ADLINK Technology cPCI-6965 Series User manual

Advance Technologies; Automate the World.
Manual Rev. 2.00
Revision Date: April 27, 2009
Part No: 50-15068-1000
cPCI-6965 Series
6U CompactPCI Single Board Computer with
Intel® Core™2 Duo, Celeron® M Processor
User’s Manual

Revision History
Revision Release Date Description of Change(s)
2.00 2009/04/27 Initial Release

Preface iii
cPCI-6965
Preface
Copyright 2009 ADLINK Technology Inc.
This document contains proprietary information protected by copy-
right. All rights are reserved. No part of this manual may be repro-
duced by any mechanical, electronic, or other means in any form
without prior written permission of the manufacturer.
Disclaimer
The information in this document is subject to change without prior
notice in order to improve reliability, design, and function and does
not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, spe-
cial, incidental, or consequential damages arising out of the use or
inability to use the product or documentation, even if advised of
the possibility of such damages.
Environmental Responsibility
ADLINK is committed to fulfill its social responsibility to global
environmental preservation through compliance with the Euro-
pean Union's Restriction of Hazardous Substances (RoHS) direc-
tive and Waste Electrical and Electronic Equipment (WEEE)
directive. Environmental protection is a top priority for ADLINK.
We have enforced measures to ensure that our products, manu-
facturing processes, components, and raw materials have as little
impact on the environment as possible. When products are at their
end of life, our customers are encouraged to dispose of them in
accordance with the product disposal and/or recovery programs
prescribed by their nation or company.
Trademarks
Product names mentioned herein are used for identification pur-
poses only and may be trademarks and/or registered trademarks
of their respective companies.

iv Preface
Using this Manual
Audience and Scope
The cPCI-6965 User’s Manual is intended for hardware
technicians and systems operators with knowledge of installing,
configuring and operating industrial grade CompactPCI modules.
Manual Organization
This manual is organized as follows:
Chapter 1, Overview: Introduces the cPCI-6965, its features,
block diagrams, and package contents.
Chapter 2, Specifications: Presents detailed specification
information, and power consumption, and technical drawings.
Chapter 3, Functional Description: Describes the cPCI-6965’s
main functions.
Chapter 4, Board Interfaces: Describes the cPCI-6965 board
interfaces, pin definitions, and jumper settings.
Chapter 5, Getting Started: Describes the installation instructions
of the cPCI-6965.
Chapter 6, Driver Installation: Describes the driver installation
procedures.
Chapter 7, Utilities: Describes the Watchdog Timer and Preboot
Execution Environment functions.
Chapter 8, BIOS Setup Utility: Describes the AMIBIOS®8 BIOS
setup utility.
Important Safety Instructions: Presents safety instructions all
users must follow for the proper setup, installation and usage of
equipment and/or software.
Getting Service: Contact information for ADLINK’s worldwide
offices.

Preface v
cPCI-6965
Conventions
Take note of the following conventions used throughout this
manual to make sure that users perform certain tasks and
instructions properly.
NOTE:
NOTE:
Additional information, aids, and tips that help users perform
tasks.
CAUTION:
Information to prevent minor physical injury, component dam-
age, data loss, and/or program corruption when trying to com-
plete a task.
WARNING:
Information to prevent serious physical injury, component
damage, data loss, and/or program corruption when trying to
complete a specific task.

vi Preface
This page intentionally left blank.

Table of Contents i
cPCI-6965
Table of Contents
Revision History...................................................................... ii
Preface.................................................................................... iii
List of Tables........................................................................... v
List of Figures....................................................................... vii
1 Overview ............................................................................. 1
1.1 Introduction.......................................................................... 1
1.2 Features............................................................................... 2
1.3 Block Diagram ..................................................................... 3
1.4 Product List.......................................................................... 4
SBC ................................................................................4
Rear Transition Module ..................................................4
1.5 Package Contents ............................................................... 5
CPU module ...................................................................5
Rear Transition Module ..................................................5
2 Specifications..................................................................... 7
2.1 cPCI-6965 SBC Specifications............................................ 7
2.2 cPCI-R6000-965(D) & cPCI-R6000(D)-L
Specifications .......................................................... 10
2.3 I/O Connectivity Table ....................................................... 11
2.4 Power Requirements......................................................... 13
Power Consumption .....................................................14
3 Functional Description .................................................... 15
Intel® Core™2 Duo Processor T7500 ..........................16
Intel® Celeron® Processor 550 ....................................17
3.1 Chipset............................................................................... 18
Intel® GME965 Memory Controller Hub .......................18
Intel® ICH8 Mobile I/O Controller Hub .........................19

ii Table of Contents
3.2 DVI..................................................................................... 20
3.3 Super I/O ........................................................................... 20
3.4 Battery ............................................................................... 20
3.5 PMC Site............................................................................ 20
3.6 Onboard USB Flash........................................................... 21
4 Board Interfaces................................................................ 23
4.1 cPCI-6965 SBC Board Layout........................................... 23
4.2 cPCI-6965 SBC Assembly Layout..................................... 24
4.3 cPCI-6965 SBC Assembly Layout..................................... 25
4.4 cPCI-6965, cPCI-6965D SBC Front Panel ........................ 26
System LEDs ................................................................27
4.5 cPCI-R6000-965/R6000-L RTM Board Layout................. 28
4.6 cPCI-R6000-965/R6000-L RTM Front Panel..................... 29
4.7 cPCI-R6000-965D/6000D-L RTM Board Layout................ 30
4.8 cPCI-R6000-965D/R6000D-L RTM Front Panel................ 31
4.9 Connector Pin Assignments............................................... 32
4.10 Switch and Jumper Settings .............................................. 45
5 Getting Started.................................................................. 49
5.1 CPU and Heatsink ............................................................. 49
5.2 Memory Module Installation............................................... 50
Installing the Memory Modules .....................................50
5.3 CompactFlash Card Installation......................................... 51
5.4 Hard Drive Installation........................................................ 52
5.5 PCI Mezzanine Card (PMC) Installation............................ 55
5.6 USB Flash Disk Module Installation................................... 59
5.7 Installing the cPCI-6965 to the Chassis............................. 60
5.8 RTM Installation................................................................. 61
6 Driver Installation.............................................................. 63
6.1 Chipset Drivers .................................................................. 63
6.2 SCSI Driver........................................................................ 64

Table of Contents iii
cPCI-6965
7 Utilities .............................................................................. 65
7.1 Watchdog Timer ................................................................ 65
Using the Watchdog in an Application ..........................65
Sample Code ................................................................66
7.2 Preboot Execution Environment (PXE).............................. 69
8 BIOS Setup Utility............................................................. 71
8.1 Starting the BIOS............................................................... 71
Setup Menu ..................................................................72
Navigation .....................................................................72
Hotkey Descriptions ......................................................73
8.2 Main Setup......................................................................... 75
System Time/System Date ...........................................75
8.3 Advanced BIOS Setup....................................................... 76
CPU Configuration ........................................................76
IDE Configuration .........................................................78
Floppy Configuration .....................................................79
Super IO Configuration .................................................80
Hardware Health Configuration ....................................82
Remote Access Configuration ......................................83
USB Configuration ........................................................85
8.4 Advanced PCI/PnP Settings.............................................. 87
8.5 Boot Settings ..................................................................... 88
Boot Settings Configuration ..........................................89
Boot Device Priority ......................................................90
Boot Device Groups ......................................................90
8.6 Security Setup ................................................................... 91
Password Support ........................................................91
Supervisor Password ....................................................92
User Password .............................................................92
Change Supervisor Password ......................................92
Change User Password ................................................92

iv Table of Contents
Clear User Password ....................................................92
Change Supervisor Password ......................................92
Change User Password ................................................93
8.7 Chipset Setup .................................................................... 94
USB Functions ..............................................................94
USB 2.0 Controller ........................................................94
HDA Controller ..............................................................94
Onboard LAN BIOS Init ................................................95
8.8 Exit Menu........................................................................... 96
Save Changes and Exit ................................................96
Discard Changes and Exit ............................................96
Discard Changes ..........................................................97
Load Optimal Defaults ..................................................97
Load Failsafe Defaults ..................................................97
Important Safety Instructions............................................... 99
Getting Service.................................................................... 101

List of Tables v
cPCI-6965
List of Tables
Table 2-1: SBC I/O Connectivity .............................................. 11
Table 2-2: RTM (4HP) I/O Connectivity ................................... 12
Table 2-3: RTM (8HP) I/O Connectivity ................................... 12
Table 2-4: CompactPCI input voltage characteristics .............. 13
Table 2-5: Power consumption of Intel® Core™2 Duo T7500 14
Table 2-6: Power consumption of Intel® Celeron® 550 .......... 14
Table 4-1: cPCI-6965 Front Panel System LED Descriptions . 27
Table 4-2: USB Connector Pin Definition ................................ 32
Table 4-3: PS/2 Keyboard/Mouse Connector Pin Definition .... 32
Table 4-4: DVI-D Connector Pin Definition .............................. 33
Table 4-5: DVI-D Connector Pin Definition .............................. 34
Table 4-6: COM1-2 Serial Port Connector Pin Definition ........ 34
Table 4-7: Parallel Port Connector Pin Definition .................... 35
Table 4-8: GbE Connector Pin Definitions ............................... 36
Table 4-9: Ethernet LED Status Definitions ............................. 36
Table 4-10: SATA Connector Pin Definition .............................. 37
Table 4-11: DB-6910SAT SATA Connector Pin Definition ........ 37
Table 4-12: CompactFlash Connector Pin Definition ................. 38
Table 4-13: PMC Connector Pin Definition ................................ 40
Table 4-14: CompactPCI J1 Connector Pin Definition ............... 41
Table 4-15: CompactPCI J2 Connector Pin Definition ............... 42
Table 4-16: CompactPCI J3 Connector Pin Definition ............... 43
Table 4-17: CompactPCI J5 Connector Pin Definition ............... 44
Table 4-18: COM1 Mode Switch Settings .................................. 45
Table 4-19: COM2 Mode Switch Settings .................................. 46
Table 4-20: PMC V(I/O) Select Jumper Settings ....................... 47

vi List of Tables
This page intentionally left blank.

List of Figures vii
cPCI-6965
List of Figures
Figure 1-1: cPCI-6965 Series Block Diagram.............................. 3
Figure 3-1: USB Flash Disk Mechanical Layout ........................ 21
Figure 4-1: cPCI-6965 Board Layout......................................... 23
Figure 4-2: cPCI-6965 SBC Assembly Layout........................... 24
Figure 4-3: cPCI-6965D SBC Assembly Layout ........................ 25
Figure 4-4: cPCI-6965 Series Front Panel Layout..................... 26
Figure 4-5: cPCI-R6000-965, cPCI-R6000-L Board Layout....... 28
Figure 4-6: cPCI-R6000-965, cPCI-R6000-L Front Panel ......... 29
Figure 4-7: cPCI-R6000-965D, cPCI-R6000D-L Board Layout . 30
Figure 4-8: cPCI-R6000-965D, cPCI-R6000D-L Front Panel.... 31

viii List of Figures
This page intentionally left blank.

Overview 1
cPCI-6965
1Overview
1.1 Introduction
The cPCI-6965 Series is a highly integrated 6U CompactPCI SBC
in single slot (4HP) or dual slot (8HP) width form factor. It has been
designed to support the Intel® Core™ 2 Duo and Celeron® M pro-
cessors in 478-pin Micro-FCPGA. The cPCI-6965 is based on the
Mobile Intel® GME965 Express chipset which offers outstanding
graphics and I/O bandwidth, asset management capabilities, stor-
age speed and reliability.
The cPCI-6965 supports dual-channel non-ECC 533/667 MHz
DDR2 memory with a maximum capacity of up to 4GB, 533/800
MHz Front-Side Bus (FSB), and Mobile Intel® Graphics Media
Accelerator X3100 (Intel® GMA X3100). The integrated graphics
support dual independent displays through two DVI outputs on the
front panel.
The cPCI-6965 offers versatile I/O ports such as two Gigabit
Ethernet ports, two RS-232/422/485/485+ selectable serial ports,
four USB 2.0 ports, PS/2 Keyboard/Mouse, and parallel port on
the front panel. Additional I/O can be routed to available Rear
Transition Modules (RTM), including USB, VGA, SCSI, Floppy
port, Mic-in, Line-out, and SATA. The board also supports one
32-bit/33MHz CompactPCI interface and a PMC expansion slot.
Storage features of the cPCI-6965 include a pin header and
mounting space for an onboard USB NAND flash module, two
Serial ATA interfaces with mounting space for a 2.5” HDD, and
CompactFlash socket.

2Overview
1.2 Features
X6U CompactPCI SBC in 4HP or 8HP width form factor
XSingle Core™ 2 Duo 2.2GHz processor, 4MB L2 cache
XFront Side Bus 800MHz
XMobile Intel® GME965 Memory Controller Hub and ICH8M
I/O Hub
XDual Channel DDR2 unbuffered non-ECC SDRAM at
667MHz
XTwo stacked SO-DIMM sockets for maximum up to 4GB
memory
X32-bit/33MHz CompactPCI Interface based on PCI specifi-
cations
XOne DVI-I and one DVI-D port on front panel
XSupports VGA+DVI or DVI+DVI dual independent displays
XTwo PCI-Express® Gigabit Ethernet egress ports
XOne EIDE CompactFlash socket
XSpace for USB NAND flash module for storage option
XOne SATA port for 2.5” HDD direct mounting and one 7-pin
signal SATA port for external HDD
XOptional Rear Transition Module

Overview 3
cPCI-6965
1.3 Block Diagram
Figure 1-1: cPCI-6965 Series Block Diagram
Intel®
GME965 DDR2 SO-DIMM
Dual Channel 533/667MHz
533/667/800MHz FSB
Intel®
Core 2 Duo
Processor
USB 1/2/3/4 BIOS
LPC
Intel®
ICH8M-DO
DMI (x2/x4)
F
R
O
N
T
P
A
N
E
L
DDR2 SO-DIMM
J2
J1
Intel®
82573L
PCIE x1
GbE1
SATA 1
IDE
COM x2
SPI
DVI-D SDVO-A
Sil1362
Intel®
82573L
PCI 32b/33M
2.5” HDD
Flash module
USB 5
CF
PS/2 KB/MS
PCI 32b/33M PCI
2050B
header SATA 2
DVI-I SDVO-B
Sil1362
RGB
GbE2 PCIE x1
J3
PMC
SATA 3, HD Audio, 5x USB, SMBus
J5
PCIEx4
J5
FDD
Parallel J3
SIO
IT8712F
J3

4Overview
1.4 Product List
Products included in the cPCI-6965 Series include:
SBC
XcPCI-6965: 4HP (single-slot) width 6U CompactPCI featur-
ing Core™2 Duo or Celeron® processor; 512MB, 1GB,
2GB or 4GB memory by SO-DIMM; CompactFlash slot,
2xSATA ports, and 4xUSB, 2xGbE, DVI-D, DVI-I, COM and
J3, J5 connectors
XcPCI-6965D: 8HP (dual-slot) width 6U CompactPCI featur-
ing Core™2 Duo or Celeron® processor; 512MB, 1GB,
2GB or 4GB memory by SO-DIMM; CompactFlash slot, and
4x USB, 2x GbE, DVI-D, DVI-I, 2xCOM, printer port and J3,
J5 connectors. A DB-6965PMC riser card is included to pro-
vide a PMC slot.
XcPCI-6965DZ: 8HP (dual-slot) width 6U CompactPCI featur-
ing Core™2 Duo or Celeron® processor; 512MB, 1GB,
2GB or 4GB memory by SO-DIMM; CompactFlash slot, and
4x USB, 2x GbE, DVI-D, DVI-I, 2xCOM, printer port without
J3, J5 connectors. A DB-6965PMC riser card is included
to provide a PMC slot.
Rear Transition Module
XcPCI-R6000-965: 4HP width Rear Transition Module for
cPCI-6965 SBCs with 2x USB, VGA, SCSI, Floppy, SATA
port
XcPCI-R6000-965D: 8HP width Rear Transition Module for
cPCI-6965 SBCs with 4x USB, VGA, SCSI, Floppy, SATA ,
Mic-in, Line-out, PS/2 KB/MS port
XcPCI-R6000-L: 4HP width Rear Transition Module for
cPCI-6965 SBCs with 2x USB, VGA, Floppy, SATA port
(without SCSI)
XcPCI-R6000D-L: 8HP width Rear Transition Module for
cPCI-6965 SBCs with 4x USB, VGA, Floppy, SATA , Mic-in,
Line-out, PS/2 KB/MS port (without SCSI)

Overview 5
cPCI-6965
1.5 Package Contents
The cPCI-6965 is packaged with the following components. If any
of the items on the contents list are missing or damaged, retain the
shipping carton and packing material and contact the dealer for
inspection. Please obtain authorization before returning any prod-
uct to ADLINK. The packing contents of the cPCI-6965 Series are
non-standard configurations and may vary depending on customer
requests.
CPU module
XThe cPCI-6965 Series CPU Module
ZCPU, RAM will differ depending on options selected
ZThermal module is assembled on the board
XY-cable for PS/2 combo port (8HP version only)
XDVI to VGA adapter
X2.5” HDD accessory pack, including DB-6910SAT adapter
and screws, standoffs
XUSB NAND flash module screw pack
XPMC accessory pack, including DB-6965PMC adapter and
screws, standoffs (8HP version only)
XADLINK All-in-One CD
XUser’s manual
Rear Transition Module
XThe cPCI-R6000-965, cPCI-R6000-965D, cPCI-R6000-L,
or cPCI-R6000D-L
XY-cable for PS/2 combo port (cPCI-R6000-965D,
cPCI-R6000D-L only)
XDVI-to-VGA adapter
X68-pin SCSI cable (cPCI-R6000-965, cPCI-R6000-965D
only)
NOTE:
NOTE:
The contents of non-standard cPCI-6965 configurations may
vary depending on the customer’s requirements.

6Overview
CAUTION:
This product must be protected from static discharge and phys-
ical shock. Never remove any of the components except at a
static-free workstation. Use the anti-static bag shipped with the
product when putting the board on a surface. Wear an
anti-static wrist strap properly grounded on one of the system's
ESD ground jacks when installing or servicing system compo-
nents.
