FEATURES:
• High power 500mW with 10dBi Directional High Gain Antenna for extra
long range access (Data rate can still reach 50Mbps @ 2 miles*)
• Compliant with standard IEEE 802.11b/g and SuperG™, highest data
rate of up to 108Mbps*
• IP 67/ 68 industrial level weather proof housing — Diecast Watertight
Housing
• Integrated Power over Ethernet (PoE)
• Functions:
♦ Access Point: can be deployed as a traditional fixed wireless Ac-
cess Point
♦ WDS: expands wireless service with WDS Link
♦ CPE (Customer Premises Equipment): connects to a Wireless
Internet Service Provider's (WISP) and functions as a wireless
gateway with NAT and DHCP Server enabled.
Wireless G 2.4GHz 500mW
OutdoorAP Bridge
w/10dBi Antenna
Model: APO1010
Tel: [phone] • [e-mail] • www.airlink101.com

FEATURES:
• High power 500mW for extra long range access (Data rate can still
reach 50Mbps @ 2 miles*)
• Compliant with standard IEEE 802.11b/g and SuperG™, highest data
rate of up to 108Mbps*
• Built-in 2 N-Female Antenna connectors for external antenna gain
• IP 67/ 68 industrial level weather proof housing — Diecast Watertight
Housing
• Integrated Power over Ethernet (PoE)
• Functions:
♦ Access Point: can be deployed as a traditional fixed wireless Ac-
cess Point
♦ WDS: expands wireless service with WDS Link
♦ CPE (Customer Premises Equipment): connects to a Wireless
Internet Service Provider's (WISP) and functions as a wireless
gateway with NAT and DHCP Server enabled.
Model: APO1000
Tel: [phone] • [e-mail] • www.airlink101.com
Wireless G 2.4GHz 500mW
OutdoorAP Bridge

Standards
• IEEE 802.11b / g
• IEEE 802.3, 802.3u compliant
Frequency Range
• 2.4GHz
Interface
• 1 x 10/100Mbps Ethernet port with weather-
proof connector (Power Over Ethernet)
• Reset Button
Antenna Type
• Built-in 1 x N-Female connectors
(APO1000)
• Built-in 10dBi Directional Antenna
(APO1010)
Security
• WPA / WPA2-PSK
• WEP 64 / 128bit
• EAP, PEAP, 802.11i
• Radius Server
• VLAN Assignment on BSSID
Data Transfer Rate
• IEEE802.11g / Super G™:
6,9,12,18,24,36,48,54, 108Mbps (auto
sensing)
• IEEE801.11b: 1,2,5,11Mbps (auto sensing)
Frequency Range
• 2.412 – 2.462GHz(USA)
RF Output Power
• 500mW
Transmit Power
• 27dBm :6MB/1MB, 23dBm:54MB
Receive Sensitivity
• 1Mbps: -96dBm, 6Mbps:-93dBm,11Mbps:-
89dBm,54Mbps:-74dBm
Temperature
• Operating: -30 °C ~ 60 °C
• Storage: -30 °C ~ 85 °C
Humidity
• Operating: 100% Non-Condensing
• Storage: 100% Non-Condensing
LEDs
• 1 x Power, 1 x LAN, 1 x WLAN, 3 x Wireless
Strength
Power Supply
• DC Output : 12V VDC, 1.5A input (PoE
Power Injector)
• AC Input : 110~220V
Unit Weight
• 0.66 kg
Unit Dimensions
• 162(L) x 102(W) x 58(H) mm
Form Factor
• Wall Mount and Pole Mount Ability, Die-Cast
aluminum Enclosure with IP67/68 Rating
Package Contents
• Outdoor AP/Bridge
• Ethernet Passive Power Injector and Power
cord
• Manual CD
• Quick Installation Guide
• Wall/Pole Mounting Bracket
Warranty
• Limited 1-year warranty
Certification
• FCC, CE
UPC Code
• 6 58729 08 192 5 (APO1010)
• 6 58729 08 193 2 (APO1000)
*Theoretical maximum wireless signal rate derived from IEEE standard 802.11 specifications. Actual data throughput will vary. Network conditions
and environmental factors, including volume of network traffic, building materials and construction, mix of wireless products used, radio frequency
interference (e.g., cordless telephones and microwaves) as well as network overhead lower actual data throughput rate. Compatibility with 802.11n
devices from other manufactures is not guaranteed. Specifications are subject to change without notice. Photo of product may not reflect actual con-
tent. All products and trademarks are the property of their respective owners. Copyright ©2010 Airlink101®
Tel: [phone] • [e-mail] • www.airlink101.com
