Advantech UR5i v2 Libratum User manual

HSPA+ Industrial Router
UR5i v2
USER MANUAL

UR5i v2
Advantech B+B SmartWorx – Americas
Advantech B+B SmartWorx
707 Dayton Road
Ottawa, IL 61350 USA
Website
www.advantech-bb.com
Advantech – Europe
Advantech Czech s.r.o.
Sokolska 71
562 04, Usti nad Orlici,
Czech Republic
Website
www.advantech-bb.com
c
2020 Advantech Czech s.r.o. No part of this publication may be reproduced or transmitted in any form or
by any means, electronic or mechanical, including photography, recording, or any information storage and retrieval
system without written consent. Information in this manual is subject to change without notice, and does not
represent a commitment on the part of Advantech.
Advantech Czech s.r.o. shall not be liable for incidental or consequential damages resulting from the furnish-
ing, performance, or use of this manual.
All brand names used in this manual are the registered trademarks of their respective owners. The use of
trademarks or other designations in this publication is for reference purposes only and does not constitute an
endorsement by the trademark holder.
1

UR5i v2
Used symbols
Danger – Information regarding user safety or potential damage to the router.
Attention – Problems that can arise in specific situations.
Information, notice – Useful tips or information of special interest.
GPL licence
Source codes under GPL licence are available free of charge by sending an email to:
[email protected].
Please see http://ep.advantech-bb.cz/devzone for more information.
Advantech Czech s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic
Document No. MAN-0016-EN, revision from May 19, 2020. Released in the Czech Republic.
i

UR5i v2
Contents
1 Safety Instructions 2
2 WEEE directive 3
3 Router Description 4
4 Contents of Package 5
5 Router Design 6
5.1 Router versions .................................... 6
5.2 Delivery identification ................................ 7
5.3 Order codes ...................................... 8
5.3.1 Order code structure ............................. 8
5.3.2 Order code examples ............................ 10
5.4 Basic dimensions of the router box ......................... 11
5.4.1 Plastic box .................................. 11
5.4.2 Metal box ................................... 11
5.5 Mounting recommendations ............................. 12
5.6 Removal from the DIN rail .............................. 14
5.7 Description of the front panel ............................ 15
5.7.1 Status indication ............................... 16
5.7.2 Power connector PWR ............................ 17
5.7.3 Antenna connector ANT, DIV and GPS (alternatively WIFI or WMBUS) . 18
5.7.4 SIM card reader ............................... 19
5.7.5 Ethernet Port ETH .............................. 20
5.7.6 PORT1 .................................... 21
5.7.7 PORT2 .................................... 21
5.7.8 USB Port ................................... 22
5.7.9 I/O Port .................................... 23
5.7.10 Reset ..................................... 25
6 First Use 26
6.1 Connecting the router before first use ....................... 26
6.2 Start .......................................... 27
6.3 Configuration ..................................... 27
6.3.1 Configuration over web browser ....................... 27
6.3.2 Configuration over SSH or Telnet ...................... 28
7 Technical Parameters 29
ii

UR5i v2
7.1 Basic parameters ................................... 29
7.2 Standards and regulations .............................. 30
7.3 Technical parameters of module .......................... 30
7.4 Technical parameters of GPS ............................ 31
7.5 Other Technical Parameters ............................. 32
7.6 Technical parameters of I/O port .......................... 32
7.7 Technical parameters of expansion port ...................... 32
8 Related Documents 33
9 Troubleshooting 34
9.1 FAQ .......................................... 34
10 Customers Support 37
10.1 Customer Support for NAM ............................. 37
10.2 Customer Support for Europe ............................ 37
10.3 Customer Support for Asia ............................. 37
iii

UR5i v2
List of Figures
1 Contents of package ................................. 5
2 Front panel UR5i v2B ................................ 6
3 Front panel UR5i v2F ................................ 6
4 Front panel UR5i v2B SL .............................. 6
5 Front panel UR5i v2F SL ............................... 6
6 Label examples .................................... 7
7 Basic dimensions of plastic box (bottom and front view) ............. 11
8 Basic dimensions of metal box (bottom and front view) .............. 11
9 Space around antennas (plastic) .......................... 12
10 Space around antennas (metal) ........................... 12
11 Cable routing (plastic) ................................ 13
12 Cable routing (metal) ................................. 13
13 Space in front of connectors (plastic) ........................ 13
14 Space in front of connectors (metal) ........................ 13
15 Default position of plastic and metal DIN rail clip ................. 14
16 Removal from the DIN rail .............................. 14
17 Front panel UR5i v2F ................................ 15
18 Power connector ................................... 17
19 Connection of power supply ............................. 17
20 Connecting of the antenna .............................. 18
21 Ejected SIM holder .................................. 19
22 Ethernet connector .................................. 20
23 Connection of ethernet cable ............................ 20
24 PORT1 cable connection .............................. 21
25 PORT2 cable connection .............................. 22
26 USB connector .................................... 22
27 I/O connector ..................................... 23
28 Connection of I/O cable ............................... 23
29 Connection of input and output to the router .................... 24
30 Router reset ...................................... 25
31 Router connection .................................. 26
32 Entering the IP address of the router ........................ 27
33 Entering login information .............................. 27
34 Router web interface ................................. 28
iv

UR5i v2
List of Tables
1 Router versions .................................... 6
2 Delivery identification ................................ 7
3 Type of port #1 .................................... 8
4 Type of port #2 .................................... 9
5 Type of router box .................................. 9
6 Type of power supply ................................. 9
7 Specific variation ................................... 10
8 Order code examples ................................ 10
9 Front panel description ................................ 15
10 Status indication ................................... 16
11 Connection of power connector ........................... 17
12 Connection of Ethernet connector .......................... 20
13 Connection of USB connector ............................ 22
14 Connection of I/O port ................................ 23
15 Description of reset and restart router ....................... 25
16 Basic parameters ................................... 29
17 Standards and regulations .............................. 30
18 Technical parameters of module .......................... 30
19 Technical parameters of GPS ............................ 31
20 Other technical parameters ............................. 32
21 Technical parameters of I/O port .......................... 32
1

UR5i v2
1. Safety Instructions
Please, observe the following instructions:
•The router must be used in compliance with all applicable international and national laws
and in compliance with any special restrictions regulating the utilization of the router in
prescribed applications and environments.
•To prevent possible injury and damage to appliances and to ensure compliance with
all relevant provisions, use only the original accessories. Unauthorized modifications or
the use of unapproved accessories may result in damage to the router and / or a breach
of applicable regulations. Unauthorized modifications or use of unapproved accessories
may void the warranty.
•The router can not be opened.
•Turn off the router and disconnect it from power supply before handling the SIM card.
•Caution! The SIM card could be swallowed by small children.
•Input voltage must not exceed 36 V DC max.
•Do not expose the router to extreme ambient conditions. Protect the router against dust,
moisture and high temperature.
•Only routers with appropriate certification and labelling should be used in locations where
flammable and explosive materials are present, including gas stations, chemical plants,
or locations in which explosives are used. We remind users of the duty to observe the
restrictions concerning the utilization of radio devices at such places.
•Switch off the router when traveling by plane. Utilization of the router on a plane may
endanger the operation of the plane or interfere with the mobile telephone network, and
may be unlawful. Failure to observe these instructions may result in the suspension or
cancellation of telephone services for the respective client and / or may result in legal
sanctions.
•When using the router in close proximity to personal medical devices, such as cardiac
pacemakers or hearing aids, you must proceed with heightened caution.
•The router may cause interference when used in close proximity to TV sets, radio re-
ceivers or personal computers.
•It is recommended that you create an appropriate copy or backup of all important settings
that are stored in the memory of the device.
2

UR5i v2
2. Product Disposal Instructions
The WEEE (Waste Electrical and Electronic Equipment: 2012/19/EU) directive was in-
troduced to ensure that electrical/electronic products are recycled using the best available
recovery techniques in order to minimize impact on the environment. This product contains
high quality materials and components which can be recycled. At the end of it’s life this pro-
duct MUST NOT be mixed with other commercial waste for disposal. The device contains the
battery. Remove the battery from the device before disposal. The battery in the device needs
to be disposed apart accordingly. Check the terms and conditions of your supplier for disposal
information.
3

UR5i v2
3. Router Description
3G UMTS/HSPA router UR5i v2 is used to wirelessly connect various equipments and
devices via Ethernet interface 10/100 to the internet or intranet. Thanks to high data trans-
fer speed of up to 14,4 Mbps (download) and upload speed up to 5,76 Mbps it is an ideal
wireless solution for traffic and security camera systems, individual computers, LAN networks,
automatic teller machines (ATM) and other self-service terminals, etc.
As a standard, this exceptionally fast 3G router UR5i v2 is equipped with one Ethernet
10/100, one USB Host port, one binary input/output (I/O) port and one SIM card. To save
and backup communication data a version with two SIM cards is available. The wide range
of interface options of the 3G router further expands expansion Port1 and Port2, which are
selected by the customer. For Port1 are available: Ethernet port 10/100, serial interface ports
RS232, RS485, RS422, MBUS or inputs/outputs (I/O – CNT). Port2 may be equipped with
serial interfaces RS232, RS485, RS422, MBUS, wireless interfaces WIFI or WMBUS, SDH
expansion port or inputs/outputs (I/O – CNT). Both of ports can be fitted with internal switch
(exp. port SWITCH). This 3G wireless router is supplied either in a plastic or metal casing,
based on the requirements of the customer.
Configuration is done via web interface protected by password. The router supports cre-
ation of VPN tunnels using technologies IPsec, OpenVPN and L2TP to ensure safe communi-
cation. Web interface provides detail statistics about the 3G router activities, signal strength,
detailed log, etc. Cellular router supports functions: DHCP, NAT, NAT-T, DynDNS, NTP, VRRP,
control by SMS and many other function.
Other diagnostic functions ensuring continuous communication include automatic inspec-
tion of PPP connection offering an automatic restart feature – in case of connection losses, or
hardware watchdog which monitors the status of the router. With the help of a special window
(start up script window) you may insert Linux scripts for various actions. For some applications
the key option to create several different configurations for one 3G cellular router, the so-called
profiles (maximum of 4), and the option to switch between them (for example via SMS, binary
input status, etc.) is essential. Cellular routers may automatically upgrade configuration and
firmware from server. This allows mass reconfiguration of many routers in one time.
The router also supports additional software like R-SeeNet for permanent traffic monitoring
of routers or communication VPN server Digicluster.
Examples of possible applications
•mobile office
•fleet management
•security system
•telematic
•telemetric
•remote monitoring
•vending and dispatcher machines
4
