Airwell RCW11 Installation instructions

IMPORTANT NOTE:
Read this manual carefully before
installing or operating your wired
remote controller. Make sure to save
this manual for future reference.
RCW11 - WIRED REMOTE CONTROLLER
Installation and Owner’s Manual
COMPATIBLE FOR DDM, CDM, FDM
RCW11-20190318-Rev1.1

●This manual gives detailed description of the precautions that should
be brought to your attention during operation.
●To ensure the correct service of the wired controller, read this manual
carefully before using the unit.
●Keep this manual after reading for future reference.

CONTENTS
1. SAFETY PRECAUTION.................................................................................................... 1
2. INSTALLATION ACCESSORY..........................................................................................2
3. INSTALLATION METHOD...............................................................................................4
5. SPECIFICATION..............................................................................................................16
6.WIRED CONTROLLER FEATURES AND FUNCTIONS...........................................17
7.WIRED CONTROLLER DISPLAY..................................................................................18
8.WIRED CONTROLLER BUTTONS...............................................................................19
9. PREPARATORY OPERATION.......................................................................................20
10. OPERATION...................................................................................................................21
11.TIMER FUNCTIONS.....................................................................................................27
12.WEEKLY TIMER.............................................................................................................30
13. SET EXTERNAL STATIC PRESSURE................................................................37
14. FAULT ALARM HANDING.........................................................................................38
15.TECHNICAL INDICATION AND REQUIREMENT .................................................38

 Read the safety precautions carefully before installing the unit.
 Stated below are important safety issues that must be obeyed.
Means improper handling may lead to personal death or severe injury.
Means improper handling may lead to personal injury or property loss.
WARNING
CAUTION
Please entrust the distributor or professionals to install the unit.
Installation by other persons may lead to imperfect installation, electric shock or fire.
Adhere to this installation manual.
Imporper installation may lead to electric shock or fire.
Reinstallation must be performed by professionals.
WARNING
Do not install the unit in a place vulnerable to leakage of flammable gases.Once
flammable gases are leaked and left around the wire controller, fire may occure.
Do not operate with wet hands or let water enter the wire controller. Otherwise,
electric shock may occur.
The wiring should adapt to the wire controller current. Otherwise, electric leakage or
heating may occur and result in fire.
The specified cables shall be applied in the wiring.No external force may be applied
to the terminal. Otherwise, wire cut and heating may occur and result in fire.
NOTE
Do not uninstall the unit randomly.
Random uninstalling may lead to abnormal operation, heating or fire of the air condition.
1
2
3
4
1. SAFETY PRECAUTION
1

2
2. INSTALLATION ACCESSORY
Don’t install at the place where cover with heavy oil, vapor or sulfureted
gas, otherwise, this product would be deformed that would lead to
system malfunction.
Select the installation location
Preparation before installation
1. Please confirm that all the following parts you have been supply.
2. Prepare the following assemblies on the site.
1
2
3
4
5
3
2
M4X20 (For Mounting on the Wall)
M4X25 (For Mounting on switch box)
1
2
1
6
7
8
3
2
No. Name Qty. Remarks
Wire controller
Installation and owner’s manual
For Mounting on the Wall
Switch box
Wiring Tube(Insulating
Sleeve and Tightening
Screw)
Qty.(embeded
into wall)
Plastic screw bars
Screws
Wall plugs
For fixing on switch box
(Optional)
No. Name Remarks
Specification
(only for reference)
Screws
1
1
1
Battery
The connection cable
1
1

3
2. INSTALLATION ACCESSORY
WIRED CONTROLLER INSTALLATION PRECAUTION
1. This manual provides the wired controller installation method. Refer
to the wiring diagram in this installation manual to wire the wired
controller with the indoor unit.
2. The wired controller works in a low voltage loop circuit. Do not
connect directly to 208/230V and 460V. Do not wire this kind of wire
into a loop. Wiring clearance between the configured tubes should
range 11.81−19.69 inches (30−50 cm) or above.
3. The shielded wire of the wired controller must be properly grounded.
4. Upon finish the wire controller connection, do not employed
tramegger to detect the insulation.

4
3. INSTALLATION METHOD
Fig 3-1
1.Wired Remote Controller Dimensions
123mm
(4.8”)
120mm
(4.7”) 18.5mm
(0.7”)
83.5mm
(3.3”)
46mm
(1.8”)
62mm
(2.4”)
Fig 3-2
2.Wiring Connection Diagram
red
black
yellow
brown
red
black
yellow
brown
Insert of the
mainboard CN40
Wire controller Indoor unit mainboard
4-Core Shield Cable, the length
is decided by installation
-----------------------------------
-----------------------------------
-----------------------------------
-----------------------------------

5
3. INSTALLATION METHOD
Connect the female joint of the wires group from the mainboard
with the male joint of the connective wires group. (See Fig.3-3)
Connect the other side of the connective wires group with the male
joint of the wires group leads from the wire controller.(See Fig.3-3)
Fig 3-3
Mainboard
4-core shielding wire
3.Wiring figure
The connection cable
CN40
Install the Adapter Board and the Display Board on the High Wall
(See the Appendix for instructions).

6
3. INSTALLATION METHOD
Fig 3-4
Fig 3-5
4.Wire controller upper part Remove
Insert a flat screwdriver into the slots in the
lower part of the wire controller (2 places).
Remove the upper part of the wire controller
(Fig.3-4)
For surface mounting, fasten the back plate on the wall with the 3
screws (M4x20) and plugs. (Fig.3-5)
Slots
NOTE:The PCB is mounted in the upper part
of the wired controller. Be careful not to
damage the board with the screwdriver.
5. Fasten the wire controller back plate
Back plate
Screws (M4×20)

7
Place the battery in the unit and ensure the positive side of the
battery is in accordance with the polarity markings.(See Fig.3-7)
Set the correct time before operating. Batteries in the wired controller
can maintain the correct time during a power failure. When the power
is restored and the displayed time is not correct, replace the battery.
Fig 3-7
Fig 3-6
3. INSTALLATION METHOD
For switch box mounting, fasten the back plate on the switch box with
2 screws (M4x25) and fasten it on the wall with 1 screw (M4x20).
(Fig.3-6)
6. Battery installation
NOTE: Place on a flat surface. Be careful not to distort the wire
controller’s back plate by over−tightening the mounting screws.
Switch box
Back plate
Screw (M4×20)
Screws (M4×25)

8
3. INSTALLATION METHOD
7. Wire the indoor unit
1 from the rear;
2 from the bottom;
3 from the top;
There are three methods:
4. Notch the part for the wiring to pass through with a nipper tool.
PCB
PCB
PCB
1
1
1
2
3

9
Fig 3-8
3. INSTALLATION METHOD
Putty
Putty
Putty
Trap
Trap
Trap
Fig 3-9
IMPORTANT: All the pictures
in this manual are for
illustration purposes only.
Your wire controller may
differ slightly.
8. Reattach the wire controller’s upper part
While adjusting and mounting the upper case, avoid clamping the
wiring during installation. (Fig 3-9)
NOTE: DO NOT allow water to enter the remote control.
Use the trap and putty to seal the wires.

16
5. SPECIFICATION
DC 12V
23~110℉(-5~43℃)
RH40%~RH90%
Input voltage
Wiring type Size Total length
Ambient temperature
Ambient humidity
Wiring specifications
Shielded vinyl cord or cable 0.029 in-0.74mm
(0.75-1.25mm )
<66 ft (20m)
2
<164 ft (50m)

17
6. FEATURE AND FUNCTION OF THE WIRED
CONTROLLER
Mode: choose Auto-Cool-Dry-Heat-Fan
Fan speed: Auto-Low-Med-High
Swing(on some models)
Timer ON/OFF
Temp setting
Weekly Timer
Follow me
Child Lock
LCD Display
Clock
Panel function (on some models)
Feature:
LCD display.
Malfunction code display: displays the
error code (helpful for servicing)
4-way wire layout design.
Room temperature display.
Weekly Timer
Swing Timer Day off/Del Confirm Back/Turbo
Copy/
Follow me
Mode
Fan speed
(Lock)
-+
MODEL: KJR-120G1/TFBG-E
MODEL: KJR-120G2/TFBG-E-02
℉
℃
Swing Timer Day off/Del Confirm Back/Turbo
Copy/
Follow me
Mode
Fan speed
(Lock)
-+
℉
℃
Function:

18
7. WIRED CONTROLLER DISPLAY
1. Operation mode indicator
2. Fan speed indicator
3. Left-right swing indicator
4. Up-down swing indicator
5. Panel function indicator
6. Main unit and secondary unit
indicator
7. Follow me function indicator
1 2 3 4 5 7
9
10
11
12
13
15 14
8.Turbo/Auxiliary Heat function indicator
9. °C / °F indicator
10.Temperature display
11. Lock indicator
12. Room temperature indicator
13. Clock display
14. On/Off timer
15.Timer display
6 8

19
8. WIRED CONTROLLER BUTTONS
1
1. Mode
2. Power
3. Adjust
4. Fan Speed
5. Swing
6.Timer
7. Day Off/Del
8. Copy/Follow me
9. Back/Turbo
10. Confirm
Swing Timer Day off/Del Confirm Back/Turbo
Copy/
Follow me
Mode
Fan speed
(Lock)
-+
2
3
4
3
5
6
7
8
9
10

20
9. PREPARATORY OPERATION
Press TIMER for 3s or more.The timer displays flashes.
Press + or − to set the current time.Press repeatedly to
adjust the current time in 1 minute increments.
Press and hold to adjust the current time.
ex.Monday AM 11:20
1
2
3
4
5
Press +or −to set the date.The selected date flashes.
Date setting is complete and the time setting is ready after
pressing TIMER or if nothing is pressed in 10 seconds.
The setting is complete after pressing TIMER or if no
button is pressed for 10 seconds.
Set the current day and time
Timer
-+
Timer
-+
Timer

21
10. OPERATION
To start/stop operation
Press the Power button.
To set the operation mode
Press MODE to set the operation mode.
(Heat function is invalid for cool only type unit)
Room temperature setting
Press + or − to set the room temperature. Indoor
Setting Temperature Range:
62~86℉(17~30℃)/62~88℉(17~31℃(depending
on models)).
Lower Raise
Operation mode setting
Mode
-+

22
10. OPERATION
Fan speed setting
Press FAN SPEED to set the fan speed
NOTE:This function is unavailable in the AUTO or DRY
modes.
Room temperature sensor selection
Indoor Unit
Press FOLLOW ME to select whether the room temperature
is detected at the indoor unit or at the wired controller.
NOTE:When the FOLLOW ME function indication appears,
the room temperature is detected at the wire remote controller.
Fan speed
(Lock)
Copy/
Follow me

23
10. OPERATION
Child lock function
Press LOCK for 3 seconds to activate the
CHILD LOCK feature and lock all buttons on
the wired controller. Press again for 3 seconds
to deactivate.
NOTE:When the child lock function is activated,
the lock image appears.
keypad tone setting
Press SWING and TIMER simultaneously for 3
seconds to disable the keypad tone.Press the
buttons again for 3 seconds to enable the
keypad tone.
°C & °F scale selection (on some models)
Press BACK and COPY simultaneously for 3
seconds to alternate the temperature display
between the ℉&℃scale.
Fan speed
(Lock)
Back/Turbo
Copy/
Follow me
Swing Timer
℉
℃
