ut Register / Status Function” is checked, it is possible to
read the Input bytes of OPC UA side with Input Registers (Function 4) and write the
Output bytes of OPC UA side with Holding Registers (Function 6/16). The Output bytes
are readable with Function 3. Otherwise, only Holding Registers will be used and the
Output bytes of OPC UA side cannot be read back.
Figure 3: “Set Communication” window

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Master / Modbus Slave
Document code: MN67E52_ENG Revision 1. Page 2 of 3
The means of the fields for the “Ethernet” section are:
In the fields “IP ADDRESS” the IP address of Ethernet side of the converter is defined;
In the fields “SUBNET Mask” the SubNet Mask of Ethernet side of the converter is defined;
In the fields “GATEWAY” the default gateway of the network is defined. This feature can be
enabled or disabled pressing the Check Box field. This feature is used for going out of the net.
