ADTRAN 1442390G1 User manual

jobAid
DESCRIPTION
The Small Form-Factor Pluggable (SFP) is a single-mode fiber SFP
that plugs into ADTRAN Gigabit Ethernet modules designed to
accept SFPs. The SFP provides a dual optical interface to a Gigabit
Ethernet physical interface.
Installed into an appropriate module, the SFP provides a 1.25
Gigabit Ethernet interface to the supporting system.
NOTE
If the SFP is installed in a GigE 4-Port Line Module
(P/N: 1187550E1), ensure that Auto Negotiation is disabled on
the line module to ensure proper operation.
This SFP is designed for use in Dense Wavelength Division Multi-
plexing (DWDM) applications.
FEATURES
The following features are supported on the SFP:
1000BASE-EX DWDM
Data rate: 1.25 Gbps
LC optical connectors
Transmit Wavelength: 1538.19 nm
Receive Wavelength: 1200 to 1620 nm
Optical distance: 120 km maximum
CAUTION
!
Due to compliance certification requirements, only use SFPs
supplied by ADTRAN with the host module. ADTRAN cannot
certify system integrity with other SFPs.
Small Form-Factor Pluggable
DWDM Gigabit Ethernet
Single-Mode 120 km
INSTALLATION
Before installation, inspect the SFP. If damage has occurred
during shipping, file a claim with the carrier, and then contact
ADTRAN Customer Support. For more information, refer to
“Warranty”.
Installation Guidelines
The following are guidelines for this installation.
The latch on the SFP is for removal only. When removing the
SFP, rotate the latch away from the SFP. The SFP should slide
easily out of the cage.
It is recommended that the connector plug remain on
whenever the transciever optical fiber connector is not
inserted.
Installation Steps
To install the SFP, complete the following steps:
1. Insert the SFP into the SFP cage on the circuit board of the
host module with the latch handle facing outward. Slide the
SFP all the way into the cage.
2. Exert adequate pressure to ensure the SFP is completely
seated in the SFP cage.
3. Do not remove the connector plug until the optical fiber
connection is made.
4. Continue the installation and turn-up of the host module.
SPECIFICATIONS
Optical Specifications:
oOptical transmit level: 0 dBm to +4 dBm
oOptical receive level: –45 dBm minimum
oOptical Budget: 45 dB
oOptical connectors: LC
Extended Environmental Support:
oOperational temperature range: –40°C to +85°C
oStorage temperature range: –40°C to +85°C
oRelative humidity to 95%, noncondensing
CLEI: BVL3AFGD_ _
Product P/N: 1442390G1
Issue Date: May 2014
Document P/N: 61442390G1-22B
Documentation for ADTRAN Carrier Networks products is available for
viewing and download directly from the ADTRAN Support Community
website.
Go to: https://supportforums.adtran.com/welcome
Registration is required.
ADTRAN offers training courses on our products, including customized
training and courses taught at our facilities or at customer sites.
For inquiries, go to: http://adtran.com/training
The following documents provide additional information for this product:
SFP/XFP/SFP+ Compatibility Matrix and Engineering Guide

CAUTION!
SUBJECT TO ELECTROSTATIC DAMAGE
OR DECREASE IN RELIABILITY
HANDLING PRECAUTIONS REQUIRED
Warranty: ADTRAN will replace or repair this product within the warranty period if it does not
meet its published specifications or fails while in service. Warranty information can
be found online at www.adtran.com/warranty.
©2014 ADTRAN, Inc. All Rights Reserved.
ADTRAN CUSTOMER CARE:
From within the U.S. 1.800.726.8663
From outside the U.S. +1 256.963.8716
PRICING AND AVAILABILITY 1.800.827.0807
*61442390G1-22B*
SAFETY AND REGULATORY COMPLIANCE
WARNING
!
Read all warnings and cautions before installing or servicing this
equipment
CAUTION
C
The product is a Class 1 Laser Product and complies with the
Laser Safety requirements of FDA 21CFR 1040.10 and 1040.11,
and EN60825-1 and -2. The SFP is NRTL listed and CB Certified to
all applicable American and European safety standards.
For continued compliance with the above laser safety standards,
only approved Class 1 modules from our approved vendor list,
located on the ADTRAN website, should be installed in ADTRAN
products.
CAUTION
!
Electrostatic Discharge (ESD) can damage electronic modules.
When handling modules, wear an antistatic discharge wrist
strap to prevent damage to electronic components. Place
modules in antistatic packing material when transporting or
storing. When working on modules, always place them on an
approved antistatic mat that is electrically grounded.
This product meets or exceeds all the applicable requirements
of NEBS, Telcordia GR-63-CORE, and GR-1089-CORE. This
product is intended for deployment in Central Office type
facilities, EEEs, EECs, and locations where the NEC applies
(for example, Customer Premises). This product is to be
installed in ADTRAN products in Restricted Access Locations
only, and installed by trained service personnel.
Per GR-1089-CORE the ADTRAN system that this product is
being deployed in is designed and intended for installation as
part of a Common Bonding Network (CBN). The ADTRAN
system that this product is being deployed in is not designed
nor intended for installation as part of an Isolated Bonding
Network (IBN).
Per GR-1089-CORE Section 9, this product does not have an
internal DC connection between battery return and frame
ground. This product can be installed in a DC-I (isolated) or
DC-C (common) installation. For installations where other
cards or the host system have internal connections between
battery return and frame ground, the system would be
intended for deployment only in a DC-C installation.
The ADTRAN system chassis frame ground terminal must be
connected to a reliable earth ground to ensure that the metal
enclosure of this product is properly grounded via the
backplane connector.
NOTE
The Gigabit Ethernet port(s) are optical and therefore are not
classified as any type of port as defined in Appendix B of GR-
1089-CORE.
This product is designed to be deployed in GR-3108-CORE
environmental class 1, 2, and 3.
This product is compliant with SFF-8472 Digital Diagnostics
Monitoring Interface for Optical Transceivers, Revision 9.3.
This product is compliant with the Small Form-Factor Pluggable
(SFP) Multi-Source Agreement (MSA).
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by ADTRAN
could void the user's authority to operate this equipment.
This product is designed to meet the following environmental
classes:
GR-3108-CORE Environmental Classes 1, 2, and 3
ETSI EN 300 019-1-1 Classification of environmental conditions;
Storage, Class 1.2
ETSI EN 300 019-1-2 Classification of environmental conditions;
Transportation, Class 2.3
ETSI EN 300 019-1-3 Classification of environmental conditions;
Stationary use at weather-protected locations, Class 3.3
The equipment is designed to function without degradation
during exposure to all test severities per Class 3.3.
This product meets EU RoHS Directive 2002/95/EC and/or
applicable exemptions. Refer to www.adtran.com for further
information on RoHS/WEEE.
