Agilent Technologies G8610 Series User manual

Vacuum Products Division
Ion Source
Replacement
for Agilent Technologies Helium
Leak Detection (G8610, G8611,
or G8612)
or for S Series Leak Detector
Part Number 699910005
Rev. B
October 2017
Field Installation Instructions

acuum Products Division
Manual 699910005, Hot Ion Source Replacement Page ii
Ion Source Replacement for Agilent Helium Leak Detector
© Agilent Technologies, Inc. 2017

acuum Products Division
Manual 699910005, Hot Ion Source Replacement Page iii
Warranty
WarrantyWarranty
Warranty
Products manufactured by Seller are warranted against defects in materials and workmanship for
twelve (12) months from date of shipment thereof to Customer, and Seller’s liability under valid
warranty claims is limited, at the option of Seller, to repair, to replace, or refund of an equitable
portion of the purchase price of the Product. Items expendable in normal use are not covered by
this warranty. All warranty replacement or repair of parts shall be limited to equipment
malfunctions which, in the sole opinion of Seller, are due or traceable to defects in original
materials or workmanship. All obligations of Seller under this warranty shall cease in the event of
abuse, accident, alteration, misuse, or neglect of the equipment. In-warranty repaired or replaced
parts are warranted only for the remaining unexpired portion of the original warranty period
applicable to the repaired or replaced parts. After expiration of the applicable warranty period,
Customer shall be charged at the then current prices for parts, labor, and transportation.
Reasonable care must be used to avoid hazards. Seller expressly disclaims responsibility for loss
or damage caused by use of its Products other than in accordance with proper operating
procedures. Except as stated herein, Seller makes no warranty, express or implied (either in fact or
by operation of law), statutory or otherwise; and, except as stated herein, Seller shall have no
liability under any warranty, express or implied (either in fact or by operation of law), statutory or
otherwise. Statements made by any person, including representatives of Seller, which are
inconsistent or in conflict with the terms of this warranty shall not be binding upon Seller unless
reduced to writing and approved by an officer of Seller.
Warranty Replacement and Adjustment
Warranty Replacement and AdjustmentWarranty Replacement and Adjustment
Warranty Replacement and Adjustment
All claims under warranty must be made promptly after occurrence of circumstances giving rise
thereto, and must be received within the applicable warranty period by Seller or its authorized
representative. Such claims should include the Product serial number, the date of shipment, and a
full description of the circumstances giving rise to the claim. Before any Products are returned for
repair and/or adjustment, written authorization from Seller or its authorized representative for the
return and instructions as to how and where these Products should be returned must be obtained.
Any Product returned to Seller for examination shall be prepaid via the means of transportation
indicated as acceptable by Seller. Seller reserves the right to reject any warranty claim not promptly
reported and any warranty claim on any item that has been altered or has been returned by non-
acceptable means of transportation. When any Product is returned for examination and inspection,
or for any other reason, Customer shall be responsible for all damage resulting from improper
packing or handling, and for loss in transit, notwithstanding any defect or non-conformity in the
Product. In all cases, Seller has the sole responsibility for determining the cause and nature of
failure, and Seller’s determination with regard thereto shall be final. If it is found that Seller’s
Product has been returned without cause and is still serviceable, Customer will be notified and the
Product returned at Customer’s expense; in addition, a charge for testing and examination may be
made on Products so returned.

acuum Products Division
Manual 699910005, Hot Ion Source Replacement Page iv
This page intentionally left blank

acuum Products Division
Manual 699910005, Hot Ion Source Replacement Page v
Table of Contents
Table of ContentsTable of Contents
Table of Contents
Warranty ...................................................................................................................................................................................................... iii
Warranty Replacement and Adjustment ............................................................................................................................................... iii
1 Preface .............................................................................................................................................................................................. 1
1.1 Documentation Standards .................................................................................................................................................... 1
1.1.1 Symbols ............................................................................................................................................................................. 1
1.2 Hazard and Safety Information ............................................................................................................................................ 2
1.2.1 Solvents ............................................................................................................................................................................. 3
1.2.2 acuum Equipment and Cleanliness ........................................................................................................................... 3
1.2.3 O-ring Care ......................................................................................................................................................................... 4
1.2.4 Metal Seal Care ................................................................................................................................................................ 4
1.2.5 Spectrometer .................................................................................................................................................................... 5
2 Filament Installation: Agilent Helium Leak Detector Model G8610, G8611, or G8612 ...................................................... 6
2.1 Equipment Required for G8610, G8611, or G8612 ........................................................................................................... 6
2.2 Installation Procedure for G8610, G8611, or G8612 ........................................................................................................ 6
3 Filament Installation: Agilent Legacy S Series Helium Leak Detector .............................................................................. 16
3.1 Equipment Required for Agilent Legacy S Series Helium Leak Detector ................................................................ 16
3.2 Installation Procedure for Agilent Legacy S Series Helium Leak Detector ............................................................. 16
Table of Figures
Table of FiguresTable of Figures
Table of Figures
Figure 2-1. Covers ...................................................................................................................................................................................... 6
Figure 2-2. Spectrometer access ........................................................................................................................................................... 7
Figure 2-3. Spectrometer exploded view .............................................................................................................................................. 8
Figure 2-4. Ion support assembly ......................................................................................................................................................... 10
Figure 2-5. M4 support screws ............................................................................................................................................................. 11
Figure 2-6. Collimator wire connection ............................................................................................................................................... 12
Figure 2-7. Ion chamber and extractor plate ...................................................................................................................................... 12
Figure 2-8. Filament positioning ........................................................................................................................................................... 13
Figure 2-9. Filament alignment ............................................................................................................................................................. 13
Figure 2-10. Spectrometer alignment .................................................................................................................................................. 14
Figure 2-11. Tightening spectrometer header screws ..................................................................................................................... 14
Figure 2-12. Ion source header pin schematic .................................................................................................................................. 15
Figure 2-13. Ion source header pin locations ..................................................................................................................................... 15
Figure 3-1. Rear screws .......................................................................................................................................................................... 16
Figure 3-2. Fan assembly ....................................................................................................................................................................... 17
Figure 3-3. Cable locations .................................................................................................................................................................... 17
Figure 3-4. Spectrometer access ......................................................................................................................................................... 18
Figure 3-5. Spectrometer exploded view ............................................................................................................................................ 19
Figure 3-6. Ion Support Assembly ........................................................................................................................................................ 21
Figure 3-7. M4 support screws ............................................................................................................................................................. 22
Figure 3-8. Collimator wire connection ............................................................................................................................................... 23
Figure 3-9. Ion chamber and extractor plate ...................................................................................................................................... 23
Figure 3-10. Filament positioning ......................................................................................................................................................... 24
Figure 3-11. Filament alignment ........................................................................................................................................................... 24
Figure 3-12. Spectrometer alignment .................................................................................................................................................. 25
Figure 3-13. Tightening spectrometer header screws ..................................................................................................................... 25
Figure 3-14. Ion source header pin schematic .................................................................................................................................. 26
Figure 3-15. Ion source header pin locations ..................................................................................................................................... 26
List of Tables
List of TablesList of Tables
List of Tables
Table 2-1. Equipment required for G8610, G8611, or G8612 models ............................................................................................. 6
Table 3-1. Equipment required for S models ................................................................................................................................... 16

acuum Products Division
Manual 699910005, Hot Ion Source Replacement Page 1
1
11
1 Preface
PrefacePreface
Preface
1.1 Documentation Standards
1.1.1 Symbols
This manual uses the following documentation standards:
NOTE
Notes contain important information.
CAUTION
Cautions appear before instructions, which if not followed,
could cause damage to the e uipment or data loss.
WARNING
Warnings appear for a particular procedure or practice which, if
not followed correctly, could lead to serious injury or death.

acuum Products Division
Manual 699910005, Hot Ion Source Replacement Page 2
1.2 Hazard and Safety Information
Operators and service personnel must be aware of all hazards associated with this equipment.
They must know how to recognize hazardous and potentially hazardous conditions, and know how
to avoid them. The consequences of unskilled, improper, or careless operation of the equipment
can be serious. Every operator or service person must read and thoroughly understand
operation/maintenance manuals and any additional information provided by Agilent. All warning
and cautions must be read carefully and strictly observed. Consult local, state, and national
agencies regarding specific requirements and regulations. Address any safety, operation, and/or
maintenance questions to your nearest Agilent office.
The common international symbols used in this manual, and on the equipment, are defined below:
OFF Supply
(Power)
Earth
(Ground)
Terminal
|
ON Supply
(Power)
Protective
Conductor
Terminal
Warning, Risk of
danger
Refer to
documentation
Frame or
Chassis
Terminal
Alternating
Current
Caution, Hot
Surface
Direct Current Caution, Risk
of Electrical
Shock
Do Not Place in
Trash

acuum Products Division
Manual 699910005, Hot Ion Source Replacement Page 3
1.2.1 Solvents
Warning The mechanical components of leak detectors may be cleaned with one
of the recommended solvents. When heated, sprayed, or exposed to
high-temperature e uipment, these solvents become flammable and
explosive, causing serious injury or death. Do not use these solvents near
a high-temperature source. Ventilate the working area with a blower and
work in a large, well-ventilated room.
Solvents are irritants, narcotics, depressants and/or carcinogens. Their
inhalation and/or ingestion may produce serious side effects. Prolonged
or continued contact with the skin results in absorption through the skin
and moderate toxicity. Always ensure that cleaning operations are
carried out in large, well ventilated rooms, and wear eye shields, gloves,
and protective clothing.
Due to the effective cleaning nature of VacuSolv solvent and its residue-
free properties, Agilent’ Component and Spectrometer Cleaning Kit (Part
Number 670029096), used in accordance with the kit instructions, is
recommended for cleaning spectrometer components. The kit can also
be used for fine cleaning of other parts in the leak detector’s vacuum
system such as valves and fittings. No rinsing steps or high-temperature
drying is re uired following cleaning with VacuSolv. Although appropriate
precautions are advised, VacuSolv is compatible with most materials and
does not contain toxic chemicals or CFCs (chlorofluorocarbons). Other
acceptable solvents are isopropyl alcohol (IPA) or Dow Corning® OS-20.
To clean the leak detector plastic top enclosure, the LCD display and
front panels, use only a soft cloth slightly dampened with water or a mild
soap.
Do NOT use excess water or cleaning solvents of any kind.
Avoid splashing any cleaning solvents into the unit through the
ventilation openings or Front Panel buttons. Wipe the surface with a dry
lint-free cloth.
1.2.2 acuum Equipment and Cleanliness
Caution
Wear non
-
powdered, ESD
-
safe Nitride or e uivalent g
loves to prevent
skin oils from getting on spectrometer internal components.

acuum Products Division
Manual 699910005, Hot Ion Source Replacement Page 4
1.2.3 O-ring Care
When removing, checking, or replacing O-rings, keep in mind the following:
NOTE
Agilent recommends replacing all O
-
rings durin
g routine maintenance or
during any maintenance procedure re uiring that O-rings be removed.
CAUTION Remove O-rings carefully with your fingers. Do not use metal tools for
this task; this prevents scratching of any sealing surfaces.
• Wipe all O-rings clean with a lint-free cloth before installation to
ensure that no foreign matter is present to impair the seal.
• Do not use grease or any other substance on O-rings that will
come in contact with the vacuum surfaces.
• Do not use alcohol, methanol or other solvents on O-rings. Doing
so causes deterioration and reduces their ability to hold a
vacuum.
• Agilent does not recommend the use of vacuum grease. If
applicable, apply a small amount of Apiezon® L grease and wipe
the O-rings shiny dry.
1.2.4 Metal Seal Care
CAUTION
Metal Seals must be replaced any time a spectrometer is opened. All
fasteners must be installed and tor ued per assembly procedure
specifications. Remove Metal Seals carefully with your fingers or a soft
tool. Metal tools scratch sealing surfaces.
• Metal Seals are supplied in pre-cleaned condition. No cleaning is
re uired. If necessary, Metal Seals can be cleaned using the
recommended solvents. Wipe Metal Seals clean with a lint-free
cloth before installation to ensure that no foreign matter impairs
the seal.
• Do not use grease or any other substance on Metal Seals that
will come in contact with the spectrometer.

acuum Products Division
Manual 699910005, Hot Ion Source Replacement Page 5
1.2.5 Spectrometer
CAUTION Store the Ion Source/Preamplifier sub-assembly in a cool, dry area in a
tightly sealed, ESD protected container. Wear non-powdered, ESD-safe
Nitride or e uivalent gloves when handling the spectrometer. Wash
hands thoroughly after handling the spectrometer filaments and
especially before smoking or eating.
The spectrometer and PCB’s are static sensitive devices. Wear a
grounding strap when performing any maintenance on these units and
especially when performing maintenance of static sensitive parts.
CAUTION The spectrometer operates at a very high vacuum produced by the high
vacuum turbomolecular pump. Service of the spectrometer re uires that
this vacuum be vented to the atmosphere.

acuum Products Division
Manual 699910005, Hot Ion Source Replacement Page 6
2
22
2 Filament Installation Agilent Helium Leak
Filament Installation Agilent Helium Leak Filament Installation Agilent Helium Leak
Filament Installation Agilent Helium Leak
Detector Model G8610, G8611, or G8612
Detector Model G8610, G8611, or G8612Detector Model G8610, G8611, or G8612
Detector Model G8610, G8611, or G8612
The same filament replacement kit is compatible with any model G8610, G8611, or G8612, as well
as legacy Agilent model S series leak detectors.
2.1 Equipment Required for G8610, G8611, or G8612
The following tools are suggested for assembly.
Table 2-1. E uipment re uired for G8610, G8611, or G8612 models
Item
ItemItem
Item Note
NoteNote
Note
Hot Ion Source Replacement Kit ( SFLDHIS) --
Slotted screw driver Use to remove leak detector covers
Metric Allen wrench set (Range 1.5 mm to
10 mm
--
Needle nose pliers or tweezer --
M3 Phillips head screw driver --
Torque wrench (must be adjustable to 40 in-
lbs (4.5 N-m) and 90 in-lbs (10.2 N-m))
--
Digital m
ultimeter (Fluke 187 or equivalent)
For resistance and continuity measurements
NOTE Inspect the new ion source kit for deformation, damage and filament
coating flaking prior to installation. Do not install if damaged. Touching
the filament under any condition will cause damage.
2.2 Installation Procedure for G8610, G8611, or G8612
For clarity, some items have been omitted from views.
Figure 2-1. Covers
Spectrometer
Header

acuum Products Division
Manual 699910005, Hot Ion Source Replacement Page 7
1. Turn off the power switch located on the back of the unit and unplug.
2. Wait 30 seconds for the high voltage to dissipate
3. Using a slotted screw driver, unfasten the captive screws holding each of the four covers.
If the unit is equipped with a handle, remove the handle.
4. Detach all four covers and rotate the top lid about the display, as to give access to the
spectrometer.
Figure 2-2. Spectrometer access
5. To remove the spectrometer top cover, it may be necessary to first pull straight out the
thermocouple gauge (shown in Figure 2-2 with the red arrow. It is shown without the
outside black plastic cover). Leave the thermocouple gauge connected to its wiring. Use an
M3 Phillips head screw driver to remove the four screws securing it. The screw shown in
the top right of Figure 2-2 will be securing a grounding strap. Leave the ground strap
hanging from the leak detector frame. Disconnect the two electrical cables plugged into
the spectrometer board, the pre-amp RJ45 style connector on the turbo side of the
spectrometer, and the ion source multi-pin connector (Cables not shown for clarity: refer to
Figure 2-3). Remove the top cover, set aside with the screws.
CAUTION
Static sensitive device, ensure that personnel are properly grounded
before proceeding.
Thermocouple
Gauge

acuum Products Division
Manual 699910005, Hot Ion Source Replacement Page 8
Figure 2-3. Spectrometer exploded view
Pre-amp
plug
Ion source
plug
M6 screws
(10X)
Belleville conical
washers
(3X/Screw)
Top cover
Spectrometer
Header
Spectrometer
Body
Filaments
(2X)
Metal gasket
(NOT REUSABLE)
Posts (4X)
Ion source
header pins
Detector
Housing
Inlet

acuum Products Division
Manual 699910005, Hot Ion Source Replacement Page 9
CAUTION Wear non-powdered, ESD-safe Nitride or e uivalent gloves (not included
in kit) to prevent skin oils from getting on vacuum surfaces.
Refer to Figure 2-3 for disassembly of the spectrometer header.
6. Loosen screws (10X) and remove spectrometer header from spectrometer body. The
vacuum system vents to atmosphere as the screws are loosened. Retain the socket head
cap screws and Belleville washers. Maintain correct orientation of Belleville (conical)
washers when removing.
7. Remove the spectrometer header. Rest upside-down on the four posts sticking up from the
printed circuit board.
8. Remove metal gasket and discard. Do not scratch the mating surface when removing the
gasket. To prevent scratching of any sealing surface, do not use metal tools for this task.
Do not attempt to reuse the gasket.
9. Examine the spectrometer cavity for discolored areas. If the inside of the spectrometer
body appears dirty, clean it with ac-u-solv spectrometer cleaning kit (Agilent part number
670029096).

acuum Products Division
Manual 699910005, Hot Ion Source Replacement Page 10
Refer to Figure 2-4 for reference.
Figure 2-4. Ion support assembly
Collimator
screw
Coupler screws (5X,
for the four green
wires and the one
brown wire in this
photo)
M4 support
screws
Extractor and
chamber wires
Ion
chamber
Extractor
plate
Filaments
(2X)

acuum Products Division
Manual 699910005, Hot Ion Source Replacement Page 11
10. Loosen the four filament coupler screws.
11. Loosen the collimator screws.
12. Loosen two M1.6 socket head screws securing the ion source high voltage connection.
13. On a clean work surface, remove the two M4 support screws. See Figure 2-5.
Figure 2-5. M4 support screws
14. Gently remove the ion support assembly from the spectrometer header.
NOTE Ensure that no damage is done to the spectrometer wire during
disassembly.
15. Position the new ion support assembly into the spectrometer header and align.
16. Secure the spectrometer header using two M4 support screws
M4
support
screws
C
o
l
l
i
m
a
t
o
r
screw

acuum Products Division
Manual 699910005, Hot Ion Source Replacement Page 12
17. Connect the collimator wire to the collimator plate using an M 1.5 screw. See Figure 2-6.
18. Connect the 4 coupler screws to their respective filaments.
Figure 2-6. Collimator wire connection
19. Insert the high voltage ion source wire (brownish-orange wire in rendering) into the ion
chamber and tighten the M1.6 socket head screw.
NOTE Pull lightly with small pliers on the high voltage ion source wire
(brownish-orange) to ensure it is connected securely and will not pull out.
Figure 2-7. Ion chamber and extractor plate
Collimator
screw
Ion
chamber
Extractor
plate

acuum Products Division
Manual 699910005, Hot Ion Source Replacement Page 13
20. Insert new filaments into a pair of couplers. erify filament alignment as shown in Figure
2-8 and Figure 2-9. Keep screws loose while aligning the filament position, then tighten
screws securely once aligned.
Figure 2-8. Filament positioning
Figure 2-9. Filament alignment

acuum Products Division
Manual 699910005, Hot Ion Source Replacement Page 14
21. Clean the mating surfaces of the spectrometer body and header with isopropyl alcohol and
a clean lint free wipe. Agilent recommends use of the ac-u-solv spectrometer cleaning kit
(Agilent part number 670029096).
22. Center the replacement metal gasket inside the bolt pattern and outside of the body cavity.
To prevent scratching of any sealing surface, do not use metal tools for this task (Figure
2-10).
23. Guide the spectrometer header into the pocket with the detector housing closest to the
inlet.
Figure 2-10. Spectrometer alignment
24. Insert a screw with three Belleville washers into each hole and finger tighten (see Figure
2-11).
25. Follow the torqueing pattern in Figure 2-11). Torque screws to 40 in-lbs (4.5 N-m).
26. Re-torque screws to 90 in-lbs (10.2 N-m) following the same pattern. Go through the entire
torque pattern twice to ensure the metal gasket is firmly compressed.
27. Wait a minimum of five minutes, then torque the screws again in the same pattern (Figure
2-11) to a value of 90 in-lbs (10.2 N-m). This wait period allows the washers to
decompress.
Figure 2-11. Tightening spectrometer header screws

acuum Products Division
Manual 699910005, Hot Ion Source Replacement Page 15
Figure 2-12. Ion source header pin schematic
28. On the PCB, use the resistance meter to verify an open circuit between any two of the six
ion source header pins (except FIL-1 to FIL-1 and FIL-2 to FIL-2 which should be 0.3 Ohms
or less). Also verify an open circuit between the body of the spectrometer and any of the
ion source header pins (Error! Reference source not found.
Error! Reference source not found.Error! Reference source not found.
Error! Reference source not found.). If there is continuity (short
circuit) at any of the points, remove the header and inspect for shorting.
29. If successful, leak check the spectrometer to ensure a leak free seal.
Figure 2-13. Ion source header pin locations
30. Place the spectrometer cover over the header and align the holes (Figure 2-13Error!
Error! Error!
Error!
Reference source not found.
Reference source not found.Reference source not found.
Reference source not found.).
31. Install screws and washers (items 5 & 6), then tighten using a M3 Phillips screw driver
(Error! Reference source not found.
Error! Reference source not found.Error! Reference source not found.
Error! Reference source not found.). Tighten one screw over the ground strap connector.
32. Re-plug in both the pre-amp and ion source cable.
33. Reinstall the leak detector covers and fasten hardware.
34. Power up the leak detector.
35. Let the unit run for 20-30 minutes, then perform a calibration (via the I/O, front panel
display, or RS232), per the user manual, to validate a successful installation.
