AIS Day to Day Tables User manual

Day to Day Tables –
Aluminum Base
www.ais-inc.com 1
T-ABTINSTALL Revision 12.12.2018

Day to Day Tables –
Aluminum Base
www.ais-inc.com
Revision Log
2
Date
Page
No.
Description of change
Name
6/25/2018
1
-6
Released
S. Powers
12/12/18
7
Added AIS Power Unit
instructijons
S. Powers
T-ABTINSTALL Revision 12.12.2018

Day to Day Tables –
Aluminum Base
www.ais-inc.com
X-Base Assembly
3/8-16 Locknut
RH-91831A127
Post Insert
RWFS-UTPI
3/8-16 X 1 3/8
Hex Bolt
RH-922400A627
Foot
Worksurface Screw
Flat head wood screw
#9 x 7/8 long
#2 Phillips drive silver
12 places
Worksurface
3
Top Plate
Hex Drive Flat Head Screw
5/16-18 X 1” Long
3/16” Hex Drive, 4 Places
T-ABTINSTALL Revision 12.12.2018

Day to Day Tables –
Aluminum Base
www.ais-inc.com 4
T-Base Assembly
Flat head wood screw #9
x 7/8 long with #2
Phillips drive, silver x 12
Worksurface
8” 8”
3” 3”
2”
2”
5”
8” 8”
2”
2”
2”
Top Plate
Double T-Base
Hex Drive Flat Head Screw
5/16-18 X 1” Long
3/16” Hex Drive, 4 Places
T-Base
T-ABTINSTALL Revision 12.12.2018

Day to Day Tables –
Aluminum Base
www.ais-inc.com 5
U-ChannelAssembly
U-Channel
(See following page for location)
Flat head wood screw #9
x 7/8 long with #2
Phillips drive, silver x 12
T-ABTINSTALL Revision 12.12.2018

Day to Day Tables –
Aluminum Base
www.ais-inc.com 6
U-ChannelAssembly
24-36D
72W use TL-UCK36
78W use TL-UCK36
84W use TL-UCK42
24-30D
30D 36D
72W use TL-UCK36
24-36D 30-36D
72W use TL-UCK36
120W use TL-UCK36 120W use TL-UCK36
42-60D
66W use TL-UCK36
72W use TL-UCK42
42-60D
42-60D
42-60D
108W use TL-UCK42
120W use TL-UCK48
42-48W
42W use TL-UCK54
48W use TL-UCK60
54W use TL-UCK66
66W use TL-UCK36
72W use TL-UCK42
108W use TL-UCK42
120W use TL-UCK48
T-ABTINSTALL Revision 12.12.2018
U-Channel Length
TL-UCK36 36”
TL-UCK42 42”
TL-UCK48 48”
TL-UCK54 54”
TL-UCK60 60”
TL-UCK66 66”
60W use TL-UCK48
63W use TL-UCK54
72W use TL-UCK60

Day to Day Tables –
Aluminum Base
www.ais-inc.com 7
T-ABTINSTALL Revision 12.12.2018
#9 x 7/8 long
Flat head wood screws
#2 Phillips drive
8 Places
Power Cover
Power Box
Power Unit
Data Jack
2 Places
#6 x 3/8” Flat Head
Sheet Metal Screw
2 Places
AIS Power Unit
Plug
2 Places
