ADInstruments Transducer Series User manual

ADINSTRUMENTS
MLT1115 Galvanic Oxygen Electrode
Transducer Series
Description
The MLT1115 Galvanic Oxygen Electrode is
designed for measuring the concentration of oxygen
in aqueous solution.
Operation
Connect the electrode to the input connector of any PowerLab (or other recording
device having an input impedance of at least 1 MΩ). The unit may be connected directly
into a BNC input or alternately to a Pod Port via the supplied MLAC22 BNC to DIN
Smart Adaptor. The output in air-saturated deionized water should be 20 – 35 mV at
25 °C. The output will be larger at higher temperatures or in water saturated with pure
oxygen or Carbogen (5% CO2, 95% O2).
Note: Constant temperature must be maintained to obtain a meaningful signal.
Principle of Operation
The electrode comprizes a platinum cathode and a lead
anode connected via an internal 7.5 kΩ resistor. As oxygen
diffuses across the membrane and into the electrolyte
solution inside the electrode, the following reactions occur:
O2+ 2H2O + 4e-→ 4OH-at cathode
2Pb + 4OH-→ 2Pb(OH)2+ 4e-at anode
O2 + 2H2O + 2Pb → 2Pb(OH)2overall
For every molecule of oxygen consumed at the cathode,
four electrons are transferred from the anode. The potential
across the internal 7.5 kΩ resistor is proportional to this
current flow therefore, to oxygen concentration.
The rate of oxygen consumption by the electrode is given
by the formula:
d[O2]/dt = E/(4000RF)
where:
d[O2]/dt is the rate of oxygen consumption in mol/s
E is the output signal (potential) in mV
R is the value of the internal resistor, 7.5 kΩ
F is the Faraday constant, 96486.7 A·s/mol
Membrane
Cathode
Cover cap,
tip
Anode
Cover cap,
cylinder

Calibration of the electrode using Units Conversion.
Operating Instructions
Use the LabChart software to set your PowerLab input channel to a gain range of
50 mV. (If you are using another recording device adjust its input sensitivity to an
appropriate range). A recording speed of 4 samples per second is more than sufficient
and provides a good graphical display as the signal moves across the computer
monitor. A low pass filter setting of 1 Hz (available on most PowerLab models) can be
used to get a noise-free signal.
To calibrate the electrode using a PowerLab, start the LabChart recording while the
electrode is immersed in stirred deoxygenated water (a steady level must be obtained
for a couple of minutes). Transfer the electrode to a stirred, air-saturated, solution
while continuing to record the signal until a steady level is obtained in LabChart.
Stop recording. Use the Units Conversion feature of the LabChart software (see
the LabChart User’s Guide) to assign values of zero and 100% O2saturation to the
appropriate regions of the signal. Other units, such as “µmol/L”, “mmHg”, or “ppm”,
can also be used.
Storage
To store the electrode for short periods of time (overnight or for a few days), place
a few drops of water in the vinyl cap used to cover the electrode tip. For long term
storage (weeks or more) the electrode should be drained of filling solution and stored
dry. Refer to the refilling instructions on the next page.

Replacement of membrane tip and refilling of the electrode.
1. Unscrew the lower part of the electrode then
pull to remove tip from cylinder.
cylinder
tip
new membrane
3.Place new membrane over top of tip and press
onto cover cylinder. Trim excess membrane.
old membrane
2. Remove old membrane and clean cylinder
and tip.
4. Use syringe (supplied with electrode) to place
a small amount of R001069 Electrolyte filling
solution into the lower part of the electrode
then screw back onto the main body. Excess
filling solution will be extruded.
Wear rubber gloves and eye protection to avoid contact with the electrolyte filling
solution. The filling solution should be replaced periodically.
Troubleshooting
Q. The probe, when in air-saturated water, displays a zero signal ?
A. Check that all cable connections are correct. Check that the probe is filled with
electrolyte (filling solution).
Q. The maximum signal, in air saturated water, is less than 20 mV ?
A. The output signal will be smaller at temperatures less than 25 °C. If the membrane
is dirty install a new membrane. Replace the electrolyte filling solution. If the electrode
is old it may need replacement.
Q. The output signal is unstable and shows random drift ?
A. Check that the sample is being maintained at a constant temperature. Check that the
stirring rate is constant. Check the grounding (if any) of the sample vessel, PowerLab and
any other instrumentation connected to the sample (temperature probes, pH meters etc).

ADINSTRUMENTS.com
ISO 9001:2008 Certified Quality Management System
MLT1115-DCW-15A
WARRANTY: ADInstruments PowerLab data acquisition units (Product Number Prefix: PL), Front-end Signal Conditioners (Product Number
Prefix: FE) are warranted against defects in materials and workmanship for a period of 5 years from the date of purchase. Other PowerLab
data acquisition units and ADInstruments manufactured Front-end and Pod Signal Conditioners, and Instruments are warranted of a period of
3 years from the date of purchase. Third party products are covered by the manufacturer’s warranty. Warranties are void if the product has
been damaged due to negligence. Consumables and electrodes are not covered by a warranty. All questions regarding service and warranty
should be directed to your nearest ADInstruments representative.
Caution
Read “Statement of Intended Use” on our website or in “Getting Started with PowerLab” before
use. The electrode filling solution is caustic and contains sodium hydroxide. Wear rubber gloves
and eye protection when refilling the electrode. If skin or eye contact occurs, wash the affected area
immediately with running water.
Specifications
Probe type: Galvanic
Cathode: Platinum
Anode: Lead
Membrane: PTFE (Teflon®)
Output: 20 – 30 mV @ 25 °C in air-saturated deionized water
< 1 mV in deoxygenated water
Response time: < 30 s to 90% of final value
DC drift: < 2% per week at constant pressure and temperature
Oxygen consumption: 3.45 × 10-13 mol O2/s per mV of signal
1.10 × 10-11 g O2/s per mV of signal
Filling solution: 2% NaOH, 65% ethylene glycol, 33% water
Electrode body: Plastic (Delrin)
Connector: BNC
Dimensions: 12 mm OD x 137 mm (0.47" OD x 5.4")
Cable length: 3 m (9.8')
All specifications were tested at the time of printing and are subject to change.
Ordering Information:
MLT1115 Galvanic Oxygen Electrode
Supplied with:
MLAC22 BNC to DIN Smart Adaptor
For use with:
Any PowerLab
