Agilent Technologies U1602B Manual

Agilent Technologies
Agilent U1602B and
U1604B Handheld Digital
Oscilloscopes
User’s and Service Guide

ii Agilent U1602B/U1604B User’s and Service Guide
Notices
© Agilent Technologies, Inc. 2006–2013
No part of this manual may be reproduced in
any form or by any means (including elec-
tronic storage and retrieval or translation
into a foreign language) without prior agree-
ment and written consent from Agilent
Technologies, Inc. as governed by United
States and international copyright laws.
Manual Part Number
U1602-90023
Edition
Tenth Edition, May 17, 2013
Printed in Malaysia
Agilent Technologies, Inc.
3501 Stevens Creek Blvd.
Santa Clara, CA 95052 USA
Warranty
The material contained in this docu-
ment is provided “as is,” and is sub-
ject to being changed, without notice,
in future editions. Further, to the max-
imum extent permitted by applicable
law, Agilent disclaims all warranties,
either express or implied, with regard
to this manual and any information
contained herein, including but not
limited to the implied warranties of
merchantability and fitness for a par-
ticular purpose. Agilent shall not be
liable for errors or for incidental or
consequential damages in connec-
tion with the furnishing, use, or per-
formance of this document or of any
information contained herein. Should
Agilent and the user have a separate
written agreement with warranty
terms covering the material in this
document that conflict with these
terms, the warranty terms in the sep-
arate agreement shall control.
Technology Licenses
The hardware and/or software described in
this document are furnished under a license
and may be used or copied only in accor-
dance with the terms of such license.
Restricted Rights Legend
U.S. Government Restricted Rights. Soft-
ware and technical data rights granted to
the federal government include only those
rights customarily provided to end user cus-
tomers. Agilent provides this customary
commercial license in Software and techni-
cal data pursuant to FAR 12.211 (Technical
Data) and 12.212 (Computer Software) and,
for the Department of Defense, DFARS
252.227-7015 (Technical Data - Commercial
Items) and DFARS 227.7202-3 (Rights in
Commercial Computer Software or Com-
puter Software Documentation).
Safety Notices
CAUTION
A CAUTION notice denotes a haz-
ard. It calls attention to an operat-
ing procedure, practice, or the like
that, if not correctly performed or
adhered to, could result in damage
to the product or loss of important
data. Do not proceed beyond a
CAUTION notice until the indicated
conditions are fully understood and
met.
WARNING
A WARNING notice denotes a
hazard. It calls attention to an
operating procedure, practice, or
the like that, if not correctly per-
formed or adhered to, could result
in personal injury or death. Do not
proceed beyond a WARNING
notice until the indicated condi-
tions are fully understood and
met.
Microsoft ®is a U.S. registered trademark
of Microsoft Corporation.

Agilent U1602B/U1604B User’s and Service Guide iii
Notices
No part of this manual may be reproduced in any form or by any means
(including electronic storage and retrieval or translation into a foreign
language) without prior agreement and written consent from Agilent
Technologies, Inc. as governed by United States and international
copyright laws.
The information contained in this document is subject to change without
notice.
To the extent allowed by local law, Agilent makes no warranty of any kind
with regard to this material, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose.
To the extent allowed by local law, Agilent shall not be liable for errors
contained herein or for incidental or consequential damages in connection
with the furnishing, performance, or use of this material.
Certification
Agilent Technologies certifies that this product met its published
specifications at the time of shipment. Agilent further certifies that its
calibration measurements are traceable to the United States National
Institute of Standard and Technology (formerly National Bureau of
Standards), to the extent allowed by that organization’s calibration facility,
and to the calibration facilities of other International Standards
Organization members.

iv Agilent U1602B/U1604B User’s and Service Guide
General Warranty
The material contained in this document is provided “as is,” and is subject
to being changed, without notice, in future editions. Further, to the
maximum extent permitted by applicable law, Agilent disclaims all
warranties, either express or implied with regard to this manual and any
information contained herein, including but not limited to the implied
warranties of merchantability and fitness for a particular purpose. Agilent
shall not be liable for errors or for incidental or consequential damages in
connection with the furnishing, use, or performance of this document or
any information contained herein. Should Agilent and the user have a
separate written agreement with warranty terms covering the material in
this document that conflict with these terms, the warranty terms in the
separate agreement will control. Duration and conditions of warranty for
this product may be superseded when the product is integrated into
(becomes a part of) other Agilent products. During the warranty period,
Agilent will, at its option, either repair or replace products which prove to
be defective. The warranty period begins on the date of delivery or on the
date of installation if installed by Agilent.
Warranty Service
For warranty service or repair, this product must be returned to a service
facility designated by Agilent. For products returned to Agilent for
warranty service, the Buyer shall prepay shipping charges to Agilent and
Agilent shall pay shipping charges to return the product to the Buyer.
However, the Buyer shall pay all shipping charges, duties, and taxes for
products returned to Agilent from another country.

Agilent U1602B/U1604B User’s and Service Guide v
Limitation of Warranty
The foregoing warranty shall not apply to defects resulting from improper
or inadequate maintenance by the Buyer, Buyer-supplied products or
interfacing, unauthorized modification or misuse, operation outside of the
environmental specifications for the product, or improper site preparation
or maintenance.
The design and implementation of any circuit on this product is the sole
responsibility of the Buyer. Agilent does not warrant the Buyer’s circuitry
or malfunctions of Agilent products that result from the Buyer’s circuitry.
In addition, Agilent does not warrant any damage that occurs as a result of
the Buyer’s circuit or any defects that result from Buyer-supplied products.
To the extent allowed by local law, Agilent makes no other warranty,
expressed or implied, whether written or oral with respect to this product
and specifically disclaims any implied warranty or condition of
merchantability, fitness for a particular purpose or satisfactory quality.
Exclusive Remedies
To the extent allowed by local law, the remedies provided herein are the
Buyer’s sole and exclusive remedies. Agilent shall not be liable for any
direct, indirect, special, incidental, or consequential damages (including
lost profit or data), whether based on warranty, contract, tort, or any other
legal theory.

vi Agilent U1602B/U1604B User’s and Service Guide
Safety Summary
The following general safety precautions must be observed during all
phases of operation of this instrument. Failure to comply with these
precautions or with specific warnings elsewhere in this manual violates
safety standards of design, manufacture, and intended use of the
instrument. Agilent Technologies, Inc. assumes no liability for the
customer’s failure to comply with these requirements.
Safety Notices
WARNING
A WARNING calls attention to a procedure, practice or the like, which, if
not correctly performed or adhered to, could result in injury or loss of
life. Do not proceed beyond a WARNING until the indicated conditions
are fully understood and met.
CAUTION
A CAUTION notice denotes a hazard. It calls attention to an operating
procedure, practice, or the like that, if not correctly performed or adhered
to, could result in damage to the product or loss of important data. Do not
proceed beyond a CAUTION notice until the indicated conditions are fully
understood and met.

Agilent U1602B/U1604B User’s and Service Guide vii
Safety Symbols
The following symbols on the instrument and in the documentation
indicate precautions which must be taken to maintain safe operation of
the instrument.
Earth ground terminal
Equipotentiality
Caution, risk of electric shock
The Instruction Documentation Symbol. The product is marked with
this symbol when it is necessary for the user to refer to the instruc-
tions in the supplied documentation.
Direct and alternating current
Direct current
Equipment protected throughout by DOUBLE INSULATION or
REINFORCED INSULATION
Caution, hot surface
CAT III Measurement category III are measurements performed in the
building installation

viii Agilent U1602B/U1604B User’s and Service Guide
Regulatory Markings
The CE mark is a registered trademark of the European
Community.This CE mark shows that the product complies with all
the relevant European Legal Directives. If it was accompanied by a
year, it indicates the year the design was approved. This ISM device
complies with Canadian ICES-001.
The CSA mark is a registered trademark of the Canadian Standards
Association.
The C-tick mark is a registered trademark of the Spectrum
Management Agency of Australia. This signifies compliance with
the Australia EMC Framework regulations under the terms of the
Radio Communication Act of 1992.

Agilent U1602B/U1604B User’s and Service Guide ix
General Safety Information
The following general safety precautions must be observed during all
phases of operation, service and repair of this instrument. Failure to
comply with these precautions or with specific warnings elsewhere in this
manual violates safety standards of design, manufacture and intended use
of the instrument. Agilent Technologies assumes no liability for the
customer’s failure to comply with these requirements.
WARNING
• All DMM/Scope COM are internally connected. Only connect
DMM/Scope COM to same potential.
• Remove all unused scope probes and test leads.
WARNING
• Do not connect DMM test leads and scope probes at the same time.
• Disconnect scope probe from instrument before using DMM
functions.
• Disconnect DMM test leads from instrument before using scope
functions.
WARNING
To avoid electrical shock or fire during battery replacement:
• Disconnect test leads, probes and power supply before opening case
or battery door.
• Do not operate the instrument with battery cover open.
• Use only specified insulated probes and leads.
• Use only U1571A, 7.2 V Ni-MH battery pack supplied by
manufacturer.

x Agilent U1602B/U1604B User’s and Service Guide
WARNING
Prevention of fire or injury:
• Use only the designated AC adapter and test leads supplied with the
instrument.
• Observe all ratings and markings on the instrument before
connecting to the instrument.
• When performing measurement, ensure that the right safety and
performance ratings of instrument and accessories are used.
Maximum Input Voltages
• Input CH1 and CH2 direct (1:1 Probe) — 300 V CAT III
• Input CH1 and CH2 via 1:10 Probe — 600 V CAT III
• Input CH1 and CH2 via 1:100 Probe — 600 V CAT III
• Meter Input —300 V CAT III, 600 V CAT II
• Scope Input — 300 V CAT III
•Voltage ratings are Vrms (50 /60 Hz) for AC sine wave and
VDC for DC applications.
Maximum Floating Voltage
• From any terminal to ground — 300 Vrms CAT III (up to 400 Hz)

Agilent U1602B/U1604B User’s and Service Guide xi
WARNING
• Plug the probe or test leads to instrument before connecting to any
active circuit for testing. Before disconnecting from instrument,
remove scope probe or test leads from active circuit.
• Do not connect the ground wire to voltages higher than 42 Vpeak (30
Vrms) from earth ground if either the DMM COM or the OSC COM is
connected to the DUT or is being accessed by the user.
• Do not expose the circuit or operate the instrument without its cover
or while power is being supplied.
• Do not use exposed metal BNC or banana plug connectors. Use only
the insulated voltage probes, test leads and adapters that come with
the instrument.
• Do not supply any voltage when measuring resistance or
capacitance in multimeter mode.
• Do not operate the instrument if it does not operate properly. Have
the instrument inspected by qualified service personnel.
• Do not operate the instrument in wet or damp environments.
• Do not operate the instrument in any environment at risk of
explosion. Do not operate the product in the presence of flammable
gases or flames.
• Keep the instrument’s surface clean and dry.
CAUTION
Prevention of electro-static discharge
Electro-static discharge (ESD) can result in damage to the components in
the instrument and accessories.
• Select a static-free work location when installing and removing
sensitive equipment.
• Handle sensitive components to the minimum extent possible. Do not
allow contacts between components and exposed connector pins.
• Transport and store in ESD preventive bag or container that protects
sensitive components from static electricity.
• The battery (optional) must be properly recycled or disposed.

xii Agilent U1602B/U1604B User’s and Service Guide

Agilent U1602B/U1604B User’s and Service Guide xiii
Waste Electrical and Electronic Equipment (WEEE) Directive
2002/96/EC
This instrument complies with the WEEE Directive (2002/96/EC) marking
requirement. This affixed product label indicates that you must not discard
this electrical/electronic product in domestic household waste.
Product Category:
With reference to the equipment types in the WEEE directive Annex 1, this
instrument is classified as a “Monitoring and Control Instrument” product.
The affixed product label is shown as below:
Do not dispose in domestic household waste
To return this unwanted instrument, contact your nearest Agilent office, or
visit:
http://www.agilent.com/environment/product
for more information.
Agilent Technologies, through Rechargeable Battery Recycling
Corporation (RBRC), offers free and convenient battery recycling options in
the U.S. and Canada. Contact RBRC at 877-2-RECYCLE (877.273.2925) or
online at: http://www.call2recycle.org/ for the nearest recycling location.

xiv Agilent U1602B/U1604B User’s and Service Guide
Environment Conditions
This instrument is designed for indoor use and in area with low
condensation. Table 1 shows general environment requirements.
Table 1 Environment Requirements
Environment Conditions Requirements
Maximum Altitude 2000 m
Temperature 0 to 50 °C (Operating)
–20 °C to 70°C (Non-operating)
Humidity 80 %RH at 40 °C (Operating at full accuracy)
CAUTION
This instrument is designed to be used for measurement in Measurement
Category III, 300V for scope measurement, Measurement Category III, 300
V and Category II, 600 V for multimeter measurement, and operate in
environment Pollution Degree 2 with the following safety compliance:
• IEC 61010-1:2001 / EN61010-1:2001
• Canada: CSA C22.2 No. 61010-1:2004
• USA: UL 61010-1:2004

Agilent U1602B/U1604B User’s and Service Guide xv
In This Guide…
1 Getting Started Chapter 1 guides you to set up and get started with
the handheld digital oscilloscope. This chapter also guides you through
the basics of the handheld scope’s front panel features.
2 Front Panel and Displays Overview Chapter 2 describes the overview of
the front panel and display of the instrument, providing you a brief picture
of the general features and functions provided by this instrument.
3 Using the Scope Functions Chapter 3 describes in detail on signal
channel coupling, waveform measuring and waveform display control.
This chapter also provides step-by-step instructions for you to get familiar
with each scope function.
4Using the Digital Multimeter Functions Chapter 4 contains reference
information to help you select and utilize multimeter functions. This
chapter also guides you on how to configure connections to perform the
meter measurements.
5Using the Data Logger Functions Chapter 5 describes the usage of the
data logging for multimeter measurement functions.
6Service and Maintenance Chapter 6 provides you with warranty
services, maintenance procedures and troubleshooting hints to solve
general problems that you may encounter with the instrument.
7Performance Tests Chapter 7 explains on how to verify the operation
and performance of the handheld scope to meet the performance
specifications.
8General Disassemble Chapter 8 contains procedures for removing
assembled parts from the handheld scope and the replaceable parts list.
9Characteristics and Specifications Chapter 9 lists specifications and
characteristics of the U1602B and U1604B handheld digital oscilloscopes.

xvi Agilent U1602B/U1604B User’s and Service Guide
Declaration of Conformity (DoC)
The Declaration of Conformity (DoC) for this instrument is available on the
Web site. You can search the DoC by its product model or description.
http://regulations.corporate.agilent.com/DoC/search.htm
NOTE
If you are unable to search for the respective DoC, please contact your
local Agilent representative.

Agilent U1602B/U1604B User’s and Service Guide xvii
Contents
1 Getting Started 1
To Inspect Package Contents 2
To Charge a Battery 5
To Power On Instrument 6
To Reset to Default Factory Settings 6
To Perform Self-Calibration 8
To Set Date and Time 9
To Set Auto-Power Off 11
To Select Quick Help Language 12
To Adjust Contrast of Display 13
To Compensate Scope Probe 14
2 Front Panel and Displays Overview 17
Front Panel Overview 17
Oscilloscope Display Overview 22
Multimeter Display Overview 24
3 Using the Scope Functions 25
Vertical Controls 26
Channel Selection for Waveform Display 26
Vertical System Setup 28
To Change Vertical Reference Ground Position 28
To Center the Waveform on the Display 29
To Change Vertical Sensitivity 30
Channel Coupling Control 31
AC Channel Coupling 31
DC Channel Coupling 32
Ground channel coupling 32

xviii Agilent U1602B/U1604B User’s and Service Guide
Probe Attenuation Control 33
Invert Control 34
Horizontal Controls 36
Vertical System Setup 36
To Change Horizontal Scale Factor 36
To Set Delay of the Waveforms 37
To Change Trigger Point Indicator 38
Horizontal Mode Functions 39
Time Base mode 39
Main/Zoom Mode 40
Roll Mode 42
Trigger Controls 43
Trigger Modes 43
Auto Trigger Mode 44
Normal Trigger Mode 44
Single Trigger Mode 44
Trigger Types 45
Edge Trigger 45
Pattern Trigger 48
Video Trigger 51
Waveform Controls 52
Normal Acquisition Mode 53
Average Acquisition Mode 53
Peak Detection Mode 54
Display Controls 55
Display Types 55
Display Contrast 56
Graticule 57
Persistence 57
Automatic Measurement 58
To Perform Automatic Measurements 59
Time Automatic Measurements 60
+ Duty 60

Agilent U1602B/U1604B User’s and Service Guide xix
–Duty 60
+Width 61
Frequency 61
Rise Time 61
Fall Time 61
Period 62
Voltage Automatic Measurements 62
Mean 62
Mean Cycle 62
Amplitude 62
Top 62
Base 63
Maximum 63
Minimum 63
Peak-to-peak 63
Phase and Delay 64
Phase 64
Delay 64
Preshoot and Overshoot 65
Preshoot 65
+Overshoot 65
–Overshoot 65
Cursor Measurement Controls 66
X-Cursor Measurement 67
Y-Cursor Measurement 70
Math Functions Control 73
Dual Waveform Math — Add, Subtract 73
Add (CH1 + CH2) 74
Subtraction (CH1 – CH2, CH2 – CH1) 75
FFT (Fast Fourier Transform) 76
Source 76
V Axis 76
Window 77
Save and Recall Controls 78

xx Agilent U1602B/U1604B User’s and Service Guide
Save and Recall Controls without USB Flash Memory
Device 78
To Save and Recall Waveform 80
To Erase Setup 82
To Erase Waveform 83
To Restore Factory Setup 84
Save and Recall Controls with USB Flash Memory Device 86
To Save Waveform 87
To Load Waveform 87
To Erase Waveform 88
To Clear Waveform 89
Autoscale and Run/Stop Controls 90
Autoscale 90
Run/Stop Controls 91
Utility Controls 92
Auto-Power Off Control 92
Language Selection 93
USB Flash Memory On/Off 93
Date and Time Setting 93
Self-Calibration 93
Probe Calibration 94
Low Battery Mode 94
Mute Function 95
4 Using the Digital Multimeter Functions 97
Voltmeter 98
Ohmmeter 100
Resistance Measurement 100
Continuity Test 102
Diode Test 103
Capacitance Measurement 105
Auxiliary Meter 106
