AETEK H21-082-30-150 User manual

Industrial 8xFE PoE + 2xCombo GbE
EXPoE Switch
100-240VAC
+ -
EX Mode
OFF
GbE
GbE
LINK/ACT
ON
9
10
LINK/ACT
13 5 7 9 9
24 6 8 10 10
PoE
LINK/ACT
PWR
VAC 100~240 power input
1. Install the PoE switch in a ventilated and dry place that is free of electromagnetic source, vibration, moisture, and dust.
2. Make sure the ventilation openings on the switch are not blocked.
3. Use CAT5 or 5e UTP/STP cables.
4. AC input (100~240V/AC, 50~60Hz)
IMPORTANT:
INTRODUCTION
LED DEFINITIONS
CONNECTION
* 1x PoE switch * 1x Quick Installation Guide
* 1x T25 L-wrench
PACKAGE CONTENTS
Power Orange ON Power is on and normal.
Orange Off Power is off.
Link/Act Green ON Ethernet port is connected.
Green Off No connection.
Green blinking Data is being transmitted or received.
GbE Green ON Link speed at 1000Mbps.
Green Off Link speed at 10/100Mbps.
PoE Orange ON Port is linked to a powered device.
Orange Off No device is connected.
Orange blinking Abnormal power supply is detected.
H21-082-30-150
H21-082-30-250
Quick Installation Guide
The H21-082-30-150/250 is an 8 port 10/100BaseT PoE switch capable of feeding 15.4/30W (54V max. per port)
power to Power over Ethernet (PoE) devices. It comes with another 2x GbE combo ports.
Outdoor Unmanaged PoE Switch
Port LED1 Port LED2
EX MODE DIP SWITCH
EX ON Ports 1 & 2 up to 250m PoE distance. When enabled, each port is isolated, but is linked to the uplink ports.
EX OFF Normal communication for ports 1 ~ 5.
* EX mode in 802.3af (15.4W): camera connection up to 250m@10Mbps via EXPoE ports.
* EX mode in 802.3at (30W): camera connection up to 200m@10Mbps via EXPoE ports.

AETEK INC.
3F, No.192, Lien-Cheng Rd., Chung-Ho, New Taipei City, 235, Taiwan, R.O.C.
|T:[phone]|W:www.aetektec.com|E:[email protected]
All specications are subject to change without noice.
Copyright © 2017 AETEK INC. All rights reserved.
Use the included M10 hex socket screws to secure the power box to a pole-mount or corner mount bracket.
3/4” conduit
M10
Outdoor PoE switch:
H21-082-30-150
The mounting hole denition is illustrated below. The same mounting hole pattern apply to all pole-mount and corner-
mount brackets.
INSTALLATION
IMPORTANT:
1. If the need should arise for connecting two outdoor switches, use the uplink ports #4 or #5. If you use PoE ports for
cross-switch connections, the 12KV surge protection will not apply.
2. The cabinet must be grounded using a ground wire between the
ground screw and earth ground.
*Effect factors
1.Must connect af PoE PD
2.Poor cabling quality with insufcient copper
3.IP camera’s networking design could not support 10Mbps@250m transmission
**Suggestion
Checking the interoperability reaching 10Mbps @ 250m before physical deployment
Adjust to “EX Mode OFF” reaching 10/100M bps @ 100m if “EX Mode ON” is fail.
