Agilent E5023U Upgrade Kit
Upgrade Manual
Third Edition
Software Revision
This manual applies directly to system which has
the software revision B.01.00 and above
Part No. E5023-90311
March 2003
Printed in Japan

2
Notices
The information contained in this document is subject to change without notice.
This document contains proprietary information that is protected by copyright.All rights
are reserved. No part of this document may be photocopied, reproduced, or translated to
another language without the prior written consent of the Agilent Technologies, Inc.
Agilent Technologies Japan, Ltd.
Component Test PGU Kobe
1-3-2, Murotani, Nishi-Ku, Kobe-shi, Hyogo, 651-2241 Japan
Microsoft is a registered trademark of Microsoft Corporation.
Windows 95/2000 and Visual Basic are registered trademarks of Microsoft Corporation.
Acrobat Reader is a registered trademark of Adobe Corporation.
ÓAgilent Technologies Japan, Ltd. 2001, 2003
Manual Printing History
The manual’s printing date and part number indicate its current edition. The printing date
changes when a new edition is printed. (Minor corrections and updates that are
incorporated at reprint do not cause the date to change.) The manual part number changes
when extensive technical changes are incorporated.
June 2001 1st Edition
October 2001 2nd Edition (part number: E5023-90310)
March 2003 3rd Edition (part number: E5023-90311)
Assistance
Product maintenance agreements and other customer assistance agreements are available
for Agilent Technologies products.
For any assistance, contact your nearest Agilent Technologies Sales and Service Office.
Addresses are provided at the back of this manual.

Contents
3
1. Introduction
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Required Items for Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Required Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Required Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2. Upgrade Procedure
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Step 1: Checking the E8491A serial number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Step 2: Installing the Backplane Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Step 3: Installing new Components for E5023A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Install the Modules in the VXI mainframe.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Place the E5043A/C and E5029K on the Spinstand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Step 4: Connecting Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Cable Connection of E5023A Option 415 (1.5 Gbps) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Cable Connection of E5023A Option 426 (2.6 Gbps) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Step 5: Uninstalling the E5022A/B System Software from your PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Step 6: Installing the E5022/23 System Software into your PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Step 7: Installing the Compensation Factor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Step 8: Put the Upgrade Model Label on the VXI Mainframe. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

4
Contents

5
Introduction 2. Chapter Title 3. Chapter Title 4. Chapter Title 5. Chapter Title
1Introduction

6Chapter 1
Introduction
Overview
Overview
This manual provides the information to upgrade the E5022A/B (600 M / 750 M / 1 Gbps)
to the E5023A (1.5 Gbps) or upgrade the E5023A (1.5 Gbps) to the E5023A (2.6 Gbps),
using the E5023U Upgrade Kit.
Required Items for Installation
The following items are required for installation.
Required Tools
Table 1-1 Required Tools
Tools Size Purpose
Torque limiting wrench 8 mm-11 kgf•cm SMC cable connector
6 mm-3.5 kgf•cm SMA cable connector
Phillips screwdriver P1 On Stage Buffer Unit Detach
Hex key T1.5 mm Connection Board Detach
Slotted screwdriver 5.5 mm Serial cable connector
Pozidriv screwdriver Pz#1 VXI modules
Chain nose pliers General purpose
Diagonal cutting pliers Cutting cable ties, etc.
Knife Opening carton, etc.
Soldering Iron Modifying E8491A
Antistatic wrist band Prevent ESD

Chapter 1 7
Introduction
Required Items for Installation
Introduction 2. Chapter Title 3. Chapter Title 4. Chapter Title 5. Chapter Title
Required Software
Table 1-2 Required Tools
Name Description
E5022/E5023 System Software Revision B.01.00 and above, for upgrading to
E5023A Option 415 (1.5 Gbps)*1.
*1.The latest system software CD-ROM is included in the upgrade kit.
Revision B.03.00 and above, for upgrading to
E5023A Option 426 (2.6 Gbps)*1.
caltool.exe E5023A Calibration Tool Software. You can
download this software from the website:
“http:\\dst.tm.agilent.com\”

8Chapter 1
Introduction
Required Items for Installation

9
1. Chapter Title Upgrade Procedure 3. Chapter Title 4. Chapter Title 5. Chapter Title
2 Upgrade Procedure

10 Chapter 2
Upgrade Procedure
Introduction
Introduction
This section explains how to upgrade the E5022A/B (600 M / 750 M / 1 Gbps) to E5023A
(1.5 Gbps) or the E5023A (1.5 Gbps) to the E5023A (2.6 Gbps).
The upgrade procedure is shown below.
Step 1. Check the E8491A serial number. If required, modify it in accordance with the service
note.
See “Step 1: Checking the E8491A serial number” on page 11 for details.
Step 2. Install the backplane connectors into the VXI mainframe.
See “Step 2: Installing the Backplane Connector” on page 13 for details.
Step 3. Install the modules into the VXI mainframe and place the E5043A/C and E5029K on the
spinstand.
See “Step 3: Installing new Components for E5023A” on page 14 for details.
Step 4. Connect the cables.
See “Step 4: Connecting Cables” on page 15 for details.
Step 5. Uninstall the old E5022/E5023 system software from the PC.
See “Step 5: Uninstalling the E5022A/B System Software from your PC” on page 24 for
details.
Step 6. Install the appropriate E5022/E5023 system software.
See “Step 6: Installing the E5022/23 System Software into your PC” on page 24 for details.
Step 7. Install the compensation factor.
See “Step 7: Installing the Compensation Factor” on page 24 for details.
Step 8. Put the Upgrade Model label on the VXI Mainframe.
See “Step 8: Put the Upgrade Model Label on the VXI Mainframe” on page 25 for details.

Chapter 2 11
Upgrade Procedure
Step 1: Checking the E8491A serial number
1. Chapter Title 3. Chapter Title 4. Chapter Title 5. Chapter Title
Upgrade Procedure
Step 1: Checking the E8491A serial number
If the serial number of the E8491A IEEE-1394 PC Link to VXI is US39000231 and below,
the modification is required.
Open the side cover of the E8491 and remove clamping diodes CR401, CR402,
CR403 and CR404 using a soldering iron.
See the service note E8491-01 in the next page.

12 Chapter 2
Upgrade Procedure
Step 1: Checking the E8491A serial number
E8491A-01
SERVICE NOTE
E8491A IEEE-1394 PC Link to VXI, C-Size
E8491-66501 PC Assembly - PC/VXI Interconnect
Serial Numbers: US39000231 and below
Clock and sync signals fail when using VXI backplane ECL trigger
lines.
To Be Performed By: Customer or Agilent Personnel
Parts Required: None
Situation:
In multi-module systems, the clock and sync signals can be distributed between modules
using the ECLTRG lines on the VXI backplane. This works as long as all modules are
designed according to the current VXI specification. Unfortunately, the E8491A circuit
design had clamping diodes on the ECL Trigger lines. These diodes corrupt the ECLTRG
waveform causing commiunication failures between VXI modules.
Solution / Action:
Remove clamping diodes CR401, CR402, CR403 and CR404.
ADMINISTRATIVE INFORMATION
SERVICE NOTE CLASSIFICATION:
MODIFICATION RECOMMENDED
ACTION
CATEGORY:
IMMEDIATELY
ON SPECIFIED FAILURE
AGREEABLE TIME
STANDARDS:
LABOR0.5 Hours
LOCATION
CATEGORY:
CUSTOMER INSTALLABLE
ON-SITE
SERVICE CENTER
SERVICE RETURN
INVENTORY: SCRAP
SEE TEXT
USED RETURN
PARTS: SCRAP
SEE TEXT
AVAILABILITY: PRODUCT’S SUPPORT LIFE AGILENT RESPONSIBLE UNTIL: November 2003
AUTHOR: DMT ENTITY: 0940 ADDITIONAL INFORMATION:
© 2000 AGILENT TECHNOLOGIES
PRINTED IN U.S.A.
SUPERSEDES: NONE
DATE: November 2000

Chapter 2 13
Upgrade Procedure
Step 2: Installing the Backplane Connector
1. Chapter Title 3. Chapter Title 4. Chapter Title 5. Chapter Title
Upgrade Procedure
Step 2: Installing the Backplane Connector
Remove the modules from the VXI mainframe and install the backplane connectors.
Figure 2-1 Installing the Backplane Connector

14 Chapter 2
Upgrade Procedure
Step 3: Installing new Components for E5023A
Step 3: Installing new Components for E5023A
Install the Modules in the VXI mainframe.
Exchange the old modules with the new modules. The old modules are no longer
necessary.
Place the E5043A/C and E5029K on the Spinstand
The E5043A is used to upgrade the old system to the E5023A Option 415 (1.5 Gbps),
while the E5043C is used to upgrade the old system to the E5023A Option 426 (2.6 Gbps).
See the spinstand installation manual since the location of these units depend on the type of
spinstand.
NOTE When you install the E5043C Head Amplifier Control Unit (main unit) on the Agilent
spinstand cover for the E5010C, you should fix the angle (bracket) with the four M3 screws
(p/n 0515-0372) and four washers (p/n 3050-0893). When you install the E5043C Head
Amplifier Control Unit (main unit) on the Agilent spinstand cover for the E5013A, you
should fix the angle (bracket) with the four M4 screws (p/n 0515-0380) (the washers are
not used). The screws and washers are included in the upgrade kit.
Table 2-1Old and new modules (upgrade to E5023A Opt. 415, 1.5 Gbps)
Old Modules New Modules
E5035A E5035B
E5037A or B E5037C
E5038A E5038B
Table 2-2Old and new modules (upgrade to E5023A Opt. 426, 2.6 Gbps)
Old Modules New Modules
E5035A E5035B
E5037A, B, or C E5037D
E5038A E5038B

Chapter 2 15
Upgrade Procedure
Step 4: Connecting Cables
1. Chapter Title 3. Chapter Title 4. Chapter Title 5. Chapter Title
Upgrade Procedure
Step 4: Connecting Cables
Connect the cables between modules.
Cable Connection of E5023A Option 415 (1.5 Gbps)
See Table 2-3 and Figure 2-2. When the system has the E5029K Option 001, see Table 2-4
and Figure 2-3. When the system has the 4395A, see the Table 2-5 and the Figure 2-4.
Table 2-3 Cable Connection of E5023A Opt. 415 (1.5 Gbps) (VXI Modules)
No. Description Connection Part No.
1 SMA(m)-SMA(m) Cable E5029K Connection Board
“R+”
E5029K Onstage Buffer Unit
“R+”
E5029-61601
2 SMA(m)-SMA(m) Cable E5029K Connection Board
“R-”
E5029K Onstage Buffer Unit
“R-”
E5029-61602
3 Flat Cable E5029K Connection Board
“Connection Board I/F”
E5029K Connection Board
“Cable ”
E5029-61608
4 SMA(m)-SMA(m) Cable E5043 “OUT D+” E5029K “W+” E5043-61611
5 SMA(m)-SMA(m) Cable E5043 “OUT D-” E5029K “W-” E5043-61612
6 SMA(m)-SMA(m) Cable E5036 “Sig In” “Junction Read Sig” E5023-61607
7 SMA(m)-SMA(m) Cable “Junction Read Sig” E5029K “Read Sig Out” E5023-61608
8 50P Halfpitch - - E5043-61613
9 SMA(m)-SMA(m) Cable E5039 “Data Out Pos” E5043 “Input2 Data+” E5039-61606
10 SMA(m)-SMA(m) Cable E5039 “Data Out Neg” E5043 “Input2 Data-” E5039-61607
11 SMA(m)-SMA(m) Cable E5037 “Clk Out Pos” E5043 “Input Clock+” E5023-61601
12 SMA(m)-SMA(m) Cable E5037 “Clk Out Neg” E5043 “Input Clock-” E5023-61602
13 SMA(m)-SMA(m) Cable E5037 “Data Out Pos” E5043 “Input1 Data+” E5023-61603
14 SMA(m)-SMA(m) Cable E5037 “Data Out Neg” E5043 “Input1 Data-” E5023-61604
15 MDR-MDR Cable E5035 “Head Amp Ctrl” E5043 “Head Amp Ctrl” E5023-61605
16 BNC(m)-BNC(m) Cable E5037 “Gate Out” E5041A “Trig In” E5041-61602
17 SMA(m)-SMA(m) Cable E5036A “Fltrd Out 5” E5041A “Signal In 509” E5041-61603
18 BNC(m)-BNC(m) Cable E5037 “Ref Out” E5040 “Ext Ref In” E5023-61606
19 SMA(m)-SMA(m) Cable E5036 “Thru Out” Spectrum Ana In E5023-61611
20 SMA(m)-SMA(m) Cable E5036 “Filtr’d Out” E5038 “Signal In” E5023-61610
21 SMA(m)-SMA(m) Cable E5035 “Trig Out 1” Oscillo E5023-61613
22 BNC(m)-BNC(m) Cable E5036 “Filtr’d Out” Oscillo Ch1 E5023-61612
23 SMA(f)-BNC(m) Adapter - - 1250-1700

16 Chapter 2
Upgrade Procedure
Step 4: Connecting Cables
24 BNC(m)-BNC(m) Cable E5035 “WG IN” E5039 “WG OUT” E5039-61609
25 SMA(m)-SMA(m) Cable E5039 “Signal In” E5036 “Out2” E5039-61608
26 IEEE-1394 Cable IEEE-1394 Port on PCI Board E8491B “Port A” 8192-8688
27 GPIB Cable, 2m GPIB Port on PCI Board 54845A GPIB port 10833B
28 GPIB Adapter Extender - - 10834A
29 BNC(m)-BNC(m) Cable E5035 “Index In” Spinstand Index E5023-61609
30 SMA(m)-SMB(m) Cable E5035 “Piezo Ctrl” PZT Ctrl Analog E5035-61601
31 Serial Cable PC COM1 Port Spinstand Serial Port E5022-61628
Table 2-3 Cable Connection of E5023A Opt. 415 (1.5 Gbps) (VXI Modules)
No. Description Connection Part No.

Chapter 2 17
Upgrade Procedure
Step 4: Connecting Cables
1. Chapter Title 3. Chapter Title 4. Chapter Title 5. Chapter Title
Upgrade Procedure
Figure 2-2 Cable Connection of E5023A Opt. 415 (1.5 Gbps) (E5029K Option 002 Buffer Board)

18 Chapter 2
Upgrade Procedure
Step 4: Connecting Cables
Figure 2-3 Cable Connection of E5023A Opt. 415 (1.5 Gbps) (E5029K Option 001 Buffer Board)
Table 2-4 Cable Connection of E5023A Opt. 415 (1.5 Gbps) (VXI Modules)
No. Description Connection Part No.
32 SMA(m)-SMA(m) Cable E5029K Connection Board
“W+”
E5029K Onstage Buffer Unit
“W+”
E5029-61604
33 SMA(m)-SMA(m) Cable E5029K Connection Board
“W-”
E5029K Onstage Buffer Unit
“W-”
E5029-61605

Chapter 2 19
Upgrade Procedure
Step 4: Connecting Cables
1. Chapter Title 3. Chapter Title 4. Chapter Title 5. Chapter Title
Upgrade Procedure
Figure 2-4 Cable Connection of E5023A Opt. 415 (1.5 Gbps) (4395A)
Table 2-5 Cable Connection of E5023A Opt. 415 (1.5 Gbps) (VXI Modules)
No. Description Connection Part No.
34 BNC(m)-BNC(m) Cable E5035 “Trig Out” 4395A “Ext Trigger” E5022-61613*1
35 SMA(m)-BNC(m) Cable E5037 “Ref Out” 4395A “Ext. Ref. Input” E5022-61614*1
36 SMA(f)-BNC(m) Adapter - - 1250-1700
37 SMA(m)-SMA(m) Cable E5036A “Filtrd Out 1” 4395A “R Input” E5022-61623*1
38 SMA(m)-N(m) Adapter - - 1250-1250*1
*1.The cable is used in E5022A/B

20 Chapter 2
Upgrade Procedure
Step 4: Connecting Cables
Cable Connection of E5023A Option 426 (2.6 Gbps)
See Table 2-6 and Figure 2-5. When the system has the E5029K Option 001, see Table 2-7
and Figure 2-6. When the system has the 4395A, see the Table 2-8 and the Figure 2-7.
Table 2-6 Cable Connection of E5023A Opt. 426 (2.6 Gbps) (VXI Modules)
No. Description Connection Part No.
1 SMA(m)-SMA(m) Cable E5029K Connection Board
“R+”
E5029K Onstage Buffer Unit
“R+”
E5029-61601
2 SMA(m)-SMA(m) Cable E5029K Connection Board
“R-”
E5029K Onstage Buffer Unit
“R-”
E5029-61602
3 Flat Cable E5029K Connection Board
“Connection Board I/F”
E5029K Connection Board
“Cable ”
E5029-61608
4 SMA(m)-SMA(m) Cable E5043 “OUT D+” E5029K “W+” E5043-61611
5 SMA(m)-SMA(m) Cable E5043 “OUT D-” E5029K “W-” E5043-61612
6 SMA(m)-SMA(m) Cable E5036 “Sig In” “Junction Read Sig” E5023-61607
7 SMA(m)-SMA(m) Cable “Junction Read Sig” E5029K “Read Sig Out” E5023-61608
8 50P Halfpitch - - E5043-61613
9 SMA(m)-SMA(m) Cable E5039 “Data Out Pos” E5043 “Input2 Data+” E5039-61606
10 SMA(m)-SMA(m) Cable E5039 “Data Out Neg” E5043 “Input2 Data-” E5039-61607
11 SMA(m) - SMA(m) Cable
E5037 “Clk Out Pos” E5043 “Input Clock+”
E5037-61621
E5037 “Clk Out Neg” E5043 “Input Clock-”
E5037 “Data Out Pos” E5043 “Input1 Data+”
E5037 “Data Out Neg” E5043 “Input1 Data-”
12 MDR-MDR Cable E5037 “Ctrl” E5043 “Control” E5043-61622
15 MDR-MDR Cable E5035 “Head Amp Ctrl” E5043 “E5035B I/F” E5023-61605
16 BNC(m)-BNC(m) Cable E5037 “Gate Out” E5041A “Trig In” E5041-61602
17 SMA(m)-SMA(m) Cable E5036A “Fltrd Out 5” E5041A “Signal In 509” E5041-61603
18 BNC(m)-BNC(m) Cable E5037 “Ref Out” E5040 “Ext Ref In” E5023-61606
19 SMA(m)-SMA(m) Cable E5036 “Thru Out” Spectrum Ana In E5023-61611
20 SMA(m)-SMA(m) Cable E5036 “Filtr’d Out” E5038 “Signal In” E5023-61610
21 SMA(m)-SMA(m) Cable E5035 “Trig Out 1” Oscillo E5023-61613
22 BNC(m)-BNC(m) Cable E5036 “Filtr’d Out” Oscillo Ch1 E5023-61612
23 SMA(f)-BNC(m) Adapter - - 1250-1700
24 BNC(m)-BNC(m) Cable E5035 “WG IN” E5039 “WG OUT” E5039-61609
25 SMA(m)-SMA(m) Cable E5039 “Signal In” E5036 “Out2” E5039-61608
26 IEEE-1394 Cable IEEE-1394 Port on PCI Board E8491B “Port A” 8192-8688
