User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 1 of 30
User Manual
Revision 1.000
English
IEC 61850 Server / Modbus Master - Converter
(Order Code: HD67733-2-A1 , HD67733-4-A1, HD67733-5-A1)
For Website information:
www.adfweb.com? roduct=HD67733
For rice information:
www.adfweb.com? rice=HD67733-2-A1
www.adfweb.com? rice=HD67733-4-A1
www.adfweb.com? rice=HD67733-5-A1
Benefits and Main Features:
Very easy to configure
Triple Electrical isolation
Temperature range: -40°C/+85°C (-40°F/+185°F)
For other IEC 61850 products see also the following link:
Converter IEC 61850 Server to
www.adfweb.com? roduct=HD67734 (Modbus Slave
www.adfweb.com? roduct=HD67735 (Modbus TCP Master
www.adfweb.com? roduct=HD67736 (Modbus TCP Slave
Do you have your customer protocol? Then go to:
www.adfweb.com? roduct=HD67003
Do you need to choose a device? Do you want help?
www.adfweb.com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 2 of 30
INDEX:
age
INDEX 2
U DATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAM LE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 8
CONFIGURATION 8
OWER SU LY 9
FUNCTION MODES 10
LEDS 11
RS232 12
RS485 12
RS422 13
ETHERNET 13
USE OF COM OSITOR SW67733 14
NEW CONFIGURATION / O EN CONFIGURATION 15
SOFTWARE O TIONS 16
SET COMMUNICATION 18
IEC 61850 ACCESS 21
MODBUS SET ACCESS 22
TLS KNOWN CERTIFICATE 24
U DATE DEVICE 25
MECHANICAL DIMENSIONS 27
ORDERING INFORMATIONS 28
ACCESSORIES 28
DISCLAIMER 29
OTHER REGULATIONS AND STANDARDS 29
WARRANTIES AND TECHNICAL SU ORT 30
RETURN OLICY 30
UPDATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
REVISION LIST:
WARNING:
ADFweb.com reserves the right to change information in this manual about
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS:
All trademarks mentioned in this document belong to their respective
owners.
Revision
Date Author Chapter
Description
1.000 18/09/2018
Ff All First Release

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 3 of 30
SECURITY ALERT:
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and
safety regulation are required for each individual application. The same applies also when using accessories.
I NTENDED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q UALIFIED P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job.
R ESIDUAL R ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage.
CE CONFORMITY
The declaration is made by our company. You can send an email to [email protected] or give us a call if you need it.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 4 of 30
EXAMPLES OF CONNECTION:

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 5 of 30
CONNECTION SCHEME:
Figure 1a: Connection scheme for HD67733- -A1

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 6 of 30
Figure 1b: Connection scheme for HD67733-4-A1

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 7 of 30
Figure 1c: Connection scheme for HD67733-5-A1

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 8 of 30
CHARACTERISTICS:
The HD67733-x-A1 are IEC 61850 / Modbus Master - Converters.
It allows for the following characteristics:
Up to 512 Modbus reading requests and 512 Modbus writing requests;
Triple isolation between RS232/RS485/RS422 - ower Supply, RS232/RS485/RS422 - Ethernet, Ethernet - ower Supply;
Two-directional information between IEC 61850 bus and Modbus bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67733 software on your C in order to perform the following:
Define the parameters of IEC 61850 line;
Define the parameters of Modbus line;
Define IEC 61850 variables that contains the data read from the Modbus slaves;
Define IEC 61850 variables that contains the data to send to the Modbus slaves;
Update the device.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 9 of 30
POWER SUPPLY:
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
8V 24V 12V 35V
Consumption at 24V DC:
Device Consumption [W/VA]
HD67733-X-A1 3.5
HD67733-X-A1
Caution:
Do n
ot reverse the polarity power

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 10 of 30
FUNCTION MODES:
The device has got two function modes depending on the position of the ‘Dip2 of Dip-Switch A’:
The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.
The second, with ‘Dip2 of Dip-Switch A’ at “ON” position, is used for uploading the roject and/or Firmware.
For the operations to follow for the updating, see ‘U DATE DEVICE’ section.
According to the functioning mode, the LEDs will have specific functions, see ‘LEDS’ section.
Warning:
Dip1 of ‘Dip-Switch A’ must be at ON position to work even if the Ethernet cable is not inserted.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 11 of 30
LEDS:
The device has got six LEDs that are used to give information about the functioning status.
The various meanings of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: ON [supply voltage ]
(green)
ON: Device powered
OFF: Device not powered
ON: Device powered
OFF: Device not powered
2: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz : update in progress
3: IEC 61850 communication
(green) It blinks when a IEC 61850 request is received Blinks quickly: Boot state Blinks very slowly (~0.5Hz : update in progress
4: Modbus communication
(green) It blinks when a Modbus response is received Blinks quickly: Boot state
Blinks very slowly (~0.5Hz : update in progress
5: Ethernet1 Tx (green) Blinks when is transmitting Ethernet frames Blinks quickly: Boot state
Blinks very slowly (~0.5Hz : update in progress
6: Ethernet2 Tx (green) Blinks when is transmitting Ethernet frames Blinks quickly: Boot state
Blinks very slowly (~0.5Hz : update in progress

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 12 of 30
RS232:
The connection from RS232 socket to a serial port (example one from a
personal computer) must be made with a Null Modem cable (a serial cable
where the pins 2 and 3 are crossed).
It is recommended that the RS232 cable not exceed 15 meters.
RS485:
For terminate the RS485 line with a 120Ω resistor it is necessary to put ON dip 1, like in figure.
The maximum length of the cable should be 1200m (4000 feet).
Here some codes of cables:
Belden: p/n 8132 - 2x 28AWG stranded twisted pairs conductor + foil shield + braid shield;
Belden p/n 82842 - 2x 24AWG stranded twisted pairs conductor + foil shield + braid shield;
Tasker: p/n C521 - 1x 24AWG twisted pair conductor + foil shield + braid shield;
Tasker: p/n C522 - 2x 24AWG twisted pairs conductor + foil shield + braid shield.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 13 of 30
RS422:
For terminate the RS485 line with a 120Ω resistor it is necessary to put ON dip 1 for T line and/or put ON dip 2 for R line, like in figure.
The maximum length of the cable should be 1200m (4000 feet).
ETHERNET:
IEC 61850 connection and the updating of the converters must be made using Connector3 and/or Connector4 of the HD67733-X-A1 with at
least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative
to connections in cat.5 up to 100 Mbps. To connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the
device to a C/ LC/other is recommended the use of a cross cable.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 14 of 30
USE OF COMPOSITOR SW67733:
To configure the Converter, use the available software that runs with Windows called SW67733. It is downloadable on the site
www.adfweb.com and its operation is described in this document. (This manual is referenced to the last version of the software present on
our web site). The software works with MSWindows (X , Vista, Seven, 8, 10; 32/64bit).
When launching the SW67733, the window below appears (Fig. 2).
Note:
It is necessary to have installed .Net Framework 4.
Figure : Main window for SW67733

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 15 of 30
NEW CONFIGURATION / OPEN CONFIGURATION:
The “New Configuration” button creates the folder which contains the entire device’s configuration.
A device’s configuration can also be imported or exported:
To clone the configurations of a programmable “IEC 61850 Server / Modbus Master -
Converter” in order to configure another device in the same manner, it is necessary to
maintain the folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “Open Configuration”.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 16 of 30
SOFTWARE OPTIONS:
By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the
compositor.
In the section “Language” it is possible to change the language of the
software.
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb.com website.
Checking the option “Check Software Update at Start of Program”, the
SW67733 checks automatically if there are updatings when it is launched.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 17 of 30
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in
the different sections of the software.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 18 of 30
SET COMMUNICATION:
By ressing the “Set Communication” button from the main window for SW67733
(Fig. 2) the window “Set Communication” appears (Fig. 3).
The window is divided in different sections in order to define the different
parameters of the converter:
IEC 61850 Server
TLS (Transport Layer Security) Server
Modbus Master
Ethernet
Figure 3a: “Set Communication” window

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 19 of 30
Figure 3b: “Set Communication  IEC 61850
Server” window
Figure 3c: “Set Communication

TLS” window
IEC 61850 S ERVER :
This section is used to define the main parameters of IEC 61850 line. The means of
the fields are:
In the field “Port” the port used for IEC 61850 communication is defined;
If the field “Password” the password used for accessing to IEC 61850
variables is defined.
TLS (T RANSPORT L AYER S ECURITY S ERVER
This section is used to define the main parameters of TLS protocol. The means of
the fields are:
If the field “Enable TLS” is checked, the TLS protocol for secure connection
is enabled;
In the field “Key” the key for the authentication is defined;
In the field “Key Password” the password for decrypting the key is defined;
In the field “Server Certificate” the certificate for the server is defined;
In the field “Root Certificate” the root of the server is defined;
If the field “Enable Only Known Certificates” is checked, the converter will
accept just connection from known Clients (defined in the section “TLS
Known Certificate”).

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 20 of 30
Figure 3e: “Set Communication  Ethernet”
window
Figure 3d: “Set Communication  Modbus Master”
window
M ODBUS M ASTER :
This section is used to define the main parameters of Modbus line. The means of the
fields are:
In the field “Serial” the serial port to use is defined (RS232 or RS485);
In the field “Baudrate” the baudrate for the serial line is defined;
In the field “Parity” the parity of the serial line is defined;
In the field “Stop Bits” the number of Stop Bits of the serial line is defined;
In the field “TimeOut (ms ” the maximum time that the converter attends
for the answer from the Slave interrogated is defined;
In the field “Cyclic Delay (ms ” the delay (idle time) between two Modbus
requests is defined.
E THERNET :
This section is used to define the general parameters of Ethernet. The means of the
fields are:
In the field “IP Address” the I address of the converter is defined;
In the field “SubNet Mask” the Subnet Mask of the converter is defined;
In the field “Gateway” the default gateway of the net is defined. This
feature can be enabled or disabled pressing the Check Box field. This feature
is used for going out of the net.
