MXS‐R30CC

ItemNo：L‐G030008

Specifications

WingSpan  75"(1915mm)

Length  67‐1/2"(1720mm)

WingArea 1023sqin(66sqdm)

FlyingWeight 9.7‐11lbs(4400g‐5000g)

Glow  91‐1.20(2C)1.10‐1.40(4C）

Gasoline 26‐35ccgasDLE30/35RAMLD35JC30Evo

Electric6‐8SLipo

Radio  4CH/5‐6servos



Description

CoveringMaterialChinakote;

CarbonFibre:  Wingtube;

Aluminumlandinggear,tailgear;

Fibreglassservoarms,hornandreinforcedU/Cmounting

Scalereaddeck

Canisterreadytunnel

Preplumbedtank

Adjustablepushrods

Ringedcowl

Predrilledhinges

RemoveableWings,Stabs



Colourschemes



 



www.aeroplusrc.com[email protected]

AeroPlusRCCopyright2013©AllRightsReserved



Unpacking



Carefullyunpackthemodelmakingsurethatifyouuseasharpknifetoopenbags,nottocutanycoveringonthe

model.Inspecteachitemtomakesurenotransitdamagehashappened.Ifyouarenothappywithanypartor

areunsurepleasecontacttheDealerthatyoupurchasedfrom.



Covering



Duetothemodelspendingtimeindifferentclimateszonesfromthefactoryonitswaytoyou,someofthe

coveringmayhavewrinkles.Wehighlyrecommendthatyoutaketimetore‐sealallcoveringedgeswithaniron

andtouseaheatguntoremoveanywrinklesandre‐tightenthecovering.Itisbesttodothisnowwhiletheplane

isnotassembled,remembertonotletanyheatgetnearanypartslikethecanopyorcowlasthismaycause

damage.



AssemblyTips



Wealsorecommendthatyougooveralltheaccessiblejointswithcyanoglue.Wickglueintoareasofhighstress

aroundtheU/Cplateandmotorbox.



UseNutlockonallmetaltometaljoints.Evenifyouareusingelectricwithlowvibrationlevelsitwillmakesure

thatthingsdonotdropoffyourairplane!!



www.aeroplusrc.com[email protected]

AeroPlusRCCopyright2013©AllRightsReserved



LandingGearAssembly



Tostopthefuselagegettingdamagedwhilethemodelisassembledwerecommendfittingthelandinggearfirst.



Parts

CFLandingGear

2xwheelpants

2xwheels

2xaxles

4xcollets

4xM3bolts



Pusheachaxlethroughthelargeholesandtightenupusing2spanners.



Placeacolletontheaxlefollowedbythewheel,thenanothercolletontheoutsideasperbelowdiagram.



Donottightenupthecolletsyetasthewheelneedstobefittedanequaldistancewithinthewheelpant.



TheU/Crakesforwardsousethecorrectwheelpantperside.Putnutlockontothe2xfactoryfittedblindnutsonthewheelpant



Fitovertheaxleandsecurewith2xcapheadbolts



Nowlineupthewheelinthecentreofthewheelpantopeningandtightenthecollets.Remembertousenutlockandtomakesurethewheelcan

movefreely.



www.aeroplusrc.com[email protected]

AeroPlusRCCopyright2013©AllRightsReserved



RearStab



Removethecoveringwheretheelevatorhornsfit,useeitherasolderingironorasharpknife.



Testfitthehorns



Theareaonthehornsthatgoesinsidetheelevatorneedstoberoughedupwithsandpaper.Thisallowsabettergluejoint.



Gluethehornsinplacewithepoxyglue.Putaboltthroughtheballjointholetomakesurethatthehornsstayinalignmentwhiledrying.



Beforefittingtheelevatorservofixanextensionleadsothatthewirecanberoutedthroughthecardboardtubewireholderinthefuselage.Onthe

servoleadjointaddaservoplugclip.

 



www.aeroplusrc.com[email protected]

AeroPlusRCCopyright2013©AllRightsReserved



Removethecoveringfortheelevatorservo



FittheElevatorServoservoandusingafinedrill,drillholesfortheservoscrews.Removetheservoanddropthincynointoall4holes.



Re‐fittheelevatorservoandsecureitinwithservoscrews.



CentretheservousingyourTX,andfitaservoarm.Useeitheranaftermarketarmorattachthearmsthatweresuppliedtoaservohead.Screwball

jointsontothepushrod(useplierstoholdpushrod)andboltinplacewithsuppliedbolts.Centreofservoshouldalignwithelevatorflattothestab.

 



Rudder



Removethecoveringwheretherudderhornspushthroughwitheitheraknifeorsolderingiron.



www.aeroplusrc.com[email protected]

AeroPlusRCCopyright2013©AllRightsReserved



Testfittherudderhorns



Sandtheareaonthehornthatfitsinsidetheruddersothegluebondsbetter



Gluetherudderhingesintoboththerudderandfinusingepoxyglue.Remembertousevaselineonthehingejoint.Whiledryingusetapetokeepit

inalignment.

 

Gluetherudderhornsthroughtherudderwithepoxy,wipeoffexcessgluewhileitiswet.Usetheballjointandboltwhilegluingtomaintain

alignment.Whilestillmovablemeasurethatthesameamountpushesouteachside.Careneedstobetakenhereotherwiseyourruddergeometry

willbeincorrect.



Assembletherudderservocontrolarmasbelow,drillholesforscrewsandusecynotostopthenutsfromcomingloose.

 

Fittherudderservoanddrillholesusingafinedrillfortheservoscrews,dropthincynointotheholestostrengthenthewood.

 

Usingservoscrewsfixtheservoinplace,notethesplineistowardsthefrontoftheplane



www.aeroplusrc.com[email protected]

AeroPlusRCCopyright2013©AllRightsReserved



Theclosedloopwiresareassembledintheplane;attachtherearballjointstotherudder.Dothistobothsides.



Fitthearmontotherudderservoandcrimpthewirestoatauttension

  



TailGear



Locateallpartsasinpicture,whenassemblingremembertonutlockallparts



AssembletheGearasperphoto



Attherearofthefuselageyouwillfindaplywoodarea,laytheCFgearonthisandmarkthe3holes.Takingcaretomakesureitisstraight.

Drilleachholewithafinedrillanddropthincynointotheholestostrengthenthewood.

 

ScrewtheCFgearonwiththethreesuppliedselftapingscrews.



Drillaholeinthebaseoftherudderfortheruddersteeringguide.



www.aeroplusrc.com[email protected]

AeroPlusRCCopyright2013©AllRightsReserved



Beforegluingwithcyano,placeitoverthethinrod.

 



AileronServos

Theaileronsonthewingsarepre‐glued.Checkeachonebygentlypullingtomakesurethattheyaresecure

Removethecoveringwheretheaileronhornsaregluedinplace.Useeitherasolderingironorasharpknife



Usingsandpaperroughtheareathatwillbegluedintotheaileron.



Gluebothhornsinwithepoxyglue,useaboltthroughthehornswhengluingtomakesurethealignmentiscorrect.



Fittheaileronservoanddrillfineholeswheretheservoscrewswillfit.Thenapplythincyanotostrengthentheholes.

 

Ifrequiredinstallaservoextensionleadontotheservo,remembertouseaservoplugclip.



Fittheservoandcentretheservoarm.

 



www.aeroplusrc.com[email protected]

AeroPlusRCCopyright2013©AllRightsReserved



Usingthepushrodsuppliedscrewballjointsontoeachend.Thecorrectlengthwillleavetheaileronlineduptotheinnerpartstillattachedtothe

wing.



Usingsuppliedboltsattachthepushrodatbothends.Checktoseeyouhavesufficientmovementoftheaileron.Ifnotadjust.

  

Carryoutthesameprocedureontheotherwing.



GasEngine

Fromthetemplatethatcamewiththeengine,usingthecrossaxisontheengineboxmarkthemountingholes.



Checkthediameteroftherequiredboltsanddrillaccordingly.



Mounttheenginewiththestandoffstothebulkhead.Remembertouselargewashersontheinsidetospreadtheloadanduseplentyofnutlock.

  

Exhaustoptions.Dependingontheenginemanyexhaustoptionsareavailable.Standardmuffler,PittsExhaustofcanisterwithheader.

  

Ifusingacanisterabracketisalreadyinsidethemodel.Usingsilicontubingitwillholdtheendofthecanister.

 



www.aeroplusrc.com[email protected]

AeroPlusRCCopyright2013©AllRightsReserved



Thefrontoutletofthecanisterwillpopoutofthebottomofthecowl



Cutouttheareafortheenginecylinderheadandtheexhaustoutletonapieceofthincardandtapethistothefuselageatoneend.



Removetheengineandfitthecowl,thenfoldthecardbackover.



Marktheareaandcutoutusingadremel.Ensurethatenoughaircangetoutofthecowl.Therationisusually,3timeoutto1in.

Fittheignitiononthesideofthemotorbox.UseVelcroandalsoastraptoensureitdoesnotcomeoffwithvibration.

Thecowlisfixedin4places,2atthetopand2atthebottom.Placemaskingtapeoverthebottom2andpiercewheretheblindnutholeis.



Refitthecowlanddrillwherethemarkedholewas.



Thefueltankispre‐installed.Attachpetrolproofpipeasperlabellingontank

 

Usethesuppliedpushrodwithaballjointtoconnecttothethrottlearmontheengine.Thenfindaconvenientplacetolocatethethrottleservo

usingthesuppliedmount.

 



www.aeroplusrc.com[email protected]

AeroPlusRCCopyright2013©AllRightsReserved



Installtheengineboxcoverplateonceallconnectionshavebeenmadefortheengine.



Electric

Assemblethesuppliedelectricmotorboxandbolttotheenginebulkhead.

 

Dependingonthelengthofyourmotoryoumayneedtousethesuppliedroundplywoodspacerstoachievethecorrectlengthforthemotor.



MounttheESCinairflowonthesideoftheelectricmotormount,usingavelcostrap.



Withtheremovalofthefueltankitleavesalargeareawherethebatteriescanbemounted.



Switch

Oneachsideofthefuselagenearthecanopyboltsareareasforswitchestobemounted.

 



RX

AconvienientplacetomounttheRXisjustinfrontoftherudderservo.Ensurethatitismountedonvelcoandstrappeddown.



www.aeroplusrc.com[email protected]



Canopy

Thecanopyisheldinplacewiththe2thumbscrews,ensurethesearetightbeforeflying



Set‐up

Wehighlyrecommendtheuseofbothdualratesandexponential.Thiswillallowthemodeltoflybothprecisionand3Dattheflickofaswitch.



LowRates ExponentialHighRate Exponential

Elevator15‐20deg 15‐20% 35‐45deg 45‐60%

Ailerons15‐20deg 15‐20% 35‐45deg 45‐60%

Rudder25‐30deg 15‐20% 35‐45deg 45‐60%



Fortestflightsalwaysuselowrates,rememberthat+and–exponentialisdifferentpermanufacturer,checkyourTXmanual.

Alwayschecktherangeonyourmodelbeforethemaidenflight.Carryoutashortflightthengoovereverythingtomakesurenothinghascomeloose.



CGLocation
