Agilent 16034E Test Fixture
Operation and Service Manual
Third Edition
Agilent PN 16034-90041
December 1999
Printed in: Japan
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2
Notices
The information contained in this document is subject to change without notice.
This document contains proprietary information that is protected by copyright.All
rights are reserved. No part of this document may be photocopied, reproduced, or
translated to another language without the prior written consent of the Agilent
Technologies.
Agilent Technologies Japan, LTD.
Component Test PGU-Kobe
1-3-2, Murotani, Nishi-Ku, Kobe-shi, Hyogo, 651-2241 Japan
Copyright © 1992, 1998, 1999 Agilent Technologies Japan, Ltd.
Manual Printing History
The manual’s printing date and part number indicate its current edition. The
printing date changes when a new edition is printed. (Minor corrections and
updates that are incorporated at reprint do not cause the date to change.) The
manual part number changes when extensive technical changes are incorporated.
July 1992 First Edition (part number: 16034-90040)
August 1998 Second Edition (part number: 16034-90041)
December 1999 Third Edition (part number: 16034-90041)
Safety Summary
The following general safety precautions must be observed during all phases of
operation, service, and repair of this instrument. Failure to comply with these
precautions or with specific WARNINGS elsewhere in this manual may impair the
protection provided by the equipment. In addition it violates safety standards of
design, manufacture, and intended use of the instrument.
The Agilent Technologies assumes no liability for the customer’s failure to comply
with these requirements.
• Ground The Instrument
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

3
To avoid electric shock hazard, the instrument chassis and cabinet must be
connected to a safety earth ground by the supplied power cable with earth
blade.
•DO NOT Operate In An Explosive Atmosphere
Do not operate the instrument in the presence of flammable gasses or fumes.
Operation of any electrical instrument in such an environment constitutes a
definite safety hazard.
•Keep Away From Live Circuits
Operating personnel must not remove instrument covers. Component
replacement and internal adjustments must be made by qualified maintenance
personnel. Do not replace components with the power cable connected. Under
certain conditions, dangerous voltages may exist even with the power cable
removed. To avoid injuries, always disconnect power and discharge circuits
before touching them.
•DO NOT Service Or Adjust Alone
Do not attempt internal service or adjustment unless another person, capable of
rendering first aid and resuscitation, is present.
•DO NOT Substitute Parts Or Modify Instrument
Because of the danger of introducing additional hazards, do not install
substitute parts or perform unauthorized modifications to the instrument.
Return the instrument to a Agilent Technologies Sales and Service Office for
service and repair to ensure that safety features are maintained.
•Dangerous Procedure Warnings
Warnings, such as the example below, precede potentially dangerous
procedures throughout this manual. Instructions contained in the warnings
must be followed.
WARNING Dangerous voltages, capable of causing death, are presenting this instrument.
Use extreme caution when handling, testing, and adjusting this instrument.
Certification
Agilent Technologies certifies that this product met its published specifications at
the time of shipment from the factory. Agilent Technologies further certifies that
its calibration measurements are traceable to the United States National Institute of
Standards and Technology, to the extent allowed by the Institution’s calibration
facility, or to the calibration facilities of other International Standards Organization
members.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4
Warranty
This Agilent Technologies instrument product is warranted against defects in
material and workmanship for a period corresponding to the individual warranty
periods of its component products. Instruments are warranted for a period of one
year. During the warranty period, Agilent Technologies will, at its option, either
repair or replace products that prove to be defective.
For warranty service or repair, this product must be returned to a service facility
designated by Agilent Technologies. Buyer shall prepay shipping charges to
Agilent Technologies and Agilent Technologies shall pay shipping charges to
return the product to Buyer. However, Buyer shall pay all shipping charges, duties,
and taxes for products returned to Agilent Technologies from another country.
Agilent Technologies warrants that its software and firmware designated by
Agilent Technologies for use with an instrument will execute its programming
instruction when property installed on that instrument. Agilent Technologies does
not warrant that the operation of the instrument, or software, or firmware will be
uninterrupted or error free.
Limitation Of Warranty
The foregoing warranty shall not apply to defects resulting from improper or
inadequate maintenance by Buyer, Buyer-supplied software or interfacing,
unauthorized modification or misuse, operation outside the environmental
specifications for the product, or improper site preparation or maintenance.
IMPORTANT No other warranty is expressed or implied. Agilent Technologies specifically
disclaims the implied warranties of merchantability and fitness for a particular
purpose.
Exclusive Remedies
The remedies provided herein are buyer’s sole and exclusive remedies. Agilent
Technologies shall not be liable for any direct, indirect, special, incidental, or
consequential damages, whether based on contract, tort, or any other legal theory.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

5
Assistance
Product maintenance agreements and other customer assistance agreements are
available for Agilent Technologies products.
For any assistance, contact your nearest Agilent Technologies Sales and Service
Office. Addresses are provided at the back of this manual.
Safety Symbol
General definitions of safety symbols used on the instrument or in manuals are
listed below.
Instruction Manual symbol: the product is marked with this symbol when it is
necessary for the user to refer to the instrument manual.
WARNING This warning sign denotes a hazard. It calls attention to a procedure, practice,
condition or the like, which, if not correctly performed or adhered to, could
result in injury or death to personnel.
CAUTION This Caution sign denotes a hazard. It calls attention to a procedure, practice,
condition or the like, which, if not correctly performed or adhered to, could result
in damage to or destruction of part or all of the product.
NOTE Note denotes important information. It calls attention to a procedure, practice,
condition or the like, which is essential to highlight.
!
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

6
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Contents
7
1. Operation
Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Typical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2. Service
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

8
Contents
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

9
1 Operation
This Operating note provides Operating and service information for the Agilent
16034E Test Fixture. Specifications are listed in Table 1-1.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

10 Chapter1
Operation
Product Description
Product Description
This test fixture is designed to facilitate easy and accurate measurements of chip
type components and similar types not furnished with lead wires. Connection of
sample components to the 16034E is done by simply pressing the loading lever to
left, inserting sample components in the V-mount center section (between fixture
jaws) and releasing lever. Components which may be measured with the 16034E
are the rectangular paralleled chip, cylindrical chip, and other similar in shape and
type to components shown in Table 1-1.
Figure 1-1
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Chapter 1 11
Operation
Operation
Operation
The set up and measurement procedure is as follows:
1. Set the cable length to 0m.
2. Connect the 16034E directly to the UNKNOWN terminals.
3. Loosen the knob A.
Figure 1-2
4. Adjust the contact pin position on the V-mount center section with the knob B
to adapt your DUT size.
Figure 1-3
5. Tighten the knob A to fix the contact pin.
6. Make the right and the left contact pins contact.
7. Perform the short compensation described in the instrument’s operation
manual.
8. Pressing the loading lever C to left.
9. Hold the lever C so that the gap of contact is as same as the DUT’s length.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

12 Chapter1
Operation
Operation
10.Perform the open compensation described in the instrument’s operation
manual.
11.Inserting a sample components in the V-mount center section (between fixture
jaws).
12.Releasing the lever C to fix the DUT.
Figure 1-4
WARNING DO NOT APPLY MORE THAN ± 40V OF DC BIAS VOLTAGE TO THE
UNKNOWN TERMINALS. AN ELECTRICAL SHOCK HAZARD WILL
EXIST DURING OPERATION WHEN THE DC BIAS VOLTAGE IS
GREATER THAN ± 40V DC.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Chapter 1 13
Operation
Specifications
Specifications
Table 1-1 Specification of the 16034E.
Function: For use with 4 terminal-pair LCR Meters and Impedance
Analyzers.
Measurable components: Chip type components ( Not furnished with lead wires)
Dimension of
measurable components:
Frequency: ≤40 MHz
Maximum Voltage: ± 40 V peak max.(AC + DC)
Dimensions of test
fixture: 128 (W) ×60 (H) ×71 (D) mm
Weight: 270 g
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

14 Chapter1
Operation
Specifications
Typical Characteristics
Table 1-2 Typical characteristics
NOTE f is the measurement frequency in MHz. The incremental errors calculated from
the equations given in this table are additive when measurements are made above
1MHz. The incremental error is applicable after completion of the OPEN/SHORT
compensation.
Figure 1-5
Incremental Error at f ≥1 MHz
Parameter reading error (%) Offset Value for D
 

------


×

±
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

15
2 Service
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

16 Chapter2
Service
Maintenance
Maintenance
An exploded view of the 16034E for parts identification is shown in Figure 2-1 and
Figure 2-2. Do not disassemble any further than shown. Maintenance consists
principally of cleaning contacts and replacing worn or damaged parts. Take special
care when cleaning contacts.
To order parts, use the Agilent Technologies part numbers listed in Table 2-1. If a
faulty part is located in an assembly that cannot be disassembled, order the next
higher assembly or return the fixture to the nearest Agilent Technologies
Sales/Service Office for repair or replacement.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Chapter 2 17
Service
Maintenance
Figure 2-1 Parts Identification
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

18 Chapter2
Service
Maintenance
Figure 2-2 Parts Identification
Table 2-1
Reference
Designation Agilent Part No. Qty. Description
1 16034-00221 1 TOP COVER
2 2200-0103 2 SCREW
3 1460-0323 1 SPRING
4 16034-01202 1 BRACKET
5 16034-25004 1 KNOB
6 2360-0201 1 SCREW
7 3050-0228 1 WASHER
8 16034-05001 1 LEVER
9 16034-23001 2 SHAFT
10 16034-25002 4 COLLAR
11 0510-0083 1 ERING
12 3050-1138 1 WASHER
13 2420-0006 1 NUT
14 16034-20002 1 BLOCK
15 16034-20001 1 BLOCK
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Chapter 2 19
Service
Maintenance
16 16034-24001 2 COLLAR
17 16034-25001 2 COLLAR
18 2200-0101 4 SCREW
19 16034-20003 2 PLUG
20 0380-0044 2 COLLAR
21 16034-25003 1 KNOB
22 2200-0769 2 SCREW
23 16034-25005 1 BLOCK
24 16034-23013 1 SCREW
25 2360-0192 2 SCREW
26 16012-7122 2 BNC ASS’Y
27 1250-1798 2 BNC
28 16034-00222 1 BOTTOM COVER
29 2950-0043 4 NUT
30 2190-0016 4 WASHER
31 16034-00601 1 SHIELD PLATE
32 16047-40000 1 STOPPER
33 2190-0206 1 WASHER
34 2200-0105 1 SCREW
35 16034-68021 2 J.W.L
36 16047-00617 2 PLATE
Reference
Designation Agilent Part No. Qty. Description
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
