Perching Stool
Fixing and Maintenance Instructions
VG864X, VG865X

Fixing and Maintenance Instructions
2
INTRODUCTION
Thank you for deciding to purchase the Perching Stool from Aidapt. The Perching Stool
range is manufactured from the finest material and components available, when installed
and used correctly it is designed to give many years of reliable trouble-free service.
BEFORE USE
Carefully remove all packaging. Avoid using any knives or other sharp instruments as this
may damage the surface of the product.
Check the product for any visible damage If you see any damage or suspect a fault, do not
use your product, but contact your supplier for support.
USE OF THE PERCHING STOOL
When moving always lift the perching stool by placing you hands on the tubular metal frame
beneath the seat.
Do not allow children or unauthorised persons to play with or use the stool.
Do not rock back and forth or sideways when using the stool as this will cause
excessive stress and possible damage and failure which may cause injury.
Do not use the perching outside the home or on uneven surfaces (such as in the
garden) as this will cause stress to the legs and possible damage which may cause
injury.
Do not place fingers or foreign objects into any of the exposed tubular sections as
this can lead to serious injury.
N.B. This equipment must be installed by a competent person and a risk assessment
may be needed as to the suitability of the chair for the particular user.
G864X - Astral Perching Stool (Arms & Plain Back)
G865X - Astral Perching Stool (Arms & Padded Back)
70 kg (26 stone) weight limit.
DO NOT exceed the weight limit stated – doing so could put the user at risk.

Fixing and Maintenance Instructions
3
HEIGHT ADJUSTMENT
Remove the ‘E’ clip from the extension leg and extend all legs evenly to the desired height
ensuring you do not exceed the last punched hole of the extension leg. (see fig. 1)
Once you have achieved the desired height; reinstall the ‘E’ clip, ensuring that it has passed
through the extension leg and that it fits neatly and snugly around the outside leg. (see fig.
2)
NB. The perching stool is designed to slant to the front. Do not adjust any of
the legs to make the seat level as this will cause e cessive stress to the legs
compromising user safety and possibly leading to permanent damage of the
perching stool, including fracture of the tubular and other sections.
COMPOSITION
The perching stools are made from mild steel PPA/ epoxy coated with upholstered CMHR
foam and fire retardant vinyl seats or contoured polyurethane seats.

Fixing and Maintenance Instructions
4
TECHNICAL SPECIFICATION -VG864X

Fixing and Maintenance Instructions
5
TECHNICAL SPECIFICATION
(VG864X)
Overall height..................................................................780 - 880mm (5 adjustments)
Overall width....................................................................530mm - 565mm
Overall depth...................................................................430mm - 460mm
Transport dimensions...................................................530 x 430 x 780mm
Height to top of seat.....................................................510 - 610mm
Top of seat to top of armrest......................................140mm
Width between armrests..............................................510mm
PU seat dimensions........................................................360 x 290 x 30mm
Gross weight...................................................................5.0kg
Net weight........................................................................4.9kg
Colour = White and Blue
Packaging = unpackaged
Height from seat to top of backrest........................270mm
Footprint on lowest setting.......................................430 x 530mm
Footprint on highest setting.....................................460 x 565mm
Max user weight............................................................170kg

Fixing and Maintenance Instructions
6
TECHNICAL SPECIFICATION -VG865X

TECHNICAL SPECIFICATION
(VG865X)
Overall height..................................................................810 - 910mm(5 adjustments)
Overall width....................................................................530mm - 565mm
Overall depth...................................................................430mm - 460mm
Transport dimensions...................................................530 x 430 x 810
Height to top of seat.....................................................510 - 610mm
Top of seat to top of arm.............................................160mm
Width between armrests..............................................510mm
PU seat dimensions........................................................360 x 290 x 30mm
PU back dimensions......................................................350 x 130 x 30mm
Gross weight...................................................................5.4kg
Net weight........................................................................5.3kg
Colour = White and Blue
Packaging = unpackaged
Height from seat to top of backrest........................300cm
Footprint on lowest setting.......................................430 x 530mm
Footprint on highest setting.....................................460 x 565mm
Max user weight............................................................170kg
Fixing and Maintenance Instructions
7

8
CLEANING
Prior to cleaning remove all pin clips and the four extension legs with the ferrules fitted.
Clean these items separately to the main frame.
Clean the upholstery using a non-abrasive cleaner or mild detergent with a soft cloth.
Abrasive cleaners e.g. AJAX and/ or abrasive cleaning pads will seriously damage the
upholstery beyond repair.
REISSUE
If you reissue or are about to reissue this product, please thoroughly check all components
for their safety.
This includes:
•Tightness of all nuts/bolts/castors and other screw in/bolt in/push in components.
•Also check all upholstery (if applicable) for security, splits, exposed staples, etc.
If in any doubt, please do not issue or use, but immediately contact your supplier for
service support.
When reissuing, a risk assessment may be required as to the suitability of the chair for
a particular user.
CARE & MAINTENANCE
Please make a safety check of the product at regular intervals or if you have any concerns.
IMPORTANT INFORMATION
The information given in this instruction booklet must not be taken as forming part of or
establishing any contractual or other commitment by Aidapt Bathrooms Limited, Aidapt
(Wales) Ltd or its agents or its subsidiaries and no warranty or representation concerning the
information is given.
Please exercise common sense and do not take any unnecessary risks when using this
product; as the user you must accept liability for safety when using the product.
Please do not hesitate to contact the person who issued this product to you or the
manufacturer (detailed below) if you have any queries concerning the assembly/use of your
product.
Aidapt Bathrooms Ltd, Lancots Lane, Sutton Oak, St Helens, WA9 3EX
Telephone: [phone] • Fa : [phone] • Web: www.aidapt.co.uk
Email: • [email protected]
