DSO3062A
DSO3102A
DSO3152A
DSO3202A
N2860A
N2861A
N2862A
N2863A
10073C
N2774A
N2775A
10076A
N2771A
3000 Series Economy Oscilloscopes
Oscilloscopes
English URL www.agilent.com/find/products
Full-featured Oscilloscopes for the Smallest
Budgets
Agilent’s 3000 Series oscilloscopes give you an affordable way to see
what’s happening in your designs. Developed with the features you
need to make your job easier.
Need flexibility? Choose from four models with bandwidths
ranging from 60 MHz to 200 MHz. To give you the debugging power
you need, each oscilloscope comes standard with advanced features
including sophisticated triggering, automatic measurements, digital
filtering, sequence mode acquisition, math functions (including
FFTs), stored setups and waveforms, mask testing and much more.
See your Signals More Clearly
All 3000 Series models have color displays to allow you to quickly
identify your signals, and the large size – 15 cm (5.9 in) with 320 x
240 resolution – makes it easier for you to see more information.
The 3000 Series’ delayed sweep also lets you see more details
in your design. You can view a long record, then window in on the
section of the signal of interest.
All the Features you Need
All 3000 Series scopes include the standard features you need to get
your job done easier and faster:
Autoscale – Autoscale lets you quickly display any active signals,
automatically setting the vertical, horizontal and trigger controls
for the best signal display.
Advanced Triggering – Includes edge, pulse width and line-selectable
video, to help you isolate the signals you want to see.
Waveform Math with FFTs – Analysis functions include addition, sub-
traction, multiplication, and Fast Fourier Transforms with four
windows (Hanning, Hamming, Blackman-Harris and rectangular).
Auto Calibration – Automatically calibrates the oscilloscope’s vertical
and horizontal systems.
Multi-language Interface – Operate the oscilloscope in the language of
your choice. Language support includes simplified and traditional
Chinese, Japanese, Korean, French, German, Italian, Portuguese,
Russian, Spanish and English.
Digital Filtering – Digital filtering selections include low pass, high
pass, band pass, and band reject filters. Limits are selectable
between 1 kHz and the bandwidth of your oscilloscope model.
Ten Waveform and Setup Memories – Store waveforms or commonly
used setups for future reference and use.
Mask Testing – Automatically compares incoming signals with a pre-
defined mask, clearly highlighting signal changes.
• Large 15-cm (5.9-in) color display
• Up to 1 GSa/s sample rate and 4 k points of memory
• Advanced triggering including edge, pulse-width, and
line-selectable video
• 20 automatic measurements and 4 math functions with FFTs
• USB connectivity and Scope Connect software, standard
• GPIB and RS232 connectivity available
• Mask test standard
Sequence Mode – Frame an area of interest on your signal and record
up to 1,000 frames for playback.
3-year Warranty – All 3000 Series scopes include a full 1-year
warranty with optional 3-year warranty coverage.
Easy to Set Up and Use – Dedicated, color-coded knobs for vertical
sensitivity, offset, and time base settings make it easy to set up and
use. Front-panel keys for triggering functions are also grouped to
make your job easier.
Specifications
Bandwidth
DSO3062A: 60 MHz
DSO3102A: 100 MHz
DSO3152A: 150 MHz
DSO3202A: 200 MHz
Real Time Sample Rate
2 channels interleaved: 1 GSa/s
Each channel 500 MSa/s
Channels
2
Display
Color, 320 x 240 1/4 VGA LCD; H: 88 mm, W: 116 mm
Memory
4 kpoints per channel
Vertical Resolution
8 bits
Vertical Sensitivity
2 mV/div to 5 V/div
DC Gain Accuracy
±3% for 10 mV/div to 5 V/div; ±4% for 2 mV/div to 5 mV/div
Vertical Zoom
Vertical expand
Maximum Input Voltage
300 Vrms CAT II; derated at 20 dB/decade above 100 kHz to 13 V p-p AC at
3 MHz and above
Time Base Range
2 ns/div to 50 s/div (5 ns/div to 50 s/div in DSO 3062A)
BW Limit
~ 20 MHz
Input Coupling
DC, AC, Ground
Input Impedance
1 MΩ: 13 pF
Time Base Accuracy
100 ppm
Acquisition Modes
Normal: Displays sampled data directly to the screen in real time
Averaging: Selectable from 2, 4, 8, 16, 32, 64, 128 or 256
Peak detect: Captures high-frequency glitches as narrow as 10 ns when
viewing signals at slower sweep speeds (slower than 5 µs/div)
Sweep Modes
Auto, Normal
Trigger Coupling
AC, DC, LF reject, HF reject
Trigger Modes
Force: Triggers immediately when front-panel button is pushed
Edge: Triggers on the positive or negative slope on any channel
Video: Triggers on one of three standard television waveforms: NTSC, PAL,
SECAM
Pulse triggering: Triggers on a pulse width greater than, equal to, or less
than a specified time limit, with time limits ranging from 20 ns to 10 s
Trigger Source
Ch 1, 2, Ext, Ext/5, Line (edge mode only)
Cursors
Modes: Manual, auto, track
Type: Time and voltage
Measurements: ΔT, ΔV, frequency
Automatic Measurements
20 plus 5-digit hardware counter
Voltage: Peak-to-peak, maximum, minimum, average, amplitude, top,
base, Vrms, overshoot, preshoot
Time: Frequency, period, +width, –width, +duty cycle, –duty cycle, rise
time, fall time, delay, phase
Math Functions
Add, subtract, multiply, FFT
