AEG BEWS18BLX180 User manual

BEWS18BLX180
Original instructions

2
2
Diameter: Ø80 mm Diameter: Ø41 mm
CUTTING FLANGE NUT
Important!
This appliance is not intended to be used or cleaned by
persons with reduced physical, sensory or mental capabilities,
or lack of experience or knowledge, unless they have been
given instructions concerning the safe use of the appliance by
a person legally responsible for their safety. They should be
supervised whilst using the appliance.
Children shall not use, clean or play with this appliance, which
when not in use should be secured out of their reach.
It is essential that you read the instructions in this manual
before assembling, operating and maintaining the product.
Subject to technical modifications.
1. Spindle lock button
2. Grinding wheel
3. Standard outer flange nut
4. Wheel guard lock lever
5. Half tool-less wheel guard
6. Auxiliary handle
7. On/off switch
8. Handle, insulated gripping surface
9. Battery port
10. Cutting guard
11. Cutting disc
12. Wrench
13. Dust cover
14. Cutting disc flange
15. Cutting flange nut
