AG Neovo TS-17R User manual

P/C: TS17R0 Version 4.0, 20070731
Panel Panel Type TFT LCD
Panel Size 17.0" (432mm)
Max. Resolution SXGA 1280 x 1024
Pixel Pitch 0.264mm
Brightness 300cd/m2(Typical)
Contrast Ratio 500:1 (Typical)
Surface Treatments Hard Coating (3H), Anti-glare
Treatment
Viewing Angle (H/V) 140°/130°(Typical)
Display Color 16.7M
Response Time 4ms (GTG)
Frequency (H/V) H: 31kHz – 82kHz
V: 50Hz – 75Hz
Max. Pixel Clock 135 MHz
Life Time 50,000hrs (Typical)
Input Touch Interface 8-Pin Mini Dim
Analog 15-Pin D-Sub
Digital 29-Pin DVI-D
Connector Power DC+12V
Technology 5-wire Resistive
Optical Transmission >80%
Positional Accuracy <1% within precision area
Active Force 300 g
Panel Interface RS-232, available in TS-17R(RS-232)
Or USB, available in TS-17R(USB)
Touch
Screen
Glass Thickness 2.1mm
Life Performance 35 million hits (finger)
100,000 characters input (pen)
Operational Temp. -20ºC to 70ºC
Storage Temp. -40ºC to 80ºC
Operating:<90%RH from –20ºC to
60ºC
Operating: 133.8 g/m3, if >60ºC
Storage:<95%RH from -20ºC to 60ºC
Humidity
Storage: 142.9g/m3, if>60ºC
Tilt Tilt +5°
Mounting VESA FPMPMI Yes (100mm)
Regulation
Approval
Certifications &
Compliance
UL/CUL, TUV/ GS, CB, FCC, CE, WEEE,
RoHS, Energy Star
VESA DDC /CI, DPMS, DDC2B
Power Power AC 100 - 240V, 50 - 60Hz
Consumption <35W (On)
<2W (Stand-by)
<1W (Off)
Dimensions Net (W x H x D) 436 X 427 X 200 mm
(17.2" x 16.8"x 7.9")
Packing (W x H x D) 525 x 550 x 175 mm
(20.7" x 21.7" x 6.9")
Weight Net Weight 7.5 Kg (16.52lbs)
Gross Weight 10Kg (22 lb)
Packing 1 Pallet 36 Cartons
20’ Container 360 Sets
40’ Container 720 Sets
All specifications are subject to change without prior notice
f17” LCD DISPLAY WITH TOUCH PANEL TECHNOLOGY fSPECIFICATION
TS-17R
fFEATURES
 Elegant and slim dual tone design
 Sharp 500 contrast ratio
 High 300 brightness for more vibrant and
colorful images
 5-wire Resistive touch technology
 Scratch resistant touch panel
 35 million finger-touch hits and 100,000
characters input stability
 Auto-adjustment for optimal setting
 User-friendly OSD with lockable key function
 Kensingtonsecurity socket
 VESA compliant for easy wall or arm
configuration
