AIS Paxton 3400 Series User manual

800.434.7400 | 978.562.7500 | Fax: [phone] | www.ais-inc.com
Assembly Instructions
Paxton
Task Chair (3400 Series)

STEP 1
STEP 2
INCLUDED PARTS STEP 3
STEP 4
STEP 6
Take both left and right arms/legs and stand them up. Take
the cross stretcher and place it in the center of both the
side frames so that it lines up with the bolt holes on each.
Using the allen wrench screw in the two M6 x 16mm bolts
underneath, one on each side. Do not tighten screws yet.
Take the seat back and align it so that the pre-drilled bolt
holes line up with the side frames pre-drilled bolt holes
(see image for reference). Take the four M6 x 20mm bolts
(2 on each side) using the allen wrench screw them in the
pre-drilled holes. Do not tighten yet.
Place Chair on a level oor. Tighten all bolts. If the chair wobbles, loosen and relevel. Once releveled,
re-tighten screws (see Step 1, 2 and 3 images for reference).
Sit back, relax and enjoy your new Paxton chair.
Left Arm/Leg x1
M6 x 16mm Bolts x2 M6 x 30mm Bolts x8 M6 x 20mm Bolts x4 Allen Wrench x1
Right Arm/Leg x1 Cross Stretcher x1 Seat x1 Seat Back x1
View the full Seating line at ais-inc.com
Phone: [phone] Fax: [phone]
View the full Seating line at ais-inc.com
Phone: [phone] Fax: [phone]
Revision 6.1.2017
© 2017, AIS, Inc.
Revision 6.1.2017
© 2017, AIS, Inc.
The cross bar should be lined up with the pre-drilled bolt
holes on the side frames. Take four of the M6 x 30mm bolts
using the allen wrench screw in two on each side in the
pre-drilled holes. Do not tighten yet.
