Agilent Technologies
Agilent
OBSAI Protocol Tester
Installation Guide

Notices
© Agilent Technologies, Inc. 2008
No part of this manual may be reproduced
in any form or by any means (including
electronic storage and retrieval or transla-
tion into a foreign language) without prior
agreement and written consent from Agi-
lent Technologies, Inc. as governed by
United States and international copyright
laws.
Manual Part Number
N5341-97000
Edition
First edition, July 2008
Printed in Germany
Agilent Technologies
Herrenberger Strasse 130
D-71034 Boeblingen, Germany
Warranty
The material contained in this docu-
ment is provided “as is,” and is sub-
ject to being changed, without notice,
in future editions. Further, to the max-
imum extent permitted by applicable
law, Agilent disclaims all warranties,
either express or implied, with regard
to this manual and any information
contained herein, including but not
limited to the implied warranties of
merchantability and fitness for a par-
ticular purpose. Agilent shall not be
liable for errors or for incidental or
consequential damages in connection
with the furnishing, use, or perfor-
mance of this document or of any
information contained herein. Should
Agilent and the user have a separate
written agreement with warranty
terms covering the material in this
document that conflict with these
terms, the warranty terms in the sep-
arate agreement shall control.
Technology Licenses
The hardware and/or software described in
this document are furnished under a
license and may be used or copied only in
accordance with the terms of such license.
Restricted Rights Legend
If software is for use in the performance of
a U.S. Government prime contract or sub-
contract, Software is delivered and
licensed as “Commercial computer soft-
ware” as defined in DFAR 252.227-7014
(June 1995), or as a “commercial item” as
defined in FAR 2.101(a) or as “Restricted
computer software” as defined in FAR
52.227-19 (June 1987) or any equivalent
agency regulation or contract clause. Use,
duplication or disclosure of Software is
subject to Agilent Technologies’ standard
commercial license terms, and non-DOD
Departments and Agencies of the U.S. Gov-
ernment will receive no greater than
Restricted Rights as defined in FAR
52.227-19(c)(1-2) (June 1987). U.S. Govern-
ment users will receive no greater than
Limited Rights as defined in FAR 52.227-14
(June 1987) or DFAR 252.227-7015 (b)(2)
(November 1995), as applicable in any
technical data.
Safety Notices
CAUTION
A CAUTION notice denotes a haz-
ard. It calls attention to an operat-
ing procedure, practice, or the like
that, if not correctly performed or
adhered to, could result in damage
to the product or loss of important
data. Do not proceed beyond a
CAUTION notice until the indicated
conditions are fully understood and
met.
WARNING
A WARNING notice denotes a
hazard. It calls attention to an
operating procedure, practice, or
the like that, if not correctly per-
formed or adhered to, could result
in personal injury or death. Do not
proceed beyond a WARNING
notice until the indicated condi-
tions are fully understood and met.
Printing HIstory
Agilent Technologies, Inc. can issue revi-
sions between the product releases to
reflect the latest and correct information in
the guide. Agilent Technologies, Inc. also
reserves its right to not issue a new edition
of the guide for every system release.

Installation Guide 3
Safety Symbols on Instruments
Indicates warning or caution. If you
see this symbol on a product, you
must refer to the manuals for
specific Warning or Caution
information to avoid personal injury
or damage to the product.
Frame or chassis ground terminal.
Typically connects to the
equipment’s metal frame.
Indicates hazardous voltages and
potential for electrical shock.
Indicates that antistatic
precautions should be taken.
Indicates hot surface. Please do
not touch.
Indicates laser radiation turned on.
CSA is the Canadian certification
mark to demonstrate compliance
with the Safety requirements.
CE compliance marking to the EU
Safety and EMC Directives.
ISM GRP-1A classification
according to the international EMC
standard.
ICES/NMB-001 compliance
marking to the Canadian EMC
standard.

4Installation Guide
Safety Summary
General Safety Precautions
The following general safety precautions must be observed during all phases of operation of this instrument.
Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety
standards of design, manufacture, and intended use of the instrument.
Agilent Technologies Inc. assumes no liability for the customer's failure to comply with these requirements.
Before operation, review the instrument and manual for safety markings and instructions. You must follow these
to ensure safe operation and to maintain the instrument in safe condition.
General
This product is a Safety Class 1 instrument (provided with a protective earth terminal). The protective features of
this product may be impaired if it is used in a manner not specified in the operation instructions.
All Light Emitting Diodes (LEDs) used in this product are Class 1 LEDs as per IEC 60825-1.
Environment Conditions
This instrument is intended for indoor use in an installation category II, pollution degree 2 environment. It is
designed to operate at a maximum relative humidity of 95% and at altitudes of up to 2000 meters.
Refer to the specifications tables for the ac mains voltage requirements and ambient operating temperature
range.
Before Applying Power
Verify that all safety precautions are taken. The power cable inlet of the instrument serves as a device to
disconnect from the mains in case of hazard. The instrument must be positioned so that the operator can easily
access the power cable inlet. When the instrument is rack mounted the rack must be provided with an easily
accessible mains switch.
Ground the Instrument
To minimize shock hazard, the instrument chassis and cover must be connected to an electrical protective earth
ground. The instrument must be connected to the ac power mains through a grounded power cable, with the
ground wire firmly connected to an electrical ground (safety ground) at the power outlet. Any interruption of the
protective (grounding) conductor or disconnection of the protective earth terminal will cause a potential shock
hazard that could result in personal injury.
Do Not Operate in an Explosive Atmosphere
Do not operate the instrument in the presence of flammable gases or fumes.
Do Not Remove the Instrument Cover
Operating personnel must not remove instrument covers. Component replacement and internal adjustments must
be made only by qualified personnel.
Instruments that appear damaged or defective should be made inoperative and secured against unintended
operation until they can be repaired by qualified service personnel.

Installation Guide 5
Environmental Information

6Installation Guide
About this Guide
This guide briefly describes OBSAI Protocol Tester, and explains the tasks and functions
required for setting up and starting OBSAI Protocol Tester.
Here is how this guide is organized:
Introduction
Provides a list of equipments supplied, and information on what hardware and software
should already be there before you move ahead in this guide.
Setting Up the Hardware
Provides information on how to assemble the OBSAI Protocol Tester hardware equipments.
Installing OBSAI Protocol Tester
Explains how to install the OBSAI Protocol Tester software.
Getting Started
Explains how to start and use OBSAI Protocol Tester.

7
Agilent OBSAI Protocol Tester
Installation Guide
Agilent Technologies
1
Introduction
Equipments Supplied 8
Installation Requirements 9
This chapter provides a list of equipments supplied as part of standard
shipment to customer, and information on what hardware and software
should already be there before you move ahead in this guide.

8Installation Guide
1Introduction
Equipments Supplied
Agilent OBSAI Protocol Tester includes:
•N5341A Base Station Link Test Module
•N5340A Base Station Test Extension Module
•N2X Chassis (2- slot or 4- slot)
•The following cables:
•RP1 cable
•RP3 cable

Introduction 1
Installation Guide 9
Installation Requirements
Prior to starting the installation process, ensure that all the system
requirements to install the software components of OBSAI Protocol Tester
are in place.
In the following sections, you will learn about the requirements of the
Controller and Client PCs.
Controller PC Requirements
•Windows XP (with Service Pack 2) operating system is installed.
•At least 1 GB RAM is installed.
•At least 500 MB free disk space is available on the C drive.
•One 100BaseT LAN interface is installed for connection to the N2X
chassis.
Agilent recommends to install two 100BaseT LAN interfaces for
concurrent access to the corporate network or other clients.
You can also use the USB network adapter as a second LAN interface.

10 Installation Guide
1Introduction

11
Agilent OBSAI Protocol Tester
Installation Guide
Agilent Technologies
2
Setting Up the Hardware
Adjusting I/O Modules Inside the Chassis 12
Connecting a Chassis to the Controller PC 16
Once all the system requirements are in place, you need to start setting up
the hardware for OBSAI Protocol Tester. This requires you to set up basic
hardware, such as I/O modules, chassis, and controller PC.

12 Installation Guide
2Setting Up the Hardware
Adjusting I/O Modules Inside the Chassis
To adjust I/O modules inside a chassis, you need to know how to attach
as well as remove them to and from chassis.
Attaching an I/O module to the chassis
To attach an I/O module to the chassis:
1Insert the I/O module inside the empty slot and push it to adjust it
inside the empty slot.
Figure 1 Chassis with an Empty Slot
2Tighten the screw locks of the I/O module.
The I/O module is now attached to the chassis.

Setting Up the Hardware 2
Installation Guide 13
Removing an I/O module from the chassis
To remove an I/O module from the chassis:
1Unscrew the screw locks.
Figure 2 Screw locks on the Chassis
2Pull the extractor levers outside the chassis.
3Pull out the I/O module to remove it from the chassis.
Once you have removed the I/O module from the chassis, hold it by the
front panel and metal case, and place it on a hard and flat surface.
WARNING Do not directly touch any component on the I/O module. It may be
hot.
CAUTION Components on the I/O module are sensitive to the static electricity.
Therefore, take necessary anti-static precautions, such as wear a
grounded wrist strap, to minimize the possibility of electrostatic
damage. Also, you should not operate a chassis with empty slots.
Fill empty slots with blanking plates to ensure correct operation on
the chassis.

14 Installation Guide
2Setting Up the Hardware
Setting up the N5341A module
Once you have adjusted the modules inside the chassis, set up the N5341A
module.
Figure 3 N5341A module
To set the N5341A module
• For RP3- 01 connection: First, ensure that SFP is inserted into the
RP3- 01 optical port. Then, connect the one end of the optical fibre
cable to the RP3- 01 optical port, and the other end to device under test
(DUT).
• For RP3 connection: Connect the electrical Tx port of DUT to the Rx
ports of the N5341A module.

Setting Up the Hardware 2
Installation Guide 15
• For RP1 connection: Do the following:
•When you are using N5341A as a Base Station with CCM, connect
the RP1 receiver port of DUT to the sync burst out port of the RP1
cable, and connect the RP1 cable to the RP1 port. The reference
clock of 30.72 MHz will be available on Sys Clk Out.
•When you are using N5341A as an RF module, connect the sync
burst and system clock from DUT to the sync burst in and sys clk
in of the RP1 cable, and connect the RP1 cable to the RP1 port.
• For Ethernet connection: Connect the LAN cable to the ethernet port
of the module to provide ethernet functionality on the RP3- 01 port.
Ensure that the ethernet connection is configured at 10/100 Mbps.
This completes the hardware setup for the N5341A module.

16 Installation Guide
2Setting Up the Hardware
Connecting a Chassis to the Controller PC
After setting up the module, you can connect the chassis to the Controller
PC. For this, you can refer to the following arrangements, as applicable:
• No LAN interface available: In this situation, you can use the USB
network adapter to connect the Controller PC to the master chassis.
The advantage of this arrangement is that you can set up a test
environment easily at different places. For example, you can use a
mobile instrument, such as laptop, as Controller PC and connect it
directly to the chassis.
• Single LAN interface available: In this situation, you can:
•Connect the chassis to the Controller PC through the private LAN.
•Use the USB network adapter, which comes with OBSAI Protocol
Tester, as a second LAN interface.
The advantage of this arrangement is that you can access the Controller
PC from anywhere within the corporate LAN. For example, multiple
Client PCs can access the Controller PC through the corporate LAN.
To connect the master chassis to the Controller PC
•Connect the MDI- X port of the chassis to the Controller PC using the
standard LAN cable.
•Or, connect the MDI- X port of the chassis to the USB network adapter
using the standard LAN cable.
NOTE The two-slot chassis and the four-slot chassis have the same connector
assembly at the rear.
NOTE Do not connect the USB cable of the USB network adapter with the
Controller PC until installation wizard prompts you for it.

17
Agilent OBSAI Protocol Tester
Installation Guide
Agilent Technologies
3
Installing OBSAI Protocol Tester
Configuring the Controller PC 18
Installing OBSAI Protocol Tester 20
Setting Up the DHCP Service 25
Once you have set up the hardware, you can start installing the software
components that come with the installation CD.

18 Installation Guide
3Installing OBSAI Protocol Tester
Configuring the Controller PC
You need to configure the Controller PC to enable communication between
the Controller and Client PCs for data interchange.
In order to configure the Controller PC, you need to set up the FTP
service.
Setting Up the FTP
On the Controller PC, you need to install and enable the FTP service to
download firmware for various test modules. For this requirement, OBSAI
Protocol Tester provides a third- party FTP server named WARftp.
Remember the following about WARftp while installing OBSAI Protocol
Tester:
•WARftp is automatically installed and configured while installing OBSAI
Protocol Tester.
•WARftp is installed only when the default FTP service is not installed
on the Controller PC.
•Do not install WARftp prior to installing OBSAI Protocol Tester.
•Uninstall WARftp if it is already installed, as it halts the installation of
OBSAI Protocol Tester.
If you are not allowed to use WARftp, you can use the FTP server that
comes with the Windows operating system. In Windows, FTP is a part of
Internet Information Services (IIS).
In this section, you will learn:
•“To Install FTP
NOTE You do not have to configure the Client PC if you have planned to install
both the Controller and Client software on a single PC.
NOTE WARftp restricts many organizations, such as government organizations,
from using it. For more information on using WARftp, please refer to
www.warftp.org. Also, please refer to the license notes to find out if you
can use WARftp.
NOTE If IIS is already installed on the Controller PC, then skip to the next section.

Installing OBSAI Protocol Tester 3
Installation Guide 19
•“To Enable FTP
To Install FTP
1Click Start > Settings > Control Panel.
The Control Panel window appears.
2Double- click the Add/Remove Programs icon.
The Add/Remove Programs window appears.
3Click the Add/Remove Windows Components button.
The Windows Components Wizard dialog box appears.
4Select the Internet Information Services (IIS) check box in the
Components list box.
5Click Details.
The Internet Information Services (IIS) dialog box appears.
6Select the File Transfer Protocol (FTP) Server check box in the Sub
components of Internet Information Services (IIS) list box.
This automatically selects the Common Files and Internet Information
Services Snap- In check boxes.
7Click OK.
This saves the changes you made and closes the Internet Information
Services (IIS) dialog box.
8Click Next to install IIS.
9Click Finish to complete the installation process.
To Enab le FT P
1Click Start > Settings > Control Panel.
The Control Panel window appears.
2Double- click the Administrative Tools icon.
The Administrative Tools window appears.
3Double- click the Services icon.
The Services window appears.
4Select the FTP Publishing Service service from the Name column.
5Select Action > Start to enable FTP.

20 Installation Guide
3Installing OBSAI Protocol Tester
Installing OBSAI Protocol Tester
Once you have prepared the system for installation, you can start
installing OBSAI Protocol Tester on it. There are two ways to install
OBSAI Protocol Tester. One is to install without using the USB network
adapter, and the other is to install using the USB network adapter.
In this section, you will learn:
•“Installing OBSAI Protocol Tester without the USB Network Adapter
•“Installing OBSAI Protocol Tester with the USB Network Adapter
•“Uninstalling the USB Network Adapter
Installing OBSAI Protocol Tester without the USB Network Adapter
To install OBSAI Protocol Tester without the USB Network Adapter:
1Insert the installation CD in the CD drive.
The installation page appears.
2Click Installation.
The Install System Protocol Tester Software page appears.
3Click the System Protocol Tester hyperlink.
The File Download - Security Warning dialog box appears. This dialog
box prompts if you want to run or save the Setup.exe file.
4Click Run.
If legacy components are installed on your computer, then a message
box appears and prompts you to remove them.
NOTE Before moving to the next section, uninstall the N2X software if it is
installed on the Controller PC.
NOTE If the installation page does not appear automatically, do the following:
1Access the CD drive using Windows Explorer.
2Browse to the SystemProtocolTester folder.
3Double-click the Setup.exe file.
Running Setup.exe takes you to the message box that is otherwise
displayed when you click Run in Step 4, or to the License Agreement
screen that is otherwise displayed when you click Next in Step 6,
whichever is applicable.
