Agilent Technologies 6010A User manual

This series of dc power supplies
take the place of multiple power
supplies on your test bench by
providing maximum power at
a variety of operating points.
They have ten-turn front panel
pots to allow precise local control.
These power supplies also may be
connected in auto-parallel or auto-
series with their corresponding
GPIB unit (6030 Series), as part
of a test system.
SupplementalCharacteristics
forallmodelnumbers
RemoteSensing: Up to 2 V drop in each
lead. Voltage regulation specification met
with up to 0.5 V drop, but degrades for
greater drops.
Modulation: (analog programming of
output voltage and current)
Inputsignal: 0 to 5 V or 0 to 4 k Ohms
RegulatoryCompliance: Certified to
CSA556B; conforms to IEC 61010-1.
Size: 425.5 mm W x 132.6 mm H x 516.4 mm D
(16.75 in x 5.25 in x 20.33 in).
See page 99 for more details
Warranty: One year
OrderingInformation
Opt120 104 to 127 Vac, 47 to 63 Hz
Opt220 191 to 233 Vac, 48 to 63 Hz
Opt240 209 to 250 Vac, 48 to 63 Hz
* Opt908 Rack-mount Kit (p/n 5062-3977)
* Opt909 Rack-mount Kit with Handles.
(p/n 5062-3983)
Opt0L2 Extra Standard Documentation Package
Opt0B0 No documentation package
OptJ01 Stabilization for loads up to 10 Henries
Agilent Performance dc Power Supplies speed and accuracy for test optimization
Specifications
(at 0˚to 55˚C unless
otherwise specified)
Power Products Catalog 2002-2003 For more detailed specifications see the product manual at www.agilent.com/find/power
52
Save rack space by using fewer outputs
Reduce cost by using fewer power supplies
Control with external voltage
6010A, 6011A, 6012B, 6015A
Single-Output, Autoranging:
200 W and 1000 W
6010A 6011A 6012B 6015A
Number of outputs 111 1
GPIB No No No No
Output ratings
Voltage 0 to 200 V 0 to 20 V 0 to 60 V 0 to 500 V
Current 0 to 17 A 0 to 120 A 0 to 50 A 0 to 5 A
Maximum power
Watts 1,200 W 1,064 W 1,200 W 1,050 W
Autoranging output V1, I1200 V, 5 A 20 V, 50 A 60 V, 17.5 A 500 V, 2 A
V2, I2120 V, 10 A 14 V, 76 A 40 V, 30 A 350 V, 3 A
V3, I360 V, 17 A 7 V, 120 A 20 V, 50 A 200 V, 5 A
Ripple and noise, 20 Hz to 20 MHz
Voltage rms 22 mV 8 mV 8 mV 50 mV
p-p 50 mV 50 mV 40 mV 160 mV
Current rms 15 mA 120 mA 25 mA 50 mA
Load regulation
Voltage 0.01%+ 5 mV 3 mV 5 mV 13 mV
Current 0.01%+ 10 mA 15 mA 10 mA 35 mA
Transient response time
10% step change
Time 2 ms 2 ms 2 ms 5 ms
Level 150 mV 100 mV 100 mV 200 mV
Supplemental Characteristics (Non-warranted characteristics determined by design that are
useful in applying the product)
Programming resolution
Voltage 50 mV 5 mV 15 mV 125 mV
Current 4.25 mA 30 mA 12.5 mA 1.25 mA
dc floating voltage ±550 V ±240 V ±240 V ±550 V
either terminal can be grounded
or floated from chassis ground
ac input current 100 Vac 24 A 24 A 24 A 24 A
120 Vac 24 A 24 A 24 A 24 A
220 Vac 15 A 15 A 15 A 15 A
240 Vac 14 A 14 A 14 A 14 A
Weight Net 16.3 kg (36 lb) 17.2 kg (38 lb) 16.3 kg (36 lb) 16.3 kg (36 lb)
Shipping 21.8 kg (48 lb) 22.7 kg (50 lb) 21.8 kg (48 lb) 21.8 kg (48 lb)
Alinecordoptionmustbe specified.
Seepages 93-98 fororderinginformation.
*Support rails required
Accessories
1494-0060 Rack Slide Kit
E3663AC Support rails for
Agilent rack cabinets
V1
I1 I2 I3
Volts
P1
P2 P3
Amps
V2
V3
AutorangingOutput:

This series of 200 watt and 1000
watt dc power supplies take the
place of multiple power supplies
in your test system by providing
maximum power at a variety of
operating points.
Industry standard SCPI commands
and VXIPlug&Play drivers make
system integration easy. Using the
serial link, up to 16 power supplies
can be connected through one
GPIB address. These power supplies
have excellent electrical efficiency,
making them a good choice for
large systems.
Agilent Performance dc Power Supplies speed and accuracy for test optimization
Specifications
(at 0˚to 55˚C unless
otherwise specified)
6030A 6031A 6032A 6033A 6035A 6038A
Power Products Catalog 2002-2003 For more detailed specifications see the product manual at www.agilent.com/find/power
53
Save rack space by using fewer outputs
Reduce cost by using fewer power supplies
6030A, 6031A,
6032A, 6035A
6033A, 6038A
Single-Output, Autoranging:
200 W and 1000 W GPIB
Number of outputs 111111
GPIB Yes Yes Yes Yes Yes Yes
Output ratings
Output Voltage 0 to 200 V 0 to 20 V 0 to 60 V 0 to 20 V 0 to 500 V 0 to 60 V
Output Current 0 to 17 A 0 to 120 A 0 to 50 A 0 to 30 A 0 to 5 A 0 to 10 A
Maximum power watts 1,200 W 1,064 W 1,200 W 242 W 1,050 W 240 W
Autoranging output V1, I1200 V, 5 A 20 V, 50 A 60 V, 17.5 A 20 V, 10 A 500 V, 2 A 60 V, 3.3 A
V2, I2120 V, 10 A 14 V, 76 A 40 V, 30 A 14 V, 17.2 A 350 V, 3 A 40 V, 6 A
V3, I360 V, 17 A 7 V, 120 A 20 V, 50 A 6.7 V, 30 A 200 V, 5 A 20 V, 10 A
Programming accuracy Voltage 0.035% 0.035% 0.035% 0.035% 0.25% 0.035%
at 25°C ±5°C +145 mV +15 mV +40 mV +9 mV +400 mV +40 mV
Current 0.2% 0.25% 0.2% 0.15% 0.3% 0.09%
+25 mA +250 mA +85 mA +20 mA +63 mA +10 mA
Ripple and noise Voltage rms 22 mV 8 mV 8 mV 3 mV 50 mV 3 mV
20 Hz to 20 MHz p-p 50 mV 50 mV 40 mV 30 mV 160 mV 30 mV
Current rms 15 mA 120 mA 25 mA 30 mA 50 mA 5 mA
Readback accuracy Voltage 0.08% 0.08% 0.08% 0.07% 0.5% 0.07%
at 25°C ±5°C +80 mV +7 mV +20 mV +6 mV +300 mV +50 mV
Current 0.36% 0.4% 0.36% 0.3% 0.5% 0.2%
+15 mA +100 mA +35 mA +25 mA +50 mA +11 mA
Load regulation
Voltage 0.01%+ 5 mV 3 mV 5 mV 2 mV 13 mV 3 mV
Current 0.01%+ 10 mA 15 mA 10 mA 9 mA 35 mA 5 mA
Line regulation
Voltage 0.01%+ 5 mV 2 mV 3 mV 1 mV 13 mV 2 mV
Current 0.01%+ 5 mA 25 mA 10 mA 6 mA 18 mA 2 mA
Transient response time Time 2 ms 2 ms 2 ms 1 ms 5 ms 1 ms
10% step change Level 150 mV 100 mV 100 mV 50 mV 200 mV 7 5 mV
V1
I1 I2 I3
Volts
P1
P2 P3
Amps
V2
V3
AutorangingOutput:

54
SupplementalCharacteristics
forallmodelnumbers
RemoteSensing: Up to 2 V drop in each
lead. Voltage regulation specification met
with up to 0.5 V drop, but degrades for
greater drops.
Modulation: (analog programming of
output voltage and current)
Inputsignal: 0 to 5 V or 0 to 4 k Ohms
Size: 6030A–32A, 6035A:
425.5 mm W x 132.6 mm H x 503.7 mm D
(16.75 in x 5.25 in x 19.83 in).
6033A, 6038A:
212.3 mm W x 177.0 mm H x 516.4 mm D
(8.36 in x 6.97 in x 17.87 in).
See page 99 for more details.
Warranty: One year
OrderingInformation
Opt001 Front panel has only line switch,
line indicator, and OVP adjust
(6030A–33A and 6038A only)
Opt100 87 to 106 Vac, 48 to 63 Hz
(power supply output is derated to 75%)
Opt120 104 to 127 Vac, 47 to 63 Hz
Opt220 191 to 233 Vac, 48 to 63 Hz
Opt240 209 to 250 Vac, 48 to 63 Hz
Opt800 Rack-mount Kit for Two
Half-rack Units Side by Side.
Lock link Kit p/n 5061-9694 and
7 in Rack adapter Kit 5063-9215
* Opt908 Rack-mount Kit for a Single
Half-rack Unit 6033A and 6038A
(with blank filler panel); p/n 5062-3960,
6030A–32A and 6035A; p/n 5062-3977
* Opt909 Rack-mount Kit with Handles.
For 6030A–32A, 6035A; p/n 5062-3983
Autoranging: 200 W and 1000 W GPIB (Continued)
Power Products Catalog 2002-2003 For more detailed specifications see the product manual at www.agilent.com/find/power
Agilent Performance dc Power Supplies speed and accuracy for test optimization
Specifications
(at 0˚to 55˚C unless
otherwise specified)
6030A 6031A 6032A 6033A 6035A 6038A
SupplementalCharacteristics (Non-warrantedcharacteristicsdeterminedbydesignand
usefulinapplyingtheproduct)
Programming resolution Voltage 50 mV 5 mV 15 mV 5 mV 125 mV 1 5 mV
Current 4.25 mA 30 mA 12.5 mA 7.5 mA 1.25 mA 2.5 mA
dc floating voltage ±550 V ±240 V ±240 V ±240 V ±550 V ±240 V
either terminal can be grounded
or floated from chassis ground
ac input current 100 Vac 24 A 24 A 24 A 6 A 24 A 6 A
120 Vac 24 A 24 A 24 A 6.5 A 24 A 6.5 A
220 Vac 15 A 15 A 15 A 3.8 A 15 A 3.8 A
240 Vac 14 A 14 A 14 A 3.6 A 14 A 3.6 A
Weight Net 16.3 kg 17.2 kg 16.3 kg 9.6 kg 16.3 kg 9.6 kg
(36 lb) (38 lb) (36 lb) (21 lb) (36 lb) (21 lb)
Shipping 21.8 kg 22.7 kg 21.8 kg 11.4 kg 21.8 kg 11.4 kg
(48 lb) (50 lb) (48 lb) (25 lb) (48 lb) (25 lb)
Opt0L2 Extra Standard
Documentation Package
Opt0B3 Service Manual
Opt0B0 No documentation package
OptJ01 Stabilization for loads up to
10 Henries (not available on 6033A)
Aline cord mustbespecified for 6030A-32A,
6035A. Seepages 93-98 forordering
information.
*Support rails required
Accessories
5080-2148 Serial Link Cable, 2 m (6.6 ft)
1494-0060 Rack Slide Kit
E3663AC Support rails for Agilent rack
cabinets

To see a copy of the user’s guide,
please visit our Web site at
www.agilent.com/find/manuals
