Advantech ARK-7060 User manual

User Manual
ARK-7060
Embedded Box PC

ARK-7060 User Manual ii
Attention!
Please note:
This package contains a hard-copy user manual in Chinese for China CCC certifica-
tion purposes. There is an English user manual included as a PDF file on the CD.
Please disregard the Chinese hard copy user manual if the product is not to be sold
and/or installed in China.

iii ARK-7060 User Manual
Copyright
The documentation and the software included with this product are copyrighted 2022
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated, or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. The information provided in this manual is intended to be accurate and reliable.
However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any
infringements of the rights of third parties that may result from its use.
Acknowledgments
Award is a trademark of Award Software International, Inc.
VIA is a trademark of VIA Technologies, Inc.
IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines Cor-
poration.
Intel® and Pentium® are trademarks of Intel Corporation.
Microsoft Windows® is a registered trademark of Microsoft Corp.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
ESS is a trademark of ESS Technology, Inc.
UMC is a trademark of United Microelectronics Corporation.
SMI is a trademark of Silicon Motion, Inc.
Creative is a trademark of Creative Technology LTD.
CHRONTEL is a trademark of Chrontel Inc.
All other product names or trademarks are properties of their respective owners.
For more information about this and other Advantech products, please visit our web-
site at:
http://www.advantech.com/
http://www.advantech.com/ePlatform/
For technical support and service, please visit our support website at:
http://support.advantech.com.tw/support/
Part No. 2006706000 Edition 1
Printed in China October 2022

ARK-7060 User Manual iv
Product Warranty (2 years)
Advantech warrants the original purchaser that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products that have been repaired or altered by
persons other than repair personnel authorized by Advantech, or products that have
been subject to misuse, abuse, accident, or improper installation. Advantech
assumes no liability under the terms of this warranty as a consequence of such
events.
Because of Advantech’s high quality-control standards and rigorous testing, most
customers never need to use our repair service. If an Advantech product is defective,
it will be repaired or replaced free of charge during the warranty period. For out-of-
warranty repairs, customers will be billed according to the cost of replacement mate-
rials, service time, and freight. Please consult your dealer for more details.
If you believe your product to be defective, follow the steps outlined below.
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any on-screen messages displayed when the prob-
lem occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain a return merchandise authori-
zation (RMA) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a completed Repair and Replacement
Order Card, and a proof of purchase date (such as a photocopy of your sales
receipt) into a shippable container. Products returned without a proof of pur-
chase date are not eligible for warranty service.
5. Write the RMA number clearly on the outside of the package and ship the pack-
age prepaid to your dealer.
Declaration of Conformity
FCC Class B
This equipment has been tested and found to comply with the limits for a Class B dig-
ital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-
vide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. However, there is no guarantee that interfer-
ence will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for assistance.

v ARK-7060 User Manual
Technical Support and Assistance
1. Visit the Advantech website at www.advantech.com/support to obtain the latest
product information.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before calling:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages
Warnings, Cautions, and Notes
Packing List
Before system installation, check that the items listed below are included and in good
condition. If any item does not accord with the list, contact your dealer immediately.
1 x ARK-7060 Unit
1 x Mounting Kit
1 x User Manual (Simplified Chinese)
1 x China RoHS
Warning! Warnings indicate conditions that if not observed can cause personal
injury!
Caution! Cautions are included to help prevent hardware damage and data
losses. For example,
“Batteries are at risk of exploding if incorrectly installed. Do not attempt
to recharge, force open, or heat the battery. Replace the battery only
with the same or equivalent type as recommended by the manufacturer.
Discard used batteries according to the manufacturer's instructions.”
Note! Notes provide additional optional information.

ARK-7060 User Manual vi
Ordering Information
ARK-7060 Default SKU Option Items
Optional Item for Default SKU
Part
No. CPU DDR4 GbE 10
GbE VGA
2.5”
SATA III
HDD Bay
RS-232/
422/485
USB
3.0
M.2 B
Key
M.2 E
Key SIM IPMI Power
Supply Expansion
ARK-
7060-
U0A1
Intel®
Xeon®
D-1746TER
Up to
128GB 22
(optional) 12
(Up to 4) 4 4 1 1 1 Yes 850W
1 x PCI
1 x PCIex4
1 x PCIx16
ARK-
7060-
U4A1
Intel®
Xeon®
D-1715TER
Up to
128GB 22
(optional) 12
(Up to 4) 4 4 1 1 1 Yes 850W
1 x PCI
1 x PCIex4
1 x PCIx16
Note! Memory/Storage and operating system bundled by request.
Part Number Description
1702002600 Power cable 3-pin 183 cm (64.1 in), USA type
1702002605 Power cable 3-pin 183 cm (64.1 in), EU type
1702031801 Power cable 3-pin 183 cm (64.1 in), UK type
1700000237 Power cable 3-pin 183 cm (64.1 in), PSE type
AMO-I029 TPM 2.0 module
AMO-I031 2 x 10GbE LAN kit
AMK-A0042 2 x internal HDD bay kit
AMK-A0043 NVIDIA A2/T4 GPU card fan kit

vii ARK-7060 User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Retain this user manual for future reference.
3. Disconnect the equipment from all power outlets before cleaning. Use only a
damp cloth for cleaning. Do not use liquid or spray detergents.
4. For pluggable equipment, the power outlet socket must be located near the
equipment and easily accessible.
5. Protect the equipment from humidity.
6. Place the equipment on a reliable surface during installation. Dropping or letting
the equipment fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. Do not cover the openings.
8. Ensure that the voltage of the power source is correct before connecting the
equipment to a power outlet.
9. Position the power cord away from high-traffic areas. Do not place anything over
the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage from transient overvoltage.
12. Never pour liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If any of the following occurs, have the equipment checked by service person-
nel:
–The power cord or plug is damaged.
–Liquid has penetrated the equipment.
–The equipment has been exposed to moisture.
–The equipment is malfunctioning, or does not operate according to the user
manual.
–The equipment has been dropped and damaged.
–The equipment shows obvious signs of breakage.
15. Do not leave the equipment in an environment with a storage temperature of
below -40 °C (-40 °F) or above 85 °C (185 °F) as this may damage the compo-
nents. The equipment should be kept in a controlled environment.
16. Any unverified component may cause unexpected damage. To ensure correct
installation, always use the components (e.g., screws) provided in the acces-
sory box.
17. CAUTION: Batteries are at risk of exploding if incorrectly replaced. Replace only
with the same or equivalent type as recommended by the manufacturer. Discard
used batteries according to the manufacturer’s instructions.
18. Always disconnect the power cord from the chassis before manually handling
the hardware. Do not implement connections or configuration changes while the
device is powered on. Sudden power surges may damage sensitive electronic
components.
19. In accordance with IEC 704-1:1982 specifications, the sound pressure level at
the operator’s position does not exceed 70 dB (A).
20. The equipment should only be installed in a restricted access areas.
21. Use a power cord connected to a socket-outlet with a grounded connection.
22. This product is intended to be supplied by a UL Listed power supply suitable for
use at minimum Tma 50 °C (122 °F) whose output meets PS2 (or LPS), ES1(or

ARK-7060 User Manual viii
SELV) and output is rated: 9-36Vdc, 16.65-4.16A. Please contact Advantech for
further information.
DISCLAIMER: These instructions are provided according to IEC 704-1 standards.
Advantech disclaims all responsibility for the accuracy of any statements contained
herein.
Consignes de Sécurité
1. Veuillez lire attentivement ces instructions de sécurité.
2. Veuillez conserver ce manuel de l'utilisateur pour référence ultérieure.
3. Veuillez débrancher cet équipement de la prise secteur avant le nettoyage. Utili-
sez un chiffon humide. Ne pas utiliser de détergent liquide ou pulvérisé pour le
nettoyage. Utilisez une feuille ou un chiffon humide pour le nettoyage.
4. Pour les équipements enfichables, la prise de courant doit être à proximité de
l'équipement et doit être facilement accessible.
5. S'il vous plaît garder cet équipement de l'humidité.
6. Posez cet équipement sur une surface fiable lors de l'installation. Une chute ou
une chute pourrait causer des blessures.
7. Les ouvertures sur le boîtier sont destinées à la convection d'air, protégeant.
ainsi l'équipement de la surchauffe. NE COUVREZ PAS LES OUVERTURES.
8. La prise de courant doit avoir une connexion mise à la terre.
9. Placez le cordon d'alimentation de sorte que personne ne puisse marcher des-
sus.
Ne placez rien sur le cordon d'alimentation.
10. Tous les avertissements et mises en garde sur l'équipement doivent être notés.
11. Si l'appareil n'est pas utilisé pendant une longue période, débranchez-le du sec-
teur pour ne pas être endommagé par une surtension transitoire.
12. Ne jamais verser de liquide dans les ouvertures de ventilation; Cela pourrait
provoquer un incendie ou un choc électrique.
13. N'ouvrez jamais l'équipement. Pour des raisons de sécurité, seul le personnel
de maintenance qualifié doit ouvrir l'équipement.
14. Si l'une des situations suivantes se présente, faites vérifier le matériel par le
personnel de service:
–Le cordon d'alimentation ou la fiche est endommagé.
–Un liquide a pénétré dans l'appareil.
–L'équipement a été exposé à l'humidité.
–L'équipement ne fonctionne pas bien ou vous ne pouvez pas le faire.
fonctionner conformément au manuel d'utilisation.
–Equipment L'équipement est tombé et a été endommagé.
–Equipment L'équipement présente des signes évidents de rupture.
15. Ne laissez pas cet équipement dans un environnement où la température de
stockage peut être inférieure à -40° C (-40° F) ou supérieure à 85° C (185° F).
Cela pourrait endommager l'équipement. L'équipement doit être dans un envi-
ronnement contrôlé.
16. Tout composant non vérifié peut causer des dommages inattendus. Pour garan-
tir une installation correcte, veuillez toujours utiliser les composants (ex. Vis)
fournis avec la boîte d'accessoires.
17. ATTENTION: L'ordinateur est équipé d'un circuit d'horloge temps réel alimenté
par batterie. Il y a un risque d'explosion si la batterie est remplacée de manière
incorrecte. Remplacez uniquement avec le même type ou un type équivalent
recommandé par le fabricant. Jetez les piles usagées conformément aux
instructions du fabricant.

ix ARK-7060 User Manual
18. Débranchez toujours complètement le cordon d'alimentation de votre châssis
lorsque vous utilisez du matériel. Ne faites pas de connexion quand l'appareil
est sous tension. Les composants électroniques sensibles peuvent être endom-
magés par des surtensions soudaines.
19. Niveau de pression acoustique au poste de l'opérateur selon la norme CEI 704-
1: 1982 n'est pas supérieur à 70 dB (A).
20. L'équipement ne doit être installé que dans une zone d'accès restreint.
21. Au moyen d'un cordon d'alimentation connecté à une prise de courant avec
mise à la terre.
22. Ce produit est destiné à être alimenté par un bloc d'alimentation homologué UL
adapté à une utilisation à Tma 50 degrés C min. dont la sortie est conforme à
PS2 (ou LPS), ES1 (ou SELV) et dont la sortie est nominale: 9-36Vdc, 16.65-
4.16A, si besoin d'aide supplémentaire, veuillez contacter Advantech pour plus
d'informations.
AVERTISSEMENT: Cet ensemble d'instructions est donné conformément à la norme
CEI 704-1. Advantech décline toute responsabilité quant à l'exactitude des déclara-
tions contenues dans ce.

ARK-7060 User Manual x

xi ARK-7060 User Manual
Contents
Chapter 1 General Introduction ...........................1
1.1 Introduction ............................................................................................... 2
1.2 Product Features....................................................................................... 3
1.2.1 General ......................................................................................... 3
1.2.2 Ethernet ........................................................................................ 3
1.3 Chipset ...................................................................................................... 4
1.3.1 Functional Specifications .............................................................. 4
1.3.2 SUSI 4.2........................................................................................ 4
1.4 Mechanical Specifications......................................................................... 5
1.4.1 Dimensions ................................................................................... 5
Figure 1.1 ARK-7060 Mechanical Dimensions Diagram ............. 5
1.4.2 Weight........................................................................................... 6
1.5 Power Requirements................................................................................. 6
1.5.1 System Power............................................................................... 6
1.6 Operating Environment Specifications ...................................................... 6
1.6.1 Operating Temperature................................................................. 6
1.6.2 Relative Humidity .......................................................................... 6
1.6.3 Storage Temperature.................................................................... 6
1.6.4 Safety............................................................................................ 6
1.6.5 EMC .............................................................................................. 6
Chapter 2 Hardware Configuration......................7
2.1 Introduction ............................................................................................... 8
2.2 Jumpers .................................................................................................... 8
2.2.1 Jumper Description ....................................................................... 8
2.2.2 Jumper List ................................................................................... 8
2.2.3 Jumper Locations.......................................................................... 9
Figure 2.1 Jumper Layout............................................................ 9
2.2.4 Jumper Settings ............................................................................ 9
2.2.5 Bottom Board Jumper List .......................................................... 11
2.2.6 Jumper Locations........................................................................ 12
2.2.7 Jumper Settings .......................................................................... 13
2.3 Connectors.............................................................................................. 15
2.3.1 External I/O Locations................................................................. 15
Figure 2.2 Front I/O Connector Diagram ................................... 15
Figure 2.3 COM Port Connector ................................................ 16
Table 2.1: COM Connector Pin Assignments............................ 16
Figure 2.4 Ethernet Connector .................................................. 17
Table 2.2: CN5/CN6 Ethernet Connector Pin Assignments ..... 17
Table 2.3: 10G Card LAN1 Ethernet Connector Pin Assignments
18
Figure 2.5 Power ON/OFF Button ............................................. 18
Figure 2.6 LED Indicators .......................................................... 18
Figure 2.7 USB 3.0 Connector................................................... 19
Table 2.4: USB 3.0 Connector Pin Assignments....................... 19
Figure 2.8 BMC Dedicated LAN Connector............................... 19
Table 2.5: CN9 BMC Dedicated LAN Connector Pin Assignments
19
Figure 2.9 BMC Dedicated COM Port ....................................... 20
Figure 2.10BMC Dedicated VGA Port ........................................ 20
Table 2.6: VGA Connector Pin Assignments............................. 20
2.4 Installation ............................................................................................... 21
2.4.1 Remove Top Cover..................................................................... 21

ARK-7060 User Manual xii
2.4.2 Memory Installation..................................................................... 22
2.4.3 HDD/SSD Installation ................................................................. 22
2.4.4 M.2 Module Installation/Internal SIM Slot ................................... 23
2.4.5 PCIex16 Graphic Card Installation ............................................. 24
2.4.6 Mounting Kit Installation............................................................. 25
2.4.7 Wide Operating Temperature Support........................................ 25
Chapter 3 BIOS Settings .................................... 27
3.1 Introduction ............................................................................................. 28
3.2 Entering the Setup .................................................................................. 29
3.2.1 Main Setup.................................................................................. 29
3.2.2 Advanced BIOS Features Setup................................................. 30
3.2.3 Platform Configuration ................................................................ 45
3.2.4 Socket Configuration .................................................................. 69
3.2.5 Server Management ................................................................... 81
3.2.6 Security....................................................................................... 87
3.2.7 Boot ............................................................................................ 89
3.2.8 Save & Exit ................................................................................. 90
Appendix A Watchdog Timer Sample Code ........ 91
A.1 EC Watchdog Timer Sample Code......................................................... 92

Chapter 1
1General Introduction
This chapter details background
information on the ARK-7060
series.

ARK-7060 User Manual 2
1.1 Introduction
Advantech’s ARK-7060 is a high-performance edge computer that empowers model-
training applications via multiple expansion slots and fast data transfer speeds. It is
equipped with the Intel® Xeon® D-1700 series processor and 4 x DDR4 SODIMM
sockets (supporting up to 128GB). This solution provides PCI, PCIe x4, and PCIe
x16 slots to enable the use of 350W graphics cards.
Multiple I/O and Storage Capabilities
ARK-7060 offers 2 x GbE, 4 x USB 3.0, and 4 x COM ports. It also supports up to 4 x
2.5” SATA III hard drive bays and delivers high data transfer rates via optional 10GbE
ports and M.2 B key for 5G modules.
Advanced Security and Remote Management
ARK-7060 features dual BIOS for BIOS backup and recovery to enhance security.
This lowers the risk of BIOS damage and protects against virus and/or data corrup-
tion. ARK-7060 also features an on-board baseboard management controller (BMC)
to provide PMI architecture for remote management.
Built-in Intelligent Management Tools — Advantech SUSI API and WISE-Devi-
ceOn
Advantech SUSI API provides a valuable suite of programmable APIs such as multi-
level watchdog, hardware monitoring, system restoration, and other user-friendly
interfaces.
SUSI API is an intelligent self-management cross platform tool that monitors system
status for problems and takes action in the event of abnormalities. SUSI API offers a
boot up guarantee in critical, low-temperature environments so systems can auto-
matically recover when voltages dip. SUSI API makes the entire system more reliable
and intelligent. ARK-7060 also supports Advantech WISE-DeviceOn software. This
software supports remote management; and enables users to monitor, configure, and
control a large number of terminals simultaneously, making maintenance and system
recovery simpler.

3 ARK-7060 User Manual
Chapter 1 General Introduction
1.2 Product Features
1.2.1 General
CPU: Intel® Xeon® D-1700 series processor (up to 10 cores 67W)
System Chipset: SoC
BIOS: AMI EFI 512Mbit
System Memory: 4 x DDR4 2666/2933MHz ECC/non-ECC SO-DIMM, up to
128GB
Watchdog Timer: Single chip Watchdog 255-level interval timer, setup by soft-
ware
I/O Interface: 4 x RS232/422/485
USB: 4 x USB 3.0 compliant ports
IPMI 2.0 support: Aspeed AST2500 BMC supports IPMI 2.0 (Intelligent Plat-
form Management Interface 2.0) via dedicate LAN, VGA, and console port
–1 x VGA
–1 x GbE management port
–1 x console port
Storage: 2 x 2.5" swappable SATAIII HDD Bay with RAID 0/1 and max height
15 mm/0.59 in (up to 4 x 2.5" SATAIII HDD Bay by AMK-A0042)
Expansion Interface:
–1 x M.2 2230/2280/3052 B Key, supporting M.2 2242/3042 with bracket (sup-
port SIM holder)
–1 x M.2 2230 E key for Wi-Fi modules
–Add-on Card Slot: 1 x slot PCI+1 x slot PCIe x 4+1 x slot PCIe x 16
TPM: TPM 2.0 (support by optional AMO-I029)
1.2.2 Ethernet
Chipset:
–LAN1/2 Intel® i210
–LAN3/4 Intel® X550 (support by optional AMO-I031)
Speed:
–LAN1/2 10/100/1000 Mbps
–LAN3/4 100/1000/10000 Mbps
Interface: Up to 4 x RJ45

ARK-7060 User Manual 4
1.3 Chipset
1.3.1 Functional Specifications
1.3.1.1 Processor
1.3.1.2 Chipset
1.3.1.3 Others
1.3.2 SUSI 4.2
Processor Intel® Xeon® D-1700 series processor (up to 10 cores 67W)
(Suspend mode S3 & S4 are not supported by this platform)
Memory Supports DDR4 2666/2933MHz up to 128GB
4 x 260-pin SODIMM socket type
SATA Interface
Supports several optional sections of Serial ATA III: Exten-
sions to Serial ATA 1.0 Specification, Revision 1.0
Supports SATA transfers to 600 Mbytes/sec.
USB Interface
USB host interface with support for 4 x USB 3.0 ports
All ports are High-Speed, Full-Speed, and Low-Speed capa-
ble
Supports legacy keyboard/mouse software
BIOS 2 x AMI 512-Mbit EFI Flash BIOS via SPI (Dual BIOS)
Serial Ports
4 x serial ports
Supports IRQ Sharing among serial ports under Microsoft
Windows OS
COM1, COM2, COM3, and COM4: RS232/422/485
Ethernet
LAN1/2 support 10/100/1000 Mbps, LAN3/4 support 100/
1000/10000 Mbps
LAN Connectors: Phone Jack RJ45 8P 90D (F)
Battery Backup BATTERY 3V/210 mAh with WIRE x 1
TPM TPM 2.0 (support by optional AMO-I029)
SUSI API
Sequence Control Supported
Watchdog Timer Multi-level WDT (set by Advantech iManager)
Programmable 1-255 sec/min
Hardware Monitor CPU Temperature/input Current/input Voltage
System Information Running HR/Boot record

5 ARK-7060 User Manual
Chapter 1 General Introduction
1.4 Mechanical Specifications
1.4.1 Dimensions
(W x H x D) 230 x 205 x 390 mm/9.05 x 8.07 x 15.35 in
Figure 1.1 ARK-7060 Mechanical Dimensions Diagram
230
205
39010

ARK-7060 User Manual 6
1.4.2 Weight
9.7 kg (21.38 lb)
1.5 Power Requirements
1.5.1 System Power
Power Type: ATX
Minimum Power Input: 100 ~ 240VAC
Power Supply: 850W power supply built in
1.6 Operating Environment Specifications
1.6.1 Operating Temperature
With extended peripherals: -10 ~ 50 °C; 14 ~ 112 °F, with 0.7m/s air flow
1.6.2 Relative Humidity
95% @ 40 °C (104 °F) (non-condensing)
1.6.3 Storage Temperature
-40 ~ 85 °C (-40 ~ 185 °F)
1.6.4 Safety
CB (62368), UL (62368), CCC, BSMI, and UKCA
1.6.5 EMC
CE/FCC Class B, CCC, BSMI, and UKCA

Chapter 2
2Hardware
Configuration

ARK-7060 User Manual 8
2.1 Introduction
The following sections show the internal jumper settings and the external connector
pin assignments for different applications.
2.2 Jumpers
2.2.1 Jumper Description
You may configure ARK-7060 to match the needs of your application by setting jump-
ers. A jumper is a metal bridge used to close an electric circuit. It consists of two
metal pins and a small metal clip (often protected by a plastic cover) that slides over
the pins to connect them. To close a jumper, you connect the pins with the clip. To
open a jumper, remove the clip. Sometimes a jumper will have three pins, labeled 1,
2 and 3. In this case you would connect either pins 1 and 2, or 2 and 3.
The jumper settings are schematically depicted in this manual as follows.
A pair of needle-nose pliers may be helpful when working with jumpers. If you have
any doubts about the best hardware configuration for your application, contact your
local distributor or sales representative before you make any changes. Generally, you
simply need a standard cable to make most connections.
2.2.2 Jumper List
closed 2-3closedopen
12 12
closed 2-3closedopen
Table 2.1: Jumper List
JCMOS1 Clear CMOS
PSON1 Auto Power On Setting
CN15 SMB Enable
SW_422_1 Fail safe
SW_422_2 Fail safe
