Installation Manual
RADIANT365
AZRA6RADIANT + AZRA6CM1VALC

1-8 ZONES (AZRA6RADIANT + AZRA6CM1VALC)

4
INDEX
Warnings and environmental policy....................................................................................................................................................................................6
Precautions...............................................................................................................................................................................................................................6
Environmental policy ...........................................................................................................................................................................................................6
System elements..........................................................................................................................................................................................................................7
Airzone RadianT365 Main Control Board (AZRA6RADIANT).................................................................................................................................7
Airzone 3 speeds/stages dehumidifier control module (AZRA6CMOD3V).....................................................................................................7
Airzone RadianT365 control module for wired valves 110/230V VALC (AZRA6CM1VALC)......................................................................7
Airzone wired thermostatic valve actuator 110/230v VALC for radiant elements (AZRA6CM1VALC).................................................8
Airzone Blueface Color Thermostat Wired (AZRA6BLUEFACEC).........................................................................................................................8
Airzone Think Monochrome thermostat Wired/Wireless (AZRA6THINK [C/R]).............................................................................................8
Airzone Lite thermostat Wired/Wireless (AZRA6LITE [C/R])..................................................................................................................................9
Webserver Airzone Cloud DIN Ethernet/wifi (AZX6WSCLOUDDIN [C/R]) .......................................................................................................9
Webserver Airzone Cloud Ethernet/WI-FI DUAL 2.4-5G (AZX6WEBSCLOUDC/AZX6WSC5GER).........................................................10
Airzone Supermaster controller (AZX6CSMASTER [S/E] [B/G]) .........................................................................................................................10
Cloud Ethernet Airzone production control board (AZX6CCPWSCC)............................................................................................................11
Airzone Production control board (AZX6CCP)........................................................................................................................................................11
Airzone air to water HP gateway (AZX6GAW XXX)................................................................................................................................................11
Airzone-Lutron integration gateway (AZX6GTILUT).............................................................................................................................................12
KNX integration gateway (AZXKNXGTWAY) ............................................................................................................................................................12
General requirements.............................................................................................................................................................................................................13
Introduction................................................................................................................................................................................................................................14
System installation...................................................................................................................................................................................................................14
Assembly and connection.....................................................................................................................................................................................................15
Airzone RadianT365 Main Control Board (AZRA6RADIANT)..............................................................................................................................15
Assembly..........................................................................................................................................................................................................................15
Connection......................................................................................................................................................................................................................15
Airzone 3 speeds/stages dehumidifier control module (AZRA6CMOD3V)..................................................................................................16
Assembly..........................................................................................................................................................................................................................16
Connection......................................................................................................................................................................................................................17
AIRZONE RADIANT365 CONTROL MODULE FOR WIRED VALVES 110/230V VALC (AZRA6CM1VALC)..............................................17
Assembly..........................................................................................................................................................................................................................17
Connection......................................................................................................................................................................................................................18
AIRZONE WIRED THERMOSTATIC VALVE ACTUATOR 110/230V VALC FOR RADIANT ELEMENTS (AZX6AC1VALC) ....................19
Assembly..........................................................................................................................................................................................................................19
Connection......................................................................................................................................................................................................................19
Airzone Wired thermostats (AZRA6BLUEFACEC / AZRA6THINKC / AZRA6LITEC) .....................................................................................19
Assembly..........................................................................................................................................................................................................................19
Connection......................................................................................................................................................................................................................20
Airzone Wireless thermostat (AZRA6THINKR / AZRA6LITER).............................................................................................................................20
Assembly..........................................................................................................................................................................................................................20
Changing batteries.......................................................................................................................................................................................................20
Webserver Airzone cloud DIN Ethernet/wifi (AZX6WSCLOUDDIN [C/R]).....................................................................................................21
Assembly..........................................................................................................................................................................................................................21
Connection......................................................................................................................................................................................................................22

5
Webserver Airzone cloud Ethernet/wifi WI-FI DUAL 2.4-5G (AZX6WEBSCLOUDC / AZX6WSC5GER) ...............................................23
Assembly..........................................................................................................................................................................................................................23
Connection......................................................................................................................................................................................................................23
Airzone Supermaster controller (AZX6CSMASTER [S/E] [B/G]) .........................................................................................................................24
Assembly..........................................................................................................................................................................................................................24
Connection......................................................................................................................................................................................................................24
Cloud ethernet Airzone production control board (AZX6CCPWSCC)............................................................................................................25
Assembly..........................................................................................................................................................................................................................25
Connection......................................................................................................................................................................................................................25
Configuration .................................................................................................................................................................................................................28
Airzone Production control board (AZX6CCP)........................................................................................................................................................28
Assembly..........................................................................................................................................................................................................................28
Connection......................................................................................................................................................................................................................29
Airzone air to water HP gateway (AZX6GAW XXX)................................................................................................................................................32
Assembly..........................................................................................................................................................................................................................32
Airzone-Lutron integration gateway (AZX6GTILUT).............................................................................................................................................33
Assembly..........................................................................................................................................................................................................................33
Configuration .................................................................................................................................................................................................................33
KNX integration gateway (AZXKNXGTWAY) ............................................................................................................................................................34
Assembly..........................................................................................................................................................................................................................34
Connection......................................................................................................................................................................................................................34
Assembly and connection evaluation..............................................................................................................................................................................35
Initial configuration .................................................................................................................................................................................................................35
Airzone Blueface and Think thermostats...................................................................................................................................................................35
Airzone Lite thermostat....................................................................................................................................................................................................37
Initial Configuration evaluation..........................................................................................................................................................................................38
Advanced settings....................................................................................................................................................................................................................38
System parameters ............................................................................................................................................................................................................39
Zone Parameters.................................................................................................................................................................................................................39
Producction parameters ..................................................................................................................................................................................................40
Self-diagnose..............................................................................................................................................................................................................................40
Airzone Blueface and Think thermostats (AZRA6BLUEFACEC / AZRA6THINK [C/R])................................................................................40
Blueface and Think Thermostats Warnings........................................................................................................................................................40
Blueface and Think Thermostats Errors................................................................................................................................................................41
Airzone Lite thermostat (AZRA6LITE [C/R])...............................................................................................................................................................48
LED STATUS...........................................................................................................................................................................................................................49
Navigation trees........................................................................................................................................................................................................................50
Navigation Tree - Blueface Thermostat......................................................................................................................................................................50
Navigation Tree - Think Thermostat............................................................................................................................................................................51

6
WARNINGS AND ENVIRONMENTAL POLICY
PRECAUTIONS
For your security, and to protect the devices, follow these instructions:
•Do not handle the system with wet or damp hands.
•Disconnect the power supply before making any connections.
•Take care not to cause a short circuit in any of the system connections.
ENVIRONMENTAL POLICY
Do not dispose of this equipment in the household waste. Electrical and electronic
equipment contain substances that may damage the environment if they are not handled
appropriately. The symbol of a crossed-out waste bin indicates that electrical equipment
should be collected separately from other urban waste. For correct environmental
management, it must be taken to the collection centers provided for this purpose, at the end
of its useful life.
The equipment's components may be recycled. Act in accordance with current regulations
on environmental protection.
If you replace it with other equipment, you must return it to the distributor or take it to a
specialized collection center.
Those breaking the law or by-laws will be subject to such purposes and measures as are laid
down in environmental protection legislation.

7
SYSTEM ELEMENTS
AIRZONE RADIANT365 MAIN CONTROL BOARD (AZRA6RADIANT)
Configurable electronic board which manages the system through wired and wireless devices. Power supplied through the
control module AZRA6CM1VALC. Device box (65 x 65 mm / Ø65 mm) mounting.
Functionalities:
•Control and management of the thermostats, up to 8 zones.
•Communication with units of integral control of the installation.
•Communications with other external control systems through integration bus.
AIRZONE 3 SPEEDS/STAGES DEHUMIDIFIER CONTROL MODULE
(AZRA6CMOD3V)
Dehumidifier control module for underfloor radiant heating installations. Control up to
three fan-speeds/stages. Externally power supplied at 110/230 and wired communications.
Mounted on DIN rail or on wall.
Functionalities:
•Two control relays for On/Off.
•Three control relays for fan-speed/stages selection.
•Automatic speed selection according to the number of zones on dehumidification
demand.
AIRZONE RADIANT365 CONTROL MODULE FOR WIRED VALVES 110/230V VALC (AZRA6CM1VALC)
Control module of radiant elements for cooling/heating stages by zone, through the management of wired valve actuators.
Communications via the Airzone connection bus of the main control board. External power supply at 110/230 VAC (50/60 Hz).
Mounted using DIN rail.
Functionalities:
•Management of up to 8 zones and 10 wired Airzone valve actuators.
•It has 2 configurable relay outputs for controlling the cooling/heating
stages and demand of 5 A at 230 VAC.
•It has 1 analogue input for the measurement of the water supply
temperature by means of a temperature probe.
•Forced operation button.

8
AIRZONE WIRED THERMOSTATIC VALVE ACTUATOR 110/230V VALC FOR RADIANT ELEMENTS
(AZRA6CM1VALC)
Head to control the radiant stage of the zone by opening and closing its valve.
Communications and power supply to 110/230Vac (50/60HZ) through the Airzone
control module of wired valves.
•Operation as normally closed.
•Visual indication of valve opening/closing by the movement of the central
red valve piston.
AIRZONE BLUEFACE COLOR THERMOSTAT WIRED (AZRA6BLUEFACEC)
Color graphic interface with capacitive screen for controlling zones in Airzone systems. Powered by main control board.
Finished in steel and glass. Available in white and black.
Functionalities:
•Available in Spanish, English, French, Italian, German and Portuguese.
•Control of temperature and Operation mode (Master thermostat).
•Room temperature and relative humidity measurement of the zone.
•Eco-Adapt function.
•Sleep function.
•Temperature and mode time schedules.
•Remote access to other zones of the system.
•Weather forecast (optional).
AIRZONE THINK MONOCHROME THERMOSTAT WIRED/WIRELESS (AZRA6THINK [C/R])
Graphic interface with low-energy e-ink screen and capacitive buttons for controlling zones in Airzone systems. Finished in
steel and glass. Wired/wireless communications. Powered from main control board (wired) or by CR2450 button battery
(wireless). Available in white and black.
Functionalities:
•Available in Spanish, English, French, Italian, German and Portuguese.
•Control of temperature and Operation mode (Master thermostat).
•Room temperature and relative humidity reading.
•Sleep function.
•Remote access to other zones of the system.
•Weather forecast (optional).

9
AIRZONE LITE THERMOSTAT WIRED/WIRELESS (AZRA6LITE [C/R])
Thermostat with capacitive buttons for controlling the temperature of the zones in Airzone
systems. Finished in steel and glass. Wired/wireless communications. Powered from main
control board (wired) or by CR2450 button battery (wireless). Available in white and black.
Functionalities:
•On/off of the zone.
•Set-point temperature control (Accuracy: ± 1ºC, max: ±3ºC.)
•Room temperature and relative humidity reading.
WEBSERVER AIRZONE CLOUD DIN ETHERNET/WIFI (AZX6WSCLOUDDIN [C/R])
Webserver for controlling Airzone systems through Airzone Cloud platform. Accessible through browser or App (available for
IOS and Android). Connected to router via Ethernet (AZX6WSCLOUDDINC) or WiFi (AZX6WSCLOUDDINR). Externally power
supplied at 110 / 230 Vac. Mounted on DIN rail or on wall.
Functionalities:
•Control of up to 32 systems.
•Configuration and control of zone parameters (Room and set-point temp., operating mode, etc.) and system
parameters via Airzone Cloud.
•Temperature and Operation mode time schedules.
•Multi-user and multi-session.
•External control through Airzone Cloud platform.
•Remote updates of the Webserver firmware and the systems connected to it.
•Remote error detection and error resolution.
AZX6WEBSCLOUDDINC
AZX6WEBSCLOUDDINR

10
WEBSERVER AIRZONE CLOUD ETHERNET/WI-FI DUAL 2.4-5G (AZX6WEBSCLOUDC/AZX6WSC5GER)
Webserver for controlling Airzone systems through Airzone Cloud platform. Accessible through browser or App (available for
IOS and Android). Connected to router via Ethernet (AZX6WEBSCLOUDC) or WiFi (AZX6WSC5GER). Power supplied through
Production Control Board (AZX6CCP).
Functionalities:
•Control of up to 32 systems.
•Configuration and control of zone parameters (Room and set-point temp., operating mode, etc.) and system
parameters via Airzone Cloud.
•Temperature and Operation mode time schedules.
•Multi-user and multi-session.
•External control through Airzone Cloud platform.
•Remote updates of the Webserver firmware and the systems connected to it.
•Remote error detection and error resolution.
Important:Only available for installations with AZX6CCP.
AIRZONE SUPERMASTER CONTROLLER (AZX6CSMASTER [S/E] [B/G])
Monochrome LCD touch screen back-lighted controller for managing the system of the installation. Power supplied through
the automation bus of the system. Wall-mounted (AZX6CSMASTERS) or wall-embedded (AZX6CSMASTERE). Available in white
and grey.
Functionalities:
•Up to 8 control groups.
•Operating mode and set-point temperature control.
•Forced mode control: it imposes the operating mode and the temperature, blocking the user control.
•Semi-forced mode control: it imposes the mode range and the temperature every hour.
•Forced mode control: it imposes the operating mode and the temperature, blocking the control for the user.
•Temperature and Operation mode time schedules
Important: This device is not compatible with the Production Control Board (AZX6CCP/AZX6CCPWSCC).
AZX6WSC5GER
AZX6WEBSCLOUDC
AZX6CSMASTERE
AZX6CSMASTERS

11
CLOUD ETHERNET AIRZONE PRODUCTION CONTROL BOARD (AZX6CCPWSCC)
Control board of production units with webserver for controlling Airzone systems through Cloud platform. Connected to router
via Ethernet and communications through domotic bus. Externally powered at 110/230 Vac. Wall mounted.
Features:
•Controls up to 32 systems.
•7 control relays for cooling/heating modes, cooling/heating air demand,
cooling/heating radiant demand.
•Inputs for semi-forced modes, boiler probe and DHW control.
•Configuration and control of zone parameters (Room and set-point temp., operating
mode, etc.) and system parameters via Airzone Cloud.
•Temperature and operating mode time schedules.
•Multi-user and multi-session.
•Remote management of firmware updates and errors.
AIRZONE PRODUCTION CONTROL BOARD (AZX6CCP)
Control board of production units through 6 relays of 10 A. Communications through domotic bus. Externally powered at
110/230 Vac. Wall mounted.
Functionalities:
•Controls up to 32 systems.
•Controls cooling and heating mode through 2 relays.
•Controls cooling air and the heating air demand through 2 relays.
•Controls the cooling and heating radiant element demand through 2 relays.
•3 Inputs for semi-forced mode.
•Input for boiler probe.
AIRZONE AIR TO WATER HP GATEWAY (AZX6GAW XXX)
Communication gateway between Airzone system and Air to water units. Powered through the AC unit bus of the production
control board (AZX6CCPWSCC).
Features:
•Two-way communication of the basic control parameters depending on the demand of the
Airzone control system.
•Reading of errors of the controlled unit.
•Imposes water production temperature based on the demand.
Important: Only available for installations with AZX6CCPWSCC.

12
AIRZONE-LUTRON INTEGRATION GATEWAY (AZX6GTILUT)
Integration gateway for Lutron control systems on Airzone systems through Lutron HomeWorks QS Processor. Connected via
Ethernet. Power supplied through the main control board automation bus.
Features:
•One Airzone-Lutron interface per system.
•Reading/Writing of the room temperature.
•Reading/Writing of the set-point temperature.
•Reading/Writing of the operating mode.
•Reading/Writing of the cooling/heating demand.
•Reading/Writing of the fan speeds.
Important: Only available for installations with AZX6CCP.
KNX INTEGRATION GATEWAY (AZXKNXGTWAY)
Airzone integration gateway of HVAC systems into KNX TP-1 control systems through Modbus. Powered through KNX bus.
DIN-rail mounting.
Functionalities:
•One Airzone system per KNX gateway.
•Full KNX.
•KNX standard data.
•Easily configurable from ETS.
•Zone control through KNX devices.
•Type of installation control.
•Communication errors detection.
Important: Device not compatible with AZX6CCPWSCC.

13
GENERAL REQUIREMENTS
Strictly follow the directions outlined in this manual:
•The system must be installed by a qualified technician.
•Verify that the units to be controlled have been installed according to the manufacturer's requirements and operate
correctly before installing the Airzone System.
•Locate and connect all the devices of the installation in accordance with the electronic regulations in force.
•Verify that the air conditioning installation to be controlled is in accordance with the regulations in force.
•It is necessary to use a Blueface Thermostat to have all the features of the Airzone system.
•Follow these recommendations to locate the thermostats:
•Perform all the connections with total abscense of power suppliance.
•In order to connect the elements of the system, use Airzone cable: shielded twisted pair cable formed by 4 wires: 2x0,22
mm2+ 2x0,5mm2(AWG 20 – 4 wired).
•Do not place the system bus close to high power lines, fluorescent lights, LED lamps, motors, etc. It might cause
interference on the communications.
•Respect the connection polarity of each device. A wrong connection may seriously damage the product.
•For elements externally powered at 110 /230 Vac, for the communications, it is only necessary to connect the poles "A"
and "B" of the bus.
•For elements externally powered at 110/230 Vac, respect the connection polarity. A wrong grounding may produce
electric shocks.
•According to the current local and national regulations, it is mandatory to add a switch (or other element to disconnect
the system) to the external supply wiring so that a constant separation between poles is guaranteed. The system will
restart automatically if the supply is eventually turned off. Use an independent circuit from the controlled system
for the power supply.

14
INTRODUCTION
Airzone systems enable the management of Master and Zone interfaces. Master thermostats enable mode management or
define the efficiency level with the Eco-Adapt function.
It is recommended the use of a Blueface thermostat as Master Interface, this enables time schedule management and more
unique functionalities.
Remember: This system only admits one Master thermostat.
To distinguish a Master Interface from a Zone Interface, check the next points.
-Blueface Master: Mode and Eco-Adapt icons shown in white color.
-Blueface Zone: Mode and Eco-Adapt icons shown in gray color.
-Think Master: Accessing the settings menu, Operation Mode is available.
-Think Zone: Accessing the settings menu, Operation Mode is unavailable.
SYSTEM INSTALLATION
Before the Airzone system commissioning, please check:
•The system is going to control works correctly without the Airzone system installed.
Important: For installations with radiant surfaces only, it is recommended the installation of buffer tanks.
In order to install the Airzone system, carefully follow these steps:
Connect all the necessary elements (see sections Assembly and Connection).
-Connect all the elements of the system (thermostats, modules, etc.)
-Power the main board.
Check all the assembly and the connection are correct (see section Assembly and Connection evaluation).
Configure the system.
-Configure all the thermostats (see sections System Start-up and Advanced settings).
If you have any other doubt, check the user and installation manuals.
Access all our technical documents and the self-diagnosis section, check the most FAQs, certificates,
watch our videos and read our declaration of conformity at: myzone.airzone.es/productos/

15
ASSEMBLY AND CONNECTION
AIRZONE RADIANT365 MAIN CONTROL BOARD (AZRA6RADIANT)
Assembly
The Main Control Board is delivered for assembling in a device box (65 x 65 mm / Ø65 mm) .
Location and installation of the module must comply the current electronic rules.
For the assembly of the Main Control Board, please follow these steps:
•Remove the cover from the main base.
•Once all the connections are set, screw the Main Control Board to the device box and
place the cover again.
Connection
Airzone connection bus connectors
The Airzone connection bus allows you to connect all the internal components independents of the Main Control Board to
control up to 8 zones. These are the elements that can be connected:
-Airzone Thermostats: Blueface (AZRA6BLUEFACEC), Think (AZRA6THINKC) and Lite
(AZRA6LITEC).
-Airzone 3 speeds/stages dehumidifier control module (AZRA6CMOD3V).
-Airzone Radiant365 Control Module for Wired Valves 110/230v VALC
(AZRA6CM1VALC).
It has 1 5-pin terminals to connect the Airzone connection bus. Both star connection and bus
connection are available. Attach the wires with the terminal screws following the color code.
SW1
The main control board can also connect to Airzone wireless elements. These elements are associated by
opening the wireless association module of the Main Control Board. Press on SW1 and wait for the LED 11
to remain red. The wireless association module will be open for 15 minutes.
System reset: If needed to return to Factory values, hold SW1 until the status of LED D11 changes.
Nº
Description
Airzone connection bus
SW1
Domotic bus

16
Domotic bus connector
The domotic bus allows you to interconnect multiple systems in order to control them through Airzone control peripherals or
to integrate them into a superior control network. These are the elements that can be connected:
-Webserver Cloud DIN (AZX6WSCLOUDDIN [C/R]).
-Airzone Production Control Board (AZX6CCP).
-Airzone Supermaster controller (AZX6CSMASTER [S/E]).
-KNX Integration Gateway (AZXKNXGTWAY)
It has a 2-pin terminal for the domotic bus connection. This system can only be connected
by bus. Attach the wires with the terminal screws following the color code.
AIRZONE 3 SPEEDS/STAGES DEHUMIDIFIER CONTROL MODULE (AZRA6CMOD3V)
Assembly
The module is mounted on DIN rail or on the wall. It is externally powered at 110/230 Vac. Location and installation of the
module must comply the current electronic rules.
Note: To take the module away, pull the reed down to release it.

17
Connection
The module is a device which connects to the Airzone connection bus of the main board. Control relay specs: Imax = 10 A at
110/230 Vac, voltage-free.
Note that to control elements with a greater power, it is recommended to use contactors in accordance with the power
required. Remember to connect the neutral connector directly from the circuit to the element to be controlled.
It has a 5-pin terminal to connect it to the Airzone connection bus of the main board . Attach
the wires with the terminal screws following the color code.
Power supply is connected to the module through a 3-pin terminal . Attach the wires with
the terminal screws following the color code.
Important: According to the current local and national regulations, it is mandatory to add a switch (or other element to
disconnect the system) to the external supply wiring so that a constant separation between poles is guaranteed. The system
will restart automatically if the supply is eventually turned off.
AIRZONE RADIANT365 CONTROL MODULE FOR WIRED VALVES 110/230V VALC (AZRA6CM1VALC)
Assembly
The module is mounted on DIN rail or on the wall. It is externally powered at 110/230 Vac. Location and installation of the
module must comply the current electronic rules.
Note: To take the module away, pull the reed down to release it.
Significado
Power supply
Airzone connection bus
Dehumidifier control relays
LED of relays state
Operation of the relays
Y-O
On / Off
V1-O
Speed 1
V
2
-O
Speed 2
V
3
-O
Speed 3
W-O
On / Off

18
Connection
The module is a device which connects to the Airzone connection bus of the main board.
Control Z1-8 relay specs: Imax = 5 A at 110/250 Vac.
Note that to control elements with a greater power, it is recommended to use contactors in accordance with the power
required. Remember to connect the neutral connector directly from the circuit to the element to be controlled. Operation
It has a 5-pin terminal to connect it to the Airzone connection bus of the main board .
Attach the wires with the terminal screws following the color code.
Power supply is connected to the module through a 3-pin terminal . Attach the wires with the
terminal screws following the color code.
Important: According to the current local and national regulations, it is mandatory to add a switch
(or other element to disconnect the system) to the external supply wiring so that a constant separation between poles is
guaranteed. The system will restart automatically if the supply is eventually turned off.
Configure the AZRA6CM1VALC module according to your installation. To do this you must leave the LED that corresponds to
your installation on:
1. Press the operation relays configuration button for 2 s.
2. Switch between the different configurations by pressing the same button.
3. Save the configuration by another 2 s pressing in the same button.
Configuration /
Relay output Configuration 1 Configuration 2 Configuration 3
R1 On/Off Pump* On/Off Pump*
Cooling Mode: On
Heating Mode: Off
Stop Mode: Off
R2
Cooling Mode: On
Heating Mode: Off
Stop Mode: On/Off**
Cooling Mode: Off
Heating Mode: On
Stop Mode: On/Off**
Cooling Mode: Off
Heating Mode: On
Stop Mode: Off
* The relay R1 is activated when demand is generated in the system with a 3-minute delay.
** The relay R2 maintains the last requested mode, prior to the Stop mode.
LEDs configuration selected

19
AIRZONE WIRED THERMOSTATIC VALVE ACTUATOR 110/230V VALC FOR RADIANT ELEMENTS
(AZX6AC1VALC)
Assembly
Airzone wired thermostatic valve actuators are mounted on each of the valves of a manifold / heater. Check that the
thermostatic valve actuator is compatible with the valve body that you are going to equip (M30 x 1.5).
Connection
Airzone wired thermostatic valve actuators are connected to the Z1-8 ports of the AZRA6CM1VALC module.
Connect throught 2 wires without polarity. Important: Use a suitable screwdriver to press in the locking tabs.
Maximum number of valves permitted: 2 for each output (20 valves in total).
AIRZONE WIRED THERMOSTATS (AZRA6BLUEFACEC / AZRA6THINKC / AZRA6LITEC)
Assembly
Wired thermostats are mounted on the wall through a support. It is recommended not to locate it more than 40 meters away
from the main control board. To fix it to the wall, follow these steps:
•Separate the back part of the thermostat from the wall support and make all the
connections.
•Fix the back part of the thermostat to the wall.
•Place the display on the support once it is fixed.
•Place the anti-theft rods for additional support (optional).

20
Connection
The Airzone thermostats are connected to the Airzone connection bus of the main board.
Attach the wires with the terminal screws following the color code.
Important: Use a suitable screwdriver to press in the locking tabs.
Note: To connect more than 4 Blueface, it is necessary an external power supply (AZX6POWER). These values can be altered
depending on the separation distance among them.
AIRZONE WIRELESS THERMOSTAT (AZRA6THINKR / AZRA6LITER)
Assembly
Wireless thermostats are mounted on the wall through a support. It is recommended not to locate it more than 40 meters away
from the main control board.
To fix it to the wall, follow these steps:
•Remove the back of the thermostat and insert the CR2450 button battery.
•Fix the back part of the thermostat to the wall.
•Place the display on the support once it is fixed.
•Place the anti-theft rods for additional support.
Changing batteries
When a wireless Think thermostat is running out of battery, it displays this icon on the screensaver. In the case of wireless
Lite thermostats, a warning message will be displayed on the Blueface. In order to know the zone of the Lite thermostat(s)
running out of battery press on the warning icon.

21
To replace the battery, separate the thermostat from its support and replace the battery (CR2450).
Important: We recommend using of top-brand batteries. Using low-quality batteries may reduce the duration of use.
Remember to deposit the old battery into an appropriate recycling point.
Note: Do not forget to remove the security system before taking away the thermostat from the wall.
WEBSERVER AIRZONE CLOUD DIN ETHERNET/WIFI (AZX6WSCLOUDDIN [C/R])
Assembly
The Webserver Airzone Cloud Din can be mounted on DIN rail or on wall. This module is externally power supplied at 110/230
Vac. Location and installation of the module must comply the current electronic rules.
Note: To take the module away, pull the reed down to release it.
Nº
Description
Ethernet
WiFi USB connector and antenna
Domotic bus
Power supply
AZX6WSCLOUDDINC
AZX6WSCLOUDDINR
