Preface
This service manual explains about the cautions for maintenance jobs and is to serve a
guide for the electric system, and troubleshooting for service personnel. Fundamental
matters and other things already mentioned in the “Instruction Manual” and the “Parts
Catalogue” are omitted to avoid duplication. Therefore, for the operation and handling of
this unit, we request you to refer to the instruction manual and caution plates, and
further for the structure and components of the unit, please refer to the “Parts
Catalogue” separately to be supplied with the unit.
If you should find any description which does not coincide with the instruction manual
and parts catalog, we request you to make sure to start the job after clarifying it.
Service personnel is required to safely take quick and proper countermeasures as well
as to use correct technology of maintenance in case of field services and periodical
maintenance. It is important that service personnel should have proper and sufficient
knowledge about the structure and function of the unit and should be well familiar with
such technique mentioned in them.
Regarding the part numbers mentioned in this manual, we request you to refer to the
Parts catalogue separately supplied together with the unit, because the parts numbers
in this manual are sometimes changed.
Copies of this service manual are intended to be distributed to limited numbers
of our customers. The unauthorized reproduction or distribution of this service
manual is prohibited.
Discount-Equipment.com

Table of Contents
1. Specification -------------------------------------------------------------------------------------- 1-1
1.1 Specifications ----------------------------------------------------------------------------------------------------------- 1-1
1.2 Set Value ----------------------------------------------------------------------------------------------------------------- 1-2
1.3 Outline Drawing -------------------------------------------------------------------------------------------------------- 1-3
1.4 Internal Components and Part Names ---------------------------------------------------------------------------- 1-5
1.5 Instrument Panel ------------------------------------------------------------------------------------------------------- 1-8
1.5.1 Indicator lamp･Warning / Emergency display --------------------------------------------------------------- 1-9
1.6 Capacity Control Device ---------------------------------------------------------------------------------------------- 1-10
1.7 Piping Diagram --------------------------------------------------------------------------------------------------------- 1-12
1.8 Fuel Piping --------------------------------------------------------------------------------------------------------------- 1-14
2. Maintenance --------------------------------------------------------------------------------------- 2-1
2.1 Cautions for Overhauling --------------------------------------------------------------------------------------------- 2-1
2.1.1 Precautions before starting work ------------------------------------------------------------------------------- 2-1
2.1.2 Disassembly and reassembly ----------------------------------------------------------------------------------- 2-1
2.2 Tightening Torque ----------------------------------------------------------------------------------------------------- 2-3
2.2.1 General bolts and nuts tightening torque --------------------------------------------------------------------- 2-3
2.2.2 Tightening torque of such important quality parts as bolts and nuts ----------------------------------- 2-4
2.3 How to Adjust Regulator --------------------------------------------------------------------------------------------- 2-7
2.4 Maintenance and Adjustment of Pressure Control Valve ---------------------------------------------------- 2-8
2.5 Change O-ring of Unloader ------------------------------------------------------------------------------------------ 2-10
2.6 Change O-ring of Auto-relief Valve and Vacuum Relief Valve ---------------------------------------------- 2-10
2.7 Change Oil Separator ------------------------------------------------------------------------------------------------- 2-11
2.8 Change of Pellet assembly of By-pass Valve ------------------------------------------------------------------- 2-12
2.9 Clean the Strainer Provided inside the Engine Feed Pump ------------------------------------------------- 2-13
2.10 Supply Grease to Trailer Hub Bearing ---------------------------------------------------------------------------- 2-13
2.11 Supply Grease to Leaf Spring Pin --------------------------------------------------------------------------------- 2-13
2.12 Check and Confirm that the Fixing Bolts for the Drawbar are Properly Tightened --------------------- 2-13
2.13 Manual Air Bleeding Method for Fuel Line System ------------------------------------------------------------ 2-14
2.14 Clean inside of Fuel Tank -------------------------------------------------------------------------------------------- 2-14
2.15 Clean Drain Separator (Aftercooler type only) ------------------------------------------------------------------ 2-15
2.16 Values of Various Adjustments of Engine ------------------------------------------------------------------------ 2-15
2.17 Suction Control Valve (SCV) Replacement Procedure ------------------------------------------------------- 2-16
3. Electric System ----------------------------------------------------------------------------------- 3-1
3.1 Electronic Control System of Engine ------------------------------------------------------------------------------ 3-1
3.1.1 Electronic control fuel injection system (Common rail type) --------------------------------------------- 3-1
3.1.2 EGR (Exhaust gas recirculation) control --------------------------------------------------------------------- 3-3
3.1.3 Acceleration control ---------------------------------------------------------------------------------------------- 3-4
3.1.4 Preheating control ------------------------------------------------------------------------------------------------- 3-4
3.2 Accelerator Controller ------------------------------------------------------------------------------------------------- 3-5
3.3 Engine Controller (ECM) --------------------------------------------------------------------------------------------- 3-8
3.4 Emergency Controller ------------------------------------------------------------------------------------------------- 3-17
3.5 Alternator ----------------------------------------------------------------------------------------------------------------- 3-25
3.6 Starter --------------------------------------------------------------------------------------------------------------------- 3-26
3.7 Solenoid Valve for Starting Unloader ----------------------------------------------------------------------------- 3-27
3.7.1 Unloader piston actuation:SV1 ------------------------------------------------------------------------------- 3-27
3.7.2 Unloader spring chamber negative pressure:SV2 ------------------------------------------------------ 3-27
3.8 Air Filter Indicator (Engine / Air-end common) ------------------------------------------------------------------- 3-28
3.9 Pressure Sensor (Secondary pressure of regulator detect) ------------------------------------------------- 3-28
Discount-Equipment.com

Table of Contents
3.10 Discharge Air Temperature･Separator Air Temperature･Engine Coolant Temperature Sensor
(Thermister) - 3-29
3.11 Fuel Meter (Display) --------------------------------------------------------------------------------------------------- 3-29
3.12 Sending Unit ------------------------------------------------------------------------------------------------------------- 3-30
3.13 Fuel Air-bleeding Electromagnetic Pump (Type with built-in filter) ----------------------------------------- 3-31
3.14 Main･Safety Relay, MR･SR ----------------------------------------------------------------------------------------- 3-31
3.15 Electromagnetic Pump Relay, FR ---------------------------------------------------------------------------------- 3-32
3.16 Glow Relay, GR -------------------------------------------------------------------------------------------------------- 3-32
3.17 Starter Relay, SY ------------------------------------------------------------------------------------------------------- 3-32
3.18 Electronic Control Engine Component ---------------------------------------------------------------------------- 3-33
3.18.1 Supply pump ------------------------------------------------------------------------------------------------------- 3-34
3.18.2 Suction control valve (SCV) ------------------------------------------------------------------------------------ 3-34
3.18.3 Fuel temperature (FT) sensor ------------------------------------------------------------------------------- 3-35
3.18.4 Common rail ------------------------------------------------------------------------------------------------------- 3-35
3.18.5 Pressure limiter --------------------------------------------------------------------------------------------------- 3-36
3.18.6 Common rail pressure sensor --------------------------------------------------------------------------------- 3-36
3.18.7 Injector -------------------------------------------------------------------------------------------------------------- 3-37
3.18.8 Engine coolant temperature (ECT) sensor ----------------------------------------------------------------- 3-37
3.18.9 Crankshaft position (CKP) sensor ---------------------------------------------------------------------------- 3-38
3.18.10 Camshaft position (CMP) sensor ------------------------------------------------------------------------- 3-39
3.18.11 Engine oil pressure sensor ----------------------------------------------------------------------------------- 3-39
3.18.12 Barometric pressure sensor -------------------------------------------------------------------------------- 3-40
3.18.13 Intake air temperature (IAT) sensor ------------------------------------------------------------------------ 3-40
3.18.14 EGR position sensor ------------------------------------------------------------------------------------------- 3-41
3.18.15 Boost pressure sensor --------------------------------------------------------------------------------------- 3-42
3.18.16 Boost temperature sensor ------------------------------------------------------------------------------------ 3-42
4. Troubleshooting --------------------------------------------------------------------------------- 4-1
4.1 Repairing Procedures ------------------------------------------------------------------------------------------------- 4-1
4.1.1 Safety caution ------------------------------------------------------------------------------------------------------- 4-1
4.1.2 Caution during failure diagnosis -------------------------------------------------------------------------------- 4-1
4.1.3 How to use the failure diagnosis ----------------------------------------------------------------------------- 4-2
4.2 Failures of Compressor and Engine ------------------------------------------------------------------------------- 4-3
4.2.1 At start-up, starter rotates slowly ------------------------------------------------------------------------------- 4-3
4.2.2 Starter turns, but engine will not start ------------------------------------------------------------------------- 4-3
4.2.3 Engine will not turn to meet rated pressure -------------------------------------------------------------- 4-3
4.2.4 Engine revolutions will drop before rises up to rated pressure ----------------------------------------- 4-4
4.2.5 Engine will not turn to meet rated revolutions --------------------------------------------------------------- 4-4
4.2.6 Minimum speed not available even upon no-load operation ---------------------------------------- 4-5
4.2.7 Safety valve bursts out during unloaded operation -------------------------------------------------------- 4-5
4.2.8 Oil mixed found in delivery air ----------------------------------------------------------------------------------- 4-6
4.2.9 Water found mixed in discharge air (Aftercooler type) ------------------------------------------------ 4-6
4.2.10 Discharge air is insufficient ------------------------------------------------------------------------------------ 4-7
Discount-Equipment.com

Table of Contents
4.3 Operation of Emergency Switch ------------------------------------------------------------------------------------ 4-8
4.3.1 Discharge air temperature (or separator air temperature) is displayed
abnormality-code and engine will stop ------ 4-8
4.3.2 Engine oil pressure is displayed abnormality-code and engine will stop -------------------------- 4-9
4.3.3 Engine coolant temperature is displayed abnormality-code and engine will stop ------------- 4-10
4.3.4 Engine RPM drop is displayed abnormality-code and engine will stop ---------------------------- 4-10
4.4 Others --------------------------------------------------------------------------------------------------------------------- 4-11
4.4.1 Abnormality-code is not shown, engine will stop ----------------------------------------------------------- 4-11
4.5 Explanation of Trouble Diagnosis ---------------------------------------------------------------------------------- 4-12
4.6 Engine Trouble Diagnosis Function ------------------------------------------------------------------------------- 4-14
4.6.1 Engine trouble diagnosis ---------------------------------------------------------------------------------------- 4-14
4.6.2 How to delete diagnostic trouble codes (DTC) ------------------------------------------------------------ 4-18
4.6.3 List of diagnostic trouble codes (DTC) ----------------------------------------------------------------------- 4-19
4.6.4 Diagnostic service tool (EMPSⅢ) ----------------------------------------------------------------------------- 4-32
5. References ----------------------------------------------------------------------------------------- 5-1
5.1 Consumable Parts and Electrical Appliances ------------------------------------------------------------------- 5-1
5.2 Engine Wiring Diagram ----------------------------------------------------------------------------------------------- 5-3
Discount-Equipment.com

1. Specification
1-1
1.1 Specifications
Item unit PDS400S<SC>-6C3
●Weight・Mass
Overall length in.(mm) 172.0(4,370)
Overall length (Bonnet only) in.(mm) 105.5(2,680)
Overall width in.(mm) 77.8(1,975)
Overall height in.(mm) 65.0(1,650)
Tire Tobelocallyprocured
Net dry mass lb(kg) 4,189<4,244>
(1,900<1,925>)
Operating mass lb(kg) 4,652<4,707>
(2,110<2,135>)
●Compressor
Free air delivery cfm(m3/min) 400(11.3)
Working pressure psi(MPa)[bar] 100(0.69)[ 6.9]
Pressure of pressure control valve psi(MPa)[bar] 58( 0.4)[ 4.0]
Burst pressure of safety valve psi(MPa)[bar] 150(1.03)[10.3]
Ambient conditions: temperature °F(℃) -59 to +104(-15 to +40)
Ambient conditions: altitude yd(m) less than 1,640(1,500)
●Engine
Type
ISUZU CI-4JJ1XYCD-01
ISUZU CI-4JJ1XYCD-01G
Rated output hp/min-1
(kW/min-1) 113.2/2,200(84.4/2,200)
Fuel consumption g/kW･h 209
Rated RPM min-1 2,200
RPM at unload conditions min-1 1,300
Net dry mass lb(kg) 639(290)
●Lubricating oils
Engine oil capacity (H/L level) gal.(L) 3.9/2.9(15/11)
Compressor oil capacity
(including receiver tank and oil cooler
etc.)
gal.(L) 13.5(51)
Compressor oil
Ambient temperature: 5°F to 104°F (-15 ℃ to +40 ℃ )
HULS : ANDEROL 3032
MOBIL : RARUS SHC 1024
TEXACO: SYN-STAR DE 32
Coolant capacity gal.(L) 2.9(11)
Fuel tank capacity gal.(L) 47(178)
●Fuel consumption ratio
(for reference only)
At no load gal./Hr(L/Hr) 2.1( 7.8)
At 50% gal./Hr(L/Hr) 3.4(12.6)
At 70% gal./Hr(L/Hr) 4.0(15.1)
At full load gal./Hr(L/Hr) 4.9(18.7)
Discount-Equipment.com

1. Specification
1-2
1.2 Set Value
Item unit PDS400S<SC>-6C3
●Emergency stop devices
Discharge air temperature °F(℃) 248(120)
Coolant temperature °F(℃) 221(105)
Engine oil pressure abnormality psi(MPa)[bar] 14.6(0.1)[1.0]
Discharge air temperature at
separator °F(℃) 248(120)
Engine speed down min-1 1,200
Discharge air temperature sensor
disconnection - Detection of disconnection
Discharge air temperature sensor
disconnection at separator - Detection of disconnection
●Warning devices
Discharge air temperature °F(℃) 239(115)
Coolant temperature °F(℃) 212(100)
Compressor air filter clogging psi(kPa)[bar] 0.9(6.23)[0.0623]
Engine air filter clogging psi(kPa)[bar] 0.9(6.23)[0.0623]
Battery abnormality - When not charged
Discharge air temperature at
separator °F(℃) 239(115)
Boost temperature rise °F(℃) 185( 85)
Coolant temperature sensor
disconnection °F(℃) Detection of disconnection
●Set value
Pressure control valve psi(MPa)[bar] 58(0.40)[ 4.0]
Actuating pressure of safety valve psi(MPa)[bar] 150(1.03)[10.3]
Unload starting pressure psi(MPa)[bar] 100(0.69)[ 6.9]
●Engine RPM
Rated RPM min-1 2,200
RPM at no load min-1 1,300
●Indications of gauges or instruments
during operation
Discharge pressure gauge(at full load) psi(MPa) 58 to 100(0.40 to 0.69)
Discharge pressure gauge(at no load) psi(MPa) 100 to 123(0.69 to 0.85)
Discount-Equipment.com

1. Specification
1-3
1.3 Outline Drawing
PC14064E
Unit : in.
Discount-Equipment.com

1. Specification
1-4
PC14064E
Unit : mm
Discount-Equipment.com

1. Specification
1-5
1.4 Internal Components and Part Names
[Standard type]
PC13022
PDS400S-6C3
No. Description No. Description
1 Control panel 13 Engine oil filter
2 Auto-relief valve 14 Engine
3 Vacuum relief valve 15 Exhaust pipe
4 Pressure control valve 16 Fan
5 Pressure sensor 17 Intercooler
6 Pressure regulator 18 Oil cooler
7 Solenoid valve for starting unloader (SV2) 19 By-pass valve
8 Safety valve 20 Exhaust muffler
9 Air filter indicator 21 Alternator
10 Air filter (For compressor air-end) 22 Turbo charger
11 Air-end 23 Battery
12 Engine oil filler port (Used as oil level gauge) 24 Discharge pipe
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
24 23 22 21 20
Discount-Equipment.com

1. Specification
1-6
PC13023
PDS400S-6C3
No. Description No. Description
25 Radiator 39 Service valve
26 Reserve tank 40 Separator receiver tank drain valve
27 Supply pump 41 Compressor oil level gauge
28 Air filter (For engine) 42 Compressor oil filler port
29 Vacuator valve (For engine) 43 Sending unit
30 Fuel pre-filter 44 Fuel tank
31 Priming pump 45 Starter
32 Fuel filter 46 Fuel air-bleeding electromagnetic pump
33 Coupling 47 Fuel filler cap
34 Vacuator valve (For compressor air-end) 48 Fuel tank drain valve
35 Compressor oil filter 49 Engine oil drain valve
36 Solenoid valve for starting unloader (SV1) 50 Oil cooler drain valve
37 Valve for low temperature start 51 Radiator drain valve
38 Separator receiver tank
25 26 27 28 29 30 31 32 33 34 35 36 37 38
51 50 49 48 47 46 45 44 43 42 41 40 39
Discount-Equipment.com

1. Specification
1-7
[Aftercooler type]
Only the special devices additionally or optionally attached to the standard machine are shown in
the following figure. For the details of the other standard devices, refer to page 1-5 & 1-6.
PC13024
PDS400SC-6C3
No. Description No. Description
1 Aftercooler 3 Drain port of aftercooler
2 Drain separator 4 Drain warming valve
1 2
4 3
Discount-Equipment.com

1. Specification
1-8
1.5 Instrument Panel
Each display of the operation panel is illustrated as follows.
Read and fully understand the explanations and be sure to operate safely:
Digital monitor
When power is supplied, revolution speed (lamp lighting) is indicated.
※In case that discharge air temperature is below 68°F, “－－－L” is indicated on screen.
[ENG.SPEED]
(min-
1
)
[ DISCHARGE TEMP. ]
(°F)
[WATER TEMP.]
(
°F )
[HOUR METER]
(Hr)
Push
Whenever indication selector switch is pushed every time, indication
screen is changed by turns as shown above.
Push Push
A120171
Lamp
Error code / Reset switch
When this switch is pushed on while lamp is blinking / lighting, it shows error
code.
When starter switch is placed to “STOP”, displayed screen is reset.
Blinking: Warning Lighting: Emergency
Discharge air pressure gauge
For indication of working
pressure
Starter switch
For starting and
stopping engine
Engine trouble diagnosis
In case of any error or trouble, diagnosis lamp continues lighting.
Pushing the diagnosis switch continuously makes the diagnosis lamp
flash, and then it will indicate contents of error or troubles.
Discount-Equipment.com

1. Specification
1-9
1.5.1 Indicator lamp･Warning / Emergency display
[Indicator lamp] Turn the starter switch to “RUN” position. Then the lamp goes on.
Item Contents Measures Monitor
GLOW
When starter switch is placed to “RUN”,
the lamp goes on and after preheating is
finished, the lamp will be off. ―
CHARGE
Lamp goes on when alternator is not
charging.
Check wiring
Check alternator
[Warning display] This displays such trouble of less importance when it occurs during operation,
but the unit continues operating.
When any abnormality happens, a ERROR CODE lamp flickers. In this time
when ERROR CODE switch is pressed, a error code will be displayed.
Item Error
code Contents Warning set value
DISCHARGE TEMP. H A1 When air temperature at the outlet of the
air-end reaches warning temperature. 239°F(115℃)
WATER TEMP. H A2 When coolant temperature reaches warning
temperature. 212°F(100℃)
COMP. AIR FILTER A3 When air filter gets clogged and suction
resistance increases.
0.062bar
(6.23kPa)
ENG. AIR FILTER A4
CHARGE A5 Belt loosened and/or cut
Faulty generation of alternator －
DISCHARGE AIR TEMP.
AT SEPARATOR
A6 When air temperature at the outlet of the
separator reaches warning temperature. 239°F(115℃)
BOOST TEMP. A7 When boost temperature reaches warning
temperature. 185°F(85℃)
WATER TEMP. SENSOR A8 When engine coolant temperature sensor is
disconnected. －
[Emergency display] When any trouble takes place during operation, this displays and it stops as
an emergency stop.
When any abnormality happens, a ERROR CODE lamp lights. In this time
when ERROR CODE switch is pressed, a error code will be displayed.
Item Error
code Contents Abnormal set value
DISCHARGE TEMP. E E1 When air temperature at the outlet of the
air-end reaches abnormal temperature. 248°F(120℃)
WATER TEMP. E E2 When coolant temperature reaches abnormal
temperature. 221°F(105℃)
ENG. OIL PRESS. E3 When engine oil pressure drops. 1.0bar
(0.1MPa)
DISCHARGE AIR TEMP.
AT SEPARATOR
E4 When air temperature at the outlet of the
separator reaches abnormal temperature. 248°F(120℃)
ENG. SPEED DOWN E5 When engine revolution speed drops. Lower than
1,200min-1
DISCHARGE TEMP.
SENSOR
E6 When air temperature sensor at the outlet of the
air-end is disconnected. －
DISCHARGE AIR TEMP.
SENSOR AT SEPARATOR
E7 When air temperature sensor at the outlet of the
separator is disconnected. －
Discount-Equipment.com

1. Specification
1-10
1.6 Capacity Control Device
PC13052-3E
Step Response
Start
Compressed air is sent into the unloader chamber through starting
unloader solenoid valve SV1 to fully open the unloader valve. Further, as
COM-NC for the solenoid valve SV2 is connecting, the spring chamber becomes
negative pressure, and unloader valve fully closes at lower pressure. Thus
starting unloader operation is performed.
●In cold seasons, it opens the low temperature starting valve, and it sends
compressed air in separator receiver tank into the unloader and the unloader
valve can be fully closed at low pressure. Thus, the load for starting can be
reduced.
●SV1 and SV2 solenoid valves operate 30 seconds at the discharge air
temperature of higher than 10℃, and the temperature should be higher than
10℃or it operates 120 seconds.
●Engine (revolution) speed is fixed at 1,600min-1 for the above mentioned
operation conditions.
Load operation
So that SV1 and SV2 solenoid valves are to be closed, the flow of air sent into
the chamber increases and decreases according to the increase and decrease
of discharge pressure. Accordingly, the position of unloader valve and engine
(revolution) speed change. Automatically discharge air volume can be controlled
steplessly from 0 – 100%.
Discount-Equipment.com

1. Specification
1-11
Step Response
Suction port closing
unload operation
When air consumption decreases and it exceeds the rated pressure, the pressure
regulator operates to close the unloader valve. At the same time, the pressure
sensor provided at the secondary side of pressure regulator detects and sends to
engine controller the signal of engine speed lowering. At the unload condition,
the inside of air end becomes high vacuum and it causes vacuum noise. In order
to prevent this noise, it opens vacuum relief valve to prevent the compressor air
end from becoming vacuum.
●Engine (revolution) speed at unload conditions is operated at 1,600min-1 under
less than discharge air temperature less than 60℃, and when it becomes
higher than 60℃, the speed will be 1,300min-1.
Stop
Detecting the pressure inside compressor air end, the auto-relief valve operates,
and the compressed air in separator receiver tank is automatically relieved to
the atmosphere from unloader primary side.
Discount-Equipment.com

1. Specification
1-12
1.7 Piping Diagram
[Standard type]
A120194E
Discount-Equipment.com

1. Specification
1-13
[Aftercooler type]
A120195E
Discount-Equipment.com

1. Specification
1-14
1.8 Fuel Piping
PC13053E
Discount-Equipment.com
