Agilent Technologies VS Series User manual

D R A F T 6 / 1 9 / 0 8
OPERATIONS MANUAL
Vacuum Products Division
VS Series
Component Leak
Detector
Manual Number: 699909948
Revision C
March 2011

D R A F T 6 / 1 9 / 0 8
VS Series Component Leak Detector
Copyright 2011
Agilent Inc.

VS Series Component Leak Detector
D R A F T 6 / 1 9 / 0 8
iii
Contents
Preface .............................................................................................................................................xiv
Documentation Standards .........................................................................................................xiv
Text.......................................................................................................................................xiv
Hazard and Safety Information ...................................................................................................xv
Solvents ................................................................................................................................xvi
Vacuum Equipment and Cleanliness....................................................................................xvi
O-ring Care ..........................................................................................................................xvii
Equipment, General............................................................................................................xviii
Power and Static Sensitivity..................................................................................................xix
Spectrometer.......................................................................................................................xxiii
Pumps................................................................................................................................. xxiii
Agilent Services .......................................................................................................................xxiv
Contacting Agilent .....................................................................................................................xxv
Section 1. Introduction to the VS Series Component Leak Detector ..............................................1-1
1.1 The VS Series Component Leak Detector ..........................................................................1-1
1.1.1 VS Series Component Leak Detector Configurations ................................................1-3
1.2 Unpacking the Leak Detector ..............................................................................................1-5
1.2.1 Unpacking Instructions ...............................................................................................1-5
1.3 Installation............................................................................................................................1-6
1.3.1 Typical VS- C-15 Leak Detection System Interconnection Diagram...........................1-7
1.3.2 Helium........................................................................................................................1-8
1.3.3 Recommended Additional Services ...........................................................................1-8
1.3.4 Storage .......................................................................................................................1-8
1.4 Front Panels ........................................................................................................................1-9
1.4.1 VS C-15 Base Unit .....................................................................................................1-9
1.4.2 VS C-15 Display Unit .................................................................................................1-9
1.5 Rear Panel.........................................................................................................................1-12
1.5.1 VS C-15 Base Unit ...................................................................................................1-12
1.5.2 VS C15 Display Unit..................................................................................................1-14
1.6 Features.............................................................................................................................1-15

VS Series Component Leak Detector
D R A F T 6 / 1 9 / 0 8
Section 2. Operating the VS C-15 Leak Detector via Front Panel Display .....................................2-1
2.6.1 Power Up Sequence...................................................................................................2-2
2.1 Initial Startup and Shutdown ...............................................................................................2-3
2.1.1 Startup .......................................................................................................................2-3
2.1.2 Calibrated Leak...........................................................................................................2-4
2.1.3 Shutdown ...................................................................................................................2-5
2.2 VS C-15 Display...................................................................................................................2-6
2.2.1 Screens Flow ..............................................................................................................2-6
2.2.2 Basic Soft Button Functions........................................................................................2-9
2.2.3 HOME Screen ..........................................................................................................2-11
2.2.4 Control Panel Screen................................................................................................2-16
2.2.5 Menus Screen...........................................................................................................2-22
2.3 Set-Up Menu......................................................................................................................2-34
2.3.6 Advanced Parameters ..............................................................................................2-38
2.3.7 Manual Tuning..........................................................................................................2-40
2.3.8 Manual Tuning Procedure (Internal or External Standard Leak) ..............................2-42
2.3.9 Manual Valve Control................................................................................................2-43
2.3.10 Output Control.........................................................................................................2-44
2.3.11 Units........................................................................................................................2-45
2.3.12 Languages ..............................................................................................................2-46
2.3.13 Gauge Calibration...................................................................................................2-47
2.3.14 Maintenance ...........................................................................................................2-50
2.3.15 Split Flow Operation or Parallel Pump Operation ...................................................2-56
Section 3. I/O Interface and Operation ...........................................................................................3-1
3.1 I/O Connector: Customer Accessible Inputs and Outputs ..................................................3-1
3.2 Analog Output Voltage.........................................................................................................3-6
3.2.1 Internal Calibration via the I/O ....................................................................................3-9
3.2.2 Full External Calibration via the I/O ............................................................................3-9
3.3 I/O Integration: Highlighted Points.....................................................................................3-10
3.4 Inputs: Helpful Tips............................................................................................................3-12
Section 4. RS-232 Interface and Operation ....................................................................................4-1
4.1 Serial Connector .................................................................................................................4-1
4.2 Protocol (RS-232), Diagnostic Port......................................................................................4-2
4.3 Communicating with RS-232 ...............................................................................................4-3
4.3.1 Windows HyperTerminal Set-Up Instructions ............................................................4-3
4.3.2 Internal Calibration via the RS232 Interface .............................................................4-16

VS Series Component Leak Detector
D R A F T 6 / 1 9 / 0 8
v
Section 5. Profinet Interface and Operation ....................................................................................5-1
5.1 Protocol (PROFINET-I/O) ...................................................................................................5-1
5.1.1 PROFINET IO Interface Introduction ..........................................................................5-1
5.1.2 PROFINET I/O Interface Setup...................................................................................5-1
5.2 VS C15 ProfiNet Data Structure ..........................................................................................5-2
5.2.1 PROFINET Input Data ................................................................................................5-2
5.2.2 PROFINET Output Data..............................................................................................5-4
5.2.3 Configuration and Status Variable Interface................................................................5-5
5.2.4 Configuration and Status Variables.............................................................................5-6
5.2.5 Internal Calibration via the Profinet Option .................................................................5-8
5.2.6 Full External Calibration via the Profinet Option .........................................................5-8
Section 6. Maintenance ..................................................................................................................6-1
6.1 Daily Maintenance ..............................................................................................................6-4
6.1.1 Sensitivity Check ........................................................................................................6-4
6.2 Spare Parts List ...................................................................................................................6-5
6.3 Leak Detector Accessory Item List ......................................................................................6-6
Appendix A. VS Series Leak Detector Hardware Descriptions .......................................................A-1
A.1 Spectrometer Tube Description...........................................................................................A-2
A.2 Printed Circuit Boards P/Ns and Descriptions.....................................................................A-3
A.2.1 CPU PCB ...................................................................................................................A-3
A.2.2 Motherboard PCB ......................................................................................................A-4
A.2.3 Ion Source PCB .........................................................................................................A-5
A.2.4 Turbo Controller PCB ................................................................................................A-6
A.2.5 Front Panel Controller PCB .......................................................................................A-6
A.2.6 Pre-Amp PCB ............................................................................................................A-7
A.2.7 Temperature Sensor PCB .........................................................................................A-8
A.2.8 Discrete I/O PCB .......................................................................................................A-8
A.2.9 PROFINET I/O Module ..............................................................................................A-9
Appendix B. Replacement Procedures ...........................................................................................B-1
B.1 VS-C15 Field Replacements: p/n EXVSC15BU..................................................................B-1
B.1.1 Configuring a Field Replacement or New VS-C15 ....................................................B-2
B.2 Turbo Pump Replacement...................................................................................................B-2
B.3 Fan Replacement ................................................................................................................B-7
B.4 Calibrated Leak .................................................................................................................B-10
B.5 Turbo Controller Board......................................................................................................B-16
B.6 CPU (Brain) Board.............................................................................................................B-18
B.7 Ion Source Board...............................................................................................................B-21
B.8 Mother Board.....................................................................................................................B-24
B.9 Discrete I/O Board.............................................................................................................B-27
B.10 Calibrated Leak Replacement .........................................................................................B-29
B.11 Spectrometer Header M1 Replacement..........................................................................B-33
B.12 Ion Source Replacement.................................................................................................B-40
B.13 Filament Replacement.....................................................................................................B-50

VS Series Component Leak Detector
D R A F T 6 / 1 9 / 0 8
Appendix C. Troubleshooting .........................................................................................................C-1
C.1 Service 1/Service 2 Commands..........................................................................................C-1
C.1.1 SERVICE1 .................................................................................................................C-1
C.1.2 SERVICE2 .................................................................................................................C-2
C.2 System Pressure Wait error message appears on the front panel display .........................C-3
C.3 Operational Failures..........................................................................................................C-10
C.4 Performance Issues ..........................................................................................................C-14
Appendix D. Introduction to Leak Detection ...................................................................................D-1
D.1 Leak Testing—Why is it Needed?.......................................................................................D-1
D.2 Agilent's Helium Leak Detection Technologies ...................................................................D-1
D.3 Methods of Leak Testing.....................................................................................................D-3
D.3.1 Vacuum Testing Method (Outside-in) ........................................................................D-4
D.3.2 Pressure Testing Method (Inside-out) .......................................................................D-5
D.3.3 System Leak Test Methods .......................................................................................D-6
D.4 Typical Leak Detection Applications....................................................................................D-8
D.4.1 Quality Control of Production Parts and Assemblies .................................................D-8
D.4.2 Maintenance of Systems ...........................................................................................D-8
D.4.3 System Integrated Leak Detection ............................................................................D-9
D.4.4 Mass Produced Parts ................................................................................................D-9
Appendix E. Specifications .............................................................................................................E-1
E.1 Specifications ......................................................................................................................E-1

VS Series Component Leak Detector
D R A F T 6 / 1 9 / 0 8
vii
Figures
1-1 VS C15 Base Unit, Outline Drawing ...................................................................................1-3
1-2 VS C-15 Display Unit Physical Dimensions: Front and Side ..............................................1-4
1-3 C-15 Interconnection Diagram............................................................................................1-7
1-4 VS C-15 Base Unit Front Panel..........................................................................................1-9
1-5 VS C-15 Display Front Panel..............................................................................................1-9
1-6 VS C-15 Base Unit Rear Panel.........................................................................................1-12
1-7 VS C-15 Component Display Unit Rear Panel..................................................................1-14
2-1 Screen Flow........................................................................................................................2-6
2-2 HOME Screen...................................................................................................................2-11
2-3 Leak Rate vs. Time Screen...............................................................................................2-13
2-4 Control Panel ....................................................................................................................2-16
2-5 Graphical Display..............................................................................................................2-20
2-6 First Menu Screen.............................................................................................................2-22
2-7 Calibration Set-up Screen.................................................................................................2-23
2-8 Reject and Audio Setpoints...............................................................................................2-26
2-9 Transfer Points with Stabilization Wait Timer ...................................................................2-28
2-10 Leak Rate Ranging...........................................................................................................2-29
2-11 System Information...........................................................................................................2-32
2-12 Control Panel Access........................................................................................................2-34
2-13 Set-Up Screen Initial.........................................................................................................2-35
2-14 Password Protection Screen.............................................................................................2-36
2-15 Set-Up Screen – Second ..................................................................................................2-36
2-16 Advanced Parameters Screen..........................................................................................2-38
2-17 Manual Tuning Screen......................................................................................................2-40
2-18 Manual Valve Control screen............................................................................................2-43
2-19 Output Control Screen......................................................................................................2-44
2-20 Units..................................................................................................................................2-45
2-21 Languages........................................................................................................................2-46
2-22 Gauge Calibration.............................................................................................................2-47
2-23 Maintenance .....................................................................................................................2-50
2-24 Current Date & Time Set-Up.............................................................................................2-51
2-25 Internal Calibrated Leak....................................................................................................2-52
2-26 Cal Leak Expiration Set-Up...............................................................................................2-54
2-27 System Defaults Screen ...................................................................................................2-55
2-28 Split Flow ..........................................................................................................................2-56
2-29 Leak Rate Keypad ............................................................................................................2-58
3-1 Optically Isolated Output Circuit Sketch..............................................................................3-5
3-2 Optically Isolated Input Circuit Sketch ................................................................................3-6
3-3 Leak Rate vs Analog Output - 1V\Dec................................................................................3-7
3-4 Leak Rate vs Analog Output - 2V\Dec................................................................................3-8
4-1 Serial Connector Map.........................................................................................................4-1
B-1 Unit Top Screws..................................................................................................................B-3
B-2 NW25 Clamp with Calibrated Leak Not Present.................................................................B-4

VS Series Component Leak Detector
D R A F T 6 / 1 9 / 0 8
B-3 Calibrated Leak O-ring........................................................................................................B-4
B-4 NW25 Clamp To Spectrometer...........................................................................................B-5
B-5 NW25 Clamp To Spectrometer...........................................................................................B-5
B-6 Pump Feet Nuts..................................................................................................................B-5
B-7 Test Port Connection..........................................................................................................B-6
B-8 Pump To Mounting Assembly.............................................................................................B-6
B-9 Unit Top Screws .................................................................................................................B-8
B-10 Fan Connector....................................................................................................................B-8
B-11 Fan Filter.............................................................................................................................B-9
B-12 Fan Exterior Screws ...........................................................................................................B-9
B-13 Fan Washer/Nut/Spacer ...................................................................................................B-10
B-14 Unit Top Screws ...............................................................................................................B-11
B-15 Turbo Pump Vent Screw...................................................................................................B-11
B-16 Turbo Pump Flange..........................................................................................................B-12
B-17 Turbo Pump Flange in Place ............................................................................................B-12
B-18 Calibrated Leak in Place...................................................................................................B-13
B-19 J7 Connector and Valve ...................................................................................................B-13
B-20 J7 Connector on Discrete I/O Board.................................................................................B-14
B-21 Leak Assembly Board Connection....................................................................................B-14
B-22 Motherboard Connection ..................................................................................................B-15
B-23 Unit Top Screws ...............................................................................................................B-17
B-24 Turbo Board Connections.................................................................................................B-17
B-25 Turbo Controller Board Screws ........................................................................................B-18
B-26 Unit Top Screws ...............................................................................................................B-19
B-27 J100 Connector ................................................................................................................B-19
B-28 Mounting Screws ..............................................................................................................B-20
B-29 Mother Board Connection.................................................................................................B-20
B-30 Pins Underneath...............................................................................................................B-21
B-31 Unit Top Screws ...............................................................................................................B-22
B-32 Connections......................................................................................................................B-22
B-33 Mounting Screws ..............................................................................................................B-23
B-34 Unit Top Screws ...............................................................................................................B-24
B-35 Mother Board Spacers......................................................................................................B-25
B-36 Mother Board Wiring.........................................................................................................B-26
B-37 Mother Board Mounting Screws .......................................................................................B-26
B-38 Unit Top Screws ...............................................................................................................B-27
B-39 Discrete I/O Board Wiring.................................................................................................B-28
B-40 Profinet and I/O Connectors .............................................................................................B-28
B-41 Unit Top Screws ...............................................................................................................B-29
B-42 Cable to Calibrated Leak Connection...............................................................................B-30
B-43 Remove Clamp.................................................................................................................B-30
B-44 Calibrated Leak Screws....................................................................................................B-31
B-45 Leak Assembly Board Connection....................................................................................B-31
B-46 Unit Top Screws ...............................................................................................................B-33
B-47 Turbo Vent........................................................................................................................B-34
B-48 NW-16 Vent ......................................................................................................................B-34

VS Series Component Leak Detector
D R A F T 6 / 1 9 / 0 8
ix
B-49 Cables To Spectrometer...................................................................................................B-35
B-50 Spectrometer Cover Screws.............................................................................................B-35
B-51 Spectrometer Header Assembly Screws ..........................................................................B-36
B-52 Spectrometer Assembly Removal.....................................................................................B-36
B-53 O-ring................................................................................................................................B-37
B-54 Inside of Spectrometer Body.............................................................................................B-37
B-55 Header Assembly Screws.................................................................................................B-38
B-56 Ion Source Header Pin Schematic....................................................................................B-39
B-57 Unit Top Screws................................................................................................................B-40
B-58 Turbo Vent........................................................................................................................B-41
B-59 NW-16 Vent ......................................................................................................................B-41
B-60 Cables To Spectrometer...................................................................................................B-42
B-61 Spectrometer Cover Screws.............................................................................................B-42
B-62 Spectrometer Header Assembly Screws ..........................................................................B-43
B-63 Spectrometer Assembly Removal.....................................................................................B-43
B-64 O-ring................................................................................................................................B-44
B-65 Inside of Spectrometer Body.............................................................................................B-44
B-66 Ion Support Assembly.......................................................................................................B-45
B-67 M4 Support Screws...........................................................................................................B-45
B-68 Partial Pressure Plate.......................................................................................................B-46
B-69 Extractor Plate ..................................................................................................................B-46
B-70 Coupler and Filament Assembly.......................................................................................B-47
B-71 Filament Position ..............................................................................................................B-47
B-72 Filament Alignment...........................................................................................................B-48
B-73 Ion Source Header Pin Schematic....................................................................................B-48
B-74 Unit Top Screws................................................................................................................B-51
B-75 Turbo Vent........................................................................................................................B-51
B-76 NW-16 Vent ......................................................................................................................B-52
B-77 Cables To Spectrometer...................................................................................................B-52
B-78 Spectrometer Cover Screws.............................................................................................B-53
B-79 Spectrometer Header Assembly Screws ..........................................................................B-53
B-80 Spectrometer Assembly Removal.....................................................................................B-54
B-81 O-ring................................................................................................................................B-54
B-82 Inside of Spectrometer Body.............................................................................................B-55
B-83 Coupler Screws.................................................................................................................B-55
B-84 Coupler and Filament Assembly.......................................................................................B-56
B-85 Filament Position ..............................................................................................................B-57
B-86 Filament Alignment...........................................................................................................B-57
B-87 Ion Source Header Pin Schematic....................................................................................B-58
C-1 Spectrometer (Ion Source Assembly)................................................................................ C-6
C-2 Spectrometer Header: Decomposition............................................................................... C-7
C-3 Pre-Amp Board - Measurement Points.............................................................................. C-7
C-4 Ion Source Board - Measurement Points......................................................................... C-12
D-1 Magnetic Separation Principle........................................................................................... D-2
D-2 Selective Ion Pump Detector ............................................................................................. D-3
D-3 Locating Leaks: Outside In ................................................................................................ D-4

VS Series Component Leak Detector
D R A F T 6 / 1 9 / 0 8
D-4 Measuring Leaks: Outside In..............................................................................................D-4
D-5 Measuring Leaks: Inside Out..............................................................................................D-5
D-6 Locating Leaks: Inside Out .................................................................................................D-5
D-7 Accumulation: Inside Out....................................................................................................D-6
D-8 Vacuum System..................................................................................................................D-7
E-1 VS C15 Interconnection Diagram .......................................................................................E-2

VS Series Component Leak Detector
D R A F T 6 / 1 9 / 0 8
xi
Tables
1-1 Installation Requirements .................................................................................................. 1-6
1-2 Base Unit Rear Panel Components................................................................................. 1-12
1-3 Display Unit Rear Panel Components ............................................................................. 1-14
1-4 VS Series VS-C-15 Features........................................................................................... 1-16
1-5 Dynamic Range Specification.......................................................................................... 1-18
2-1 VS C15 Startup Scenario................................................................................................... 2-3
2-2 General Description........................................................................................................... 2-7
2-3 Basic Soft Button Functional Items.................................................................................... 2-9
2-4 On-Screen Icons.............................................................................................................. 2-10
2-5 VS C-15 Leak Detector Operating States........................................................................ 2-13
2-6 Leak Detector Condition States....................................................................................... 2-14
2-7 System Information Display Detail................................................................................... 2-32
3-1 I/O Connector Pin Signals.................................................................................................. 3-1
3-2 VS C15 Startup Scenario................................................................................................... 3-8
4-1 Serial Connector Summary................................................................................................ 4-1
4-2 Internal Operating Parameters........................................................................................... 4-5
4-3 Non-Volatile Operating Parameters................................................................................... 4-9
4-4 Spectrometer Operating Parameters............................................................................... 4-12
4-5 Leak Detection Actions.................................................................................................... 4-12
4-6 VS C15 Startup Scenario................................................................................................. 4-15
5-1 Configuration and Status Variables ................................................................................... 5-6
5-2 VS C15 Startup Scenario................................................................................................... 5-7
6-1 Scheduled Maintenance .................................................................................................... 6-3
6-2 As-Required Maintenance ................................................................................................. 6-3
6-3 Fuses and Circuit Breakers................................................................................................ 6-4
6-4 Leak Detector Spare Parts................................................................................................. 6-5
6-5 Leak Detector Accessories............................................................................................... 6-6
C-1 Spectrometer Header, Pre-amp Board J1 Pin Assignments ............................................. C-8
E-1 Leak Detector Series Specifications ..................................................................................E-1

VS Series Component Leak Detector
This page intentionally left blank.
D R A F T 6 / 1 9 / 0 8

Agilent, Inc.
John Ehmann
Leak Detector Business Manager
We
Wir
Nous
Nosotros
Wij
Noi
Lexington, MA, 02421-3133 USA
121 Hartwell Avenue
Lexington, Massachusetts, USA
Agilent, Inc.
CE DECLARATION OF CONFORMITY
The authorized representative located within Community is:
Va rian Vacuum Technologies (Torino)
Varian S.p.A
Via F.lli Varian.54
Leini (Torino) - Italy
Tel: [phone]
Fax: [phone]
declare under our sole responsibility that the product,
erklären, in alleniniger Verantwortung, daß dieses Produkt,
déclarons sous notre seule responsabilité que le produit,
declaramos, bajo nuestra sola responsabilidad, que el producto,
verklaren onder onze verantwoordelijkheid, dat het product,
dichiariamo sotto nostra unica responsabilità, che il prodotto,
Vacuum Products Division
VS Series Component Leak Detectors
to which this declaration relates is in conformity with the following standards:
Safety:
• EN 61010-1, Second Edition, 2001 - Safety Requirements for Electrical Equipment for Measurement, Control, and Laboratory Use-Part 1:
General Requirements
per the provisions of the Low Voltage Directive - 2006/95/EC of 21 December 2006.
• CAN/CSA-C22.2 No. 61010-1-04 - Safety Requirements for Electrical Equipment for Measurement, Control, and Laboratory Use-Part 1: General
Requirements (Adopted IEC 61010-1:2001, MOD)
• UL 61010-1, Second Edition, 2004 - Safety Requirements for Electrical Equipment for Measurement, Control, and Laboratory Use-Part 1:
General Requirements
EMC Emission and Immunity:
• EN 55011:1998/A1: 1999/A2: 2002 Group 1 Class A: ISM radio-frequency equipment - Radio disturbance characteristics - Limits and methods
of measurement (EU)
• EN 61326:1997/A1: 1998 /A2:2001 Electrical equipment for measurement, control and laboratory use - EMC requirements (EU)
per the provisions of the Electromagnetic Compatibility Directive 2004/108/EEC of 31 December 2004.
EMC Emission:
• FCC: Code of Federal Regulations, 47CFR: 2004, Part 15, Class A (USA)
Test Specification for Profinet IO Device, Version 2.2.2, Jan. 2008

VS Series Component Leak Detectors
xiv
D R A F T 3 / 2 2 / 1 1
Preface
Documentation Standards
This manual uses the following documentation standards:
NOTE Notes contain important information.
CAUTION Cautions appear before instructions, which if not followed,
could cause damage to the equipment or data loss.
WARNING Warnings appear for a particular procedure or practice which, if
not followed correctly, could lead to serious injury or death.
Text
Hard buttons are depicted in text in bold text.
Soft key screen buttons are depicted in bold text when part of an action.
Italics is used for emphasis or to indicate screen text.

VS Series Component Leak Detectors
D R A F T 3 / 2 2 / 1 1
xv
Hazard and Safety Information
The common international symbols used in this manual and on the equipment are defined
below.
Operators and service personnel must be aware of all hazards associated with this
equipment. They must know how to recognize hazardous and potentially hazardous
conditions, and know how to avoid them. The consequences of unskilled, improper, or
careless operation of the equipment can be serious. Every operator or service person must
read and thoroughly understand operation/maintenance manuals and any additional
information provided by Agilent. All warning and cautions must be read carefully and
strictly observed. Consult local, state, and national agencies regarding specific requirements
and regulations. Address any safety, operation, and/or maintenance questions to your
nearest Agilent office.
OFF Supply (Power) Earth (Ground) Terminal
ON Supply (Power) Caution, Hot Surface
AC – Alternating Current Caution, Risk of Electrical
Shock
Warning, Risk of danger Protective Conductor
Terminal
Frame or chassis Terminal Do Not Place in Trash
Indoor, Dry Location Use
Only
Caution, Radio
Restriction
°
l

VS Series Component Leak Detectors
xvi
D R A F T 3 / 2 2 / 1 1
Solvents
WARNING The mechanical components of leak detectors are typically
cleaned with alcohol, methanol, or other solvents.
When heated, sprayed, or exposed to high-temperature
equipment, these solvents become flammable and explosive,
causing serious injury or death. Do not use these solvents near
a high-temperature source. Ventilate the working area with a
blower and work in a large, well-ventilated room.
Alcohol, methanol, or other solvents are irritants, narcotics,
depressants and/or carcinogens. Their inhalation and/or
ingestion may produce serious side effects. Prolonged or
continued contact with the skin results in absorption through
the skin and moderate toxicity. Always ensure that cleaning
operations are carried out in large, well-ventilated rooms, and
wear eye shields, gloves, and protective clothing.
To clean the leak detector enclosure and the LCD display, use
only a soft cloth slightly dampened with water or a mild soap.
Do NOT use excess water or cleaning solvents of any kind.
Avoid splashing any cleaning solvents into the unit through the
ventilation openings. Wipe the surface with a dry lint-free cloth.
CAUTION Do not clean any aluminum parts with Alconox®. Alconox is
not compatible with aluminum and will cause damage.
Vacuum Equipment and Cleanliness
Cleanliness is vital when servicing the leak detector or any vacuum equipment. There are
some techniques that are more important in leak detector servicing than in general vacuum
work:
CAUTION Do not use silicone oil or silicone grease.
Use powder-free butyl or polycarbonate gloves to prevent skin
oils from getting on vacuum surfaces.
NOTE Agilent does not recommend the use of vacuum grease.
Vacuum grease absorbs helium tracer gas and releases this
slowly resulting in helium background during leak test
operations. If it must be used, use it sparingly and avoid
silicone types. Apiezon®L grease is recommended (Agilent Part
No. 695400004).

VS Series Component Leak Detectors
D R A F T 3 / 2 2 / 1 1
xvii
O-ring Care
When removing, checking or replacing O-rings, keep in mind the following:
NOTE Agilent recommends replacing all O-rings during routine
maintenance or during any maintenance procedure requiring
that O-rings be removed.
NOTE Due to the effective cleaning nature of VacuSolv solvent and
its residue-free properties, Agilent’ Component and
Spectrometer Cleaning Kit (Part Number 670029096), used in
accordance with the kit instructions, is recommended for
cleaning spectrometer components. The kit can also be used for
fine cleaning of other parts in the leak detector’s vacuum
system such as valves and fittings. No rinsing steps or
high-temperature drying are required following cleaning with
VacuSolv. Although appropriate precautions are advised,
VacuSolv is compatible with most materials and does not
contain toxic chemicals or CFCs (chlorofluorocarbons). Other
acceptable solvents are isopropyl alcohol (IPA) or Dow
Corning®OS-20.
CAUTION Remove O-rings carefully with your fingers. Do not use metal
tools for this task; this prevents scratching of any sealing
surfaces.
❑ Wipe all O-rings clean with a lint-free cloth before
installation to ensure that no foreign matter is present to
impair the seal.
❑ Do not use grease or any other substance on O-rings that
will come in contact with the spectrometer.
❑ Do not use alcohol, methanol or other solvents on O-rings.
Doing so causes deterioration and reduces their ability to
hold a vacuum.
❑ Agilent does not recommend the use of vacuum grease. If
applicable, apply a small amount of Apiezon®L grease and
wipe the O-rings shiny dry.

VS Series Component Leak Detectors
xviii
D R A F T 3 / 2 2 / 1 1
Equipment, General
Environment of intended use:
❑ Indoors use in an industrial and laboratory installation only.
❑ Altitude up to 2000m
❑ POLLUTION DEGREE 2, Overvoltage Category: I, Class III
(DC powered)
❑ Operating Temperature: +5 °C to +48 °C, Relative
Humidity (RH) up to 80% max. Operating in the top working
range of [-3, -4, -5, -6], avoid operating with a constant
foreline pressure > 500 mTorr at +48° C.
❑ Storage ambient conditions: RH from 0% to 95%,
non-condensing, temperature: -20°C to +60°C
WARNING ❑ Do not use in presence of flammable or explosive gas.
❑ Do not attempt to disassemble or modify the equipment.
Such action could lead to electric shock or injury. Agilent's
authorized technician will do any repair work.
❑ If there is smoke or unusual smell or noise, stop the using the
equipment immediately, and contact the Agilent Service
Center.
WARNING The leak detector is not designed for use with hazardous gases.
Verify that the system to be tested has been purged of all
hazardous gases prior to using the leak detector. When testing a
system that contained hazardous gases, connect the exhaust of
the leak detector to a scrubbed or toxic containment exhaust.
Exposure to hazardous gases could result in serious injury or
death.
WARNING Equipment tightness is guaranteed for normal operating
conditions when the equipment leaves the factory. It your
responsibility to maintain the level of tightness, particularly
when pumping dangerous products.
CAUTION The performance and operating safety of this equipment can
only be guaranteed if it is operated according to normal
conditions of use.
Allow at least 4" of clearance adjacent to the ventilation slots at
the front, sides and back of the equipment enclosure.
Allow sufficient room for the operator to safely maneuver to
perform testing.

VS Series Component Leak Detectors
D R A F T 3 / 2 2 / 1 1
xix
LCD Display
WARNING If the LCD display breaks, avoid getting any liquid crystal in mouth
or eyes. If it gets on the operator hands, feet or clothing, wash it
immediately with soap and water.
CAUTION Do not apply excessive pressure to the LCD display as this may
cause smears.
In general, the lower the temperature, the longer it takes the LCD
display to turn on. Performance of the LCD display may deteriorate
in low temperature.
Power and Static Sensitivity
The power supply requirements for VS C15 Component leak detector: 24 VDC, 5 A min.
The VS Component leak detector can be ordered with or without an external 24 VDC
AC-DC power supply.
❑ When ordered with the universal external AC-DC power supply (VSC15PS), you
must provide a mains supply:
❑ 100-230 VAC ± 10%, 50/60 Hz ± 2%, with a 10 A local power switch/circuit
breaker.
❑ When ordered without the external power supply, you must supply a 24 VDC
+/- 5%, 5 A min. power supply with a local power switch.
Provide the 24 VDC power to the VS Component leak detector via a detachable cable: 18
AWG triple-twisted wires terminated by Molex’s HCS-125 Receptacle (P/N 03-12-1036),
with 3-socket female terminals (Molex P/N 18-12-1222) that are compatible with a DC inlet
connector of an EMI filter on the rear panel of the VS C15 Base Unit. Wire as follows:
❑ +24 VDC: position 1 (D-shape terminal) of the receptacle.
❑ PE wire: position 2 (middle terminal) of the receptacle; to provide grounding
between the VS C15 units and the external power supply system.
❑ 24VRTN wire: position 3 of the receptacle.

VS Series Component Leak Detectors
xx
D R A F T 3 / 2 2 / 1 1
Figure 1 24VDC Input Power Connection
Provide the 24 VDC power to an optional VS C15 Display Unit via a High Density 15-pin
D-Sub M/F cable connected to the DISPLAY connector on the rear panel of the Base Unit as
shown below.
CAUTION Use surge protection to improve the immunity of the leak
detector against unidirectional transients caused by the
following phenomena:
❑ Switching phenomena in the power network
(e.g., switching of capacitor banks, inductive loads,
electrical motors, etc.)
❑ Faults in the power network
❑ Indirect lightning strokes
CAUTION Many components of the leak detector are static sensitive.
Wear a grounding device when performing any maintenance
on the leak detector, especially when performing maintenance
of static sensitive parts, such as circuit boards and the
spectrometer.
(1)
(2)
(3)
