Advantech PCM-3335 User manual

PCM-3335
All-in-one 386SX with Flat
Panel/CRT PC/104 Module

FCC STATEMENT
THISDEVICECOMPLIESWITHPART15FCCRULES.OPERA-
TIONISSUBJECTTOTHEFOLLOWINGTWOCONDITIONS:
(1)THISDEVICEMAYNOTCAUSEHARMFULINTERFER-
ENCE.(2)THISDEVICEMUSTACCEPTANYINTERFERENCE
RECEIVEDINCLUDINGINTERFERENCETHATMAYCAUSE
UNDESIREDOPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO
COMPLY WITH THE LIMITS FOR A CLASS"A" DIGITAL
DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASON-
ABLE PROTECTION AGAINTST HARMFUL INTERFER-
ENCEWHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENER-
ATES,USES, AND CAN RADIATE RADIO FREQENCY
ENERGYAND, IFNOTINSTATLLEDANDUSED IN ACCOR-
DANCEWITH THE INSTRUCTION MANUAL, MAY CAUSE
HARMFUL INTERFERENCE TO RADIO COMMUNICA-
TIONS.OPERATION OF THIS EQUIPMENT IN A RESIDEN-
TIALAREA IS LIKELY TO CAUSE HARMFUL INTERFER-
ENCE IN WHICH CASE THE USER WILL BE REQUIRED
TOCORRECT THE INTERFERENCE AT HIS OWN EX-
PENSE.

Copyright Notice
This document is copyrighted, 1995, 1996, by AAEON Technology
Inc. All rights are reserved. AAEON Technology Inc. reserves the
right to make improvements to the products described in this
manual at any time without notice.
No part of this manual may be reproduced, copied, translated or
transmitted in any form or by any means without the prior written
permission of AAEON Technology Inc. Information provided in
this manual is intended to be accurate and reliable. However,
AAEON Technology Inc. assumes no responsibility for its use, nor
for any infringements upon the rights of third parties which may
result from its use.
Acknowledgements
ALI is a trademark of Acer Laboratories, Inc.
AMI is a trademark of American Megatrends, Inc.
CyrixisatrademarkofCyrixCorporation.
IBM, PC/AT, PS/2 and VGA are trademarks of International
Business Machines Corporation.
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows®and MS-DOS are registered trademarks of
Microsoft Corp.
PartNo. 2006335000 1st Edition
Printed in Taiwan October 1996

Packing list
Before you begin installing your card, please make sure that the
following materials have been shipped:
• 1 PCM-3335CPU card
• 1 5-pin PC-AT keyboard adapter
• 1 Hard disk drive(IDE) interface cable (40 pin)
• 1 Floppy disk drive interface cable (34 pin)
• 1 Flat panel cable (44 pin)
• PC/104 module mounting supports
• 1 SVGA adapter (16 pin)
• 1 parallel port adapter (26-pin)
• 2 Serial port adapters (10-pin)
• 1 utility disk with SVGA utility programs and drivers
• 1 VGA BIOS disk which contains the standard BIOS files for
both CRT and LCD displays
If any of these items are missing or damaged, contact your distribu-
tor or sales representative immediately.

Contents
1 GeneralInformation ......................................1
Introduction............................................................................ 2
Specifications.......................................................................... 3
2 Installation...................................................5
Jumpers and connectors........................................................ 6
BoardLayout .......................................................................... 7
Setting jumpers ...................................................................... 8
Safety precautions .................................................................. 9
IDE hard drive connections (HARD CON.) ...................... 10
Connecting the hard drive ...................................................... 10
Floppy drive connections (FLOPPY CON.) ...................... 12
Connecting the floppy drive................................................... 12
Parallel port (PRINTER PORT) ........................................ 13
Installing the retaining bracket .............................................. 13
Power supply connections (CN4, CN6)............................... 14
Power supply connector ......................................................... 14
Display connections (VGA CON., FLAT PANEL CON.).. 15
Keyboard connections (PS2 KB.) ....................................... 17
Serial ports (COM1, COM2) .............................................. 18
Reset switch (RST SW.) ......................................................... 18
HDD LED (HD-LED)............................................................ 19
Clear CMOS (CLEAR CMOS) ............................................. 19

3 AMIBIOSSetup ............................................ 21
General information ............................................................ 22
Starting AMIBIOS setup........................................................ 22
AMIBIOS main menu............................................................ 22
Standard Setup..................................................................... 23
Advanced Setup .................................................................... 24
Advanced Chipset Setup...................................................... 27
4 SVGASetup ................................................. 31
Simultaneous display mode ................................................. 32
Sleep mode ............................................................................ 32
Software support .................................................................. 33
Driver installation ................................................................ 34
Windows setup ....................................................................... 35
AutoCAD R12 ....................................................................... 38
Lotus 1-2-3 and Lotus Symphony.......................................... 40
VESA ..................................................................................... 42
Word....................................................................................... 43
WordPerfect............................................................................ 44
A InstallingPC/104Modules ........................... 47
Installing PC/104 modules................................................... 48
B LCDDisplayBIOSConfiguration.................... 51
Configuring various LCD display ...................................... 52

Chapter 1 General Information 1
1
General
Information
This chapter provides background
information for the PCM-3335.
Sections include:
• Card specifications
• Board layout
CHAPTER

2PCM-3335 User'sManual
Introduction
The PCM-3335 comes equipped with an embedded microcontroller
ALI M6117 which is Intel 386SX-40 compatible. In addition, it
comes with two serial ports (RS-232), one bi-directional printer port
supporting SPP, ECP and EPP modes, an IDE HDD interface and a
floppy disk controller. With its industrial grade reliability, the PCM-
3335 can operate continuously at temperatures up to 140º F (60º C).
The PCM-3335 is specially designed as a compact all-in-one CPU
card which incorporates a PC/104 connector into its design, making
non-passive backplane SBC applications possible. The numerous
features provide an ideal price/performance solution for high-end
commercial and industrial applications where stability and reliability
are essential.
The PCM-3335 features an SVGA interface which supports CRT and
Flat Panel (TFT, STN, Mono and EL displays), with 512 KB on-board
display memory.

Chapter 1 General Information 3
Specifications
CPU 40MHz 80386SX
Bus Interface PC/104 (ISA) bus
Data Bus 16-bit
Processing Ability 32-bit
RAM memory 2MB or 4MB
Shadow RAM Support for system and video BIOS up to 256KB in
32KB blocks
Display Memory 512KB DRAM chip on board
IDE HDD interface Supports up to two IDE (AT bus) HDDs
FDD interface Supports up to two FDDs
Parallel port Bi-directional parallel port (SPP/ECP/EPP modes)
Serial ports Two RS-232
(both use 16C550 UART with 16-byte FIFO)
Real time clock ALI M6117B internal RTC, lithium battery for up to
10 years data retention
PC/104 connector 104 pins for 16-bit bus. Supports pc/104 modules such as Flash/RAM/ROM disk modules and/or a
PCMCIA module.
DMA channels 7
Interrupt levels 15
Keyboard interface 5-pin mini-DIN keyboard connector.
Bus speed 8 MHz
Max. power req. +5V @ 1.5A (typical)
Power supply voltage +5V ±10%
Operating temp. 32 to 140º F (0 to 60º C)
Board size 3.55" (L) x 3.775" (W) (90 mm x 96 mm)
MTBF 55,532 hours @ 25º C
(Standard: MIL-HDBK-217F Notice 1)

4PCM-3335 User'sManual

Chapter 2 Installation 5
2
Installation
This chapter explains set up procedures
for the PCM-3335 hardware, including
instructions on setting jumpers and
connecting peripherals, switches and
indicators. Be sure to read all safety
precautions before you begin the installa-
tion procedure.
CHAPTER

6PCM-3335 User's Manual
Jumpers and connectors
Connectors on the board link it to external devices such as hard
disk drives, a keyboard, or floppy drives. In addition, the board
has a number of jumpers that allow you to configure your system
to suit your application.
The table below lists the function of each of the board jumpers
and connectors:
Jumpers and connectors
Number Function
HARDCON. HDDconnector
FLOPPYCON. FDDconnector
FLATPANELCON. LCDpanelconnector
PRINTERPORT Parallelport
COM2 COM2(RS-232)
COM1 COM1(RS-232)
VGACON. VGAconnector
CN2 PC/104(64-pin)
CN1 PC/104(40-pin)
PS2KB Externalkeyboardconnector
CN4,CN6 Powerconnector
HD-LED HDDLEDconnector
RSTSW. Resetswitchconnector
CLEARCMOS ClearCMOSconnector

Chapter 2 Installation 7
ALI
M6117B
COM2
PS2 KB.
COM1VGA CON.
CN4
CN6
PC/104 Interface
FLOPPY CON.
PRINTER PORT
FLAT PANEL CON. HARD CON.
CLEAR
CMOS
RST SW.
HD-LED
UMC
UM8663BF
BAT.
DRAM
DRAM
Board Layout
AMI
Flash
BIOS
PCM-3335

8PCM-3335 User's Manual
Setting jumpers
You configure your card to match the needs of your application by
setting jumpers. A jumper is the simplest kind of electric switch. It
consists of two metal pins and a small metal clip (often protected
by a plastic cover) that slides over the pins to connect them. To
“close” a jumper you connect the pins with the clip. To “open” a
jumper you remove the clip. Sometimes a jumper will have three
pins, labeled 1, 2 and 3. In this case you would connect either pins
1 and 2 or 2 and 3.
The jumper settings are schematically depicted in this manual as
follows:
A pair of needle-nose pliers may be helpful when working with
jumpers.
If you have any doubts about the best hardware configuration for
your application, contact your local distributor or sales represen-
tative before you make any changes.
Generally, you simply need a standard cable to make most
connections.
13
2
Open Closed Closed2-3
Open Closed Closed2-3
1 2 3

Chapter 2 Installation 9
Safety precautions
Warning! Always completely disconnect the power cord
from your chassis whenever you are working on
it. Do not make connections while the power is
on because sensitive electronic components can
be damaged by the sudden rush of power. Only
experienced electronics personnel should open
the PC chassis.
Caution! Always ground yourself to remove any static
charge before touching the CPU card. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis.

10 PCM-3335 User's Manual
IDE hard drive connections
(HARD CON.)
You can attach two Enhanced Integrated Device Electronics hard
disk drives to the PCM-3335's internal controller. The card comes
with a 40-pin flat cable.
Connecting the hard drive
Wire number 1 on the cable is red or blue, and the other wires are
gray.
1. Connect one end of the cable to the IDE connector. Make sure
that the red (or blue) wire corresponds to pin 1 on the connec-
tor, which is labeled on the board (on the right side).
2. Plug the other end of the cable to the Enhanced IDE hard
drive, with pin 1 on the cable corresponding to pin 1 on the
hard drive. (See your hard drive's documentation for the
location of the connector.)
Unlike floppy drives, you can make the connections with any of
the connectors on the cable. If you install two drives, you will
need to set one as the master and one as the slave. You do this
using jumpers on the drives. If you install just one drive, set it as
the master.

Chapter 2 Installation 11
Pin assignments
The following table lists the pin numbers and their respective
signals:
IDE Connector (HARD CON.)
Pin Signal Pin Signal
1 Reset 2 GND
3D7 4D8
5D6 6D9
7 D5 8 D10
9 D4 10 D11
11 D3 12 D12
13 D2 14 D13
15 D1 16 D14
17 D0 18 D15
19 GND 20 N.C.
21 N.C, 22 GND
23 IOW 24 GND
25 IOR 26 GND
27 IORDY 28 BALE
29 N.C. 30 GND
31 IRQ 32 -I/OCS16
33 A1 34 N.C.
35 A0 36 A2
37 CS0 38 CS1
39 -ACT 40 GND
41 VCC 42 VCC
43 GND 44 NC

12 PCM-3335 User's Manual
Floppy drive connections (FLOPPY CON.)
You can attach up to two floppy disks to the PCM-3335's on-board
controller. You can use any combination of 5¼" (360 KB and 1.2
MB) and/or 3½" (720 KB, 1.44 MB, and 2.88 MB) drives.
The PCM-3335 CPU card comes with a 34-pin daisy-chain drive
connector cable. On one end of the cable is a 34-pin flat-cable
connector. There are two sets of floppy disk drive connectors,
one in the middle, and one on the other end. Each set consists of
a 34-pin flat-cable connector (usually used for 3.5" drives) and a
printed-circuit board connector (usually used for 5.25" drives).
Connecting the floppy drive
1. Plug the 34-pin flat-cable connector into the floppy disk
connector.
2. Attach the appropriate connector on the other end of the cable
to the floppy drive(s). You can use only one connector in the
set. The set on the end (after the twist in the cable) connects
to the A: floppy. The set in the middle connects to the B:
floppy.
Pin assignments
The following table lists the pin assignments for the floppy disk
connector:
FLOPPY DISK Connector (FLOPPY CON.)
Pin Signal Pin Signal
1~33(odd)GND 2 Highdensity
4, 6 Unused 8 Index
10 MotorenableA 12 DriverselectB
14 DriverselectA 16 MotorenableB
18 Direction 20 Steppulse
22 Writedata 24 Writeenable
26 Track0 28 Writeprotect
30 Readdata 32 Selecthead
34 Diskchange

Chapter 2 Installation 13
Parallel port (PRINTER PORT)
Normally, the parallel port is used to connect the card to a printer.
The PCM-3335 includes an on-board parallel port, accessed
through PRINTER PORT, and a 26-pin flat-cable connector. The
CPU card comes with an adapter cable, which lets you use a
traditional DB-25 connector. The cable has a 26-pin connector on
one end and a DB-25 connector on the other, mounted on a
retaining bracket.
Installing the retaining bracket
The retaining bracket installs at an empty slot in your system's
chassis. It provides an external port that allows your parallel
peripheral to access to the card's parallel port connector.
1. Find an empty slot in your chassis.
2. Unscrew the plate that covers the end of the slot.
3. Screw in the bracket in place of the plate.
4. Next, attach the flat-cable connector to PRINTER PORT. Wire
1 of the cable is red or blue, and the other wires are gray. Make
sure that Wire 1 connects to Pin 1 of PRINTER PORT. Pin 1 is
on the right side of PRINTER PORT.
Pin assignments
PRINTER Connector (PRINTER PORT)
Pin Signal Pin Signal
1 Strobe 2 Data0
3 Data1 4 Data2
5 Data3 6 Data4
7 Data5 8 Data6
9 Data9 10 -Acknowledge
11 Busy 12 Paperempty
13 +Select 14 - Autofeed
15 -Error 16 - Init printer
17 -Selectinput 18~25 GND
