Installing the Tinted Acrylic Door
Installation Note
!"Installation Note
Installing the Tinted Acrylic Door
This procedure describes how to install the Tinted Acrylic Door on the
Agilent E840xA mainframe. The doorrequires mainframe Standard Adapter
Kit Option AXA (p/n E8400-80923), and is compatible with either the
support rail kit (Agilent E3664AC) or the rack slide kit (p/n 1494-0411).
Parts List The parts included in the door kit are shown in Table 1.
Note The door requires the mainframe to be recess mounted a minimum of
111 mm (4.36") or up to a maximum of 270.7 mm (10.6 inches) to
accommodate wiring terminals on the VXI instruments. When using the
minimum recess distance, field wiring cables must enter/exit the
instruments through the top and/or bottom openings only.
Procedure 1. Recess mount the mainframe a minimum of 111 mm (4.36 inches)
using the Standard Adapter Kit and either the support rail kit or rack
slide kit (see E8400-90038 for mainframe mounting instructions).
Note For the minimum recess distance, attach the rack mount adapters to the
mainframe beginning with the 12th hole from the front of the adapter.
2. If necessary, remove the dress screws (0570-1577) securing the
adapters to the rack.
3. Attach the hinge pins to the right rack mount adapter using four 10-32
x 0.375 flat head screws (Figure 1). Attach the rubber door stops and
door latch to the left adapter using four m3x8 pan head screws as also
shown in Figure 1.
Table 1. Agilent E840xA Door Kit Parts List.
Quantity Description Part Number
1 Acrylic Door Assembly E8400-09301
2 Hinges 3110-0409
1 Door Latch, Lock, and Keys 1390-0891
2 Rubber Door Stops 0403-0002
4 Screws - 10-32x0.375 flat head 2680-0100
4 Screws - m3x8 pan head 0515-0897
*E8400-90039*
Manual Part Number: E8400-90039
Edition 3 E0309

Installing the Tinted Acrylic Door Installation Note
4. Slide mainframe into the rack until the rack mount adapters contact
the rack’s vertical rails. Start the dress screws but do not tighten.
5. Install the door assembly by placing the hinges over the hinge pins on
the right adapter. Adjust the door for squareness and clearance by
holding the door in place while tightening the dress screws.
6. Adjust the latch keeper so that the door latches as it makes contact
with the rubber door stops.
Note Once installed and adjusted, the door can be removed when necessary by
lifting the door off the hinge pins.
Figure 1 . Installing the Acrylic Door Hinges, Door Stops, and Latch Keeper.
Rubber Door
Stop
Door
Latch
10-32 x 0.375
Flat Head Screws
10-32 x 0.375
Flat Head
Hinge
Pins
m3x8
Pan
Head
Screws
Rubber
Door
Stop
Screws
